Planet GSD-908HP Manuel utilisateur

8-Port 10/100/1000T 802.3at PoE +

1-Port 10/100/1000T Desktop Switch

GSD-908HP

User’s Manual

Trademarks

Contents are subject to revision without prior notice.

PLANET is a registered trademark of PLANET Technology Corp. All other trademarks

belong to their respective owners.

Disclaimer

PLANET Technology does not warrant that the hardware will work properly in all

environments and applications, and makes no warranty and representation, either

implied or expressed, with respect to the quality, performance, merchantability, or

tness for a particular purpose.

PLANET has made every effort to ensure that this User’s Manual is accurate;

PLANET disclaims liability for any inaccuracies or omissions that may have

occurred.

Information in this User’s Manual is subject to change without notice and does not

represent a commitment on the part of PLANET. PLANET assumes no responsibility

for any inaccuracies that may be contained in this User’s Manual. PLANET makes

no commitment to update or keep current the information in this User’s Manual,

and reserves the right to make improvements to this User’s Manual and/or to the

products described in this User’s Manual, at any time without notice.

If you nd information in this manual that is incorrect, misleading, or incomplete,

we would appreciate your comments and suggestions.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with

the Instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at

his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product may cause radio

interference, in which case the user may be required to take adequate measures.

Energy Saving Note of the Device

This power required device does not support Standby mode operation.

For energy saving, please remove the power cable to disconnect the device from

the power circuit.

Without removing power cable, the device will still consuming power from the

power source. In the view of Saving the Energy and reduce the unnecessary power

consuming, it is strongly suggested to remove the power connection for the device

if this device is not intended to be active.

WEEE Warning

To avoid the potential effects on the environment and human health as a

result of the presence of hazardous substances in electrical and electronic

equipment, end users of electrical and electronic equipment should

understand the meaning of the crossed-out wheeled bin symbol. Do not

dispose of WEEE as unsorted municipal waste; WEEE has to be collected

separately.

Revision

PLANET 8-Port 10/100/1000T 802.3at PoE + 1-Port 10/100/1000T Desktop Switch

User’s Manual

For Model: GSD-908HP

Revision: 1.0 (JUNE, 2014)

Part No.: 2351-AK3180-000

Table of Contents

1. Introduction ............................................................................................... 5

1.1 Checklist............................................................................................. 5

1.2 Product Description.............................................................................. 5

1.3 Features ............................................................................................. 7

1.4 Specications ...................................................................................... 8

2. Hardware Description .................................................................................. 9

2.1 Front Panel ......................................................................................... 9

2.1.1 LED Indicators ........................................................................... 9

2.2 Rear Panel .........................................................................................10

3. Installation................................................................................................11

3.1 Desktop Installation ............................................................................11

3.2 Magnet Installation .............................................................................12

3.3 Wall Mount Installation........................................................................13

3.4 Protective Grounding Cable Installation.................................................14

3.4.1 Installation Environment with Grounding Bar ...............................14

3.4.2 Installation Environment without Grounding Bar...........................15

3.5 Hardware Connection..........................................................................16

4. Troubleshooting .........................................................................................18

Appendix: A Networking Connection .................................................................19

A.1 PoE RJ-45 Port Pin Assignments...........................................................19

A.2 Switch’s Data RJ-45 Pin Assignments - 1000Mbps, 1000Base-T ..............19

A.3 10/100Mbps, 10/100Base-TX ...............................................................20

1. Introduction

1.1 Checklist

Check the contents of your package for the following parts:

zGSD-908HP x 1

zUser’s Manual x 1

zExternal AC to DC Adapter x 1

zPower Cord x 1

zWall Mount Kit x 1

zMagnet / Screw x 4

zRubber Feet x 4

If any of these pieces are missing or damaged, please contact your dealer

immediately; if possible, retain the carton including the original packing material,

and use them again to repack the product in case there is a need to return it to us

for repair.

The term “PoE Ethernet Switch” mentioned in this user’s manual also means the

GSD-908HP.

