ProLights EclProfile CT+ Manuel utilisateur

USER MANUAL

REV.02-07/20 English version

EclProfile CT+

High quality six colours full

spectrum ellipsoidal LED

Thank you for choosing PROLIGHTS

Please note that every PROLIGHTS product has been designed in Italy to meet quality and performance requirements

for professionals and designed and manufactured for the use and application as shown in this document.

Any other use, if not expressly indicated, could compromise the good condition/operation of the product and/or be

a source of danger.

This product is meant for professional use. Therefore, commercial use of this equipment is subject to the respectively

applicable national accident prevention rules and regulations.

Features, specications and appearance are subject to change without notice. Music & Lights S.r.l. and all afliated

companies disclaim liability for any injury, damage, direct or indirect loss, consequential or economic loss or any other

loss occasioned by the use of, inability to use or reliance on the information contained in this document.

Product user manual can be downloaded from the website www.prolights.it , or can be inquired to the ofcial

PROLIGHTS distributors of your territory (https://www.prolights.it/sales_network.html).

Scanning the below QR Code, you will access the download area of the product page, where you can nd a broad

set of always updated technical documentation: specications, user manual, technical drawings, photometrics,

personalities, xture rmware updates.

The PROLIGHTS Logo, PROLIGHTS names and all other trademark in this document pertaining to PROLIGHTS services

or PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its afliates, and subsidiaries.

136,200; Itri 04020, Italy.

Visit the download area

of the product page

PROLIGHTS - EclProfile CT+ 1

INDEX

SAFETY INFORMATION 02

1 - PACKAGING 05

PACKAGE CONTENT..................................................................................................... 05

OPTIONAL ACCESSORIES............................................................................................. 05

2 - TECHNICAL DRAWING 06

3 - INSTALLATION 07

MOUNTING.................................................................................................................... 07

4 - CONNECTION TO THE MAINS SUPPLY 08

5 - START UP 08

CONNECT AND DISCONNECT POWER FROM THE PRODUCT.................................. 08

6 - PRODUCT OVERVIEW 09

7 - DMX CONNECTION 10

CONNECTION OF THE CONTROL SIGNAL: DMX LINE .............................................. 10

INSTRUCTIONS FOR A RELIABLE DMX CONNECTION ............................................... 10

CONNECTION DAISY CHAIN........................................................................................ 10

CONNECTION OF THE DMX LINE................................................................................ 10

CONSTRUCTION OF THE DMX TERMINATION ........................................................... 11

DMX ADDRESSING ........................................................................................................ 11

8 - CONTROL PANEL 12

DISPLAY AND BUTTONS LAYOUT................................................................................. 12

9 - MENU STRUCTURE 13

10 - RDM FUNCTIONS 16

11 - ERROR MESSAGES 17

12 - DMX CHARTS 18

13 - ACCESSORIES INSTALLATION 24

OPTIC (CODE ECLPRL)................................................................................................... 24

GEL FILTER FRAME (CODE ECLPRTPG)......................................................................... 25

GOBO HOLDER (CODE ECLPRGH) ............................................................................... 26

STEEL IRIS DIAPHRAM (CODE ECLPRIRIS) .................................................................... 28

SOFT EDGE FILTER (CODE ECLPRSEF1) ....................................................................... 29

SOFT FOCUS DIFFUSION (CODE ECLPRSMOOTHF1) ................................................. 30

THE POLE OPERATED YOKE (CODE ECLPRPOYO) ...................................................... 31

14 - MAINTENANCE 32

MAINTENANCE AND CLEANING THE PRODUCT........................................................ 32

REPLACING THE FUSE................................................................................................... 32

VISUAL CHECK OF PRODUCT HOUSING ..................................................................... 32

TROUBLESHOOTING..................................................................................................... 33

PROLIGHTS - EclProfile CT+

SAFETY INFORMATION

WARNING!

• Please read carefully the instruction reported in this section before installing, power-

ing, operating or servicing the product and observe the indications also for its future

handling.

This unit is not for household use, only professional applications.

Connection to mains supply

• The Connection to the mains supply must be carried out by a qualied electrical

installer.

• Use only AC supplies 100-240V 50-60 Hz, the xture must be electrically connected

to ground (earth).

• Select the cable cross section in according with the maximum current draw of the

product and the possible number of products connected at the same power line.

