ProSoft Technology MVI56E-61850S Manuel utilisateur

MVI56E-61850S

ControlLogix Platform

IEC 61850 Server Communication

Module

September 3, 2014

USER MANUAL

Your Feedback Please

We always want you to feel that you made the right decision to use our products. If you have suggestions, comments,

compliments or complaints about our products, documentation, or support, please write or call us.

ProSoft Technology

5201 Truxtun Ave., 3rd Floor

Bakersfield, CA 93309

+1 (661) 716-5100

+1 (661) 716-5101 (Fax)

www.prosoft-technology.com

[email protected]

MVI56E-61850S User Manual

September 3, 2014

ProSoft Technology®, is a registered copyright of ProSoft Technology, Inc. All other brand or product names are or

may be trademarks of, and are used to identify products and services of, their respective owners.

In an effort to conserve paper, ProSoft Technology no longer includes printed manuals with our product shipments.

User Manuals, Datasheets, Sample Ladder Files, and Configuration Files are provided on the enclosed DVD and are

available at no charge from our web site: http://www.prosoft-technology.com

Content Disclaimer

This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of

these products for specific user applications. It is the duty of any such user or integrator to perform the appropriate

and complete risk analysis, evaluation and testing of the products with respect to the relevant specific application or

use thereof. Neither ProSoft Technology nor any of its affiliates or subsidiaries shall be responsible or liable for

misuse of the information contained herein. Information in this document including illustrations, specifications and

dimensions may contain technical inaccuracies or typographical errors. ProSoft Technology makes no warranty or

representation as to its accuracy and assumes no liability for and reserves the right to correct such inaccuracies or

errors at any time without notice. If you have any suggestions for improvements or amendments or have found errors

in this publication, please notify us.

No part of this document may be reproduced in any form or by any means, electronic or mechanical, including

photocopying, without express written permission of ProSoft Technology. All pertinent state, regional, and local safety

regulations must be observed when installing and using this product. For reasons of safety and to help ensure

compliance with documented system data, only the manufacturer should perform repairs to components. When

devices are used for applications with technical safety requirements, the relevant instructions must be followed.

Failure to use ProSoft Technology software or approved software with our hardware products may result in injury,

harm, or improper operating results. Failure to observe this information can result in injury or equipment damage.

Printed documentation is available for purchase. Contact ProSoft Technology for pricing and availability.

North America: +1 (661) 716-5100

Asia Pacific: +603.7724.2080

Europe, Middle East, Africa: +33 (0) 5.3436.87.20

Latin America: +1.281.298.9109

Agency Approvals and Certifications

Agency

RoHS

ATEX

CSA

CSA CB Safety

cULus

GOST-R

Important Safety Information

North America Warnings

A Warning - Explosion Hazard - Substitution of components may impair suitability for Class I, Division 2.

B Warning - Explosion Hazard - When in Hazardous Locations, turn off power before replacing or rewiring

modules.

C Warning - Explosion Hazard - Do not disconnect equipment unless power has been switched off or the area is

known to be nonhazardous.

D Suitable for use in Class I, Division 2 Groups A, B, C, and D, Hazardous Locations or Non-Hazardous Locations.

ATEX/IECEx Warnings and Conditions of Safe Usage:

Power, Input, and Output (I/O) wiring must be in accordance with the authority having jurisdiction

A Warning - Explosion Hazard - When in hazardous locations, turn off power before replacing or wiring modules.

B Warning - Explosion Hazard - Do not disconnect equipment unless power has been switched off or the area is

known to be non-hazardous.

C These products are intended to be mounted in an ATEX/IECEx Certified, tool-secured, IP54 enclosure. The devices

40%. This device must be used only with ATEX certified backplanes.

DBefore operating the reset switch, be sure the area is known to be non-hazardous.

shall provide external means to prevent the rated voltage being exceeded by transient disturbances of more than

<Ex>

II 3 G

Ex nA IIC T4 Gc

0°C <= Ta <= 60°C

-25°C <= Ta <= 70°C (XT models only)

II – Equipment intended for above ground use (not for use in mines).

