Quoizel SNN8409PN Instructions de montage

Part Description Quantity

ACrossbar 1pc.

2pcs.

HexNut

LockWasher

PackageContents

Quoizel,Inc.

6CorporateParkway

GooseCreek,SC

29445

CustomerService

Phone631.273.2700

Fax631.231.7102

www.quoizel.com

WarningsandCautions

Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.

Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstalling

thefixture.Westronglyrecommendthatalicensed,professionalelectricianperformtheinstallation.

Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocool

beforeremoval.Donotsubjectglasspartstoanyshockwhileinoperationorshatteringmayresult.

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

MountingScrew

AssemblyInstructionSheet#IS-SNN8409PN

ForStyleSNN8409PN

1of6

ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wire

strippers,electricaltape,safetyglasses.

EstimatedAssemblyTime:20-30minutes

Preparation:Identifyandinspectallpartsbeforebeginninginstallation.Checkpackage

contentlistanddiagramsbelowtobesureallpartsarepresent.Ifanypartsaremissing

ordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomer

serviceforreplacementparts.

6CORPORATEPARKWAY

GOOSECREEKSC29445

wwwquoizelcom

1pc.

2pcs.

LockBall

FixtureBody

2013QuoizelInc. October2013

BulbRecommended: (1)MediumBase100WMaximum

SNN8409PN

2of6

FINISH:PALLADIANBRONZE

PARTNUMBER

NOTE:ALLDIMENSIONSAREROUNDEDUPTOTHENEAREST1/2"

REPLACEMENTPARTDESCRIPTION REQ.

NO.

(1)100WMedium

BaseBulb

(NotSupplied)

G3729PA PANELGLASSBENTWATER 4

GND

2.4mm

13Ga

QUOIZEL R

10.5

9.5

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

3of6

STEP2-AttachCrossbartoOutletBox

A.AttachtheCrossbar(A)toOutletBoxandsecureby

threadingOutletBoxScrews(notsupplied)intothe

MountingHolesontheOutletBox.Tightenuntilsnug.

Crossbar

Outlet

Box

OutletBox

Screw

Mounting

Hole Figure2

AssemblyInstructionSheet#IS-SNN8409PN

ForStyleSNN8409PN

Figure1

Crossbar

Mounting

Screw

LockWasher

HexNut

Backplate

STEP1-AttachMountingScrews,Lock

WashersandHexNutstoCrossbar

A.LineupasetofholesontheCrossbar(A)andHoleson

theBackplateoftheFixtureBody(F).

B.ThreadMountingScrews(B)intotheholesonthe

Crossbar(A),passLockWashers(C)andthreadHex

Nut(D)ontotheMountingScrews(B).Handtighten

untilsnug.

6CORPORATEPARKWAY

GOOSECREEKSC29445

wwwquoizelcom

Fixture

Body

2013QuoizelInc. October2013

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

4of6

AssemblyInstructionSheet#IS-SNN8409PN

ForStyleSNN8409PN

STEP3MakeWireConnections-

A.Usestandardwireconnectorstomakeallwire

connections.(Connectorsarenotincludedwithfixture.)

Stripandpreparewireendsaccordingtoinstructions

suppliedwithconnectors.

B.ConnectWhiteSupplyWirefromtheOutletBoxtoWhite

Wirefromfixture.

C.ConnectBlack(orRed)SupplyWirefromtheOutletBox

toBlackWirefromfixture.

D.ConnectGroundWirefromtheOutletBoxtoGround

Wirefromfixture.

E.Twistconnectorsuntilwiresaretightlyjoinedtogether.

F.Wrapeachconnectionwithapprovedelectricaltapeand

carefullystuffalltheconnectedwiresintotheOutletBox.

Figure4

Whitewirefromsupply Whitewirefromfixture

Blackwirefromsupply

(orRed) Blackwirefromfixture

Groundwirefromsupply Groundwirefromfixture

Figure5

6CORPORATEPARKWAY

GOOSECREEKSC29445

wwwquoizelcom

Figure3

Mounting

Screw

LockBall

Backplate

FixtureBody

2013QuoizelInc. October2013

STEP4-AttachFixtureBodytoMounting

Screw

A.PlacetheBackplateoftheFixtureBody(F)overthe

MountingScrews(B).Placecaulk(notsupplied)into

threadsofMountingBalls(E)andthreadthemontothe

MountingScrews(B).Handtightenuntilsnug.

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

5of6

AssemblyInstructionSheet#IS-SNN8409PN

ForStyleSNN8409PN

6CORPORATEPARKWAY

GOOSECREEKSC29445

wwwquoizelcom

2013QuoizelInc. October2013

Figure6

Bulb

Socket

STEP5-InstallBulb

A.Thisfixtureusesstandardbulbwithamediumscrewbase.

Maximum100watts.

B.Insertbulbandscrewsnuglyintoplace.

STEP6ApplySiliconeSealer-

A.Makesureexteriorwallsurfaceandfixturebackplate

arefreeofdirtbeforeapplyingcaulk.Usingexterior

gradecaulk,caulkovertopofbackplateanddown

otherside.Donotcaulkbottomoffixturebackplateto

ensurepropermoisturedrainage.

Yourfixtureisnowassembledandreadytouse.

Enjoy!

Exterior

GradeCaulk

Outdoor

Fixture

Backplate

Exterior

WallSurface

Figure7

ThankyouforpurchasingaQuoizelproduct.

Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-631-273-2700

orvisituson-lineatwww.quoizel.com

6of6

AssemblyInstructionSheet#IS-SNN8409PN

ForStyleSNN8409PN

6CORPORATEPARKWAY

GOOSECREEKSC29445

wwwquoizelcom

2013QuoizelInc. October2013

STEP7RemovetheCagefromFixtureHood-

A.ByunscrewingtheLockScrews,removetheCagefromthe

FixtureHood.

REPLACEGLASSPANELS

Figure9

GlassPanel

STEP8ReplaceGlassPanels-

A.UnscrewtheLockScrewsonthetopoftheCage.Remove

theGlassHolderfromtheCage.

B.RemovethebrokenGlassPanelinsideoftheCageand

insertthereplacementGlassPanel.

C.PlacetheGlassHolderbackontothetopoftheCageand

securewithLockScrews.Handtightenuntilsnug.

GlassHolder

Cage

LockScrew

STEP9InstalltheCage-

A.AttachtheCagewithGlassPanelsbackontotheFixture

HoodandsecurewithLockScrews.Handtightenuntilsnug.

Figure8

Lock

Screw

Fixture

Hood

Cagewith

GlassPanels

Figure10

LockScrew

FixtureHood

Cagewith

GlassPanels