• The AC mains power distribution circuit must be equipped with magnetic+residual

current circuit breaker protection.

• Do not connect it to a dimmer system; doing so may damage the product.

Protection and Warning against electrical shock

• Do not remove any cover from the product, always disconnect the product from AC

power before servicing.

• Ensure that the xture is electrically connected to ground (earth). And use only a

source of AC power that complies with local building and electrical codes and has

both overload and ground-fault (earth-fault) protection.

• Before using the xture, check that all power distribution equipment and cables are

in perfect condition and rated for the current requirements of all connected devices.

• Isolate the xture from power immediately if the power plug or any seal, cover, ca-

ble, or other components are damaged, defective, deformed or showing signs of

overheating.

• Do not reapply power until repairs have been completed.

• Refer any service operation not described in this manual to PROLIGHTS Service team

or an authorized PROLIGHTS service center.

Installation

• Make sure that all visible parts of the product are in good visible condition before its

use or installation.

• Make sure the point of anchorage is stable before positioning the projector.

• When suspending the xture above ground level, secure it against failure of primary

attachments by attaching a safety cable that is approved as a safety attachment for

the weight of the xture to the attachment point on the main frame of the product. ln

case the safety cable, enter in action, it needs to be replaced with a new one.

• Install the product only in well ventilated places.

• For non temporary installations, ensure that the xture is securely fastened to a load-

bearing surface with suitable corrosionresistant hardware.

• For a temporary installation with clamps, ensure that the quarter-turn fastener and/or

screws are turned fully, and secured with a suitable safety cable.

0,5 m Minimum distance of illuminated objects

• The projector needs to be positioned so that the objects hit by the beam of light are

at least 0.5 meters (1.64 ft) from the lens of the projector.

PROLIGHTS - EclProfile CT+ 03

45°

aMax operating ambient temperature (Ta)

• Do not operate the xture if the ambient temperature (Ta) exceeds 45 °C (113 °F).

-20°

Minimum operating ambient temperature (Ta)

• Do not operate the xture if the ambient temperature (Ta) is below -20 °C (-4 °F).

Protection from burns and re

• The exterior of the xture becomes hot during use. Avoid contact by persons and

materials.

• Ensure that there is free and unobstructed airow around the xture.

• Keep ammable materials well away from the xture

• Do not expose the front glass to sunlight or any other strong light source from any an-

gle. Lenses can focus the sun’s rays inside the xture, creating a potential re hazard.

• Do not attempt to bypass thermostatic switches or fuses.

Indoor use

• This product is designed for indoor and dry environments.

• Do not use in wet location and do not expose the xture to rain or moisture.

• Never use the xture in places subject to vibrations or bumps.

• Make certain that no inammable liquids, water or metal objects enter the xture.

• Excessive dust, smoke uid, and particle build up degrades performance, causes

overheating and will damage the xture.

• Damages caused by inadequate cleaning or maintenance are not covered by the

product warranty.

50°

Temperature of the external surface

• The surface of the xture can reach up to 50 °C (122 °F) during operation. Avoid

contact with people and materials.

Maintenance

• Warning! Disconnect the xture from AC mains power and allow to cool for at least

10 minutes before handling.

• Only technicians who are authorized by PROLIGHTS or Authorised service partners

are permitted to open the xture.

• Users may carry out external cleaning, following the warnings and instructions pro-

vided, but any service operation not described in this manual must be referred to a

qualied service technician.

• Important! Excessive dust, smoke uid, and particle build up degrades performance,

causes overheating and will damage the xture. Damages caused by inadequate

cleaning or maintenance is not covered by the product warranty.

Photobiological safety

• This device emits potentially dangerous optical radiation and is identied in the cat-

egory of Risk Group 2 according to EN 62471.

Minimun

distance

Risk

Group 2

Risk

Group 1

0.2 m

0.7 ft

3.30 m

10.83 ft

PROLIGHTS - EclProfile CT+

Do not stare at the operating light source

• Do not look directly at the LED source during operation. It can be harmful to the eyes

and skin.

• During Installation, operation and maintenance, be prepared for the xture to light

and move suddenly when connected to power.

• The device should be positioned so that prolonged staring into the luminaire at a

distance closer than 3.30 m is not expected.

