Planet Uh-400 Manuel utilisateur

Introduction

The UH-400 is an Universal Serial Bus (USB) hub,

which is an USB cable concentrator and a bridge

between PC USB host controller and USB devices.

The USB hub has one upstream port and four

downstream ports. It supports both full speed

(12Mbps) and low speed (1.5Mbps) devices such as

mouse, keyboard, joystick and etc. The USB hub

provides both self-powered and bus-powered modes,

and also provides per-port over-current detection

and protection.

Package Contains

The hub package will contains:

FOne high speed USB hub for 4 ports

FOne USB cable

FOne AC power adapter (output: 6V DC, 2.1A)

FThis User’s Guide

System Requirements

1. Windows 95 OSR 2.1 above or Windows 98

2. Macintosh, iMac, G3, 300, 350, 400 with Mac

OS 8.1

3. Your PC must have USB host controllers inside

the H/W system.

Key Features

1. A real plug-and-play and hot-plugged device.

2. Supporting both self-powered and bus-powered

modes and locating the power mode

automatically.

3. Supporting up to 127 physical devices.

4. Per-port over-current detection and protection.

Sample Diagram

Specification

Function Description

Upstream port (Root port) 1

Downstream port 4

Self powered(Red LED) /

Bus powered(Green LED) 1

LED

Downstream power

(Green LED) 4

Per-port Output Voltage DC+5V

Per-port Output Current 500mA

Weight 100g

Dimension (L*W*H, mm) 119 * 66 * 32

Power Mode

The 4 port USB hub has two power modes, self-

powered mode and bus-powered mode.

Power Adapter

If more power is required to supply the downstream

port devices, you can use the DC 6V 2.1A adapter

to increase the motivation power of the USB hub.

Installation

FIG-1

Step 1. Please insert the plug of DC 6V 2.1A power

adapter into the power jack of the USB hub.

Step 2. Connect the series-A connector of the USB

cable into the downstream port of PC USB

host connector or one downstream port of

the upper level USB hub.

Step 3. Connect the series-B connector of the USB

cable into the upstream port of the USB hub.

Step 4. Connect the series-A connector of USB

devices into any one of the downstream port

of the USB hub.

Note: Please install the USB hub following the

procedures step by step.

Install USB Hub Device driver for

Windows 98

After plugging the USB cable, Windows 98 will

automatically detect the new hardware of the USB

hub. These procedures require Windows 98 setup

CD-ROM, and you will be prompted while

inserting your CD-ROM.

In response to the message of Add New Hardware

Wizard (Figure 3), you can insert the Windows 98

setup CD-ROM into the drive (Figure 4) and follow

the system prompts step by step (Figure 5 & 6).

Your USB hub has been installed correctly and is

now ready for use.

Figure 2.

Figure 3

Figure 4

Figure 5

Figure 6

EM-UH400

ISO9002

PLANET Technology Corp.
