ADSLModem Router

ADE-3100

User s Manual

The products and programs described in this User s Manual are licensed products of

PLANETTechnology,This User s Manual contains proprietaryinformation protected by

documentation are copyrighted.

No part ofthis User s Manual maybe copied, photocopied, reproduced, translated, or

reduced to anyelectronic medium or machine-readable form byanymeans byelectronic or

mechanical. Including photocopying, recording, or information storage and retrieval

systems, for anypurpose other than the purchaser's personal use, and without the prior

express written permission of PLANETTechnology.

Disclaimer

PLANETTechnology does not warrant that the hardware will work properlyin all

environments and applications, and makes no warrantyand representation, either implied

or expressed, with respect to the quality,performance, merchantability,or fitnessfora

particular purpose.

PLANEThas made everyeffort to ensure that this User s Manual is accurate; PLANET

disclaims liabilityfor anyinaccuracies or omissions that mayhave occurred.

Information in this User sManual is subject to change without notice and does not

represent acommitment on the part ofPLANET.PLANETassumes no responsibilityfor any

inaccuracies that maybe contained in this User sManual. PLANETmakes no commitment

to update or keep current the information inthis User sManual, and reserves the right to

make improvements to this User sManual and/or to the products described in this User s

Manual, at anytime without notice.

If you find information in this manual that is incorrect, misleading, or incomplete, we would

appreciate your commentsand suggestions.

FCC Compliance Statement

This equipment generates and uses radio frequencyenergyand ifnot installed and used

properly, that is, in strict accordance with the instructionsprovided with the equipment, may

cause interference to radio and TV communication. The equipment has been tested and

found to complywith the limits for a Class A computing device in accordance with the

specifications in Subpart B ofPart 15 ofFCC rules, which are designed to provide

reasonable protection against such interference in a residential installation. However, there

is no guarantee that interference will not occur in a particular installation. Ifyou suspect this

equipment is causing interference, turn your Ethernet Switch on and offwhile your radio or

TV is showing interference, ifthe interference disappears when you turn your Ethernet

Switch offand reappears when you turn it back on, there is interference being caused by

the Ethernet Switch.

You can tryto correct the interference byone or more ofthe following measures:

w Reorient the receiving radio or TV antenna where this maybe done safely.

w To the extent possible, relocate the radio, TV or other receiver awayfrom the Switch.

w Plug the Ethernet Switch into a different power outlet so that the Switch and the receiver

are on different branch circuits.

If necessary, you should consult the place ofpurchase or an experienced radio/television

technician for additional suggestions.

CE mark Warning

The is a class B device, In a domestic environment, this product maycause radio

interference, in which case the user maybe required to take adequate measures.

Trademarks

The PLANETlogo is a trademark ofPLANETTechnology.Thisdocumentation mayrefer to

numeroushardware and software productsbytheir trade names. In most, ifnot all cases,

these designationsare claimed as trademarksor registered trademarks bytheir respective

companies.

Revision

User s Manual for PLANETADSLModem Router:

Model: ADE-3100A/ADE-3100B

Rev: 2.0 (Nov2004)

Part No.: EM-ADE3100v2

TABLE OF CONTENTS

1. Introduction............................................................................................................1

1.1 Features..........................................................................................................1

1.2 System Requirements.....................................................................................1

2. Knowing Your Router.............................................................................................2

2.1 Front Panels....................................................................................................2

2.2 Rear Panels....................................................................................................2

2.3 LED Indicators.................................................................................................2

3. Login.......................................................................................................................3

4. Status Pages...........................................................................................................4

