PROAIM LV-SCFH-01 Manuel utilisateur

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Sway Mitchell Dampening Head (LV-SCFH-01)

Assembly Manual

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

Proaim Sway Control

Fricon Levelling Head Hard Case

 Firstly, remove Castle Ring from Sway Mitchell

Dampening Head.

 Aach the Sway Mitchell Dampening Head

with the Camera Mount Plate and ghten the

Castle Ring from the top using the Castle Nut

Wrench.

 Loosen the Mitchell Ronin Mount and remove

the Castle nut.

 Now, aach the castle nut to the boom part

of the Sway Mitchell Dampening Head, as

shown in the image.

Smooth Camera Moves

Mitchell Dampening Head Setup

 Aer aaching the Mitchell Ronin Mount with

the Sway Mitchell Dampening Head, ghten

the aachment through the Castle Ring.

 Slide the Gimbal (Not Included) onto the

Mitchell Ronin Mount.

 Lock the assembly with the locking lever

provided on the Gimbal (Not Included).

NOTE: Addionally, a reliable adjustment knob

aids in precisely seng the exact amount of

2-axis damping you need for your shot.

YOUR PROAIM SWAY MITCHELL DAMPENING HEAD

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and

evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

utmost support and care unl you use our product.