3 – Category 3 equipment, investigated for normal operation only.

G – Equipment protected against explosive gasses. <cULus>

E183151

Class I, DIV 2, groups A,B,C,D

T5 for all models

0°C to +60°C

-25°C to +70°C (XT models only)

MVI56E-61850S ♦ ControlLogix Platform Contents

IEC 61850 Server Communication Module User Manual

ProSoft Technology, Inc. Page 5 of 81

September 4, 2014

Contents

Your Feedback Please........................................................................................................................2

Content Disclaimer..............................................................................................................................2

Important Safety Information...............................................................................................................3

1Start Here 7

1.1 System Requirements...............................................................................................8

1.2 Package Contents.....................................................................................................9

1.3 Setting Jumpers ........................................................................................................9

1.4 Installing the Module in the Rack ............................................................................10

1.5 Connecting Your PC to the ControlLogix Processor...............................................12

1.6 Downloading the Sample Program to the Processor..............................................13

1.6.1 Configuring the RSLinx Driver for the PC COM Port ..............................................14

2Setting Up ProSoft Configuration Builder 17

2.1 Installing ProSoft Configuration Builder ..................................................................17

2.2 Setting Up the Project .............................................................................................18

3MVI56E-61850S Configuration 21

3.1 Backplane Configuration.........................................................................................22

3.2 Ethernet1.................................................................................................................23

3.3 61850S Identification...............................................................................................24

3.4 61850S Network......................................................................................................25

3.5 61850S IP Filter.......................................................................................................26

3.6 61850S Data DB Configuration...............................................................................28

3.7 61850S Data SoE....................................................................................................30

3.8 61850S Data Control...............................................................................................32

3.9 61850S Buffered Reports........................................................................................34

3.9.1 61850S BR0x Dataset.............................................................................................36

3.10 61850S Unbuffered Reports ...................................................................................38

3.10.1 61850S UR0x Dataset.............................................................................................40

3.11 Downloading the Project to the Module ..................................................................42

3.11.1 Connecting Your PC to the Module's Ethernet Port................................................44

4RSLogix 5000 Configuration 49

4.1 MVI56E-61850S User-Defined Data Types............................................................49

4.2 MVI56E-61850S Controller Tags ............................................................................49

4.2.1 61850S Controller Tag Overview............................................................................49

4.2.2 MVI56E61850S.DATA.............................................................................................50

4.2.3 MVI56E61850S.COMMAND...................................................................................51

4.2.4 MVI56E61850S.STATUS Tag.................................................................................52

4.2.5 MVI56E61850S.UTIL Tag.......................................................................................52

Contents MVI56E-61850S ♦ ControlLogix Platform

User Manual IEC 61850 Server Communication Module

Page 6 of 81 ProSoft Technology, Inc.

September 4, 2014

5Examples 53

5.1 Data DB Example ................................................................................................... 53

5.2 SoE Example.......................................................................................................... 58

5.3 Control Example ..................................................................................................... 62

6Diagnostics and Troubleshooting 65

6.1 Ethernet LED Indicators.......................................................................................... 65

6.1.1 Scrolling LED Status Indicators.............................................................................. 66

6.1.2 Non-Scrolling LED Status Indicators ...................................................................... 67

6.2 Clearing a Fault Condition ...................................................................................... 67

6.3 Troubleshooting...................................................................................................... 68

6.4 Using the Diagnostics Menu in ProSoft Configuration Builder ............................... 69

6.4.1 Monitoring Module Information............................................................................... 72

6.4.2 Monitoring Backplane Information.......................................................................... 73

6.4.3 Monitoring Base Configuration Information............................................................ 74

6.4.4 Monitoring Data Mappings Information................................................................... 75

6.4.5 Monitoring Backplane Information.......................................................................... 76

6.4.6 Monitoring Flat Database Information .................................................................... 77

6.5 Connect to the Module’s Web Page ....................................................................... 78

7Support, Service & Warranty 79

7.1 Contacting Technical Support................................................................................. 79

7.2 Warranty Information .............................................................................................. 80