4.1 Home Page.....................................................................................................4

4.2 PPPPage........................................................................................................5

4.3 ADSLPage......................................................................................................7

5. Configuration Pages..............................................................................................1

5.1 Modes.............................................................................................................1

5.2 WAN Configuration..........................................................................................2

5.2.1 ATM.......................................................................................................3

5.2.2 DHCPClient..........................................................................................5

5.2.3 MAC Spoofing.......................................................................................5

5.2.4 Static IPSettings...................................................................................5

5.3 LAN Configuration...........................................................................................1

5.3.1 DHCPServer........................................................................................1

5.3.2 Ethernet Mode Setting..........................................................................2

5.4 PPPConfiguration...........................................................................................3

5.4.1 PPPAccount Configuration...................................................................3

5.4.2 PPPSession Configuration...................................................................4

5.4.3 PPPDisconnect Timer Configuration....................................................6

5.4.4 PPPMiscellaneous Configuration.........................................................8

5.5 NATConfiguration Pages................................................................................9

5.6 Virtual Server Configuration..........................................................................11

5.7 Bridge Filtering..............................................................................................12

5.8 DNS Configuration........................................................................................13

5.9 User Password Configuration........................................................................14

5.10 Save Settings / Reboot...............................................................................15

6. Admin Privilege....................................................................................................17

6.1 WAN Status...................................................................................................17

6.2 ATM Status....................................................................................................17

6.3 ADSLConfiguration.......................................................................................18

6.4 Route Table...................................................................................................19

6.4.1 System Default GatewayConfiguration..............................................20

6.4.2 Route Configuration............................................................................20

6.5 Learned MAC Table......................................................................................21

6.6 RIPConfiguration..........................................................................................21

6.6.1 RIPPer Interface Configuration..........................................................23

6.7 Miscellaneous Configuration.........................................................................24

6.8 TCPStatus....................................................................................................26

6.9 Admin Password Configuration.....................................................................27

6.10 Reset to FactoryDefault.............................................................................27

6.11 Diagnostic Test............................................................................................28

6.12 System Log.................................................................................................28

6.13 Local Code Image Update...........................................................................29

APPENDIX A. COMPLIANCE STATEMENT 30

APPENDIX B. ENCAPSULATION MODE 30

APPENDIX C. TROUBLESHOOTING 30

APPENDIX D. SPECIFICATIONS 33

1. Introduction

This Router is a highlyintegrated, cost-effective solution. All setup and provisioning is

accomplished via a simple intuitiveWeb interface which further enhances the user

experience.

1.1 Features

l ADSLCompliance

n Compliant with ADSLstandards

u Full-rate ANSI T1.413 Issue 2 and ITU G.dmt (G.992.1) standards

u Splitterless ITU G.lite (G.992.2) specification

u ADSLover POTS (AnnexA) and ADSLover ISDN (AnnexB)

n DMTmodulation and demodulation

n Full-rate adaptive modem

u Maximum downstream rate of 8 Mbps

u Maximum upstream rate of1 Mbps

l ATM Protocols

n WANmode support: PPPover ATM (RFC 2364) and PPPover Ethernet (RFC

2516)

n LAN mode support: bridged/routed Ethernet over ATM (RFC 1483) and

Classical IPover ATM (RFC 1577)

n ATM Forum UNI 3.1/4.0 PVC

n Up to 8 VCs (Virtual Circuits)

l Bridge Mode

n Ethernet to ADSLself-learning Transparent Bridging (IEEE 802.1D)

n Supports up to 128 MAC learning addresses

l Router Mode

n IProuting–RIPv2

n Static routing

n DHCP(Dynamic Host Configuration Protocol) Server and Client

n NAPT(Network Address and Port Translation)

n NAT(Network Address Translation)

n ICMP(Internet Control Message Protocol)

l Security

n User authentication forPPP

n PAP(Password Authentication Protocol)

n CHAP(Challenge Authentication Protocol)

n Password protected system management

1.2 System Requirements

l Pentium III 266 MHzprocessor minimum

l 128 MB RAM minimum

l 20 MB offree disk space minimum

l Ethernet Network Interface Controller (NIC) RJ45 Port

l Internet Browser

l Ethernet (CAT5) Cable

2. Knowing Your Router

When selecting the location for the Router, allowroom to accessthe connectionson the

rear panel. You will want to place the Router so that you will be able to see the LED

indicators on the front panel. It maybe convenient for you locate the Router near the PC

you intend to use for initial configuration of the Router.

2.1 Front Panels

Place the Router in a location that permits an easyviewofthe LED indicators shown in

the front panel diagram below.

READY

PWR

ADSL

ACT

LNK ADSL Modem Router

ADE-3100

WAN

LAN

2.2 Rear Panels

The rear panel ofthe Router provides access to the power adapter cord connection as

well as the port connections.

VAC

RESET

LANADSL

RESET button: This button has two (2) functions:

1. When pressed and released, ADE-3100 will reboot (restart).

2. When reset button is pressed over 10 seconds and then release. ALLdata will be

clear and restoreALLsettings to the factorydefault values.

2.3 LED Indicators

LEDs Color

Active

Description

PWRGreen

ON The power adaptor is connected to the

Modem.

READY Green

Blink The system is readyto use.

ADSL

Green

ON ADSLconnection is established.

TXGreen

Blink Transmitting data via ADSLlink.

WAN

RX Orange

Blink Receiving data via ADSLlink.

LNK

Green

ON The Ethernet connection is established.

LAN

ACT

Green

Blink Transmitting data or receiving data over

Ethernet link.

3. Login

There are two levels of access rights/privileges for the Router:

l Administrator: User name admin, the administrator account hascomplete

read/write access on all pages (Status, Configuration, Admin Privilege, and Firewall

Configuration). Admin account also hasFTPserver access.

l User: User name user, the User account has read/write access to pages under the

Status and Configuration sections.

