Plantronics DiscoVErY™640E

BlUEtootH®HEaDsEt

USER GUIDE

WElcomE

This User Guide provides instructions for

setup and use of the Plantronics Discovery™

640E Bluetooth®Headset.

Before getting started, please review the

safety booklet included in your package.

For additional help, service or support

information, refer to your product warranty

card or visit www.plantronics.com.

taBlE of contEnts

Welcome ...........................................................2

Package contents and features........................3

Connecting the components ............................4

Charging ...........................................................5

Powering ..........................................................5

Bluetooth pairing...............................................6

Multipoint (multiple devices)............................6

Fitting your headset..........................................7

Using your headset...........................................8

Status indicators...............................................9

Troubleshooting..............................................10

Spare parts and accessories..........................11

Technical assistance.......................................11

10.

11.

12.

PackagE contEnts

anD fEatUrEs

1. Headset

2. Headset status indicator

3. Call control button (on/off)

4. Volume/mute button

5. Headset carrying pocket

6. Battery charger

7. Battery holder

8. Battery (AAA)**

9. Optional ear stabilizer

10. Soft gel ear tip

a. small

b. medium

c. large

11. Microphone

12. AC power adapter

**Only replace with a non-rechargeable

AAA battery.

connEcting tHE

comPonEnts

The battery charger and AAA charging adapter

are connected to the headset carrying pocket by

pushing the two components together. Ensure

that the indent on the attachment lines up with

the shirt clip on the headset carrying pocket.

To separate the components, take hold both the

headset carrying pocket and the attachment

with the shirt clip facing you. Bend the outsides

back and the components will snap apart.

CAUTION Do not twist the components apart.

“SNAP”

cHarging YoUr HEaDsEt

Prior to ﬁrst use, the Plantronics Discovery

640E headset must be charged for a minimum

of 1 hour; 3 hours for full charge. An AC power

adapter is included. You may also charge

the headset using the AAA battery charger.

The headset status Indicator glows red while

charging and turns off when fully charged.

USING THE AC POWER ADAPTER

1. Plug the AC power adapter into the

base of the headset carrying pocket and

connect it to your power source.

2. Insert the headset into the headset

carrying pocket.

USING THE AAA BATTERY

One battery will operate the headset for

up to 15 hours of talk time.

1. Twist the bottom of the battery charger

anticlockwise and release the battery

holder.

2. Insert the battery into the AAA battery

holder.

3. Slide the battery holder back into the

battery charger and turn clockwise.

4. Snap battery charger onto headset

carrying pocket.

5. Insert the headset into the headset

carrying pocket.

PoWEring on anD off

1. Power on the headset by pressing and

holding the call control button until the

headset status indicator glows blue. If you

are wearing the headset, you will hear a

beep when the power turns on. The headset

status indicator will ﬂash blue every 6

seconds when the headset power is on.

NOTE When the headset is turned on, the

headset status indicator will indicate the

charge level of the headset.

Greater than 2/3 battery charge =

3 red ﬂashes.

1/3 to 2/3 battery charge =

2 red ﬂashes.

Less than 1/3 battery charge =

1 red ﬂash.

2. Power off the headset by pressing the call

control button for 6-8 seconds until the

headset status indicator glows red or until you

hear the beep. The headset status indicator

remains unlit when the power is off.

”BEEP”

BlUEtootH Pairing

Before using your headset for the ﬁrst time,

you must pair it with another Bluetooth device,

such as a mobile phone. Ensure the headset is

fully charged.

Look in your Bluetooth device manual for the

section that describes how to set up a Bluetooth

wireless connection.

1. Move through the menu selections on your

phone until the phone display shows “Look

for Devices,” or equivalent, as a selection.

2. With your headset turned off, hold down the

call control button until the headset status

indicator brieﬂy glows blue, then ﬂashes red

and blue. The headset is now in discovery

mode and will stay that way for 30 seconds.

3. On your phone, highlight and select “Look

for Devices,” or equivalent, to activate the

scan for the headset.

4. When the phone display shows the scan

results, select “6xx Plantronics”. The phone

will continue to search for the headset.

5. When the phone display asks for a passkey,

type “0000” and press Enter.

Your headset is now linked to your phone.

Using mUltiPoint (morE

tHan onE BlUEtootH

DEVicE)

Plantronics Discovery 640E supports multipoint

technology, which permits simultaneous

connections with two different Bluetooth

audio devices.

TO PAIR ANOTHER BLUETOOTH DEVICE Repeat

the previous pairing steps with the new device.

INITIATE A CALL The headset will assume you

wish to initiate a call on the device recently

used.