Index 81

MVI56E-61850S ♦ ControlLogix Platform Contents

IEC 61850 Server Communication Module User Manual

ProSoft Technology, Inc. Page 7 of 81

September 4, 2014

1 Start Here

In This Chapter

System Requirements............................................................................. 8

Package Contents .................................................................................. 9

Setting Jumpers...................................................................................... 9

Installing the Module in the Rack...........................................................10

Connecting Your PC to the ControlLogix Processor..............................12

Downloading the Sample Program to the Processor.............................13

To get the most benefit from this User Manual, you should have the following skills:

Rockwell Automation®RSLogix™ software: launch the program, configure ladder

logic, and transfer the ladder logic to the processor

Microsoft Windows®:install and launch programs, execute menu commands, navigate

dialog boxes, and enter data

Hardware installation and wiring: install the module, and safely connect IEC 61850

and ControlLogix devices to a power source and to the MVI56E-61850S module’s

application port(s)

Contents MVI56E-61850S ♦ ControlLogix Platform

User Manual IEC 61850 Server Communication Module

Page 8 of 81 ProSoft Technology, Inc.

September 4, 2014

1.1 System Requirements

The MVI56E-61850S module requires the following minimum hardware and software

components:

Rockwell Automation®ControlLogix®processor (firmware version 10 or higher) with

compatible limited voltage power supply and one free slot in the rack for the MVI56E-

61850S module. The module requires 800 mA of available 5 VDC and 3 mA of available

24 VDC power.

Rockwell Automation RSLogix™5000 programming software

oVersion 16 or higher required for Add-On Instruction

Rockwell Automation RSLinx®communication software version 2.51 or higher

ProSoft Configuration Builder (PCB) (included)

ProSoft Discovery Service (PDS) (included in PCB)

Pentium®II 450 MHz minimum. Pentium III 733 MHz (or better) recommended

Supported operating systems:

oMicrosoft Windows®Vista

oMicrosoft Windows XP Professional with Service Pack 1 or 2

oMicrosoft Windows 7 Professional (32 or 64-bit)

oMicrosoft Windows 2000 Professional with Service Pack 1, 2, or 3

oMicrosoft Windows Server 2003

128 MB of RAM minimum, 256 MB of RAM recommended

100 MB of free hard disk space (or more based on application requirements)

256-color VGA graphics adapter, 800 x 600 minimum resolution (True Color 1024 768

recommended)

DVD drive

Note: The Hardware and Operating System requirements in this list are the minimum recommended to install

and run software provided by ProSoft Technology®. Other third party applications may have different minimum

requirements. Refer to the documentation for any third party applications for system requirements.

Note: You can install the module in a local or remote rack. For remote rack installation, the module requires

EtherNet/IP or ControlNet communication with the processor.

MVI56E-61850S ♦ ControlLogix Platform Contents

IEC 61850 Server Communication Module User Manual

ProSoft Technology, Inc. Page 9 of 81

September 4, 2014

1.2 Package Contents

The following components are included with your MVI56E-61850S module, and are all

required for installation and configuration.

Important: Before beginning the installation, please verify that all of the following items are present.

Qty.

Part Name

Part Number

Part Description

MVI56E-61850S Module

MVI56E-61850S

IEC 61850 Server Communication Module

Ethernet Cable

RL-CBL025

Straight-through Ethernet cable

ProSoft Solutions DVD

DVD-001

Contains sample programs, utilities, and documentation.

Files can also be found at

http://www.prosoft-technology.com

If any of these components are missing, please contact ProSoft Technology Technical

Support for replacement parts. If the DVD is not present, please visit

http://www.prosoft-technology.com for the latest files.

1.3 Setting Jumpers

The Setup Jumper acts as "write protection" for the module’s flash memory. In "write

protected" mode, the Setup pins are not connected, and the module’s firmware cannot be

overwritten. The module is shipped with the Setup jumper OFF. Do not jumper the Setup

pins together unless you are directed to do so by ProSoft Technical Support (or to update

the module firmware).

The following illustration shows the MVI56E-61850S jumper configuration with the Setup

Jumper OFF.

