41/43-182B User Manual

PXI/PXIe 6 GHz Solid State Attenuator Modules

Issue 1.1 October 2022

Page (II) PXI/PXIe 6GHz Solid State Attenuator Module 41/43-182B

pickering

Page (II) REED RELAY MODULE 40-110/115/120/125

pickering

No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by

any means without the written permission of Pickering Interfaces.

Technical details contained within this publication are subject to change without notice.

ISO 9001

Reg No. FM38792

Page (III)

PXI/PXIe 6GHz Solid State Attenuator Module 41/43-182B

pickering

Page (III)

REED RELAY MODULE 40-110/115/120/125

pickering

TECHNICAL SUPPORT

For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.

WARRANTY

All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of

three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be

defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.

Products serviced and repaired outside of the warranty period are warranted for ninety days.

Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.

ENVIRONMENTAL POLICY

Pickering Interfaces operates under an environmental management system similar to ISO 14001.

Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the

environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and

safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can

be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

Worldwide Technical Support and Product Information

pickeringtest.com

Germany

Tel: +49 89 125 953 160

E-mail: [email protected]

Sweden

Tel: +46 340-69 06 69

E-mail: [email protected]

USA

Tel: (West) +1 541 471 0700

Tel: (East) +1 781 897 1710

E-mail: [email protected]

Czech Republic

Tel: +420 558 987 613

E-mail: [email protected]

France

Tel +33 9 72 58 77 00

E-mail [email protected]

Pickering Interfaces Headquarters

Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom

Tel: +44 (0)1255-687900

E-Mail: [email protected]

China

Tel: +86 4008 799 765

E-mail: [email protected]

Page (IV) PXI/PXIe 6GHz Solid State Attenuator Module 41/43-182B

pickering

Page (IV) REED RELAY MODULE 40-110/115/120/125

pickering

MEANING / DESCRIPTION SYMBOL

PROTECTIVE EARTH (GROUND)

To identify any terminal which is intended for connection to an external conductor for

protection against electric shock in case of a fault, or the terminal of a protective earth

(ground) electrode.

DANGEROUS VOLTAGE

To indicate hazards arising from dangerous voltages.

WARNING / CAUTION

An appropriate safety instruction should be followed or caution to a potential hazard

exists.

Refer to the relevant instructions detailed within the product manual.

HEAVY

If this product is heavy reference should be made to the safety instructions for

provisions of lifting and moving.

STATIC SENSITIVE

To indicate that static sensitive devices are present and handling precautions should

be followed.

SAFETY SYMBOLS

PRODUCT SAFETY

The following safety symbols may be used on the product and throughout the product documentation.

Page (V)

PXI/PXIe 6GHz Solid State Attenuator Module 41/43-182B

pickering

Technical Support and Warranty................................................III

Product Safety .............................................................................IV

Contents (this page)....................................................................V

Warnings and Cautions ..............................................................VII

Section 1

Technical Specication...............................................................1.1

Section 2

Technical Description .................................................................2.1

Functional Description..........................................................2.1

Section 3

Installation....................................................................................3.1

Pre Operation Checks...........................................................3.1

Hardware Installation ............................................................3.2

Software Installation .............................................................3.2

Section 4

Programming Guide....................................................................4.1

Programming Options For Pickering PXI/PXIe Modules ...4.1

Module Architecture..............................................................4.2

Programming The Module ....................................................4.3

Using Pickering Drivers in LabVIEW ...................................4.5

Programmable Attenuator Soft Front Panel .......................4.6

Section 5

Connector Information................................................................5.1

Section 6

Trouble Shooting .........................................................................6.1

Section 7

Maintenance Information............................................................7.1

CONTENTS

Page (VI) PXI/PXIe 6GHz Solid State Attenuator Module 41/43-182B

pickering

THIS PAGE INTENTIONALLY BLANK

Page (VII)

PXI/PXIe 6GHz Solid State Attenuator Module 41/43-182B

pickering

Page (VII)

2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

WARNINGS AND CAUTIONS

WARNING - HAZARDOUS ENVIRONMENTS SYMBOL

This product is not specically designed for use in hazardous environments, for example in explosive

atmospheres. If the product is to be used in hazardous environments we recommend that the user

ensures suitable protective measures are taken.

WARNING - DANGER OF ELECTRIC SHOCK SYMBOL

This module may contain hazardous voltages. Before removing the module from the rack remove all

supplies and disconnect user I/O signals.

Unused slots in the host chassis are populated with blanking plates to prevent access to user I/O

signals that may be present. Blanking panels are available to order from Pickering in a variety of

slot widths. If the product is not used in this manner for example by using an extender card then

additional care must be taken to avoid contact with exposed signals.

Not to be used in safety critical circuits, refer to the Pickering Interfaces’ terms & conditions of sale.

This module must not be used for the switching of Mains Circuits. For the switching of voltages up

to the module’s full specication, Secondary Circuit power supplies and the Device Under Test must

be fully isolated from the Mains Circuit and the safety earth.

The host chassis must be correctly installed and be connected to mains or factory safety ground,

please refer to your chassis installation manual.

Diagram Showing Separation Between The Mains Circuit and Secondary Circuit / DUT

For the purposes of this document, a Mains Circuit is an installation classied as Overvoltage

Category II up to 300V. Separation between the Secondary Circuit and Mains Circuit is achieved

by a transformer in which the primary windings are separated from the secondary windings by

reinforced insulation, double insulation, or a screen connected to the protective conductor terminal.

CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL

Certain semiconductor devices used in this equipment are liable to damage due to static voltage.

