PLANTRONICS PULSAR™260

STEREO BLUETOOTH HEADSET

USER GUIDE

| |

TABLE OF CONTENTS

Package contents and features 3

Charging 4

Powering 4

Indicator lights 4

Pairing 5

Making/answering/ending calls 5

Wearing options 6

Powered speaker & stereo uses 6

Pod controls 7

Headset controls 8

Troubleshooting 9

System reset 9

Product speciﬁcations 10

Technical assistance 10

Regulatory Information 11

Warnings 12

Visit www.plantronics.com/productregistration to register your product online so that

we can provide you with the best possible service and technical support.

Mute/play/pause

Volume up

Volume down

Track forward

Track back

PACKAGE CONTENTS & FEATURES

Pulsar 260 headset

Sound-isolating

earbuds

2.5mm plug

Microphone with call

control button

Audio-out cable

Stereo Bluetooth pod

Detachable clip

Indicator light

Power on/off/pairing

2.5mm port

Mini-USB port

This user guide provides instructions on the setup and usage of the Plantronics Pulsar™

260 Bluetooth®Headset. Before getting started, please review the safety booklet included

in your package.

For additional help, service or support information, refer to product warranty card or

Troubleshooting on page 9, or visit www.plantronics.com.

WELCOME

LanyardAC charger

Pod controls:

| |

CHARGING

You must charge for 3 hours before ﬁrst use.

To charge, connect AC charger to pod mini-

USB socket.

Pod indicator light ﬂashes red when charging

and changes to solid blue when fully charged.

POWERING ON/OFF

POD INDICATOR LIGHTS

NOTE: Flashes red

when headset is

initially powered on.

Pairing/connect Flashes red and blue

Fully charged Solid blue

Charging

Action

Flashes red

Light

Bluetooth pod connected

to headset

Flashes blue

Power/battery status

3 red flashes. =

2 red flashes. =

1 red flash. =

PAIRING

To pair pod with phone:

Begin with pod powered on.

1. Press and hold both the mute/play/

pause button and the power on/off/

pairing button simultaneously. When

the indicator light ﬂashes red and

blue, release buttons.

2. While pod is ﬂashing red and blue,

use the phone menu to search for

Bluetooth devices and select “260

Plantronics”.

3. When prompted for password, enter

0000.

Pod ﬂashes blue when paired successfully.

For set up and pairing instructions with

Bluetooth devices other than mobile

phones, please consult your Bluetooth

device user guide.

260Plantronics

M3000 Plantronics

M2500 Plantronics

0000

Enter

password

MAKING/ANSWERING/ENDING CALLS

To make a call:

Dial on phone; call transfers

automatically to headset.

To answer or end a call:

Brieﬂy press call control

button on headset.

To adjust volume:

Short press +or –buttons on

pod for incremental change, hold

for continuous change.

Press and hold power on/off switch for >2 seconds.

| |

WEARING OPTIONS

Pulsar 260 can be worn in two ways:

• Clipped to your belt or clothing

• Around your neck using the lanyard

POWERED SPEAKER & STEREO USES

POD CONTROLS

KEY FEATURE Action Tone

Power on/off Short press No tone

Track forward and

back*

Short press to skip to next

track or to go back to

previous track

High tone

Mute call/audio Short press to mute/unmute Repeating low tone

every 60 seconds

Play and pause* Short press to pause/

resume audio

High tone

Adjusting volume Short press Mid tone for each

adjustment, double

low tone at limit

*Only works if Bluetooth device supports Bluetooth Audio/Video Remote

Control Profile (AVRCP).

Power on/off

For public listening you can connect the

stereo Bluetooth pod directly to powered

speakers or your home stereo with the

included audio-out cable (provided your

speakers/home stereo is ﬁtted with a

Line-in or Auxiliary 3.5mm audio socket).

Please consult your equipment guide.

1. Ensure the stereo Bluetooth pod

and your speakers/home stereo are

powered off.

2. Connect the audio-out cable 2.5mm

plug to the stereo Bluetooth pod

and the 3.5mm plug to the powered

speakers/home stereo Line-in or

Auxiliary 3.5mm audio socket as

shown below.

3. Power on both the stereo Bluetooth

pod and your speakers/home

stereo.

| |

TROUBLESHOOTING

Problem Solution

My headset does not work

with my phone. • See page 5 “Pairing”.

