Package Contents

RT-2015E/Q 15” fanless touch terminal or

RT-2016E/Q 15.6” fanless touch terminal..x1

Power adapter……………………………..x1

Power cord………………………………...x1

User manual……………………………….x1

Screw for back cover……………………...x1

RT-2015E/2016E/2015Q/2016Q

Fanless Touch POS Terminal

User Manual

16950902040 Ver. D0

http://www.posiflex.com

SOME IMPORTANT NOTES

FCC NOTES

This system meets industry & government requirements and applicable

standards. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions

manual, may cause interference to radio communications. It has been tested

and found to comply with limits for a Class A digital device pursuant to

subpart B of Part 15 of FCC Rules, which are designed to provide reasonable

protection against interference when operated in a commercial environment.

Operation of this equipment in a residential area is likely to cause interference

in which case the user at his own expense will be required to take whatever

measures to correct the interference.

This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

CE CLASS A WARNING

This equipment is compliant with Class A of CISPR 32. In a residential

environment this equipment may cause radio interference.

AVERTISSEMENT CE CLASSE A

Cet équipement est conforme à la classe A de CISPR 32. Dans un

environnement résidentiel, cet équipement peut provoquer des interférences

radio.

WARRANTY LIMITS

Warranty will terminate automatically when the machine is opened by any

person other than the authorized technicians. The user should consult his/her

dealer for the problem happening. Warranty voids if the user does not follow

the instructions in application of this merchandise. The manufacturer is by no

means responsible for any damage or hazard caused by improper application.

LIMITES DE GARANTIE

La garantie prend fin automatiquement lorsque la machine est ouverte par une

personne autre que les techniciens autorisés. L'utilisateur doit consulter son

revendeur pour le problème qui se produit. La garantie s'annule si l'utilisateur

ne suit pas les instructions d'application de cette marchandise. Le fabricant

n'est en aucun cas responsable de tout dommage ou danger causé par une

mauvaise application.

警告使用者

這是甲類的資訊產品，在居住的環境中使用時，可能會造成射頻干擾，

在這種情況下，使用者會被要求採取某些適當的對策。

BATTERY CAUTION NOTES

Dispose of used batteries according to the instructions.

Replacement of a battery with an incorrect type that can defeat a

safeguard (for example, in the case of some lithium battery types)

Disposal of a battery into fire or a hot oven, or mechanically crushing

or cutting of a battery that can result in an explosion.

Leaving a battery in an extremely high temperature surrounding

environment that can result in an explosion or the leakage of flammable

liquid or gas.

A battery subjected to extremely low air pressure that may result in an

explosion or the leakage of flammable liquid or gas.

BATTERIE ATTENTION NOTES

Jetez les piles usagées conformément aux instructions.

Remplacement d'une batterie avec un type incorrect qui peut annuler

une sauvegarde (par exemple, dans le cas de certains types de batterie

au lithium)

Mise au rebut d'une batterie dans le feu ou dans un four chaud, ou

écrasement ou coupure mécanique d'une batterie pouvant entraîner une

explosion.

Laisser une batterie dans un environnement environnant à des

températures extrêmement élevées pouvant entraîner une explosion ou

la fuite de liquide ou de gaz inflammable.

Une batterie soumise à une pression atmosphérique extrêmement basse

pouvant provoquer une explosion ou une fuite de liquide ou de gaz

inflammable.

警告

本電池如果更換不正確會有爆炸的危險，請依製造商說明書處理用過之

電池。

Views of RT-2015E/2016E/2015Q/2016Q

Front View

15” RT-2015E/2015Q

15.6” RT-2016E/2016Q

Rear View

Bottom View

Release Lever for System Back Cover

Screw Hole

System Back Cover

Attachment Bay

Wall- Mount

Screw Hole

Thumbscrew for VESA Mount Bracket

P-Cap Touch Panel

LED indicator

Camera (Optional)

Right-Side View

Left-Side View

View of I/O Interface of RT-2015E/2016E/2015Q/2016Q

Bottom Side

24V PoweredUSB Port

DB9 COM Port

CR Port

LAN Port

DC IN Power Connector

Mini DisplayPort

RJ50 COM Ports

USB 2.0 Ports

Brightness Adjustment Button ＋

Power Button

Brightness Adjustment Button －

Rubber Shield for USB2.0 Port

USB 3.0 Port

Left Side

Connecting Power Adapter and Cables

The following provides instructions required to connect your cables.

