SCS 440/450/460/660/661
Consoles Universal
CAN AccuBoom
Installation Manual
P/N 0160-0171-073 Rev C 01/17 E28992
Copyright 2017
While every effort has been made to ensure the accuracy of this document,
Raven Industries assumes no responsibility for omissions and errors. Nor is any
liability assumed for damages resulting from the use of information contained
herein.
Raven Industries shall not be responsible or liable for incidental or consequential
damages or a loss of anticipated benefits or profits, work stoppage or loss, or
impairment of data arising out of the use, or inability to use, this system or any of
its components. Raven Industries shall not be held responsible for any
modifications or repairs made outside our facilities, nor damages resulting from
inadequate maintenance of this system.
As with all wireless and satellite signals, several factors may affect the availability
and accuracy of wireless and satellite navigation and correction services (e.g.
GPS, GNSS, SBAS, etc.). Therefore, Raven Industries cannot guarantee the
accuracy, integrity, continuity, or availability of these services and cannot
guarantee the ability to use Raven systems, or products used as components of
systems, which rely upon the reception of these signals or availability of these
services. Raven Industries accepts no responsibility for the use of any of these
signals or services for other than the stated purpose.
Disclaimer
CHAPTER
1
INTRODUCTION
____________________________________________________________
Congratulations on your purchase of the Raven AccuBoom system! This
system is designed to provide worry free turn on and turn off of your
booms with respect to the as-applied coverage map. The following
instructions are designed to assist you in the proper installation of the
AccuBoom system. See the Viper Installation and Operation Manual for
instructions on setting up the software and using the AccuBoom system.
You will also need a valid AccuBoom Control activation key for your
Viper in order to activate the AccuBoom system.
Important! All boom switches must remain
in the OFF position while AccuBoom control
is in operation!
COMPONENTS
NEEDED
•CAN AccuBoom Control Node – P/N 063-0172-316
•AccuBoom Control Activation Key – P/N 077-0180-010
•SCS440/450/460/660/661 Console Universal CAN AccuBoom Cable
– P/N 115-1001-003
•CAN AccuBoom installation Sheet, SCS440/450/460/660/661
Universal Cable – P/N 016-0171-073
Important: If no CAN system currently exists
on the machine you are installing AccuBoom
on, you will need these additional
components:
Manual #016-0171-073 Rev. C 01/17
1
Kit, CANBus, Terminators & Power Adapter “T” – P/N 117-0159-923
Appropriate length CANBus Tee Cable:
6 inch CAN Tee Cable – 115-0171-364
6 Ft CAN Tee Cable – 115-0171-326
12 Ft CAN Tee Cable – 115-0171-362
18 Ft CAN Tee Cable – 115-0171-690
24 Ft CAN Tee Cable – 115-0171-363
Notes:
Manual #016-0171-073 Rev. C 01/17
2
CHAPTER
2
INSTALLATION
___________________________________________________________
Use the following procedure to properly install the CAN AccuBoom
Serial Console cable:
1. Connect the CAN AccuBoom/Serial Console Cable P/N 115-1001-003
to the Raven console.
Important! The CAN AccuBoom/Serial
Console Cable P/N 115-1001-003 is
compatible with Raven SCS440,
SCS450, SCS460, SCS660, and SCS661
consoles only.
a. Disconnect the existing console cable from the back of the console.
Manual #016-0171-073 Rev. C 01/17
3
b. Connect the CAN AccuBoom/Serial Console Cable P/N 115-1001-
003 to the back of the Raven console.
c. Connect the console cable previously disconnected to the mating
connector on the CAN AccuBoom/Serial Console Cable P/N 115-
1001-003.
Manual #016-0171-073 Rev. C 01/17
4
2. Connect the CAN AccuBoom cable to the CAN AccuBoom node.
a. Connect the rectangular connectors from the CAN
AccuBoom/Serial Console Cable P/N 115-1001-003 to the CAN
AccuBoom Node P/N 063-0172-316.
3. Mount The CAN AccuBoom Node.
a. Route the CAN AccuBoom/Serial Console Cable P/N 115-1001-
003 from the console connection to a location suitable to mount the
CAN AccuBoom node P/N 063-0172-316.
b. Identify a suitable location to secure the CAN AccuBoom Node
P/N 063-0172-316 to the machine.
c. Bolt the CAN AccuBoom Node P/N 063-0172-316 securely in
place.
Manual #016-0171-073 Rev. C 01/17
5
4. Connect the Master Switch Power to AccuBoom Node
(SCS460/660/661 Consoles only).
a. Install a male spade connector on the end of an 18 ga (minimum)
wire.
b. Connect the male spade connector to the female spade connector
coming out of the CAN AccuBoom/Serial Console Cable P/N 115-
1001-003.
c. Connect the other end of the wire to the output of the master
spread/hold switch.
Note: Raven SCS440/450 consoles have
the master switch in the control console.
The CAN AccuBoom/Serial Console
Cable P/N 115-1001-003 is pre-wired to
the master switch in the control console.
5. Connect the CAN AccuBoom cable to the CANBus system.
Note: If your system does not currently
have a CAN system installed, see the
CAN installation instructions in Chapter
3 of this installation guide.
6. The AccuBoom installation is now complete.
Manual #016-0171-073 Rev. C 01/17
6
CHAPTER
3
CAN INSTALLATION
________________________________________________________________________
If the machine you are working on does not currently have a Raven CAN
system, you will need a Kit, CANbus, Terminators & Power Adapter “T”
P/N 117-0159-923. This kit contains the CAN Cable Adapter Tee With
Power P/N 115-0171-368 and two (2) CANBus Terminators P/N 063-
0172-369. To install a Raven CAN system:
1. Connect CAN Tee to power and ground.
a. Locate a convenient source of power and ground near the control
system.
b. Connect the power wire of the CAN Cable Adapter Tee With
Power P/N 115-0171-368 to a source of clean 12 volt power.
c. Connect the ground wire from the CAN Cable Adapter Tee With
Power P/N 115-0171-368 to a clean battery ground.
Manual #016-0171-073 Rev. C 01/17
7
2. Connect the CAN bus to the Controller.
a. Connect CAN Terminator P/N 063-0172-369 to one connector on
the Can Cable Adapter Tee With Power P/N 115-0171-368.
b. Connect the second connector on the CAN Cable Adapter Tee
With Power P/N 115-0171-368 to the CAN connector on the
Envizio or Viper interface cable.
The CAN bus system is now installed and CAN nodes may be connected
to it.
CAN Terminator
Manual #016-0171-073 Rev. C 01/17
8