• Perform a reset on Pulsar 260 as described below.

Callers cannot hear me. • Headset is muted. Press the mute button on the pod

to unmute the microphone.

• Ensure pod is powered on and headset is paired

with audio device. See page 5 “Pairing”.

Callers say my voice is too

quiet. Ensure that microphone is pointing towards your

mouth.

I cannot hear caller/dial

tone or audio sound. • Pod is turned off. Check the indicator light for

status.

• Headset is out of range. Walk to within 10 metres of

the phone and check the Bluetooth link on your

phone’s display.

• Battery is dead. Charge your battery using the AC

power adapter supplied.

• Listening volume is too low. Press the volume/mute

button to increase the sound heard in the headset.

I cannot hear music from

my powered speakers/Hi-Fi

when using the audio-out

cable.

• Pod must be turned on and connected to the

powered speakers/Hi-Fi with the audio-out cable.

• Check music player on Bluetooth phone is switched

on and Pulsar 260 is the active Bluetooth device.

SYSTEM RESET

KEY FEATURE Action Tone

Making/answering/ending

calls

Short key press High tone

Switching an active call

from headset to phone or

phone to headset

Long key press High tone

followed by low

HEADSET CONTROLS

KEY FEATURE Action Tone

Activate last

number redial

Double short key press High tone for each

key press

Activate voice dial Long key press High tone followed by

low

Call reject Long key press High tone followed by

low

Hands-free features

Features must be supported by Bluetooth device or service provider.

A reset button is located

(recessed) behind the clothing

clip.

To reset:

1. Remove clip as shown at

right.

2. Press and release button

using a pen.

| |

TECHNICAL ASSISTANCE

Visit our web site at www.plantronics.com/support for technical support including

frequently asked questions, compatibility and accessibility information.

The Plantronics Technical Assistance Centre (TAC) is also ready to assist you on

0800 410014 from the UK.

EXPOSURE TO RF RADIATION

The internal wireless radio operates within the guidelines found in radio frequency

safety standards and recommendations, which reﬂect the consensus of the scientiﬁc

community. Independent studies have shown that the internal wireless radio is safe

for use by consumers. Visit www.plantronics.com for more information.

NOTE: Modiﬁcations not expressly approved by Plantronics, Inc. could void the user’s

authority to operate the equipment.

MODEL AND COUNTRY INFORMATION

GBR

37677-04

37677-05

AUT, BEL, DEU, DNK, ESP,

FRA, GRC, ITA, IRL, LUX,

NLD, PRT, SWE, FIN, CYP,

CZE, EST, HUN, LVA, LTU,

MLT, POL, SVK, SVN.

PRODUCT SPECIFICATIONS

Listen time* Up to 7 hours

Talk time* Up to 9 hours

Standby time* Up to 200 hours

Charge time 3 hours

Range Bluetooth standard 10 metres

Headset and pod weight 25 grams

Power requirements 5VDC - 300 mA

Battery type Lithium ion polymer

Speaker frequency response • Telephony 300 Hz to 3600 Hz (CVSD)

• Stereo audio 20 Hz to 20 kHz (16-bit 48 kHz SBC coding)

Impedance 32 +-4 Ohms x1 kHz

Distortion <5% to 19 kHz

Version Bluetooth 2.0

Supports Bluetooth hands-free and headset profiles, Advanced Audio Distribution

Profile (A2 DP), Audio/Video Remote Control Profile (AVRCP) and Generic Audio/

Video Distribution Profile (GAVDP). For stereo sound, Bluetooth-enabled devices

must support the Advanced Audio Distribution Profile (A2DP).

* Performance may vary by device.

Pulsar are trademarks or registered trademarks of Plantronics, Inc. The

Bluetooth

word mark and logos

are owned by the Bluetooth SIG, Inc. and any use of such marks by Plantronics, Inc. is under licence.

Patents Pending.

Printed in USA. 37771-01 (05-06)

WARNING: Use of a headset that covers both ears will impair your ability

to hear other sounds. Use of such a headset while operating a motor

vehicle or riding a bicycle may create a serious hazard to you and/or

others and is illegal in most regions.

Do not use headphones/headsets at high volumes for an extended period

of time. Doing so can cause hearing loss. Always listen at moderate levels.

