PLANET 5/8-Port 10/100/1000Mbps Gigabit Ethernet Switch User's Manual

For Models: GSD-503 / GSD-504 / GSD-803 / GSD-804

Revision: 3.0(AUGUST.2007)

Part No: EM_GSD58v3 (2010-A33130-001)

TABLE OF CONTENTS

1. INTRODUCTION.......................................................................................... 5

1.1 Package Contents ................................................................................. 5

1.2 How to Use This Manual ....................................................................... 5

1.3 Product Features................................................................................... 5

1.4 Product Specications............................................................................ 7

2. INSTALLATION............................................................................................ 8

2.1 Product Description ............................................................................... 8

2.1.1 Product Overview............................................................................... 8

2.1.2 Switch Front Panel ............................................................................. 9

2.1.3 LED Indicators ..................................................................................10

2.1.4 Switch Rear Panel .............................................................................10

2.2 Installing the Switch ............................................................................11

2.2.1 Desktop Installation ..........................................................................11

3. SWITCH OPERATION..................................................................................13

3.1 Address Table......................................................................................13

3.2 Learning .............................................................................................13

3.3 Forwarding & Filtering ..........................................................................13

3.4 Store-and-Forward ...............................................................................13

3.5 Auto-Negotiation..................................................................................14

4. TROUBLESHOOTING...................................................................................15

APPENDIX A: NETWORKING CONNECTION...................................................16

A.1 Switch‘s RJ-45 Pin Assignments ............................................................16

A.2 RJ-45 cable Pin Assignments ................................................................17

1. INTRODUCTION

1.1 Package Contents

Check the contents of your package for following parts:

● Gigabit Ethernet Switch x 1

● User's manual x 1

● Power adapter x 1

● Rubber feet x 4

If any of these are missing or damaged, please contact your dealer immediately,

if possible, retain the carton including the original packing material, and use them

against to repack the product in case there is a need to return it to us for repair.

1.2 How to Use This Manual

This Gigabit Ethernet Switch User Manual is structured as follows:

Chapter 2 Installation

The chapter explains the feature, functionality and the physical installation of the

Switch.

Chapter 3 Switch operation

The chapter explains the Gigabit Ethernet Switch transmit operation.

Chapter 4 Troubleshooting

The chapter explains the troubleshooting of the Gigabit Ethernet Switch.

Appendix A

This chapter contains cable information of the Gigabit Ethernet Switch.

1.3 Product Features

● Comply with IEEE 802.3, 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab

1000Base-T

● 5/8-Port 10/100/1000Mbps Gigabit Ethernet ports

● Features Store-and-Forward mode with wire-speed ltering and forwarding rates

● Hardware based 10/100Mbps, half / full duplex and 1000Mbps full duplex mode,

ow control and auto-negotiation

● IEEE 802.3x ow control for full duplex operation and Backpressure for half du-

plex operation

● Integrated address look-up engine, support 8K absolute MAC addresses

● 9K Jumbo packet support

● Automatic address learning and address aging

● Supports Auto MDI/MDI-X function

● Support CSMA/CD protocol

● External power adapter 12V 1A

● FCC, CE class A compliant

1.4 Product Specications

Product GSD-503 GSD-504 GSD-803 GSD-804

Hardware Specication

10/100/1000Base-T

Ports 5 Auto MDI/MDIX ports 8 Auto MDI/MDIX ports

Dimensions (mm)

(W x D x H) 155x86x26 176x106x30 155x86x26 176x106x30

Weight (kg) 0.36 0.16 0.45 0.18

Power Requirement External power adapter 12V 1A

Power Consumption

/ Dissipation 5.4 watts / 18 BTU 9.2 watts / 31 BTU

Switch Specication

Switch Processing

Scheme Store-and-Forward

Address Table 8K entries

Flow Control Back pressure for half duplex, IEEE 802.3x Pause Frame

for full duplex

Switch fabric 10Gbps 16Gbps

Throughput

(packet per second) 7.44Mpps 11.9Mpps

Jumbo packet size 9K

Standards Conformance

Standards

Compliance

IEEE 802.3 (Ethernet)

IEEE 802.3u (Fast Ethernet)

IEEE 802.3ab (Gigabit Ethernet)

IEEE 802.3x (Full-duplex ow control)

Temperature Operating: 0~50 degree C

Storage: -40~70 degree C

Humidity Operating: 5% to 90%,

Storage: 5% to 90% (Non-condensing)

Regulation

Compliance FCC Part 15 Class A, CE

2. INSTALLATION

This section describes the functionalities of the Gigabit Ethernet Switch’s

components and guides how to install it on the desktop. Basic knowledge of

networking is assumed. Please read this chapter completely before continuing.

2.1 Product Description

The PLANET GSD-503/GSD-504 and GSD-803/GSD-804 are 10/100/1000Mbps

Gigabit Ethernet Switches in a compact housing for easily desktop placement.

With 5/8 ports respectively, non-blocking wire-speed performance and 10/16Gbps

internal switching fabric, the Switches can handle extremely large amounts of data

in a secure topology linking to a backbone or high capacity servers. The Switches

has 8K MAC Address table. The Switches offers wire-speed packets transfer

performance without risk of packet loss. The high data throughput of Switches

makes it ideal for most Gigabit environments, especially while network upgrades to

a Gigabit environment.

All RJ-45 copper interfaces support 10/100/1000Mbps Auto-Negotiation for optimal

speed detection through RJ-45 Category 6, 5 or 5e cables. Support is standard

for Auto-MDI/MDI-X that can detect the type of connection to any Ethernet device

without requiring special straight or crossover cables.

The Flow Control function allows your Gigabit Switch supported routers and servers

to directly connect to this Switch for fast, reliable data transfer.

2.1.1 Product Overview

The PLANET GSD-503/GSD-504 and GSD-803/GSD-804 are Gigabit Ethernet

Switches with 5/8 RJ-45 10/100/1000Mbps ports for high-speed network

connectivity. The Switches can also automatically identify and determine the correct

transmission speed and half / full duplex mode of the attached devices with its 5/8

ports. The Gigabit ports with jumbo frame feature supported, can handle extremely

large amounts of data transmission in a secure topology linking to a backbone or

high-power servers.

The GSD-503/GSD-504 and GSD-803/GSD-804 also supports Store-and-Forward

forwarding scheme to ensure low latency and high data integrity, eliminates

unnecessary trafc and relieves congestion on critical network paths. With an

intelligent address recognition algorithm, the Switches could recognize up to 8K

different MAC address and enables ltering and forwarding at full wire speed.

2.1.2 Switch Front Panel

Figure 2-1 & 2-2 & 2-3 & 2-4 shows a front panel of GSD-503 / GSD-504 / GSD-

803 / GSD-804.

Figure 2-1 GSD-503 front panel

Figure 2-2 GSD-504 front panel

Figure 2-3 GSD-803 front panel

Figure 2-4 GSD-804 front panel

2.1.3 LED Indicators

LED Color Function

PWR Green Lights to indicate that the Switch is powered on.

1000 Green

Lit: indicate that the port is operating at

1000Mbps.

Off: indicate that the port is operating at 10Mbps

or 100Mbps.

LNK/ACT Green

Lit: indicate the link through that port is

successfully established.

Blinks to indicate that the Switch is actively

sending or receiving data over that port.

2.1.4 Switch Rear Panel

Figure 2-5 & 2-6 & 2-7 & 2-8 shows a rear panel of GSD-503 / GSD-504 / GSD-

803 / GSD-804.

Figure 2-5 GSD-503 rear panel

Figure 2-6 GSD-504 rear panel
