Provision ISR AUTO SYNC FOCUS SERIES Manuel utilisateur
Features
• 4~9mm Auto sync. Lens
• Day &night function, 30m IR Distance.
• 600TV Lines.
• 2D-DNR, DWDR.
• OSD control.
• RS-485 for OSD and lens control.
• Round design for all direction movements.
1. Do not install the camera in places where the temperature is above
50°C or under -10°C.
2. Do not touch the CCD surface with your finger. If cleaning is
needed, please wipe it using a soft cloth with a little bit of alcohol.
3. Do not install in places with high humidity, it can seriously damage
the quality of the picture.
4. Do not drop the camera and the controller and avoid physical shock.
5. Do not face your camera to a strong light, it can damage the CCD.
6. Do not expose the camera to rain or dusty surroundings.
7. It’s highly important to use the correct and suitable power supply
(DC12V) for the camera.
8. Only professional and qualified technician can install and test this
camera.
9. During use, if any errors occur, cut off the power immediately and
contact your local distributor.
12
Note:
In order to avoid electrical
proper power according to
the manual.
WARNING
Note: Only professional technicians is
allowed to open the front or back cover
of this camera.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Precautions
Content
2
2
3
4
5
7
8
9
13
23
25
28
29
33
Features
Precautions
OSD Main Menu
The controller
Connection
Settings up baud rate, protocol
and camera address
The Menu
1) Exposure
2) Special
3) White Bal
4) Backlight
5) Reset
Specifications
MANUAL EN ESPAÑOL
3 4
The controller
OSD Main Menu
Exposure
Shutter/Brightness/AGC/DWDR
Special
Cam Title/Motion/Privacy/Image Adjustmen
Lens Shad/2DNR/Mirror/Font Color/Contrast/Sharpness/Display/Negative image.
White Balance
ATW/ATW2/AWC SET/Manual
Backlight
BLC/HLC/Off
Reset
Use the arrows to navigate in the menu and change values.
Open menu
Zoom In
Zoom Out
Save parameter of
function setup.
Press long to change
protocol setup
Special function setup
DC12 Volt
Power
RS 485
Conection
5 6
3) Connect the video cable (Rj-59) to the camera and connect the
camera to the electricity:
When powering on the remote, the green LED on the right top corner
will turn on. If the LED is blinking constantly try removing the power
cable and plug it back in.
The controller auto-detects the protocol and baud rate of the camera,
The protocol and baud rate will be displayed on screen when the
powering on the camera.
Connection
1) Connect the RS-485 cables, make sure you connect as
described below:
2) Connect the controller to the electricity
AB
Power Suply Cable
for Controller
and Camera
Included
Power Led
Power Suply Cable
for Controller and Camera
Included
Video cable
Rj-59
7 8
a) Press and hold for 3 seconds the button on the remote.
The following lines will blink on the screen:
c) Press the button again to set BAUD RATE – use
to change parameter.
This is the main menu page.
Press to enter the setup menu.
d) When done, press the button to save and exit.
When you see the sign – press to enter the sub menu.
- Press the again to set cameras ADDRESS – Use
to change parameter.
b) While blinking – press on the button on the remote,
Protocol line will appear on the screen:
- To change protocol between PELCO-D / PELCO-C use the
Button on the remote.
Settings up baud rate, protocol and camera address
The Menu
SETUP
EXPOSURE
SPECIAL
WHITE BAL ATW 1
BACKLIGHT OFF
RESET
EXIT
PROTOCOL: PELCO D
BAUD RATE: 2400
ADDRESS: 001
PROTOCOL: PELCO D
9 10
1) Exposure The EXPOSURE menu
To compensate for the lighting conditions, the exposure control can
be adjusted.
Use this menu to set the means for the camera to automatically
control the brightness.
Available means include automatic gain control (AGC), electronic
light control (ELC or SHUTTER).
These settings determine how the cameras will behave at various
light levels and affect video image quality.
SHUTTER - Controls the amount of light according to your own
environment. Increase SHUTTER value in dark places for a brighter
picture,
Decrease SHUTTER value in places with more light for reducing
amount of light. It is recommended to use AUTO.
Enter the exposure menu:
- Scroll to EXPOSURE using
- Scroll to SHUTTER using
- Use or ► to change SHUTTER value.
It is recommended to use AUTO.
- Press to enter the EXPOSURE menu.
SETUP
EXPOSURE
SPECIAL
WHITE BAL ATW 1
BACKLIGHT OFF
RESET
EXIT
EXPOSURE
SHUTTER AUTO
BRIGHTNESS 0|------|-----|255
AGC MIDDLE
DWDR ON
RETURN RET
11 12
EXPOSURE
SHUTTER AUTO
BRIGHTNESS 0|------|-----|255
AGC MIDDLE
DWDR ON
RETURN RET
AGC - At low lightning conditions, if the image is too dark – select
higher AGC level which means that the camera would amplify the
CCD input signal and make image will become brighter but noisier.