1. To remove the back cover, hold down the

release levers at the bottom of the system

back cover and then pulling the cover

outwards.

2. Connect the connector of the power adapter to

the DC-IN power jack. If necessary, properly

insert other cables into the correct ports.

3. Neatly arrange the cables along the cable slots.

4. Place back the sytem back cover. Make sure it

is well locked into place with a click sound.

5. Make sure the cable could be pulled out of the cable exit from the bottom

of the base.

USB 2.0 Port

6. Locate the dedicated back cover screw from the

packing box. Then, pleaseinsert the screw into

the screw hole indicated in the figure, and secure

it.

Cable connectors like the connector of LAN cable have to be gently inserted

until a click sound is given. It is recommended that the I/O ports, such as COM

(DB9) port and VGA port, should be fastened with connector thumb screws

after the I/O cable connectors are completely connected. And please make sure

that each connector has to be connected to the right peripheral device in the

right way.

CAUTION: On doing insertion or extraction of a cable connector, please

always hold the connector head itself instead of pulling the cable wire.

Doing this could damage the cables, which is considered as an artificial

damage and is not covered by the warranty. The means of power cord

should be connected to a socket-outlet with earthing connection.

ATTENTION: Lors de l'insertion ou de l'extraction d'un connecteur de

câble, veuillez toujours tenir la tête du connecteur elle-même au lieu de

tirer le fil du câble. Cela pourrait endommager les câbles, ce qui est

considéré comme un dommage artificiel et n'est pas couvert par la

garantie. Le cordon d'alimentation doit être connecté à une prise de

courant avec mise à la terre.

Adjustment for VESA Mount Bracket

1. There are two thumbscrews on the VESA mount bracket. Loosen the

two thumbscrews.

2. After loosening the thumbscrews, you can carefully move the monitor

downward around 45°to do the service.

3. To close the VESA mount bracket, please gently move the monitor

back and then fasten the two thumbscrews.

Installing Optional Upgrade Kits and Peripherals

RT-2015E/2016E/2015Q/2016Q is an expandable model which allows you to

upgrade its own capacity by additionally installing multiple peripheral devices,

such as magnetic stripe reader (MSR), fingerprint or iButton sensors, and 2nd

POS monitor, according to your preference. The following will give you brief

instructions on how to expand on your current POS system with these optional

upgrade kits. Before proceeding with the installation of peripherals, please

make sure the POS system is completely shut down to prevent damage.

Status LED Indicator

LED status indicator, which is located at the bottom edge of the LCD panel, is

mainly responsible for notifying users of the current system status by emitting

various LED signals. In the chart provided below, it describes all the possible

LED status as a quick reference.

15” RT-2015E/2015Q

LED Status

Description

Off

System power OFF

Green

System standby

Blue

System power ON

15.6” RT-2016E/2016Q

LED Status

Description

Off

System power OFF

Orange

System standby

Blue

System power ON

Powering ON/OFF RT-2015E/2016E/2015Q/2016Q

Power ON RT-2015E/2016E/2015Q/2016Q

Press down the power button to power on the POS.

Power OFF RT-2015E/2016E/2015Q/2016Q

In most cases, press the power button of the POS to power

the system off. If the terminal fails to turn off the machine

for unknown reasons, please be advised to hold the power

button more than 10 seconds to force a shutdown of the

system.

Power

Button

Installing an Operating System

You are highly advised not to install an operating system on

RT-2015E/2016E/2015Q/2016Q without professional instructions. Improper

installation could lead to system malfunction or failure. Please contact with

your dealers about the issues of operating system installation.

Performing System Recovery

For RT-2015E/2016E/2015Q/2016Q model with preloaded operating systems,

Recovery DVD which includes useful utilities will be provided in the package

to assist you in efficiently restoring or repairing your damaged system.

However, you are not encouraged to recover your system without the help of

system integrators. Please be advised to contact your service center for further

assistance with system recovery.

Operation Environment

To prevent RT-2015E/2016E/2015Q/2016Q from overheating, it is suggested

to position your terminal in a well-ventilated working environment. In doing

so, please be advised to keep the POS terminal at least 25mm away from other

devices to ensure the machine is properly cooled down and functioning

normally.

