Page 1.1

VERY HIGH DENSITY MULTIPLEXER MODULE 40-670A

pickering SECTION 1 - TECHNICAL SPECIFICATION

SECTION 1 - TECHNICAL SPECIFICATION

pickeringtest.com

PXI Very High Density Multiplexer Module 40-670A

ISSUE 11.1 APR 2023

Supported by

eBIRST

These test tools simplify fault-ﬁnding by quickly testing the

system and graphically identifying the faulty relay.

For more information go to: pickeringtest.com/ebirst

yVery High Density Multiplexer

yUp to 198 Switch Pins Available with 1, 2, 4, 8, 16

or 32-Pole Switching Formats

yAll Versions Use High Reliability Pickering

Reed Relays

yFast Operating Speed 500µs Typical per Relay

ySwitch up to 150 VDC/100 VAC, 0.5 A with

10 W Max Power

yAutomatic Isolation Switches Reduce Capacitive

Loading in Large Systems

yDrivers Supplied for Windows & Linux,

Plus Support for Real-time Systems

ySupported by PXI or LXI Chassis

ySupported by

eBIRST

™

y3 Year Warranty

Com

Isolation

Switch

198

40-670A-022 198-Channel 1-Pole Multiplexer

The 40-670A module features a wide range of multiplexer

conﬁgurations based on high performance ruthenium reed

relays. Typical applications include signal routing in ATE

and data acquisition systems. User connections are via a

front panel 200-pin socket.

40-670A Very High Density Multiplexer Range:

198-Channel, 1-Pole (with isolation switching)

99-Channel, 2-Pole (with isolation switching)

99-Channel, 1-Pole (with isolation switching)

49-Channel, 4-Pole (with isolation switching)

49-Channel, 2-Pole (with isolation switching)

24-Channel, 8-Pole (with isolation switching)

24-Channel, 4-Pole (with isolation switching)

10-Channel, 16-Pole (no isolation switching)

10-Channel, 8-Pole (no isolation switching)

5-Channel, 32-Pole (no isolation switching)

5-Channel, 16-Pole (no isolation switching)

The majority of 40-670A models (see order codes)

allow multiple channels to be simultaneously selected.

Alternatively, product variants can be supplied that operate

as a conventional multiplexer with break-before-make

action when a new channel is selected.

Note: The multiple channel selection option is not available

for the 40-670A-022-198/1 multiplexer.

Versions with automatic isolation switching (see range

table above) connect only the active multiplexer bank to

the common terminal, thereby keeping capacitive loading

and leakage currents in large multiplexer systems to a

minimum. Larger multiplexers may be constructed by

daisy chaining the common signals from multiple modules.

(Multiple channel selection not available for this version)

Front Panel Connector

This product is based on the obsolete Molex LFH series

connector that has been superseded by a Pickering

commissioned form, ﬁt, function equivalent. The new

connector series is 100% compatible with the Molex

connectors allowing either gender of Pickering connector

to mate with the corresponding Molex part without issue.

Page 1.2 VERY HIGH DENSITY MULTIPLEXER MODULE 40-670A

pickering

SECTION 1 - TECHNICAL SPECIFICATION

Very High Density Multiplexer, 40-670A

pickeringtest.com

Overview

40-670A-022 99-Channel 2-Pole Multiplexer

1.1

2.1

Com 1

49.1

Isolation

Switch

1.2

2.2

Com 2

49.2

1.3

2.3

Com 3

49.3

1.4

2.4

Com 4

49.4

40-670A-022 49-Channel 4-Pole Multiplexer

1.1

2.1

Com 1

99.1

Isolation

Switch

1.2

2.2

Com 2

99.2

1.1

1.25

Com 1

5.1

1.2

1.26

Com 2

5.2

1.3

1.27

Com 3

5.3

1.4

1.28

Com 4

5.4

1.5

1.29

Com 5

5.5

1.6

1.30

Com 6

5.6

1.7

1.31

Com 7

5.7

1.8

1.32

Com 8

5.8

Com 25

Com 26

Com 27

Com 28

Com 29

Com 30

Com 31

Com 32

5.25

5.26

5.27

5.28

5.29

5.30

5.31

5.32

CHANNEL 1CHANNEL 5

40-670A-022 5-Channel 32-Pole Multiplexer40-670A-022 10-Channel 16-Pole Multiplexer

1.1

1.9

Com 1

10.1

1.2

1.10

Com 2

10.2

1.3

1.11

Com 3

10.3

1.4

1.12

Com 4

10.4

1.5

1.13

Com 5

10.5

1.6

1.14

Com 6

10.6

1.7

1.15

Com 7

10.7

1.8

1.16

Com 8

10.8

Com 9

Com 10

Com 11

Com 12

Com 13

Com 14

Com 15

Com 16

10.9

10.10

10.11

10.12

10.13

10.14

10.15

10.16

CHANNEL 1CHANNEL 10

Table des matières

Autres manuels Pickering Unité de contrôle

Pickering

Pickering PXI 60-104 Manuel utilisateur

Pickering

Pickering 40-534 Manuel utilisateur

Pickering

Pickering 40-290-021 Manuel utilisateur

Pickering

Pickering 40-296 Manuel utilisateur

Pickering

Pickering PXI 40-510 Manuel utilisateur

Pickering

Pickering PXI BRIC 40-562A Manuel utilisateur

Pickering

Pickering 40-540 Manuel utilisateur

Pickering

Pickering 40-553A Manuel utilisateur

Pickering

Pickering PXI 40-710 Manuel utilisateur

Pickering

Pickering 40-522 Manuel utilisateur

Pickering

Pickering PXI 40-597 Manuel utilisateur

Pickering

Pickering 40-580 Manuel utilisateur

Pickering

Pickering PXI BRIC 40-569 Manuel utilisateur

Pickering

Pickering 45-541 Manuel utilisateur

Pickering

Pickering 40-170 Manuel utilisateur

Pickering

Pickering 4x-585A Manuel utilisateur

Pickering

Pickering 40-592A Manuel utilisateur

Pickering

Pickering PXI BRIC 40-595A Manuel utilisateur

Pickering

Pickering SYSTEM 10 Manuel utilisateur

Pickering

Pickering BRIC 40-565B Manuel utilisateur

Pickering

Pickering 41-180 Manuel utilisateur

Pickering

Pickering 40-575 Manuel utilisateur

Pickering

Pickering 40-280 Manuel utilisateur

Pickering

Pickering 41-760 Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