- Scroll to AGC using
- Use to change AGC level between:
LOW/MIDDLE/HIGH or OFF.
DWDR - WDR is used when your want to see BOTH bright and dark
zones of the image. In the mode, you will see the details in both the
dark and bright.
- Scroll to DWDR using
- Use to change DWDR level between ON or OFF,
If select ON – press to set DWDR level.
- Scroll to LEVEL using
- Use ◄ or ► to change level.
DWDR
LEVEL 0 -------|-------63
RETURN RET
When seeing “RETURN” option-
You can either return to last page, or quit the menu,
Scroll to RETURN using
Use to select between RETURN- return to previous page,
END - close the menu.
BRIGHTNESS - You can control the BRIGHTNESS of the picture in
a very accurate level of between 0 to 255.
- Scroll to BRIGHTNESS using
- Use to change BRIGHTNESS level,
You can set level between 0-255.
13 14
SETUP
EXPOSURE
SPECIAL
WHITE BAL ATW 1
BACKLIGHT OFF
RESET
EXIT
- Press to enter the SPECIAL menu. - Use to move, select with the characters with .
- Use CLR to clear (backspace), press END when finished.
0 1 2 3 4 5 6
7 8 9 A B C D E
F G H I J K L M
V W X Y Z ►
( ) - _
/ = & :~ , .
CLR POS END
- - - - - - - - - - - -
- Scroll to CAM TITLE using
- Use select ON/OFF, if selected ON press to
configure the camera name.
a) CAM TITLE – Configure a name for the camera.
SPECIAL
CAM TITLE ON
MOTION OFF
PRIVCAY OFF
IMAGE ADJ.
RETURN
Configure Motion Detect option, privacy masks and image settings
like brightness, special modes and camera name.
- Scroll to SPECIAL using
2) SPECIAL
15 16
MOTION
AREA SEL. AREA1
AREA STATE ON
HEIGHT ------|------
WIDTH ------|------
LEFT/RIGHT ------|------
TOP/BOTTOM ------|------
DEGREE ------|------
VIEW ON
RETURN
- Use to scroll in the MOTIOM menu.
- Use to change the parameters.
- Scroll to PRIVACY using .
AREAL SEL - You can select between 4 different areas to adjust
motion detect in them individually.
AREA STATE - select current area ON/OFF.
HEIGHT/WIDTH - Adjust the size of the area.
TOP BOTTOM LEFT/RIGHT - adjust the position of the area.
DEGREE - Set degree level.
VIEW - you can see the where motion is detected on the picture In a
brick mode and camera will display a small icon every time
motion is detected.
c) PRIVACY - You can set privacy masks on areas in the pictures
you don’t want to show.
Size color and position are adjustable.
SETUP
CAM TITLE ON
MOTION ON
PRIVCAY ON
IMAGE ADJ .
RETURN
- Scroll to MOTION using
- Use to select ON/OFF, if selected ON press
to enter motion detection menu.
b) MOTION - You can select up to 4 motion detection areas with
adjustable height and widths and position.
SPECIAL
CAM TITLE ON
MOTION OFF
PRIVCAY OFF
IMAGE ADJ.
RETURN
17 18
d) IMAGE ADJ - adjust special effects like 2DNR function, contrast,
Sharpness etc.
- Scroll to PRIVACY using .
- Press to enter the IMAGE ADJ. menu.
- Use to scroll in theIMAGE ADJ. menu.
- Use to change the parameters.
SETUP
CAM TITLE ON
MOTION ON
PRIVCAY ON
IMAGE ADJ .
RETURN
IMAGE ADJ.
LENS SHAD. ON
2DNR ON
MIRROR OFF
FONT COLOR
CONTRAST
------|------
SHARPNESS
------|------
DISPLAY CRT
NEG. IMAGE OFF
RETURN
- Use to select ON/OFF, if selected ON press
to enter the PRIVACY menu.
- Use to scroll in the PRIVACY menu.
- Use to change the parameters.
AREAL SEL -You can adjust 8 different privacy masks individually.
AREA STATE - select current mask ON/OFF.
HEIGHT/WIDTH/LEFT/RIGHT - adjust size of the mask.
TOP BOTTOM/LEFT/RIGHT - adjust the position of the mask.
PRIVACY
AREA SEL. AREA1
AREA STATE ON
HEIGHT ------|------
WIDTH ------|------
LEFT/RIGHT ------|------
TOP/BOTTOM ------|------
RETURN
