Planet IGS-6325-8T4X Manuel utilisateur

Industrial L3 Multi-Port Gigabit

Managed Ethernet Switch

IGS-6325 DIN-rail Series

Quick Installation Guide

Table of Contents

1. Package Contents ....................................................................................... 3

2. Requirements ............................................................................................. 5

3. Wiring the Power Inputs.............................................................................. 6

3.1 Grounding the Device .......................................................................... 8

4. Terminal Setup ........................................................................................... 9

4.1 Logging on to the Console...................................................................10

 4.2 ConguringIPAddressviaConsole ......................................................11

 4.3 StoringCurrentSwitchConguration....................................................12

5. Starting Web Management .........................................................................13

5.1 Logging in to the Industrial Managed Switch.........................................13

 5.2 SavingCongurationviaWeb ..............................................................15

6. RecoveringBacktoDefaultConguration.....................................................17

7. Customer Support .....................................................................................19

1. Package Contents

Thankyouforpurchasing PLANETL3Industrial ManagedSwitch,IGS-6325 DIN-rail

series. The descriptions of these models are as follows:

IGS-6325-16P4S IndustrialL316-Port10/100/1000T802.3atPoE+4-Port

1G/2.5GSFPManagedEthernetSwitch

IGS-6325-16T4S IndustrialL316-Port10/100/1000T+4-Port1G/2.5G

SFPManagedEthernetSwitch

IGS-6325-8T4X IndustrialL38-Port10/100/1000T+4-Port10GSFP+

ManagedEthernetSwitch

IGS-6325-8T8S IndustrialL38-Port10/100/1000T+8-Port1G/2.5GSFP

ManagedEthernetSwitch

IGS-6325-8T8S4X IndustrialL38-Port10/100/1000T+8-Port1G/2.5GSFP+

4-Port10GSFP+ManagedEthernetSwitch

IGS-6325-8UP2S IndustrialL38-Port10/100/1000T802.3btPoE+2-Port

1G/2.5GSFP+ManagedEthernetSwitc

IGS-6325-8UP2S2X

IndustrialL38-Port10/100/1000T802.3btPoE+2-Port

1G/2.5GSFP+2-Port10GSFP+ManagedEthernet

Switch

“Industrial Managed Switch” mentioned in this Quick Installation Guide refers

to the above models.

Open the box of the Industrial Managed Switch and carefully unpack it. The

box should contain the following items:

The

Industrial

Managed

Switch

DB9 to RJ45

Interface

RS232

Console

Cable

Quick

Installation

Guide

Wall

Mounting

Kit

RJ45

Dust

Cap

SFP

Dust

Cap

IGS-6325-16P4S    

17 4

IGS-6325-16T4S    

IGS-6325-8T4X     9 4

IGS-6325-8T8S     9 8

IGS-6325-8T8S4X     912

IGS-6325-8UP2S     9 2

IGS-6325-8UP2S2X     9 4

Ifanyof theseare missingor damaged,please contactyourdealer immediately.If

possible, retain the carton including the original packing materials to enable you to

repack the product in case there is a need to return it to us for repair.

2. Requirements

The Industrial Managed Switch provides remote login interface for management

purposes. The following equipment is necessary for further management:

zWorkstationsrunningWindows XP/2003/2008/Vista/7/8/10,MACOS X orlater,

Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPProtocols.

zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard).

zSerialPortConnection(Terminal)

The above Workstations come with COM Port (DB9) or USB-to-RS232

converter.

The above Workstations have been installed with terminal emulator,suchas

HyperTerminalincludedinWindowsXP/2003,puttyorteraterm.

Serial cable -- one end is attached to the RS232 serial port, while the other

end to the console port of the Industrial Managed Switch.

zEthernetPortConnection

Network cables--Usestandardnetwork(UTP)cableswithRJ45connectors.

The above PC is installed with Web browser.

Note

It is recommended to use Internet Explorer 8.0 or above to access

the Industrial Managed Switch.

3. Wiring the Power Inputs

The Upper Panel of the Industrial Managed Switch indicates an inlet power

socket and consists of one green terminal block connector within 6 contacts. Please

follow the steps below to insert the power wire.

