PDP67 F 4 code
Operating Manual 1001531-EN-06
}Decentralised periphery
Preface
This document is a translation of the original document.
All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made
for internal purposes. Suggestions and comments for improving this documentation will be
gratefully received.
Pilz®, PIT®, PMI®, PNOZ®, Primo®, PSEN®, PSS®, PVIS®, SafetyBUS p®,
SafetyEYE®, SafetyNET p®, the spirit of safety® are registered and protected trademarks
of Pilz GmbH & Co. KG in some countries.
SD means Secure Digital
Contents
Operating Manual PDP67 F 4 code
1001531-EN-06 3
Section 1 Introduction 5
1.1 Validity of documentation 5
1.1.1 Retaining the documentation 5
1.2 Using the documentation 5
1.3 Definition of symbols 5
Section 2 Overview 7
2.1 Unit structure 7
2.1.1 Range 7
2.1.2 Unit features 7
2.2 Front view 8
Section 3 Safety 9
3.1 Intended use 9
3.2 Safety regulations 9
3.2.1 Use of qualified personnel 9
3.2.2 Warranty and liability 9
3.2.3 Disposal 10
Section 4 Function description 11
4.1 Operation 11
4.1.1 Internal wiring diagram 11
4.1.2 Diagnostics 11
Section 5 Installation 12
5.1 General installation guidelines 12
5.1.1 Dimensions 12
Section 6 Wiring 13
6.1 General wiring guidelines 13
6.2 Assignment of female connectors 13
Section 7 Preparing for operation 15
7.1 Connection 15
7.1.1 Independent circuit 15
7.1.1.1 Examples of independent circuit 16
7.1.2 Series connection of modules 17
7.1.2.1 Examples of series connection 18
7.1.2.2 Voltage drop 19
Section 8 Operation 21
8.1 Messages 21
8.1.1 Display elements for device diagnostics 21
Section 9 Technical details 22
Section 10 Order reference 24
Contents
Operating Manual PDP67 F 4 code
1001531-EN-06 4
10.1 Order reference for module 24
10.2 Order reference for accessories 24
Section 11 EC declaration of conformity 25
Introduction
Operating Manual PDP67 F 4 code
1001531-EN-06 5
1 Introduction
1.1 Validity of documentation
This documentation is valid for the products PDP67 F 4 code, PDP67 F 4 codeVA. It is
valid until new documentation is published.
This operating manual explains the function and operation, describes the installation and
provides guidelines on how to connect the product.
1.1.1 Retaining the documentation
This documentation is intended for instruction and should be retained for future reference.
1.2 Using the documentation
This document is intended for instruction. Only install and commission the product if you
have read and understood this document. The document should be retained for future ref-
erence.
1.3 Definition of symbols
Information that is particularly important is identified as follows:
DANGER!
This warning must be heeded! It warns of a hazardous situation that poses
an immediate threat of serious injury and death and indicates preventive
measures that can be taken.
WARNING!
This warning must be heeded! It warns of a hazardous situation that could
lead to serious injury and death and indicates preventive measures that can
be taken.
CAUTION!
This refers to a hazard that can lead to a less serious or minor injury plus
material damage, and also provides information on preventive measures
that can be taken.
Introduction
Operating Manual PDP67 F 4 code
1001531-EN-06 6
NOTICE
This describes a situation in which the product or devices could be dam-
aged and also provides information on preventive measures that can be
taken. It also highlights areas within the text that are of particular import-
ance.
INFORMATION
This gives advice on applications and provides information on special fea-
tures.
Overview
Operating Manual PDP67 F 4 code
1001531-EN-06 7
2 Overview
2.1 Unit structure
2.1.1 Range
}Module PDP67 F 4 code/PDP67 F 4 codeVA
}1 Adapter PDP67Connectorcs/PDP67ConnectorcsVA for connecting the supply
voltage for the module and sensors
}5 labels
}4 blind plugs for sealing unused female connectors
2.1.2 Unit features
Application of the products PDP67 F 4 code, PDP67 F 4 codeVA:
Decentralised passive distributor for use in rugged industrial environments up to protection
type IP67 for connecting PSENcode, PSENslock and PSENini sensors to a Pilz control sys-
tem.
The product has the following features:
}Protection type IP67
}M12 female connectors
}A maximum of 4 sensors can be connected to each module
}Female connectors for series connection
}LED indicator for:
– Supply voltage
– Status of sensors
Overview
Operating Manual PDP67 F 4 code
1001531-EN-06 8
2.2 Front view
Key:
}X1 ... X4:
Female connectors for connecting the sensors
}X5:
Female connectors for connecting to the evaluation device (for connecting the sensors
to X1 ... X4)
}X6:
Female connectors for connecting signal outputs (Diag) and inputs for control com-
mands for magnetic guard locking (Lock)
}LEDs:
– Power
– Diag
– Lock
Safety
Operating Manual PDP67 F 4 code
1001531-EN-06 9
3 Safety
3.1 Intended use
Decentralised passive distributor for use in rugged industrial environments up to protection
type IP67 for connecting PSENcode, PSENslock and PSENini sensors to a Pilz control sys-
tem.
The following is deemed improper use in particular:
}Any component, technical or electrical modification to the product
}Use of the product outside the areas described in this manual
}Use of the product outside the technical details (see Technical details).
NOTICE
EMC-compliant electrical installation
The product is designed for use in an industrial environment. The product
may cause interference if installed in other environments. If installed in other
environments, measures should be taken to comply with the applicable
standards and directives for the respective installation site with regard to in-
terference.
3.2 Safety regulations
3.2.1 Use of qualified personnel
The products may only be assembled, installed, programmed, commissioned, operated,
maintained and decommissioned by competent persons.
A competent person is someone who, because of their training, experience and current pro-
fessional activity, has the specialist knowledge required to test, assess and operate the
work equipment, devices, systems, plant and machinery in accordance with the general
standards and guidelines for safety technology.
It is the company’s responsibility only to employ personnel who:
}Are familiar with the basic regulations concerning health and safety / accident preven-
tion
}Have read and understood the information provided in this description under "Safety"
}And have a good knowledge of the generic and specialist standards applicable to the
specific application.
3.2.2 Warranty and liability
All claims to warranty and liability will be rendered invalid if
}The product was used contrary to the purpose for which it is intended
}Damage can be attributed to not having followed the guidelines in the manual
}Operating personnel are not suitably qualified
Safety
Operating Manual PDP67 F 4 code
1001531-EN-06 10
}Any type of modification has been made (e.g. exchanging components on the PCB
boards, soldering work etc.).
3.2.3 Disposal
}When decommissioning, please comply with local regulations regarding the disposal of
electronic devices (e.g. Electrical and Electronic Equipment Act).