Contents MVI56E-61850S ♦ ControlLogix Platform

User Manual IEC 61850 Server Communication Module

Page 10 of 81 ProSoft Technology, Inc.

September 4, 2014

1.4 Installing the Module in the Rack

Make sure your ControlLogix processor and power supply are installed and configured,

before installing the MVI56E-61850S module. Refer to your Rockwell Automation product

documentation for installation instructions.

Warning: You must follow all safety instructions when installing this or any other electronic devices. Failure to

follow safety procedures could result in damage to hardware or data, or even serious injury or death to

personnel. Refer to the documentation for each device you plan to connect to verify that suitable safety

procedures are in place before installing or servicing the device.

After you have checked the placement of the jumpers, insert the MVI56E-61850S into the

ControlLogix chassis. Use the same technique recommended by Rockwell Automation to

remove and install ControlLogix modules.

You can install or remove ControlLogix system components while chassis power is applied

and the system is operating. However, please note the following warning.

Warning: When you insert or remove the module while backplane power is on, an electrical arc can occur. An

electrical arc can cause personal injury or property damage by sending an erroneous signal to the system’s

actuators. This can cause unintended machine motion or loss of process control. Electrical arcs may also cause

an explosion when they happen in a hazardous environment. Verify that power is removed or the area is non-

hazardous before proceeding.

Repeated electrical arcing causes excessive wear to contacts on both the module and its mating connector.

Worn contacts may create electrical resistance that can affect module operation.

1 Align the module with the top and bottom guides, and then slide it into the rack until the

module is firmly against the backplane connector.

2 With a firm, steady push, snap the module into place.

3 Check that the holding clips on the top and bottom of the module are securely in the

locking holes of the rack.

Table des matières

Autres manuels ProSoft Technology Unité de contrôle

ProSoft Technology

ProSoft Technology inRAx MVI46-DFNT Manuel utilisateur

ProSoft Technology

ProSoft Technology inRAX MVI69-S3964R Manuel utilisateur

ProSoft Technology

ProSoft Technology MVI69-GSC CompactLogix Manuel utilisateur

ProSoft Technology

ProSoft Technology CompactLogix MVI69E-MBS Manuel utilisateur

ProSoft Technology

ProSoft Technology ILX34-MBS485 Manuel utilisateur

ProSoft Technology

ProSoft Technology ControlLogix inRAx MVI56E-MNETR Manuel utilisateur

ProSoft Technology

ProSoft Technology MVI69-GEC Manuel utilisateur

ProSoft Technology

ProSoft Technology MVI69E-LDM-MQTT Manuel utilisateur

ProSoft Technology

ProSoft Technology ILX69-PBM Manuel utilisateur

ProSoft Technology

ProSoft Technology PS69-DPM Manuel utilisateur

ProSoft Technology

ProSoft Technology MVI69E-MBTCP Manuel utilisateur

ProSoft Technology

ProSoft Technology MVI69E-GSC Manuel utilisateur

ProSoft Technology

ProSoft Technology MVI56E-LDM-MQTT Manuel utilisateur

ProSoft Technology

ProSoft Technology ILX69-PBS Manuel utilisateur

ProSoft Technology

ProSoft Technology inRax MVI56-DNPSNET Manuel utilisateur

ProSoft Technology

ProSoft Technology ProLinx ASCII Note de version

ProSoft Technology

ProSoft Technology inRax MVI56-DH485R Manuel utilisateur

ProSoft Technology

ProSoft Technology inRax MVI71-BDW Manuel utilisateur

ProSoft Technology

ProSoft Technology MVI71-GEC Manuel utilisateur

ProSoft Technology

ProSoft Technology InRAX MVI46-PDPS Manuel utilisateur

ProSoft Technology

ProSoft Technology inRAx MVI56-GEC Manuel utilisateur

ProSoft Technology

ProSoft Technology inRax MVI56E-GSC Manuel utilisateur

ProSoft Technology

ProSoft Technology inRAx MVI56-HART Manuel utilisateur

ProSoft Technology

ProSoft Technology inRAx MVI56-S3964R Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
