Protech PA-3252 Manuel utilisateur

USER’S

MANUAL

PA-3252

15” POS System Powered by

Intel

Atom

D525 Platform

Preface

PA-3252 POS System

With LCD / Touchscreen

PREFACE

This user’s manual is meant to assist users in installing and setting up the system. The

information contained in this document is subject to change without any notice.

This manual is copyrighted May 2012. You may not reproduce or transmit in any

form or by any means, electronic, or mechanical, including photocopying and

recording.

ACKNOWLEDGEMENTS

All trademarks and registered trademarks mentioned herein are the property of their

respective owners.

CE NOTICE

This is a class A product. In a domestic environment this product may cause radio

interference in which case the user may be required to take adequate measures.

Preface

FCC NOTICE

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful interference

in which case the user will be required to correct the interference at his own expense.

You are cautioned that any change or modifications to the equipment not expressly

approve by the party responsible for compliance could void your authority to operate

such equipment.

CAUTION!

Danger of explosion if battery is incorrectly replaced. Replace only with the same or

equivalent type recommended by the manufacturer. Dispose of used batteries according to

the manufacturer’s instructions.

WARNING!

Some internal parts of the system may have high electrical voltage. And therefore we

strongly recommend that qualified engineers can open and disassemble the system. The

LCD and Touchscreen are easily breakable, please handle them with extra care.

Contents

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION

1-1 About This Manual .......................................................

1-2

1-2 POS System Illustration ................................................

1-3

1-3 System Specification .....................................................

1-4

1-4 Safety Precautions .........................................................

1-7

CHAPTER 2 SYSTEM CONFIGURATION

2-1 Jumper & Connector Quick Reference Table ...............

2-2

2-2 Component Locations ...................................................

2-3

2-3 How to Set the Jumpers ................................................

2-4

2-4 COM Port & VGA Connector ……………………….. 2-6

2-5 COM Port RI and Voltage Selection ………………… 2-9

2-6 Mini-DIN and USB Connector ………………………. 2-13

2-7 LAN & USB Connector ………………………………

2-14

2-8 Cash Drawer Connector ………………………………

2-15

2-9 Cash Drawer Power Selection ………………………...

2-16

2-10 Power LED Connector ………………………………….

2-17

2-11 Smart FAN Connector ….……………………………. 2-17

2-12 Power Connector …………………………………….. 2-17

2-13 Reset Switch Connector ……………………………… 2-18

2-14 Power for Thermal Printer Connector ………………...

2-18

2-15 External Speaker Connector …………………………..

2-18

2-16 Inverter Connector …………………………………… 2-19

2-17 MSR/ Card Reader Connector ……………………….. 2-19

2-18 Printer Connector ……………………………………. 2-20

2-19 LVDS Connector …………………………………….. 2-21

2-20 SATA Connector ……………………………………...

2-23

2-21 SATA Power Connector ………………………………

2-23

2-22 Touch Panel Connector ……………………………….

2-24

2-23 Touch Panel Selection ………………………………. 2-24

2-24 Clear CMOS Data Selection ………………….……… 2-25

2-25 Compact Flash Connector …………………………….

2-26

Contents

CHAPTER 3 SOFTWARE UTILITIES

3-1 Introduction …...............................................................

3-2

3-2 Intel

Chipset Software Installation Utility …...............

3-3

3-3 VGA Driver Utility …………………………….…….. 3-4

3-4 LAN Driver Utility …....................................................

3-5

3-5 Sound Driver Utility …..................................................

3-6

CHAPTER 4 AMI BIOS SETUP

4-1 Introduction …...............................................................

4-2

4-2 Entering Setup …...........................................................

4-3

4-3 Main …………………………….….............................

4-5

4-4 Advanced …………………………...............................

4-6

4-5 Boot ………………………….......................................

4-16

4-6 Security Settings ……….…….......................................

4-20

4-7 Chipset ……………………..……………………….... 4-21

4-8 Exit ………………………............................................

4-25

APPENDIX A SYSTEM ASSEMBLY

Exploded Diagram for PA-3252 Top Case …………………...

A-3

Exploded Diagram for PA-3252 Open & Close ……………...

A-4

Exploded Diagram for PA-3252 Bottom Case ………………..

A-5

Exploded Diagram for PA-3252 Inside Box ………………….

A-6

Exploded Diagram for PA-3252 CPU Cooler ………………...