1.Insert positive/negative DC power wires into Contacts 1 and 2 for Power 1, or

Contacts 5 and 6 for Power 2.

IGS-6325-16P4S:DC48-56V

0DI

1DO

0DO

1GND GND

Fault

V1+ V2+1A@24V

DC2DC1

Dual power input is required

for maximum PoE loading.

Refer to user’s manual for

more details.

Input: 48-56V , 7.5A max.

1 2 3 4 5 6

Figure 3-1: IGS-6325-16P4S Upper Panel

IGS-6325-16T4S:DC9-48V,AC24V

DI1 DO0 DO1DI0 GNDGND

Max. fault loading: 24V, 1A

DC Input: 9-48V , 3.3A max.

AC Input: 24V

, 1.2A max.

V1+ V2+

PWR1 PWR2Fault

1 2 3 4 5 6

Figure 3-2: IGS-6325-16T4S Upper Panel

IGS-6325-8T4X/IGS-6325-8T8S/IGS-6325-8T8S4X:DC12~48V,AC24V

DI1 DO0 DO1DI0 GNDGND

Max. fault loading: 24V, 1A

V1+ V2+

PWR1 PWR2Fault

DC Input: 12-48V , 4A max.

AC Input: 24V , 2A max.

1 2 3 4 5 6

Figure 3-3: IGS-6325-8T4X/IGS-6325-8T8S/IGS-6325-8T8S4X Upper Panel

IGS-6325-8UP2S/IGS-6325-8UP2S2X:DC48~56V

PWR1 PWR2

Fault

DI1 DO0 DO1DI0 GNDGND

DC Input:

48-56V , 7.5A max.

Max. fault loading: 24V, 1A

Dual power input is required

for maximum PoE loading.

Refer to user’s manual for

more details.

1 2 3 4 5 6

Figure 3-4: IGS-6325-8UP2S/IGS-6325-8UP2S2X Upper Panel

2.Tightenthewire-clampscrewsforpreventingthewiresfromloosening.

123456

V+ V- V+ V-

Power 1 Power 2

Figure 3-5: The pin of 6-contact terminal block connector

Note

1. The wire gauge for the terminal block should be in the range

from 12 to 24 AWG.

2.Please check the wire AWG Ampere specification before

connectingPLANETIndustrialManagedSwitch.

3.1 Grounding the Device

Users MUST complete grounding wired with the device; otherwise, a sudden

lightning could cause fatal damage to the device.

0DI

1DO

0DO

1GND GND

Fault

V1+ V2+1A@24V

DC2DC1

Dual power input is required

for maximum PoE loading.

Refer to user’s manual for

more details.

Input: 48-56V , 7.5A max.

1 2 3 4 5 6

Earth Ground

4. Terminal Setup

To congure the system, connect a serial cable to a COM port on a PC or

notebook computer and to RJ45 type serial (console) port of the Industrial

Managed Switch.

PC/Workstation with

Terminal Emulation Software

RJ45 to DB9 RS232 Cable

Serial Port

Console Port

115200,N,8,1

IGS Industrial Managed Switch

Console

115200,N,8,1

A terminal program is required to make the software connected to the Industrial

Managed Switch.

1. Run terminal program on the OS.

2.When the following screen appears, make sure that the COM port should be

conguredas:

Baud: 115200

Parity:None

Data bits: 8

Stop bits: 1

Flowcontrol:None

4.1 Logging on to the Console

Once the terminal has been connected to the device, power on the Industrial

Managed Switch and the terminal will display “running testing procedures”.

Note

The following console screen is based on the IGS-6325-16P4S.

The display of the IGS-6325 series is the same as that of the IGS-

6325-16P4S.

Then, the following message asks to log in user name and password. The factory

defaultusernameandpasswordare shownasfollowsastheloginscreen inFigure

4-1appears

UserName:admin

Password: admin

Figure 4-1: Console Login Screen

The user can now enter commands to manage the Industrial Managed Switch. For

adetaileddescriptionofthecommands,pleaserefertothefollowingchapters.

Note

1.For security reason, please change and memorize the new

password after this first setup.

2. Only accept command in lowercase letter under console inter-

face.