Disposal

• This product is supplied in compliance with European Directive 2012/19/EU – Waste

Electrical and Electronic Equipment

• (WEEE). To preserve the environment please dispose/ recycle this product at the end

of its life according to the local regulation.

The product contains a lithium ion battery

• Don't throw the unit into the garbage at the end of its lifetime.

• Make sure to dispose according to your local ordinances and/or regulations, to avoid

polluting the environment!

• The packaging is recyclable and can be disposed.

The products to which this manual refers comply with:

• 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD).

• 2014/30/EU - Electromagnetic Compatibility (EMC).

• 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS).

PROLIGHTS - EclProfile CT+ 05

1 - PACKAGING

PACKAGE CONTENT

• ECLCTPLUS:

• Power cable 1.5 m, Schuko - PowerCon True1;

• User manual.

OPTIONAL ACCESSORIES

• ECLPRGH: Gobo holder for ECLFS and ECLCTPLUS;

• ECLPRSMOOTHF1: ECL Proles Soft Focus Diffusion kit to be installed inside the xtures;

• ECLPRIRIS: Steel iris diaphram for ECLFS and ECLCTPLUS proler;

• ECLPRL05BK: Optic for ECLFS and ECLCTPLUS proler, 5°, black;

• ECLPRL10BK: Optic for ECLFS and ECLCTPLUS proler, 10°, black;

• ECLPRL14BK: Optic for ECLFS and ECLCTPLUS proler, 14°, black;

• ECLPRL19BK: Optic for ECLFS and ECLCTPLUS proler, 19°, black;

• ECLPRL26BK: Optic for ECLFS and ECLCTPLUS proler, 26°, black;

• ECLPRL36BK: Optic for ECLFS and ECLCTPLUS proler, 36°, black;

• ECLPRL50BK: Optic for ECLFS and ECLCTPLUS proler, 50°, black;

• ECLPRL70BK: Optic for ECLFS and ECLCTPLUS proler, 70°, black;

• ECLPRLZ1530BK: Zoom optic for ECLFS, 15°-30°, black;

• ECLPRLZ2550BK: Zoom optic for ECLFS, 25°-50°, black;

• ECLPRSEF1: Soft edge lter and holder kit for ECLFS and ECLCTPLUS proler;

• ECLPRTPG: Gel lter frame for ECLFS and ECLCTPLUS proler;

• FCLECLPR: Flight case for 8 pcs of ECLFS and ECLCTPLUS proler;;

• ECLPRPOYO: Pole operated aluminium yoke bracket for ECLCTPLUS and ECLFS;

• UPBOX2P5: Firmware uploader kit, USB IN, 5-pin XLR DMX OUT;

• RSR: Steel security cable for hanging bodies, inox steel shackle;

• C6002: Slim aluminium clamp, 200 kg loading, 48-51 mm tubes, M10 bolt.

PROLIGHTS - EclProfile CT+

2 - TECHNICAL DRAWING

Weight: 7.9 kg - 17.41 lbs ECLCTPLUS without optic

Weight: 10.8 kg - 23.80 lbs ECLCTPLUS with ECLPRL05

Weight: 9.8 kg - 21.60 lbs ECLCTPLUS with ECLPRL10

Weight: 11.2 kg - 24.69 lbs ECLCTPLUS with ECLPRL14

Weight: (ECLPRL19) 10.2 kg - 22.49 lbs; (ECLPRL26)

10.3 - 22.70 lbs; (ECLPRL36) 10 - 22.05 lbs; (ECLPRL50)

9.6 - 21.16 lbs

ECLCTPLUS with ECLPRL19-26-36-50

Weight: 9.7 kg - 21.38 lbs ECLCTPLUS with ECLPRL70

PROLIGHTS - EclProfile CT+ 07

Fig.2

3 - INSTALLATION

MOUNTING

Check that the supporting structure can safely bear the weight of all installed xtures, clamps, cables,

auxiliary equipment, etc. and complies with locally applicable regulations.

When suspending the xture above ground level, secure it against failure of primary attachments by

attaching a safety wire that is approved as a safety attachment for the weight of the xture to an anchor

point on the product main frame.

Do not use removable parts or weak anchors for secondary attachment.

Warning! When clamping the xture to a truss or other structure at any angle, use clamps of half-cou-

pler type. Do not use any type of clamp that does not completely encircle the structure when fastened.