Specifications

RT-2015E/Q

RT-2016E/Q

CPU

Intel Bay Trail-D

Intel Celeron - J1900 (2.0 GHz, QC, 10W TDP)

System Memory

1 x DDR3L SO-DIMM

Storage Port

2 x S-ATA port

OS Support

Windows 7 / POSReady 7 / Windows Embedded

8.1 Industry / Windows 10 IoT

Power Source

12V/60W external power adapter (can be upgraded

to 150W while adopting poweredUSB module)

LCD Panel

15" with LED

backlight

15.6" LCD with LED

backlight

LCD Resolution

1024 x 768

1920 x 1080 FHD

Touch Sensor

P-CAP touch

Serial Port

3 ports, 1 x DB9 + 2 x RJ-50 (on I/O plate)

USB Port

(External Port)

1.) 3, 1 x USB 3.0 (on I/O plate) + 2 x USB2.0 (1

on I/O plate + 1 on side edge)

2.) 1 x 24V PoweredUSB port

PoweredUSB

Port

1 x 24V PoweredUSB port

Autres manuels pour RT-2015E

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels POSIFLEX Terminal tactile

POSIFLEX

POSIFLEX PD - 2600 Manuel utilisateur

POSIFLEX

POSIFLEX HT-4312 Series Manuel utilisateur

POSIFLEX

POSIFLEX Jiva TP-8000 Manuel utilisateur

POSIFLEX

POSIFLEX KS - 6715 Manuel utilisateur

POSIFLEX

POSIFLEX HT-3600 Series Manuel utilisateur

POSIFLEX

POSIFLEX PS-3416 Manuel utilisateur

POSIFLEX

POSIFLEX HS-3510W-E Manuel utilisateur

POSIFLEX

POSIFLEX RT-1016A Manuel utilisateur

POSIFLEX

POSIFLEX XT-2614E Manuel utilisateur

POSIFLEX

POSIFLEX JIVA HS-2410W Manuel utilisateur

POSIFLEX

POSIFLEX Jiva TP-5815 Pro series Manuel utilisateur

POSIFLEX

POSIFLEX KS - 6815 Manuel utilisateur

POSIFLEX

POSIFLEX HS-35 W-G2 Series Manuel utilisateur

POSIFLEX

POSIFLEX KS - 6910 series Manuel utilisateur

POSIFLEX

POSIFLEX HT-4600 Series Manuel utilisateur

POSIFLEX

POSIFLEX XP-3000 Series Manuel utilisateur

POSIFLEX

POSIFLEX TX-2000 Manuel utilisateur

POSIFLEX

POSIFLEX XT-6015C Manuel utilisateur

POSIFLEX

POSIFLEX KS7300 Series Manuel utilisateur

POSIFLEX

POSIFLEX KS - 6810 Manuel utilisateur

POSIFLEX

POSIFLEX MT-4308W Series Manuel utilisateur

POSIFLEX

POSIFLEX PS-3216A Manuel utilisateur

POSIFLEX

POSIFLEX TX-3700 Series Manuel utilisateur

POSIFLEX

POSIFLEX XP-2000 Series Manuel utilisateur

Manuels Terminal tactile populaires d'autres marques

Wincor Nixdorf

Wincor Nixdorf iPOS plus Advanced Manuel utilisateur

Ingenico

Ingenico AXIUM EX4000 Manuel utilisateur

Heisei Electronics

Heisei Electronics Q-POS 815 Manuel utilisateur

Amano

Amano MTX-15 Manuel utilisateur

FLOWBIRD

FLOWBIRD CWT Compact Touch Manuel utilisateur

Demco

Demco SP7 Manuel utilisateur

Lathem

Lathem PC600 Series Manuel utilisateur

Partner

Partner MF-2352 Manuel utilisateur

NCR

NCR RealPOS 7460-2 Manuel

Simrad

Simrad MS50 Instructions de montage

Unitech

Unitech MR350 MKII Guide de démarrage rapide

Jungheinrich

Jungheinrich WMT 210 Manuel utilisateur

Motorola

Motorola MTP850 Manuel utilisateur

YASKAWA

YASKAWA 62H-MDC0 Manuel utilisateur

MVG industries

MVG industries NeptuLink Manuel utilisateur

Price Industries Limited

Price Industries Limited FDC Manuel d'instructions

Honeywell

Honeywell TemaKey Manuel utilisateur

EBN

EBN BPC65-B-A16G Manuel utilisateur