1.2 Product Description

Centralized Power Distribution for Ethernet Networking

The GSD-908HP, a new member in the PLANET 802.3af / 802.3at PoE Unmanaged

Gigabit Ethernet Switch family, is an 8-port 10/100/1000T 802.3at Power

over Ethernet + 1-port 10/100/1000T Desktop Switch with a total of 120

watts of PoE budget, which is an ideal solution to fullling the demand of sufcient

PoE power for network applications with Gigabit Ethernet speed transmission. The

eight 802.3af / 802.3at PoE Gigabit ports provides PoE power injector function

which is able to drive 8 IEEE 802.3af compliant powered devices or 4 IEEE 802.3at

compliant powered devices. The GSD-908HP also provides a simple, cost-effective

and non-blocking Gigabit wire-speed performance. It comes with a metal compact

housing, suitable for desktop deployment in SOHO ofce or department network

application.

Perfectly Integrated Solution for IP PoE Camera and NVR System

Different from the general IT industrial PoE Switch which usually comes with 12 or

24 PoE ports, the GSD-908HP provides eight 802.3af / 802.3at PoE Gigabit ports

for catering to small scale of IP Surveillance networks at a lower total cost. The

GSD-908HP comes with high performance switch architecture and 120-watt PoE

power budget. The recorded video les from 8 PoE IP Cameras can be powered by

the GSD-908HP and saved in the 8-channel NVR system or surveillance software

to perform comprehensive security monitoring. For instance, one GSD-908HP

can be combined with one 8-channel NVR and 8 PoE IP cameras as a kit for the

administrators to centrally and efciently manage the surveillance system in the

local LAN and the remote site via Internet.

Stable and High Performance Switch Architecture

The GSD-908HP has a 4K MAC address table, featuring high performance switch

architecture capable of providing the non-blocking 18Gbps switch fabric and wire-

speed throughput as high as 13.3Mpps, which greatly simplies the tasks of

upgrading the LAN for catering to increasing bandwidth demands. Besides, the

802.3x Full-Duplex ow control function of the GSD-908HP enables PD devices

and servers to be directly connected to the switch for wire-speed packet transfer

performance without the risk of packet loss.

The GSD-908HP RJ-45 copper interfaces support 10/100/1000Mbps Auto-

Negotiation at port 1 to port 9 for optimal speed detection through RJ-45 Category

6, 5 or 5e cables. It also supports standard Auto-MDI/MDI-X that can detect the

type of connection to any Ethernet device without requiring special straight or

crossover cables.

Easy Cable Connection

With data and power over Ethernet from one unit, the GSD-908HP reduces cabling

requirements and eliminates the need for dedicated electrical outlets on the wall,

ceiling or any unreachable place. A wire that carries both data and power can

lower the installation costs, simplify the installation effort and eliminate the need

for electricians or extension cords. Providing 8 PoE interfaces, the GSD-908HP

is ideal for small businesses and workgroups requiring deploying the PoE for the

wireless access points, IP-based surveillance camera or IP phones in any places

easily, efciently and cost-effectively.

1.3 Features

zRJ-45 Interface

Complies with IEEE 802.3, 10Base-T, IEEE 802.3u, 100Base-TX, IEEE 802.3ab,

1000Base-T

9-Port 10/100/1000Mbps Gigabit Ethernet Switch

8-Port supports 51V DC power to PoE Powered Device (Port 1 to port 8)

zPower over Ethernet

Complies with IEEE 802.3af / 802.3at Power over Ethernet End-Span PSE

Up to 8 IEEE 802.3af devices powered

Supports PoE Power up to 15.4 watts for each PoE port

Up to 4 IEEE 802.3at devices powered

Supports PoE Power up to 30 watts for each PoE port

120-watt PoE budget

Auto detects powered device (PD)