The following stepswill enable you to log into the Router:

1. Launch the Web browser (Internet Explorer, Netscape, etc.).

2. Enter the LAN port default IPaddress (default gateway) http://10.0.0.2 in the address

bar.

3. Entryof the username and password will be prompted. Enter the default login User

Name and Password:

The default login User Name ofthe administrator is admin, and the default login Password

is epicrouter.The default login User Name for the non-administrator is user, and the

default login Password is password.

4. Remember mypassword checkbox: Bydefault, this boxis not checked. Users can

check this boxso that Internet Explorer will remember the User name and Password

for future logins. It is recommended to leave this boxunchecked for securitypurposes.

Admin and User passwords can be changed after login. Refer to Section 5.9 for User

Password configuration and Section 6.9 for Admin Password configuration for further

instruction.

4. Status Pages

The links under the Status column are associated with the pages that represent the status

ofsystem (computer and Router) and interfaces (connections). This includes LAN, WAN,

DHCP, PPP, and ADSL status. These pages can be viewed and modified byboth user and

admin accounts.

4.1 Home Page

The Home page shows the firmware versions; LAN, WAN, and DHCPinterface status;

and Ethernet connection status.

Firmware Version: It is the default version number, which is not changeable.

Customer Software Version: It is the version ofthe firmware that is controllable bythe

ADSLModem/Router manufacturer.

WAN and LAN: It displays the IPaddress, Subnet Mask and MAC address for the WAN

(ADSL) and LAN interface.

Total Number of LANInterfaces: It displays the total number of available interfaces for

the LAN interface. The total number of available interfaces is the amount ofcomputers

that are able to hook up to the DHCPServer.

Number of Ethernet Devices Connected to the DHCPServer: It displays the DHCP

client table with the assigned IPaddresses and MAC addresses.

If there are no devicesconnected to the DHCPserver, then a table will not

appear, otherwise a table listing all devicesconnected to DHCPserver will appear on

the bottomof the page.

Ethernet Link Status: It displays the link up or down for the Ethernet connection (up if

connected, down ifnot connected).

USB Link Status (reserved function): It displays the link up or down for the USB

connection (up ifconnected, down ifnot connected).

4.2 PPPPage

The PPPStatus page shows the status of each PPPsession for each PPPinterface.

This page containsinformation that is dynamic and will refresh every8 seconds.

PPPinterfaces can be created, modified, and deleted in the PPPConfiguration

page. Refer to Section 5.4 for further information.

PPP(Point-to-Point Protocol): The table displays the following fields:

l Connection Name: This is user defined. User defined connectionsfor PPPcan

be created in PPPConfiguration page.

l Interface: States the interface that is being used (PVC0 ... PVC7).

l Mode: There are two available modes for the connection:

PPPover Ethernet (PPPoE)

PPPover ATM (PPPoA)

l Status: StateswhetherPPPconnection is Connected or Not Connected.

l Packets Sent: Number ofpackets sent bya particular PPPConnection.

l Packets Received: Number of packets received bya particular PPPConnection.

Autres manuels pour ADE-3100

Table des matières

Autres manuels Planet Routeur réseau

Planet

Planet GSD-800S Manuel utilisateur

Planet

Planet IGS-5225-16T4S Manuel utilisateur

Planet

Planet WNRT-625G Manuel utilisateur

Planet

Planet FGSW-2624SF Series Manuel utilisateur

Planet

Planet SOHOConnect Series Manuel utilisateur

Planet

Planet FGSW-2620 Manuel utilisateur

Planet

Planet ADSL 2/2+ VPN Firewall Router ADW-4302A v2 Manuel utilisateur

Planet

Planet FSD-401ST Manuel utilisateur

Planet

Planet ADE-3400 Manuel utilisateur

Planet

Planet ADSL 2/2+ Router with USB Port ADE-3410v2 Manuel utilisateur

Planet

Planet WBS-900AC-KIT Manuel utilisateur

Planet

Planet ADE-4400 Manuel utilisateur

Planet

Planet ADSL 2/2+ VPN Firewall Router ADE-4300A/B Manuel utilisateur

Planet

Planet ADN-4101 Manuel utilisateur

Planet

Planet IGS-20040MT Manuel utilisateur

Planet

Planet VC-230 Manuel utilisateur

Planet

Planet MGSW-28240F Manuel utilisateur

Planet

Planet gsd-1002vhp Manuel utilisateur

Planet

Planet 85M Powerline Ethernet PL-201-UK/US Manuel utilisateur

Planet

Planet VC-23 Series Manuel utilisateur

Planet

Planet ERT-805 Manuel utilisateur

Planet

Planet FNSW-2400PS Manuel utilisateur

Planet

Planet IVR-100 Series Manuel utilisateur

Planet

Planet XRT-101A Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
