Plantronics CALISTO Manuel utilisateur
Plantronics®Calisto™Headset
with Bluetooth®USB Adapter
User Guide
56-K61A-23010
iii
Contents
Package Contents.......................................................................... 1
Product Features............................................................................ 2
Wearing Your Headset .................................................................... 3
Powering Your Headset and
USB Bluetooth Adapter .................................................................. 4
Headset Indicator Lights and Alerts ................................................ 6
Headset Indicator Lights.......................................................... 6
Headset Alerts......................................................................... 6
USB Bluetooth Adapter Indicator Lights ......................................... 7
Pairing Your Headset with the
USB Bluetooth Adapter .................................................................. 7
Adjusting Computer Audio Settings ................................................ 8
Using Your Headset with Dragon NaturallySpeaking ....................... 8
Using the Headset with Dragon Dictate ........................................ 10
Regulatory Notices ....................................................................... 11
1
Package Contents
Calisto Headset
BT300 Bluetooth Adapter USB Headset Charger
2
Product Features
Charge Connection
Noise-Canceling Microphone
Call Control Button (on/off)
Reversible Earloop
Volume Adjust
Indicator Light
USB Connector
3
Your headset can be worn on your left or right ear. To switch from one ear
to the other, flip the ear loop to the side, and twist around.
Wearing Your Headset
The ear tip should fit
comfortably in the opening
of your ear canal
Point the mouthpiece toward
your mouth
4
The headset automatically powers up when it is charging.
Powering up: Press and hold Headset button for 2 seconds.
4 ascending beeps will sound when powered on.
Powering down: Press and hold Headset button for 4 seconds.
4 descending beeps will sound when powered off.
NOTE For your convenience, the headset comes pre-paired with the USB
Bluetooth adapter, and (if the headset is within range) will automatically
connect to the adapter when powered on.
The USB Bluetooth adapter is automatically powered on upon inserting into
the USB port of the computer.
Powering Your Headset and
USB Bluetooth Adapter
5
Charging Your Headset
Before using, you must first charge your headset. The indicator light
glows solid red while charging and turns solid blue when the headset is
fully charged.
Charge the headset for a minimum of 2 hours.
Battery talk time is up to 8 hours.
NOTE Do not use headset while charging and do not connect the charger
while headset is in use.
6
Headset Indicator Lights and Alerts
Headset Indicator Lights
Action Button Action Sounds Indicator Lights
Turn
headset on
Press and hold
for 2 seconds
4 ascending
beeps
Flashes blue every
10 seconds
Turn
headset off
Press and hold
for 4 seconds
4 descending
beeps
Turn
microphone
on/off
Press for
1 second
1 high beep
Adjust volume Press left or right
(not inward)
2 beeps when
max/min volume
reached
Headset Alerts
Alert Sounds Indicator Lights
Low battery 3 beeps every
30 seconds
Flashes red 3 times every 3 seconds
Charging Glows solid red
Fully charged Glows solid blue while connected
to charge
7
USB Bluetooth Adapter Indicator Lights
Action Indicator Lights
Disconnected from the headset No LED
Connected to the headset Solid blue
Radio link active Flashes blue
Pairing mode Flashes blue rapidly
Pairing Your Headset with the
USB Bluetooth Adapter
NOTE The Bluetooth USB adapter comes pre-paired to the headset;
however, if you find that you need to pair your headset to the adapter again,
you can do so by performing the following steps.
2 sec.
1. Start with the headset powered off.
2. Press and hold the power button for about 5-6 seconds until the light on
the headset starts flashing an alternating red-blue. Release the power
button.
3. Insert the Bluetooth USB adapter into the computer. Once the devices
pair successfully, the LED on the headset stops flashing.
8
Adjusting Computer Audio Settings
1. On your PC, launch the Control Panel and select Sound.
2. On the Sound dialog, make sure the Plantronics Bluetooth Adapter is
selected as the default device in the Playback and Recording tabs.
3. Press OK.
Using Your Headset with Dragon
NaturallySpeaking
1. First, plug the USB adapter of the Calisto microphone into your PC, and
make sure your headset is charged, paired with the adapter, and powered
on. Then start Dragon.
2. You can now create a new user profile within Dragon to use this
microphone. However, if you already have a Dragon profile, you should
instead add the Calisto microphone to it, which is done through the
DragonBar’s Profile menu. Having multiple sources within your profile
allows you to access the same customizations, including words and
phrases you’ve added to the vocabulary, regardless of which of your
audio sources you’re using.
3. When Dragon presents the list of sources to choose from (during profile
creation or when you add a source to your profile), select Enhanced
Bluetooth (in Dragon version 12) or Bluetooth (in earlier versions).
4. If Dragon prompts you to “Choose
your sound system”, select the
Plantronics Adapter from the
list and then click Next to continue.