TO USE THE SECOND DEVICE Initiate the call

using the controls on the second device. The

second device forms the link with the headset.

ANSWER A CALL An incoming call on either

device will ring through the headset. In most

cases, the ring tone from the device will

transfer through to the headset, allowing the

user to determine which device is ringing. In

some cases, however, the headset applies a

ring tone to the incoming call. In either case,

the user may be able to determine which device

is ringing through the distinct ring tone.

To answer the call, press the call control

button.

TO ANSWER A CALL ON ONE DEVICE WHILE

TALKING ON THE OTHER There is no function

for placing one call on hold while answering

another. Therefore, to answer the second call,

the ﬁrst call must be terminated.

Terminate the ﬁrst call by pressing the call

control button once.

Wait for the beep and then answer the second

call by pressing the call control button again. If

you choose not to answer the second call, and

you have voice mail on the second device, the

call will go to voice mail.

640E

*Neutral Position

fitting YoUr HEaDsEt

The headset comes with three soft gel ear tips

and an optional ear stabilizer. The medium

sized ear tip is installed for wearing on the

right ear.

1. Twist the ear tip to the right for left

ear wearing.

2. Place the headset into your ear with the

elongated side of the ear tip pointing up and

forward.

If the fit is not comfortable, either too tight or

too loose, remove the ear tip from the headset

by turning the ear tip to the neutral* position

and pulling the ear tip away from the headset.

1. Next, select the ear tip size that ﬁts most

comfortably in your ear.

2. Hold the ear tip with the elongated edge

pointing down and push the ear tip post into

the opening on the headset.

3. Twist the ear tip to the left for right ear

wearing or to the right for left ear wearing.

4. Place the headset into your ear with the

elongated side pointing up and forward.

USING THE OPTIONAL EAR STABILIZER

The ear tip stabilizer may be attached to the

Headset to improve stability.

1. Remove the ear tip from the headset

by turning the ear tip to the centre or

neutral position* and pulling the ear tip

away from the headset.

2. Attach the stabilizer in-between the ear tip

and the headset.

3. Replace the ear tip.

ansWEring anD

EnDing calls

1. To answer a call, brieﬂy press the call

control button or the volume/mute button.

2. To end a call, brieﬂy press the call

control button.

If the headset is in the headset carrying pocket

when a call is received, the carrying pocket will

vibrate. Removing the headset from the pocket

will answer the call.

Returning the headset to the headset carrying

pocket will end the call.

aDjUsting tHE VolUmE

To increase the listening volume of the headset,

press the upper end (+) of the volume/mute button.

To decrease the listening volume, press

the lower end (-).

WARNING: Do not use headphones/headsets

at high volumes for an extended period of time.

Doing so can cause hearing loss. Always listen

at moderate levels.

last nUmBEr rEDial

To activate last number redial, double click the

call control button. You will hear a high tone for

each key press.

NOTE: Last number redial must be supported

by your device or mobile phone provider.

Using tHE mUtE

To turn the mute on whilst on a call, press

both sides of the volume/mute button

simultaneously until you hear a beep.

To turn the mute off, press both buttons again.

moVing oUt of rangE

As the headset is moved away from the mobile

phone or Bluetooth device, the following could

occur:

• Audio quality will degrade.

• A beep will be heard in the headset.

• Only the power off function will operate.

After 30 seconds, the headset will make one

attempt to reconnect to the phone or device.

Using VoicE actiVatED Dialling

To use voice activated dialling, the voice activated dialing feature must be enabled on your device. See your

Bluetooth device manual for instructions. With the headset on, one long press on the call control button activates

the voice activated dialling feature on the headset.

mUltiPlE UsEs of a long PrEss on tHE call

control BUtton

HEADSET FUNCTION STATE OF THE

Bluetooth DEVICE RESULT

Turn on power Power off Turns the power on

Re-link to

Bluetooth device

Power on

Link dropped Re-links the device

Reject call

Power on

Linked

Incoming call

Disconnects the call or sends the call

to voice mail depending on your device

Transfer a call between

Headset and Bluetooth device

Power on

Linked

On a call

Transfers the call from

one device to another

Voice activated dialing

Power on

Linked

No call

Activates the voice recognition feature

HEADSET STATUS HEADSET STATUS INDICATOR

Powering on Blue light appears and ﬂashes every 6 seconds

Power on Blue light ﬂashes every 6 seconds

Powering off Red light appears and goes off

Power off Indicator is not lit

Charging battery Red light is on

Battery fully charged Red light is off

Discovery state Indicator ﬂashes blue and red for 30 seconds

Missed call Infrequent ﬂashing blue/red

Press any button to cancel

Ringing Rapid ﬂashing blue/red

On Line Indicator (OLI) Blue ﬂash every 10 seconds

Low battery Flashes red

statUs inDicators

troUBlEsHooting

POSSIBLE CAUSE SOLUTION

Headset was not in discovery mode when

mobile phone menu selections were made. See page 6 “Bluetooth pairing”.