Circuit protection prevents power interference between ports

Remote power feeding up to 100m

zSwitching

Hardware based 10/100Mbps, Half / Full Duplex and 1000Mbps Full Duplex

mode, Flow Control and Auto-negotiation and Auto MDI/MDI-X

 Features Store-and-Forward mode with wire-speed ltering and forwarding

rates

 IEEE 802.3x ow control for Full Duplex operation and backpressure for Half

Duplex operation

Integrates address look-up engine, supporting 4K absolute MAC addresses

192 KB packet buffer

9K Jumbo frame supports at 1000Mbps speed duplex mode

Automatic address learning and address aging

Supports CSMA/CD protocol

zHardware

Made of metal and desktop size and wall-mount design

LED indicators for system power, PoE usage 100%, per port PoE In-Use (Port

1 to port 8), per port Link / Act (10/100/1000Mbps, port 1 to port 9).

51V DC, 2.5A external power adapter

FCC, CE Class A compliant

1.4 Specications

Model GSD-908HP

Hardware Specications

Network Connector 9-Port RJ-45 for 10/100/1000Base-T

PoE Inject Port 8-Port with 802.3af / 802.3at PoE injector function

LED Display

System: Power (Green), PoE Usage 100% (Green)

Per PoE Port: PoE (Green), port 1 to port 8

LNK/ACT (Orange), port 1 to port 9

Switch Architecture Store and forward

MAC Address Table 4K MAC address table with auto learning function

Data Buffer 192 KB

Switch Fabric 18Gbps

Switch Throughput 13.3Mpps@64Bytes

Flow Control Back pressure for Half-Duplex. IEEE 802.3x Pause

Frame for Full-Duplex

Power Requirements DC 51V, 2.5A max.

Power Consumption 120 watts / 409BTU

Dimensions (W x D x H) 103 x 235 x 27 mm

Weight 628g

Power over Ethernet

PoE Standard IEEE 802.3af / 802.3at Power over Ethernet PSE

PoE Power Supply Type End-Span

PoE Power Output Per Port 51V DC, 350mA. Max. 15.4 watts

Per Port 51V DC, 600mA. Max. 30 watts

Power Pin Assignment 1/2(+), 3/6(-)

PoE Power Budget 120 watts

Max. Number of Class 2 PD 8

Max. Number of Class 3 PD 8

Max. Number of Class 4 PD 4

Standard Conformance

EMI Safety FCC Class A, CE

Operating Environment 0 ~ 50 degrees C

Storage Environment -10 ~ 70 degrees C

Operating Humidity 5 ~ 95%, relative humidity (non-condensing)_

Storage Humidity 5 ~ 95%, relative humidity (non-condensing)

Standard Compliance

IEEE 802.3

IEEE 802.3u

IEEE 802.3ab

IEEE 802.3x

IEEE 802.3af

IEEE 802.3at

Ethernet

Fast Ethernet

Gigabit Ethernet

Flow Control

Power over Ethernet

High Power over Ethernet

2. Hardware Description

This product provides three different running speeds –10/100/1000Mbps at port 1

to port 9 and automatically distinguishes the speed of incoming connection.

This section describes the hardware features of the GSD-908HP. For easier

management and control of the switch, familiarize yourself with its display

indicators, and ports. Front panel illustrations in this chapter display the unit LED

indicators. Before connecting any network device to the GSD-908HP, please read

this chapter carefully.

2.1 Front Panel

The front panel of the GSD-908HP PoE Ethernet Switch consists of 9x Auto-Sensing

10/100/1000Mbps Ethernet RJ-45 Ports. The LED Indicators are also located on the

RJ-45 ports of the PoE Ethernet Switch.

GSD-908HP

PWR

PoE Usage 100%

ACTLNK PoE In-Use

87654321 9- Uplink

Figure 2-1: GSD-908HP Switch Front Panel

2.1.1 LED Indicators

System

LED Color Function

PWR Green Light: Indicates the switch has power.

PoE Usage

100% Green Light: Indicates the system has 100% PoE power usage.

Per 10/100/1000T Port

LED Color Function

LNK/ACT Orange

Light: indicates the link through that port is successfully

established at 10/100/1000Mbps.

Blink: indicates that the switch is actively sending or

receiving data over that port.

