Raven AccuBoom Manuel utilisateur
Parallel Installation Manual
Hagie Sprayers with 4600 Console
Manual # 016-0171-030 Rev A 03/06
1
CHAPTER
I
NTRODUCTION
Congratulations on your purchase of the Raven AccuBoom system! This
system is designed to provide worry free turn-on and turn-off of your
booms with respect to the as-applied coverage map. The following
instructions are designed to assist you in the proper installation of the
AccuBoom system. See the Viper Installation and Operators Manual for
instructions on setting up the software and using the AccuBoom system.
You will also need a valid AccuBoom Control Activation Key for your
Viper system in order to activate the AccuBoom system.
Components
Needed
• Parallel AccuBoom Control Node - P/N 063-0172-517
• Hagie with 4600 Console Series AccuBoom Cable - P/N 115-0171-630
• AccuBoom Control Activation Key - P/N 077-0180-010
Important! All boom switches must remain in
the OFF position while AccuBoom control is in
operation!
Hagie Sprayers with 4600 Console Series Parallel AccuBoom Installation and Operators Manual
2
Notes:
Manual # 016-0171-030 Rev A 03/06
3
CHAPTER
I
NSTALLATION
Use the following procedure to properly install the AccuBoom system on a
Hagie sprayer using a 4600 Raven console connected to a Raven Viper:
1. Tee in the Parallel AccuBoom cable (P/N 115-0171-630):
a. Disconnect the existing cable from the back of the 4600 console
connector.
b. Connect the Parallel AccuBoom cable (P/N 115-0171-630) to the
console connector.
c. Connect the other end of the previously disconnected cable to the
Parallel AccuBoom cable (P/N 115-0171-630).
Hagie Sprayers with 4600 Console Series Parallel AccuBoom Installation and Operators Manual
4
2. Connect the Parallel AccuBoom Cable (P/N 115-0171-630) to the
control switch harness:
a. Remove the two knobs securing the Hagie control console in place
and swing the control console open.
b. Locate the boom switch interface connectors. These are 12-pin
rectangular Deutsche connectors.
c. Disconnect the existing connectors.
d. Tee in the Parallel AccuBoom cable (P/N 115-0171-630) by
plugging in the corresponding 12-pin rectangular connectors.
Boom
Connectors
Manual # 016-0171-030 Rev A 03/06
5
3. Connect the Parallel AccuBoom Cable (P/N 115-0171-630) to the
Viper communication port.
4. Mount the Parallel AccuBoom node (P/N 063-0172-517) in the cab.
Comm Port
Connection
Hagie Sprayers with 4600 Console Series Parallel AccuBoom Installation and Operators Manual
6
5. Connect the corresponding gray and black connectors from the Parallel
AccuBoom cable (P/N 115-0171-630) to the Parallel AccuBoom node
(P/N 063-0172-517).
6. The Parallel AccuBoom hardware installation is now complete. Install
the Activation Key on the Viper system and the AccuBoom system is
ready for operation.
RAVEN INDUSTRIES
LIMITED WARRANTY
WHAT IS COVERED?
This warranty covers all defects in workmanship or materials in your Raven
Flow Control Product under normal use, maintenance, and service.
HOW LONG IS THE COVERAGE PERIOD?
This warranty coverage runs for 12 months from the purchase date of your
Raven Flow Control Product. This warranty coverage applies only to the
original owner and is not transferrable.
HOW CAN YOU GET SERVICE?
Bring the defective part, and proof of date of purchase, to your local dealer.
Ifyourdealeragreeswiththewarrantyclaim,hewillsendthepart,andproof
of purchase to his distributor or to Raven for final approval.
WHAT WILL RAVEN INDUSTRIES DO?
Whenour inspectionprovesthe warrantyclaim,we will,atour option,repair
or replace the defective part and pay for return freight.
WHAT DOES THIS WARRANTY NOT COVER?
Raven Industries will not assume any expense or liability for repairs made
outsideourplantwithoutwrittenconsent. Wearenotresponsiblefordamage
toanyassociatedequipmentorproductandwillnotbeliableforlossofprofit
orotherspecialdamages. Theobligationofthiswarrantyisinlieuofallother
warranties,expressedorimplied,andnopersonisauthorizedtoassumefor
usany liability. Damagescausedby normalwearandtear,mis-use, abuse,
neglect,accident,orimproperinstallation andmaintenance arenot covered
by this warranty.
Raven Industries Toll Free 800-243-5435
Flow Controls Division Fax 605-331-0426
P.O. Box 5107 www.ravenprecision.com
Sioux Falls, SD 57117-5107 fcdinfo@ravenind.com
Hagie Sprayers with 4600 Console Series Parallel AccuBoom Installation Manual (P/N 016-0171-030 Rev A 03/06)
