Provision ISR I2-350A-28 Manuel utilisateur

5MP Pro HD Analog Series

USER MANUAL

Contents

1) Cautions:

2 ) Product Introduction

2.1 Camera Introduction

2.2 Product Features

Menu Setup

4) Product Installation

Specifications

4.1 General Notes

4.2 Installation Tools and Information

4.3 Installation Method

4.4 Setting the Camera

4.5

4.7

Setting the video output type

OSD Control

4.8OSD Menu Scheme

4.6Connection

2 3

1 Cautions:

1. To reduce the risk of electric shock, do not open the

camera or perform internal maintainance by yourself.

Please consult a professional service person if needed.

2. To prevent fire or electrical shock hazard, make sure

that the input voltage, current, polarity and operating

temperature meet the requirements of the camera.

3. Please note the operating temperature and environ-

mental limits of the camera. Do not install in higher/low-

er temperatures than -30°C~+50°C (-4°F~122°F).

These cameras are not waterproof! Minimize dust and

moisture erosion, otherwise camera would be damaged.

4. Avoid directing the camera to sunlight while powered

on, otherwise the sensor will be damaged.

5. Do not touch the sensor surface. If any foreign objects

exists use a cotton swab or lens paper to clean. if it is

difficult to remove, use a neutral detergent diluted with

water.

6. In order to ensure smooth and satisfactory image,

the power and video cables shouldn’t be too long.

Please follow general AHD/Analog sepcifications for

cables types and lenghts.

7. In order to prevent the camera from falling, please

install the camera on a stable surface.

8. The camera should not be placed near a radiator or

heating resistor.

4 5

3 Menu Setup

AHD/TVI: Click on “Iris+” button from the DVR’s PTZ

interface to call the OSD Menu. Use the PTZ interface to

scroll through the menu and “Iris+” to confirm.

CVI: Click “

►” button from the DVR’s PTZ interface,

then click “ ” and press “Enter” to call the OSD Menu.

4 Product Installation

4.1 General Notes

1. Make sure the unit is powered off before installation.

2. Check power supply voltage consistent with the

electric voltage to prevent voltage unworthy, resulting in

damage to the device.

3. Do not use in environment conditions exceeding the

specified temperature and humidity.

4. The installation and maintenance of this product

should be done by a professional. Please do not remove

or modify the camera in any way.

4.2 Installation Tools and Information

Prepare the required tools and instructions. Before

installation please prepare the following tools:

A straight or a Phillips-head screwdriver, multi-meter,

cutter, needle nose pliers, measuring tape, pencil.

4.3 Installation Method

1. Check the camera for any external damage.

2. Mount the bracket or base:

① For cement wall, install the expansion screws, and

then mount the bracket/base.

② For wooden wall use self-tapping screws to mount.

Note:

The wall needs to bear at least 3X weight of

bracket (base) and camera. Installation

method above is for reference only.

4.4 Setting the camera:

a. Dome Camera

Adjust the lens position so it aims at the main monitoring

point and gives a clear picture.

b. Bullet Camera

Adjust the body so that the lens aims at the main

monitoring point and gives a clear picture. Tighten the

screws to ensure that it does not move.

4.5 Setting the video output type:

The camera supports AHD/TVI/CVI/CBVS video output.

And PAL/NTSC system is switchable by setting a DIP

switch on the cable as illustrated:

Note: DAI Models cannot switch between PAL/NTSC by

hardware. Chaning the output (AHD/TVI/CVI/CVBS) is

done by a switching button on the cable.

2 Product Introduction

2.1 Camera Introduction

PROVISION-ISR’s new series of cameras have

adopted a high performance CMOS image sensor,

which provides mega pixel resolution and supports HD

video. Moreover, it supports monitoring signals coaxial

transmission. Transmission distance can reach more

than 200M based on Rg59 coaxial cable. The series

can support all HD analog resolutions: AHD/TVI/CVI

as well as CVBS 960H output.

2.2 Product Features

● Coaxial cable with BNC connector

● DIP Switch for output selection

● Auto Day/Night (ICR)

● BLC

● 3D-DNR

● Super High Resolution Lens

● AHD/TVI/CVI/CVBS Signal Selectable

●PAL/NTSC (System Selectable by DIP switch)*

6 7

3 Menu Setup

AHD/TVI: Click on “Iris+” button from the DVR’s PTZ

interface to call the OSD Menu. Use the PTZ interface to

scroll through the menu and “Iris+” to confirm.

CVI: Click “

►” button from the DVR’s PTZ interface,

then click “ ” and press “Enter” to call the OSD Menu.

4 Product Installation

4.1 General Notes

1. Make sure the unit is powered off before installation.

2. Check power supply voltage consistent with the

electric voltage to prevent voltage unworthy, resulting in

damage to the device.

3. Do not use in environment conditions exceeding the

specified temperature and humidity.