WARNINGS

Plantronics Ltd

Interface Business Park

Bincknoll Lane

Wootton Bassett

Wiltshire SN4 8QQ, ENGLAND

Tel: 0800 410 014

Plantronics B.V.

Hoofddorp, Nederland

Tel: 0800 752 6876 (NL)

00800 752 687 66 (BE/LUX)

Plantronics Sarl

Noisy-le-Grand, France

No Indigo: 0825 0825990

15 4 TTC/mn

+33 14167 4141

Plantronics GmbH

Hürth, Deutschland

Tel: 0800 9323400

Österreich: 0800 242 500

Schweiz: 0800 932 340

Plantronics Acoustics

Italia Srl

Milano, Italia

Numero Verde: 800 950 934

Plantronics Iberia, S.L.

Madrid, España

Tel: 902 415 191

+34 91 640 47 44 (ES)

Tel: 800 844 517 (PT)

Nordic Region

Tel: Finland: 0800 117 095

Tel: Sverige: 02002 14681

Tel: Danmark: 8088 4610

Tel: Norge: 800 113 36

Plantronics Middle East,

Eastern Europe and Africa

Tel: +44 1793 842 443

Plantronics, Inc.

345 Encinal Street

Santa Cruz, CA95060 USA

Tel: 1 831 426 5868

Autres manuels pour PULSAR 260

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Plantronics casque

Plantronics

Plantronics Savi Office WO100 Manuel utilisateur

Plantronics

Plantronics VOYAGER 520 Manuel utilisateur

Plantronics

Plantronics CS540-XD Manuel utilisateur

Plantronics

Plantronics BLACKWIRE C610-620 - QUICK START GUIDES Manuel utilisateur

Plantronics

Plantronics Blacktop 500 Manuel utilisateur

Plantronics

Plantronics Savi Office WO300 Manuel utilisateur

Plantronics

Plantronics M2300 Manuel utilisateur

Plantronics

Plantronics SupraPlus H261N Manuel utilisateur

Plantronics

Plantronics VOYAGER 510 Manuel utilisateur

Plantronics

Plantronics Voyager 5200 Series Manuel utilisateur

Plantronics

Plantronics BLUETOOTH HEADSET 220 SERIES Manuel utilisateur

Plantronics

Plantronics C565 Manuel utilisateur

Plantronics

Plantronics Voyager 104 Manuel utilisateur

Plantronics

Plantronics MX100 Manuel utilisateur

Plantronics

Plantronics M M120 Manuel utilisateur

Plantronics

Plantronics M25 Manuel utilisateur

Plantronics

Plantronics BLACKWIRE C420 START GUIDES Manuel utilisateur

Plantronics

Plantronics CS540 Series Manuel utilisateur

Plantronics

Plantronics S10 Manuel utilisateur

Plantronics

Plantronics BLACKWIRE C210 Manuel utilisateur

Plantronics

Plantronics EXPLORER 210 Guide de référence

Plantronics

Plantronics VOYAGER 510-USB Manuel utilisateur

Plantronics

Plantronics Voyager 3200 Series Manuel utilisateur

Plantronics

Plantronics GAMECOM X95 - QUICK START GUIDES Manuel utilisateur

Manuels casque populaires d'autres marques

Sena

Sena SMH10 Manuel utilisateur

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuel utilisateur

Sennheiser

Sennheiser EPOS ADAPT 230 Manuel utilisateur

Doro

Doro Flexus HS2005 Manuel utilisateur

GE 98971 Manuel utilisateur

Hama

Hama 00184070 Manuel utilisateur

Blue Tiger

Blue Tiger Advantage PLUS Manuel utilisateur

Jawbone

Jawbone Icon Manuel utilisateur

Jabra

Jabra FR 20 Manuel utilisateur

Roxcore

Roxcore Flow A+ Manuel utilisateur

Turtle Beach

Turtle Beach XP 510 Manuel utilisateur

Philips

Philips SHB6101 Manuel utilisateur

Jabra

Jabra PRO 9460 Duo Manuel utilisateur

HyperX

HyperX HyperX Cloud Flight Manuel utilisateur

Bose

Bose MIE2 Mobile Manuel utilisateur

Jabra

Jabra Steel Manuel utilisateur

HyperX

HyperX cloud ii Manuel utilisateur

Southwing

Southwing SA505 Manuel utilisateur