Observe the following precautions when handling these devices in their unterminated state, or

sub-assemblies containing these devices:

1. Persons removing sub-assemblies from equipment using these devices must be earthed by a

wrist strap and a resistor at the point provided on the equipment.

2. Soldering irons used during the repair operations must be low voltage types with earthed tips and

isolated from the mains voltage by a double insulated transformer.

3. Outer clothing worn must be unable to generate static charges.

4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in

anti-static bags.

PXI Switching

Module

Device

Under Test

Power

Supply

Power

Supply

Host Chassis

Secondary Circuit

Mains

Circuit

Mains

Circuit

Mains/Factory

Safety Ground

Page (VIII) PXI/PXIe 6GHz Solid State Attenuator Module 41/43-182B

pickering

Page (VIII) 2 AMP 1-POLE UHD MATRIX MODULES 40-575 / 576 / 577 / 578 / 579

pickering

CAUTION - PRODUCT DOCUMENTATION SYMBOL

Suitably qualied & trained users should ensure that the accompanying documentation is fully read

and understood before attempting to install or operate the product.

SAFETY INSTRUCTIONS

All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O

signals (refer to the Maintenance Section).

• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or

the combined weight of the modules & chassis.

• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the

chassis and the user I/O signals.

• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.

• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on

the front of the unit.

Page 1.1

PXI/PXIe 6GHz Solid State Attenuator Module 41/43-182B

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI/PXIe 6 GHz Solid State Attenuators 41/43-182B

ISSUE 1.1 OCT 2022

yAvailable as PXI or PXIe Modules

y10 MHz To 6 GHz Programmable Attenuator

y0 to 31.75 dB in 0.25 dB Steps For Fine

Level Control

yThree or Six Channels Per Module

ySolid State Switching For Long Service Life

yRobust SMA Connectors

yVISA, IVI & Kernel Drivers Supplied for

Windows

yPXI Versions Supported in PXI or

LXI Chassis

y3 Year Warranty

1dB 2dB 4dB 8dB0.5dB 16dB0.25dB

ATTENUATOR 1

1dB 2dB 4dB 8dB0.5dB 16dB0.25dB

ATTENUATOR 2

1dB 2dB 4dB 8dB0.5dB 16dB0.25dB

ATTENUATOR 3

41/43-182B Triple 6 GHz Solid State Attenuator Functional Diagram

(Default Condition Shown - All Channels Set To 0 dB Attenuation)

The 41-182B (PXI) and 43-182B (PXIe) are programmable

RF attenuator modules with 3 (in one slot) or 6 (in two

slots) channels each capable of inserting a signal loss of

0 to 31.75 dB in 0.25 dB steps. The attenuator uses solid

state switches for a long service life and fast operation

with minimum settling time and no bounce. DC blocking

reduces the risk of damage by the accidental application of

DC sources from ampliﬁers or other bias devices.

The 41/43-182B is ideal for conditioning signal levels in

RF test systems to ensure equipment is used in its optimal

range. Fast operating speed ensures minimal delays in

setting up the required attenuation. Long service life

independent of the number of operations allows RF test

sequences to be arranged to optimize the life of other

switching components in the system.

The attenuator channels can be connected in series to

increase the attenuation range available and high isolation

minimizes signal leakage.

The attenuator can be used for back to back testing,

providing the ability to condition the signal level between

devices. It is also ideal for the conditioning of special to

type signal sources which lack ﬁne level control.

SMA connectors ensure that the attenuators can be used

with standard cabling and the input and output ports are

fully interchangeable.

Page 1.2 PXI/PXIe 6GHz Solid State Attenuator Module 41/43-182B

pickering

SECTION 1 - TECHNICAL SPECIFICATION

6 GHz Solid State Attenuator, 41/43-182B

pickeringtest.com

Speciﬁcations

Insertion loss for every discrete attenuator setting

for all channels of 41/43-182B-003 (normalized to 0 dB)

Insertion loss for 41/43-182B-003 with

each attenuator channel set to 0 dB

VSWR for 41/43-182B-003

with all attenuator channels set to 0 dB

Attenuation values for 41/43-182B-003

with three attenuator channels in series

(set to major step values)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Pickering Unité de contrôle

Pickering

Pickering Module Manuel utilisateur

Pickering

Pickering Pxi 41-182A Manuel utilisateur

Pickering

Pickering 40-518A Manuel utilisateur

Pickering

Pickering 41-761 Manuel utilisateur

Pickering

Pickering PXI 40-785 Manuel utilisateur

Pickering

Pickering 40-519A Manuel utilisateur

Pickering

Pickering 4 890 Series Manuel utilisateur

Pickering

Pickering 41-735 Manuel utilisateur

Pickering

Pickering 45-542 Manuel utilisateur

Pickering

Pickering 40-575 Manuel utilisateur

Pickering

Pickering 40-280 Manuel utilisateur

Pickering

Pickering PXI BRIC 40-595A Manuel utilisateur

Pickering

Pickering PXI BRIC 40-569B Manuel utilisateur

Pickering

Pickering 40-870 Manuel utilisateur

Pickering

Pickering 40-650A Manuel utilisateur

Pickering

Pickering 40-582 Manuel utilisateur

Pickering

Pickering PXI BRIC 40-569 Manuel utilisateur

Pickering

Pickering Pxi 41-660 Manuel utilisateur

Pickering

Pickering PXI 40-795-001 Manuel utilisateur

Pickering

Pickering PXI 40-535 Manuel utilisateur

Pickering

Pickering 4x-727A Manuel utilisateur

Pickering

Pickering 40-540 Manuel utilisateur

Pickering

Pickering 40-561A Manuel utilisateur

Pickering

Pickering 40-565A Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
