Quoizel HC1612IB Manuel utilisateur

PackageContents

Quoizel,Inc.

6CorporateParkway

GooseCreek,SC29445

CustomerService

Phone631.273.2700

Fax631.231.7102

www.quoizel.com

ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,

safetyglasses.

BulbRecommended:

EstimatedAssemblyTime:

Preparation:

(2)MediumBase60WbulbsMaximum,Alternatebulb(2)13WCFLMaximum.

20-30minutes

Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagrams

belowtobesureallpartsarepresent.Ifanypartsaremissingordamaged,donotattempttoassemble,install,or

operatethefixture.Contactcustomerserviceforreplacementparts.

WarningsandCautions

1of2

AssemblyInstructionSheet#IS-HC1612IB

ForStyleHC1612IB

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

2014QuoizelInc. March2014

Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.

Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly

recommendthatalicensed,professionalelectricianperformtheinstallation.

Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.Donotsubject

glasspartstoanyshockwhileinoperationorshatteringmayresult.

BCage

FlatWasher

CGlass

Panel

HexCoupling

Stemwith

HexNut

HardwareContents

AA Crossbar

ACeiling

Canopy

Knurled

Nut

LockWasher

HexNut

Nipple

BB CC

StepA

StepD

STEP1InstallCrossbar-

A.AA)AttachtheCrossbar(totheOutletBoxwiththeheadoftheGreen

GroundScrewfacingyou.SecureitwithOutletBoxScrews(not

included)Tightenuntilsnug..

Figure1

OutletBox

OutletBoxScrew

(notincluded)

GreenGroundScrew

Figure2

LockWasher

Finial

STEP2InstallNippletoCrossbar-

*Pliersisrequiredforthisstep.

A.ThreadoneHexNut(CC)tothemiddleoftheNipple(DD).Placethe

LockWasher(BB)overtheNipple(DD)andthenthreadtheNipple

(DD)intotheCrossbar(AA)untiltheNipple(DD)isabout0.375

abovetheCrossbar(AA).

B.PositionthecenterholeoftheCeilingCanopy(A)overtheendofthe

Nipple(DD).AdjusttheNipple(DD)soapprox0.375 oftheNipple

(DD)isprotrudingfromthemountingholeontheCeilingCanopy(A).

Thisadjustmentmaytakeafewtries.

C.RemovetheCeilingCanopy(A)andthentightentheHexNut(CC)

againsttheCrossbar(AA)tosecureinplace.

D.ThreadanotherHexNut(CC)ontotheendoftheNipple(DD).

ThreadthisHexNut(CC)onjustenoughsotheinsidesurfaceofthe

CeilingCanopy(A)restsagainstit.*Youmayhavetotrialfitthe

CeilingCanopy(A)onemoretimestoinsurethisdistancealso.This

HexNut(CC)isneededheretopreventyoufromcrushingdownthe

centeroftheCeilingCanopy(A).

E.RefertoStep3forwireconnections.

F.AttachtheCeilingCanopy(A),theFlatWasher(F)andoneLock

Washer(BB)overtheendoftheNipple(DD)asshown.Secureby

threadingtheHexCoupling(H)ontotheNipple(DD)andtightenuntil

snug.

STEP3-WireConnections

A.Usestandardwireconnectors(notincluded)tomakeallwire

connections.(Connectorsarenotincludedwithfixture.)Stripand

preparewireendsaccordingtoinstructionssuppliedwith

connectors.

B.ConnectWhiteSupplyWirefromtheOutletBoxtoRibbedsideWire

fromfixture.

DLockScrew

ETab

2of2

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

2014QuoizelInc. March2014

Figure6

STEP5-InstallBulb

A.Thisfixtureusesstandardbulbwith

mediumbase.Maximum60watts.

B.Insertbulbandscrewsnuglyintoplace.

Figure5 Bulb

Whitewire

fromsupply Ribbedsidewire

fromfixture

Blackwirefrom

supply(orRed) Smoothsidewire

fromfixture

Groundwire

fromsupply Groundwire

fromfixture

Figure3

HC1612IB

PARTNUMBER

11612IBH

G1422PA

G1421PA

M1033FIIB

NOTE:ALLDIMENSIONSAREROUNDEDUPTOTHENEAREST1/2"

REPLACEMENTPARTDESCRIPTION

BASEIMPERIALBRONZEFLUSHMOUNT

BOTTOMPANEL9-3/4"SQX3/8"D

SIDEPANEL5-1/8"HX9-3/4"

FINIAL0.37HX1.12""IMPERIALBRONZE

REQ.

NO.

(2)60WBulbs

(NotSupplied)

Medium

Base

FINISH:IMPERIALBRONZE ONELIGHTSHOWNFOR

ILLUSTRATIONPURPOSEONLY.

C.ConnectBlack(orRed)SupplyWirefromtheOutletBoxtoSmooth

sideWirefromfixture.

D.ConnectGroundWirefromtheOutletBoxtoGroundWirefrom

fixture.

E.Twistconnectorsuntilwiresaretightlyjoinedtogether.

F.Wrapeachconnectionwithapprovedelectricaltapeandcarefully

stuffalltheconnectedwiresintotheOutletBox.

STEP4-InstallStemwithHexNut

A.ThreadtheHexNutendoftheStem(I)

intotheHexCoupling(H).Byusing

pliers,threadtheHexNutagainstthe

HexCoupling(H)andhandtightenuntil

snug.

Figure4

Socket

STEP7-InstallCage

A.PlacetheCage(B)overtheendofthe

Stem(I)andsecurewiththeKnurledNut

(J).Handtightenuntilsnug.

B.ThreadtheFinial(K)ontotheendofthe

Stem(I)andhandtightenuntilsnug.

Yourfixtureisnowassembledandready

touse.Enjoy!

Figure7

STEP6-InstallGlassPanels

A.InserttheGlassPanels(C)intotheCage(B).AttachtheTabs(E)to

thetopedgeoftheGlassPanels(C)andsecurewiththeLock

Screws(D).Handtightenuntilsnug.

10 SQ.

11.5