4. The installation and maintenance of this product

should be done by a professional. Please do not remove

or modify the camera in any way.

4.2 Installation Tools and Information

Prepare the required tools and instructions. Before

installation please prepare the following tools:

A straight or a Phillips-head screwdriver, multi-meter,

cutter, needle nose pliers, measuring tape, pencil.

4.3 Installation Method

1. Check the camera for any external damage.

2. Mount the bracket or base:

① For cement wall, install the expansion screws, and

then mount the bracket/base.

② For wooden wall use self-tapping screws to mount.

Note:

The wall needs to bear at least 3X weight of

bracket (base) and camera. Installation

method above is for reference only.

4.4 Setting the camera:

a. Dome Camera

Adjust the lens position so it aims at the main monitoring

point and gives a clear picture.

b. Bullet Camera

Adjust the body so that the lens aims at the main

monitoring point and gives a clear picture. Tighten the

screws to ensure that it does not move.

4.5 Setting the video output type:

The camera supports AHD/TVI/CVI/CBVS video output.

And PAL/NTSC system is switchable by setting a DIP

switch on the cable as illustrated:

Note: DAI Models cannot switch between PAL/NTSC by

hardware. Chaning the output (AHD/TVI/CVI/CVBS) is

done by a switching button on the cable.

8 9

4.6 Connection

Connection as shown in the figure below

4.8 OSD Menu Scheme:

4.7 OSD Control

The OSD control is available by CoC (Control over

Coax). If your AHD/TVI/CVI DVR supports this function*,

use the DVR’s PTZ interface to press on “Iris+” or “ ”

to open the OSD menu. Navigate through the OSD

menu using the PTZ direction arrows.

* Notice: CoC function works no more than 200M by RG59 coaxial cable

* All of Provision-ISR’s DVRs support CoC Starting from version 3.4.4

Main Menu Second Menu Third Menu

Manual 1~20

Mode

Iris Speed

Shutter

0~15

0~100

Off / On

BLC / Off

D-WDR

Backlight

ATW

AWC -> Set

Ext D->N (Delay)

N->D (Delay)

Auto

Color

B/W

Sharpness

D->N (AGC)

D->N (Delay)

N->D (AGC)

Adjust

Lens

Exposure

AGC

Brightness

White Balance

Day & Night

N->D (Delay)

IR Smart

2DNR

3DNR

5 Specifications:

5MP Pro HD Analog Series

Model

Image Sensor

Image Format

Effective Pixels

Scanning System

Resolution

FPS

Min. Illumination

D&N

IR LED

OSD Menu

CoC Support

Day & Night Mode

Backlight Compensation

S/N Ratio

White Balance

Noise Reduction

Video Output

Privacy Mask

D-Effect

WDR

Lens (Field Of View)

Power

Operation Temperature

Protection Rate

Dimensions

Net Weight

1/2.7" 5MP Sensor

5MP - 4:3. 4MP - 16:9

2608x1960

Progressive

"5MP: 2592x1944 AHD/TVI

4MP: 2560x1440 AHD/TVI/CVI

CVBS: 700TVL

25/30FPS

Color: 0.01lux @F1.2, AGC ON, B/W: 0lux with IR

True Day&Night-ICR

Available via CoC Only

Yes

Ext/Auto/Day/Night

BLC

≥52dB (AGC OFF)

Auto / Auto->Set

3D-DNR

5MP / 4MP (Selected by OSD Menu)

AHD/TVI/CVI/CVBS + PAL/NTSC (Selected by DIP Switch)

Mirror + Flip

Digital

-30°C ~ 50°C, 10% ~ 90% humidity

IP67

I2-350A-28

1LED Array (20m)

2.8mm Fixed (91°)

DC12V/320mA

172.2*73.4*74.5mm

475g

I4-350A-28

2LED Array (40m)

2.8mm Fixed (91°)

DC12V/470mA

220.8*79.4*81.2mm

645g

I4-350A-VF

2LED Array (40m)

2.8-12mm VF (84°-32°)

DC12V/470mA

220.8*79.4*81.2mm

645g

10 11

Color Gain

Red Gain

Blue Gain

Mirror

Live DPC

White DPC

Eng / Ger / Fra / Ita / Spa /

Pol / Rus / Por / Ned

4MP - AHD/TVI/CVI

5MP - AHD/TVI

CVBS

PAL / NTSC

Language

Save and Exit

Reset

Not Save

Adjust

Exit

DPC

LSC

Model

Image Sensor

Image Format

Effective Pixels

Scanning System

Resolution

FPS

Min. Illumination

D&N

IR LED

OSD Menu

CoC Support

Day & Night Mode

Backlight Compensation

S/N Ratio

White Balance

Noise Reduction

Video Output

Privacy Mask

D-Effect

WDR

Lens (Field Of View)

Power

Operation Temperature

Protection Rate

Dimensions

Net Weight

I4-350A-MVF

2LED Array (40m)

