Premier Mounts PSD-TTS/B Manuel utilisateur

9532-002-001-11 PSD-TTS-B Installation Guide

INSTALLATION MANUAL

TABLETOP STAND

PSD-TTS-B

1321 S State College Blvd. Fullerton, CA 92831 Phone: 800 368-9700 Fax: 800 832-4888

9532-002-001-11 PSD-TTS-B Installation Guide

www.mounts.com

oSafety & precautions

oStand diagrams

oParts list (1)

oFlat panel list

oParts list (2)

oChecking the thread depth on your flat panel

oBuilding the stand

oSecuring the mounting brackets

oSecuring the flat panel to the stand

o(Optional) fixed installation

The entire installation instructions should be fully read and understood, including all of the safety symbols and safety precautions before

beginning installation. The installation instructions should be read, understood and followed to prevent personal injury or property damage.

Keep these installation instructions in an easily accessible location for future reference.

Do not install near heater, fireplace, direct sunlight or air conditioning or any other source of direct heat energy. Failure to do so may

result in damage to the flat panel display and could cause a risk of fire.

At least two qualified people should always perform the installation work. Injury and damage can result from dropping or mishandling

the flat panel display.

Contents

Safety & Precautions

WARNING: Safety precaution measures must be practiced at all times during the installation of this product. Use proper safety gear and tools for the

installations procedure to prevent personal injury or damage to the flat panel display mount.

The tabletop should be capable of supporting a max weight of 160 Lbs., the weight of the flat panel. More than 160 Lbs the tabletop must

be reinforced. Proper installation procedure by qualified personnel as outlined in the installations instructions must be adhered to. Failure to

do so could result in serious personal injury.

9532-002-001-11 PSD-TTS-B Installation Guide

32.000

(812)

30.590

(776.9)

30.00

(762)

27.746

(704.7)

1.500

(38.1)

Ø1.500

(38.1)

8.271

(210.0)

1.000

(25.4)

PART#:

PSD-TTS-B

COLOR:

Silver

A. Back cover

B. Vertical brackets

C. Mounting brackets

D. Griplates™ & mounting hardware

E. Aluminum block

F. Base

Stand diagrams

Dimensions are in Inches and (mm)

Base dimensions:

1.00”(25.4) Hx 30.00”(762) W x 13.0”(330) D

9532-002-001-11 PSD-TTS-B Installation Guide

Parts list (1)

All of these parts are used to install the mounting bracket. Make sure that none of these parts are missing before beginning installation. If there

are parts missing stop the installation and contact Premier Mounts.

Griplates™ (8)

Thread depth

indicator (1)

Parts list (2)

Aluminum block (1)

Mounting brackets (2)

Base (1)

Tubes (2)

Allen key (1)

M5 x 10 Phillips

screws (2)

M5 x 30 Phillips flat

head screws (5)

Socket head

Screws (6)

Tube caps (2)

Wood screws (2)

(Optional use)

Rubber vinyl (4)

(used on the PSD-TTS/C only)

Rubber feet (4)

(used on the PSD-TTS only)

M6 Phillips

screws (4)

Back cover (1)

9532-002-001-11 PSD-TTS-B Installation Guide

NOTE: This wall mount is shipped with all proper installation hardware and components. Make sure that none of these parts are missing before

beginning installation. If there are parts missing stop the installation and contact Premier Mounts.

9532-002-001-11 PSD-TTS-B Installation Guide

Checking the thread depth on your flat panel

Inverted flat panel

display

Thread insert

Thread depth

indicator

Figure 2

Figure 3

Figure 1

Marking the depth

1. Insert the thread depth

indicator (supplied) through

the thread inserts found on

the back of the flat panel to

make sure the inserts

measure the same full depth

and mark it.

(see figure 1)

2. Locate the correct diameter

screw for the thread insert.

Compare your marking to the

screws (supplied). If your

selected screw is longer than

the marking on the thread

depth indicator DO NOT USE

this screw.

The screw length must not

bypass the marking. Select

another screw size

(see figure 2 and 3). Until you

find one that comes closest to

your mark without going past.

Marking

Screw

Marking

9532-002-001-11 PSD-TTS-B Installation Guide

Building the stand

Step 1

Unpack the components from the box and set them on the floor. Invert and secure the rubber vinyl or rubber feet depending on model to

the bottom of the base. Secure the aluminum block to the base as shown in (figure 1) to the base by using the five (5) M5 x 30 (mm) Phillip

flat head screws (supplied).

CAUTION: Do not over tighten the screws. Find a suitable location for the stand.

Aluminum

block

Base

(5) M5 x 30 (mm)

Phillips flat head

screws

9532-002-001-11 PSD-TTS-B Installation Guide

Step 2

Insert the tubes into the secured aluminum block. See diagram to set the cable access openings before tightening the set screws.

See figure A. Once the poles are fully inserted into the block and set to their proper positions lock the tubes by tightening the two

(2) M8 socket head screws. Do not over tighten the set screws. Install the plastic caps to the top of the tubes. See figure 2.

Plastic caps

Allen wrench

(2) M8 x 10 socket

head screws

Base

Tubes

2 O’clock

10 O’clock

Tube location for cable

access

9532-002-001-11 PSD-TTS-B Installation Guide

Step 3

Invert the flat panel display and lay it on a soft and flat surface. Apply the vertical brackets and center the mounting brackets from left to

right on the display. Secure the mounting brackets with the hardware and griplates™ (supplied). NOTE: The griplates™ come with an

M4,M5,M6 and M8 access holes. Find out what your proper hardware for your flat panel will be and use accordingly.

Do not over tighten the hardware.

See figure 3.

(2) Mounting

brackets

Mounting hardware

(see charts) on

page 5,6

(8) Griplates™

(supplied)

NOTE: All Griplates™

tips must be facing up

prior to installation.

(4) M8x10 Socket

head screws

Allen key

Soft and flat

surface

9532-002-001-11 PSD-TTS-B Installation Guide

Securing the flat panel to the stand

Step 4

Raise the display (see warning on this page) and slide the mounting brackets over the tubes, set the height required and using the Allen

wrench secure the height by tightening the four (4) M8 socket head screws. Do not over tighten the screws. Make all proper connections

at this time. Install the back cover plate and secure it using two (2) M5 x 10 phillips screws (supplied). See figure 4.

Allen wrench

Back cover

(2) M5 x 10

phillips screws

WARNING: AT LEAST (2) QUALIFIED

PERSONNEL ARE STRONGLY

RECOMMENDED FOR INSTALLATION OF

THIS PRODUCT. FAILURE TO DO SO

COULD RESULT IN SERIOUS INJURY AND

POSSIBLE DAMAGE TO THE FLAT PANEL.

Cable routing access

points