A-8

Exploded Diagram for PA-3252 LCD Panel …………………

A-9

Exploded Diagram for PA-3252 Printer Box ……………...….

A-11

Exploded Diagram for PA-3252 2 Inch Printer ....……………

A-12

Exploded Diagram for PA-3252 2 Inch Printer Cover .………

A-14

Exploded Diagram for PA-3252 3 Inch Printer ....……………

A-15

Exploded Diagram for PA-3252 3 Inch Printer Cover .………

A-17

Exploded Diagram for PA-3252 Printer Control Board ...........

A-18

Exploded Diagram for PA-3252 Hard Disk Drive ………...….

A-20

Exploded Diagram for PA-3252 VFD Cover ……………...….

A-21

Exploded Diagram for PA-3252 SSD Module ………...……..

A-23

Exploded Diagram for PA-3252 RFID Module ………...…….

A-24

Exploded Diagram for PA-3252 Memory Maintenance ……...

A-26

Exploded Diagram for PA-3252 Mini PCIE and CF Card

Maintenance ………………………………………………….

A-27

Contents

Exploded Diagram for PA-3252 2 Inch Printer Maintenance ...

A-29

Exploded Diagram for PA-3252 3 Inch Printer Maintenance ...

A-30

Exploded Diagram for PA-3252 Printer Platen Block

Maintenance ............................................................................

A-31

APPENDIX B TECHNICAL SUMMARY

Block Diagram .........................................................................

B-2

Interrupt Map ............................................................................

B-3

DMA Channels Map ................................................................

B-4

I/O Map ....................................................................................

B-5

Watchdog Timer Configuration ………………………………

B-8

Flash BIOS Update ………………………………………….. B-10

Page:1-1

INTRODUCTION

This chapter gives you the information for PA-3252. It also outlines the

system specifications.

Sections included:

About This Manual

POS System Illustration

System Specifications

Safety Precautions

Experienced users can jump to chapter 2 on page 2-1

for a quick start.

CHAPTER

Chapter 1 Introduction

Page: 1-2 PA-3252 USER

′

S MANUAL

1-1. ABOUT THIS MANUAL

Thank you for purchasing our PA-3252 system. The PA-3252 is an updated system

designed to be comparable with the highest performance of IBM AT personal

computers. The PA-3252 provides faster processing speed, greater expandability and

can handle more tasks than before. This manual is designed to assist you how to install

and set up the whole system. It contains four chapters and two appendixes. Users can

configure the system according to their own needs.

Chapter 1 Introduction

This chapter introduces you to the background of this manual. It also includes

illustrations and specifications for the whole system. The final section of this chapter

indicates some safety reminders on how to take care of your system.

Chapter 2 System Configuration

This chapter outlines the location of motherboard components and their function. You

will learn how to set jumper and how to configure the system to meet your own needs.

Chapter 3 Software Utilities

This chapter contains helpful information for proper installations of the Intel Utility,

VGA Utility, LAN Utility, Sound Utility, and Touch Screen Utility.

Chapter 4 AMI BIOS Setup

This chapter indicates you how to change the BIOS configurations.

Appendix A System Assembly

This appendix gives you the exploded diagrams and part numbers of the PA-3252.

Appendix B Technical Summary

This appendix gives you the information about the allocation maps for the system

resources, Watchdog Timer Configuration, and Flash BIOS Update.

Chapter 1 Introduction

PA-3252 USER

′

S MANUAL Page: 1-3

1-2. POS SYSTEM ILLUSTRATION

Front

iew

Rear

iew

Side View

Chapter 1 Introduction

Page: 1-4 PA-3252 USER

′

S MANUAL

1-3. SYSTEM SPECIFICATIONS

MAINBOARD (PROX3520LF)

CPU Type:

Intel

ATOM D525

Chipset:

Intel

ICH8M

Memory:

One 204-pin DDRIII SO-DIMM socket on board, up to 2GB

Cache:

Depends on CPU

Real-Time Clock / Calendar:

Embedded in Intel

ICH8M South Bridge

BIOS:

AMI SPI BIOS

8Mbits with VGA BIOS

Keyboard Connector:

PS/2 Keyboard, with mini DIN connecter on rear panel

Mouse Connector:

PS/2 Mouse, with mini DIN connecter on rear panel

Serial Port:

3 x DB-9 (COM 1/2/4)

1 x RJ45 (COM3)

+5/12V Selectable (COM 1~3)

Universal Serial BUS Port:

4 x USB2.0 ports

1 x USB2.0 on side bezel