2.8-12mm MVF (84°-32°)

DC12V/660mA

220.8*79.4*81.2mm

690g

1312

1/2.7" 5MP Sensor

5MP - 4:3. 4MP - 16:9

2608x1960

Progressive

"5MP: 2592x1944 AHD/TVI

4MP: 2560x1440 AHD/TVI/CVI

CVBS: 700TVL

25/30FPS

Color: 0.01lux @F1.2, AGC ON, B/W: 0lux with IR

True Day&Night-ICR

Available via CoC Only

Yes

Ext/Auto/Day/Night

BLC

≥52dB (AGC OFF)

Auto / Auto->Set

3D-DNR

5MP / 4MP (Selected by OSD Menu)

AHD/TVI/CVI/CVBS + PAL/NTSC (Selected by DIP Switch)

Mirror + Flip

Digital

-30°C ~ 50°C, 10% ~ 90% humidity

IP67

DI-350A-28

1LED Array (20m)

2.8mm Fixed (91°)

DC12V/280mA

Φ97*82.6mm

465g

DI-350A-VF

3LED Array (40m)

2.8-12mm VF (84°-32°)

DC12V/620mA

Φ113*99.6mm

675g

Model

Image Sensor

Image Format

Effective Pixels

Scanning System

Resolution

FPS

Min. Illumination

D&N

IR LED

OSD Menu

CoC Support

Day & Night Mode

Backlight Compensation

S/N Ratio

White Balance

Noise Reduction

Video Output

Privacy Mask

D-Effect

WDR

Lens (Field Of View)

Power

Operation Temperature

Protection Rate

Dimensions

Net Weight

*DAI Model does not support PAL/NTSC switching by DIP switch

1/2.7" 5MP Sensor

5MP - 4:3. 4MP - 16:9

2608x1960

Progressive

"5MP: 2592x1944 AHD/TVI

4MP: 2560x1440 AHD/TVI/CVI

CVBS: 700TVL

25/30FPS

Color: 0.01lux @F1.2, AGC ON, B/W: 0lux with IR

True Day&Night-ICR

Available via CoC Only

Yes

Ext/Auto/Day/Night

BLC

≥52dB (AGC OFF)

Auto / Auto->Set

3D-DNR

5MP / 4MP (Selected by OSD Menu)

AHD/TVI/CVI/CVBS + PAL/NTSC (Selected by DIP Switch)*

Mirror + Flip

Digital

-30°C ~ 50°C, 10% ~ 90% humidity

DI-350A-MVF

3LED Array (40m)

2.8-12mm MVF (84°-32°)

DC12V/620mA

IP66

Φ113*99.6mm

675g

DAI-350A-MVF

3LED Array (40m)

2.8-12mm MVF (84°-32°)

DC12V/600mA

IP66, IK10

Φ140.9*100.3mm

805g

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Provision ISR Caméra de sécurité

Provision ISR

Provision ISR DAIPT-390AX4 Manuel utilisateur

Provision ISR

Provision ISR Ultra-Z-18s Manuel utilisateur

Provision ISR

Provision ISR Ultra-Z IP series Manuel utilisateur

Provision ISR

Provision ISR MC-392AHD37+ Manuel utilisateur

Provision ISR

Provision ISR I1-380AHDB36 Manuel utilisateur

Provision ISR

Provision ISR I1-325CS Manuel utilisateur

Provision ISR

Provision ISR DAI-390IP04 Manuel utilisateur

Provision ISR

Provision ISR PT-737 Instructions d'utilisation et d'entretien

Provision ISR

Provision ISR I2-320A-28 Manuel utilisateur

Provision ISR

Provision ISR ZP-20A-2(IR) Manuel utilisateur

Provision ISR

Provision ISR I4-380IPVF Manuel utilisateur

Provision ISR

Provision ISR Effio-E Infra Red Manuel utilisateur

Provision ISR

Provision ISR Mini Ultra-Z Z-10AHD-1 (IR) PTZ Manuel utilisateur

Provision ISR

Provision ISR Light Cruiser LC-10 Manuel utilisateur

Provision ISR

Provision ISR I5PT-320IPMX10-P Manuel utilisateur

Provision ISR

Provision ISR DAI-390IPVF Manuel utilisateur

Provision ISR

Provision ISR UltraVision Series Manuel utilisateur

Provision ISR

Provision ISR PT-848 Manuel utilisateur

Provision ISR

Provision ISR DI-380AHD36 Manuel utilisateur

Provision ISR

Provision ISR ISR BOX CAMERA Manuel utilisateur

Provision ISR

Provision ISR 5MP 4 in 1 Series Manuel utilisateur

Provision ISR

Provision ISR DA-352CS DA-322CS Manuel utilisateur

Provision ISR

Provision ISR BX-380IP Manuel utilisateur

Provision ISR

Provision ISR PT-737 Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