Incorrect menu selections were

made on your mobile phone. See page 6 “Bluetooth pairing”.

mY HEaDsEt DoEs not Work WitH mY PHonE.

POSSIBLE CAUSE SOLUTION

Mute is turned on. Press both sides of the

volume/mute button simultaneously.

callErs cannot HEar mE.

POSSIBLE CAUSE SOLUTION

The headset is not turned on. Press the call control button for 2 seconds until you hear

a beep or see the headset status indicator glow blue.

Your headset is out of range. Move the headset closer

to the phone or Bluetooth device.

Your headset battery is ﬂat. Charge your battery using the AC

power adapter supplied, or a AAA battery charger.

The listening volume is too low. Press the top part of the volume/mute button

to increase the sound heard in the headset.

i cannot HEar callEr/Dialling tonE.

i DiD not EntEr mY Pass kEY.

POSSIBLE CAUSE SOLUTION

Your phone did not locate the headset. Repeat the pairing process on page 6.

Incorrect menu selections were

made on your mobile phone. Repeat the pairing process on page 6.

Autres manuels pour Discovery 640E

Table des matières

Autres manuels Plantronics casque

Plantronics

Plantronics PULSAR 260 Manuel utilisateur

Plantronics

Plantronics CS530 Series Manuel d'instructions

Plantronics

Plantronics VOYAGER 520 Manuel utilisateur

Plantronics

Plantronics DUOSET WITH FIREFLY Manuel utilisateur

Plantronics

Plantronics Savi W740 Guide d'installation

Plantronics

Plantronics VOYAGER PRO Manuel utilisateur

Plantronics

Plantronics WIRELESS OFFICE HEADSET SYSTEM CS50/55 Manuel utilisateur

Plantronics

Plantronics Stereo SupraPlus USB Manuel utilisateur

Plantronics

Plantronics Savi W720-M Manuel utilisateur

Plantronics

Plantronics M M220 Manuel utilisateur

Plantronics

Plantronics GameCom P90 Fiche technique

Plantronics

Plantronics GameCom 780 Manuel utilisateur

Plantronics

Plantronics Blackwire 710 Manuel utilisateur

Plantronics

Plantronics CS50 Dimensions

Plantronics

Plantronics CS540-XD Manuel utilisateur

Plantronics

Plantronics Savi W440-M Manuel utilisateur

Plantronics

Plantronics Voyager Edge Series Manuel utilisateur

Plantronics

Plantronics BLACKWIRE C610-620 MOC - QUICK START GUIDES Manuel utilisateur

Plantronics

Plantronics Savi W730 Manuel utilisateur

Plantronics

Plantronics Marque M155 Manuel utilisateur

Plantronics

Plantronics Poly Voyager 5200 Series Manuel utilisateur

Plantronics

Plantronics GameCom 377 Manuel utilisateur

Plantronics

Plantronics MS50 Starset Manuel utilisateur

Plantronics

Plantronics SupraPlus CS361N Manuel utilisateur

Manuels casque populaires d'autres marques

Sena

Sena SMH10 Manuel utilisateur

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuel utilisateur

Sennheiser

Sennheiser EPOS ADAPT 230 Manuel utilisateur

Doro

Doro Flexus HS2005 Manuel utilisateur

GE 98971 Manuel utilisateur

Hama

Hama 00184070 Manuel utilisateur

Blue Tiger

Blue Tiger Advantage PLUS Manuel utilisateur

Jawbone

Jawbone Icon Manuel utilisateur

Jabra

Jabra FR 20 Manuel utilisateur

Roxcore

Roxcore Flow A+ Manuel utilisateur

Turtle Beach

Turtle Beach XP 510 Manuel utilisateur

Philips

Philips SHB6101 Manuel utilisateur

Jabra

Jabra PRO 9460 Duo Manuel utilisateur

HyperX

HyperX HyperX Cloud Flight Manuel utilisateur

Bose

Bose MIE2 Mobile Manuel utilisateur

Jabra

Jabra Steel Manuel utilisateur

HyperX

HyperX cloud ii Manuel utilisateur

Southwing

Southwing SA505 Manuel utilisateur