Ø13 [Ø0.5]

40 [1.6] 40 [1.6]

PROLIGHTS - EclProfile CT+

5 - START UP

CONNECT AND DISCONNECT POWER FROM THE PRODUCT

To apply and disconnect power to the product:

• Check that the product is installed and secured as indicated in the Safety Informations, and that

personal safety will not be put at risk when the xture lights up.

• Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz).

• The product is then ready for its operations and can be controlled through the available input sig-

nals on board.

• To disconnect power from the product, disconnect the Mains from the socket.

4 - CONNECTION TO THE MAINS SUPPLY

WARNING: For protection from electric shock, the xture must be earthed!

The product is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz

AC power source from 100-240 Volts.

If you need to install a power plug on the power cable to allow connection to power outlets, install a

grounding-type (earthed) plug, following the plug manufacturer’s instructions. If you have any doubts

about proper installation, consult a qualied electrician.

The max power consumption is 264W.

Core (EU) Core (US) Connection Plug terminal marking

Brown Black Live L

Blue White Neutral N

Yellow+green Green Earth

Table des matières

Autres manuels ProLights Matériel de DJ

ProLights

ProLights ARCLED1107UV Manuel utilisateur

ProLights

ProLights POLAR500 Manuel utilisateur

ProLights

ProLights MINIECLFRFC Manuel utilisateur

ProLights

ProLights V575WASH Manuel utilisateur

ProLights

ProLights LUMIPIX 12QIP Manuel utilisateur

ProLights

ProLights LUMIPAR18TRI Manuel utilisateur

ProLights

ProLights SUNPIX24TRI Manuel utilisateur

ProLights

ProLights EclSoft LinearIP Manuel utilisateur

ProLights

ProLights SUNBAR2500MAX Manuel utilisateur

ProLights

ProLights ECLFRJPTU-DY Manuel utilisateur

ProLights

ProLights LASERCOMBY Manuel utilisateur

ProLights

ProLights PIXIEWASH Manuel utilisateur

ProLights

ProLights STUDIOCOBFC Manuel utilisateur

ProLights

ProLights LUMIPAR6UQ Manuel utilisateur

ProLights

ProLights JETSPOT-3 Manuel utilisateur

ProLights

ProLights RUBYFCX Manuel utilisateur

ProLights

ProLights SUPERFLOWER DMX led Manuel utilisateur

ProLights

ProLights PHYRO1200SNOW Manuel utilisateur

ProLights

ProLights ARCLED7337VW Manuel utilisateur

ProLights

ProLights jetbeam-2 Manuel utilisateur

ProLights

ProLights MINIECLFRTU-DY Manuel utilisateur

ProLights

ProLights TRIBE LUMIPIX12UT Manuel utilisateur

ProLights

ProLights Tribe LUMIPIX12UQPRO Manuel utilisateur

ProLights

ProLights PF5 Series Manuel utilisateur

Manuels Matériel de DJ populaires d'autres marques

ALPHA LITE

ALPHA LITE ALPHA 1500 Manuel du propriétaire

Chauvet

Chauvet OVATION E-930VW Manuel utilisateur

Zumtobel

Zumtobel APHRODITE Home Manuel utilisateur

Snow Masters

Snow Masters Zig Oscillator Manuel utilisateur

EuroLite

EuroLite 50530554 Manuel utilisateur

Beamz

Beamz BUV243 Manuel utilisateur

thomann

thomann Stairville DJ Lase 40-G MK-III Manuel utilisateur

Eagletone

Eagletone 6 Eyes Flower Manuel utilisateur

EuroLite

EuroLite FLD-1508 Manuel utilisateur

Technical Pro

Technical Pro LG8xSEA Manuel utilisateur

JB Systems

JB Systems Lounge Laser DMX Manuel utilisateur

Lightmaxx

Lightmaxx Vega Halo 90 Manuel utilisateur

Elation

Elation FUZE WASH Z350 Manuel utilisateur

Maverick

Maverick MK3 WASH Manuel utilisateur

Infinity

Infinity TF-260C7 Fresnel Manuel utilisateur

Chauvet

Chauvet EVE E-50Z Manuel utilisateur

Eliminator Lighting

Eliminator Lighting E 138 Manuel utilisateur

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manuel utilisateur