PoE In-Use Green Light: indicates the port is providing 51V DC in-line power

(1-8 ports).

2.2 Rear Panel

The rear panel of the PoE Ethernet Switch indicates a DC power socket, which

accepts DC 51V input power; there is a security slot that allows using an anti-

theft lock to attach the PoE Ethernet Switch to a xed object against theft. The

grounding terminal provides lightning protection ability for the PoE Ethernet Switch.

51V DC

Figure 2-2: GSD-908HP Switch Rear Panel

Power

Notice

The device is a power-required device, meaning it will not work till

it is powered. If your networks should be active all the time, please

consider using UPS (Uninterrupted Power Supply) for your device.

It will prevent you from network data loss or network downtime.

In some areas, installing a surge suppression device may also help

to protect your GSD-908HP from being damaged by unregulated

surge or current to the GSD-908HP or the power adapter.

Before startup

Before your installation begins, please refer to the following for your cabling:

10/100/1000Base-T (Port 1 to Port 9)

The 10/100/1000Base-T port comes with Auto-Negotiation capability, which

automatically supports 1000Base-T, 100Base-TX and 10Base-T networks. Users

only need to plug a working network device into the 10/100/1000Base-T port, and

then turn on the PoE Ethernet Switch. The port will automatically run in 10Mbps,

20Mbps, 100Mbps or 200Mbps and 1000Mbps or 2000Mbps after negotiating with

the connected device.

Cabling

Each 10/100/1000Base-T port uses RJ-45 sockets -- similar to phone jacks

-- for connection of unshielded twisted-pair cable (UTP). The IEEE 802.3 /

802.3u / 802.3ab Fast / Gigabit Ethernet standard requires Category 5 UTP for

100Mbps 100Base-TX. 10Base-T networks can use Cat.3, 4, 5 or 1000Base-T uses

Cat.5/5e/6 UTP (see table below). Maximum distance is 100 meters (328 feet).

Port Type Cable Type Connector

10Base-T Cat 3, 4, 5, 2-pair RJ-45

100Base-TX Cat.5 UTP, 2-pair RJ-45

1000Base-T Cat.5/5e/6 UTP, 4-pair RJ-45

Any Ethernet devices like hubs/PCs can connect to the GSD-908HP PoE Ethernet

Switch by using straight-through wires. The nine RJ-45 ports are auto-MDI/MDI-X,

which can be used on straight-through or crossover cable.

Table des matières

Autres manuels Planet Routeur réseau

Planet

Planet EPN-102 Manuel utilisateur

Planet

Planet WRT-403 Manuel utilisateur

Planet

Planet FSD-1603 Manuel utilisateur

Planet

Planet GSW-1600HP Manuel utilisateur

Planet

Planet FNSW-1601 Manuel utilisateur

Planet

Planet WGSD-10020 Manuel utilisateur

Planet

Planet FGSW-2620 Manuel utilisateur

Planet

Planet WNAP-7335 Manuel utilisateur

Planet

Planet VC-23 Series Manuel utilisateur

Planet

Planet GS-4210 SERIES Manuel utilisateur

Planet

Planet VIP-280 Manuel utilisateur

Planet

Planet WNRT-617 Manuel utilisateur

Planet

Planet GRT-101 Manuel utilisateur

Planet

Planet VR-100 Series Manuel utilisateur

Planet

Planet ADSL 2/2+ VoIP Router IAD-200W Manuel utilisateur

Planet

Planet WNRT-625G Manuel utilisateur

Planet

Planet ADSL 2/2+ VPN Firewall Router ADW-4302A v2 Manuel utilisateur

Planet

Planet WGSW-2620PV Manuel utilisateur

Planet

Planet ADE-3410 Manuel utilisateur

Planet

Planet FGSW-2620VM Series Manuel utilisateur

Planet

Planet XRT-101A Manuel utilisateur

Planet

Planet GS-5220-48T4X Manuel utilisateur

Planet

Planet FNSW-3200 Manuel utilisateur

Planet

Planet ADE-4110 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
