Phonak Slim™L-R

User Guide

Phonak Slim L-R

Phonak Slim L-R Trial

Phonak Slim Charger

2 3

Your hearing aid and charger details

Hearing aid models Earpieces

cPhonak Slim L-R (L90/L70/L50/L30) cDome

cPhonak Slim L-R Trial cSlimTip

      

Charging accessory

cPhonak Slim Charger

incl. USB cable (< 3m)

If no box is checked and you do not know the

model of your hearing aid or charging accessories,

please ask your hearing care professional.

The hearing aids described in this user guide

contain a built-in and non-removable rechargeable

lithium-ion battery.

Please also read safety information regarding

handling rechargeable hearing aids (chapter 24).

Wireless hearing aids

Phonak Slim L90-R

Phonak Slim L70-R

Phonak Slim L50-R

Phonak Slim L30-R

Phonak Slim L-R Trial

Charging accessory

Phonak Slim Charger

This user guide is valid for:

Note that instructions for the

activity tracking functions can

be found in the myPhonak app

user guide.

4 5

Your hearing aids and chargers have been developed by

Phonak – a world leader in hearing solutions based in

Zurich, Switzerland. These premium products are the

result of decades of research and expertise and are

designed with your well-being in mind. We thank you for

making such a great choice and wish you many years of

listening pleasure.

Please read the user guide carefully to make sure that you

understand and get the best out of your device. Training

is not required for handling of this device. A hearing care

professional will help set up this device according to your

individual preferences during the tting consultation.

For more information regarding features, benets, set up,

use, maintenance or repairs of your hearing aid and

accessories, please contact your hearing care professional

or the manufacturer representative. Additional

information can be found in the datasheet of your

product.

Phonak - life is on

www.phonak.com

Contents

Using the hearing aid

Your hearing aid and charger

1. Quick guide

Using the charger

2. Parts of the hearing aid and charger 9

3. Preparing the charger 11

4. Charging the hearing aids 12

5. Left and right hearing aid markings 18

6. Putting on the hearing aid 19

7. Removing the hearing aid 20

8. Multi-function button 21

9. On/O 22

10. Tap control (L90/L70) 23

11. Connectivity overview 24

12. MyPhonak App overview 25

13. Roger overview 26

14. Initial pairing 27

15. Phone calls 29

16. Flight mode 34

17. Rebooting your hearing aid 37

6 7

Further Information

18. Operating, transport and storage conditions 38

19. Care and maintenance 40

20. Exchanging the earwax protection 43

21. Service and warranty 54

22. Compliance information 56

23. Information and description ofsymbols 63

24. Troubleshooting 70

25. Important safety information 76

1. Quick guide

Left & right hearing aid markings

Charging your hearing aids

Lasered L marking for

left hearing aid.

Lasered R marking for

right hearing aid.

After placing your hearing aid

in the charger, the indicator

light on the hearing aid will

show the charging state of the

battery until it is fully charged.

When fully charged the

indicator light will be

constantly on, i.e. solid

green light.

Before using your hearing aid for the rst time, it is

recommended to charge it for 3 hours.

8 9

Multi-function button

The button has several functions.

It functions as an on/o switch,

a volume control and/or a program

change depending on the hearing aid

programming. This is indicated in your

individual instructions.

Phone calls: If paired with a Bluetooth® enabled phone, a

short press will accept and a long press will reject an incoming

call.

On/O: Firmly press the button until the indicator light blinks.

On: indicator light is solid green

O: indicator light is solid red

Enter ight mode: When device is o, press the lower part of

the button for 7 seconds until the solid orange light appears.

Then release the button.

Tap Control (L90/L70)

If paired with a Bluetooth® enabled device, multiple functions

can be accessed using Tap Control, please refer to chapter 10.

This is also indicated in your individual instructions. To use Tap

Control tap the top of your ear twice.

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth

SIG, Inc. and any use of such marks by Sonova AG is under license.

2. Parts of the hearing aid and

charger

The following pictures show the hearing aid model and

charger accessories described in this user guide. You can

identify your personal models by:

• checking “Your hearing aid and charger details” on

page 3.

• comparing your earpieces, hearing aid and charger with

the following models.

Charging contacts

Anchor (optional) Speaker

(without earpiece attached)

Multi-function button

Phonak Slim L-R

Phonak Slim L-R Trial

Tube

Possible earpieces

SlimTipDome

10 11

Phonak Slim Charger

USB-C

connection

to external

power supply

Indicator

light for

power

Hearing aid

charging

inserts

with left/

right

indicators

USB cable (< 3 m) Power supply

External power supply

a) Plug the larger end of

the charging cable into

the power supply.

b)Plug the smaller end

into the USB port on

the charger.

c) Plug the power supply

into a power outlet.

3. Preparing the charger

Connecting the power supply

a b

Power supply specication

Power supply input voltage:

Power supply output voltage

100-240 VAC, 50/60 Hz, current 0.25 A

5 VDC +/-10%, current 1 A

Charger input voltage 5 VDC +/-10%, current 500 mA

USB cable specications 5 V min. 1 A, USB-A to USB-C,

maximum length 3 m

d) The indicator light on the left side of the USB port will

light up green when the charger is connected to the

power outlet.

The Phonak Slim Charger may be used with an external

power supply that fullls the specications in the table

below:

12 13

4. Charging the hearing aids

Low power: You will hear two beeps when the

hearing aid battery is low. You will have

approximately 60 minutes before you have to

charge the hearing aids, after this time the hearing

aid automatically shuts down (this can vary,

depending on the hearing aid settings).

The hearing aid contains a built-in and non-

removable rechargeable lithium-ion battery.

Before using your hearing aid for the rst time, it

is recommended to charge it for 3 hours.

The hearing aid must be dry before charging,

see chapter 18.

Please ensure to charge and use the hearing aid

within operating temperature range: +5° to +40°

Celsius (41° to 104° Fahrenheit).

4.1 Using the Phonak Slim Charger

Please refer to chapter 3 for how to set up the charger.

Insert the hearing aids into the charging inserts.

Make sure the left and right hearing aid markings match

the left (L), right (R) indicators next to the charging

inserts. The hearing aids will automatically switch o once

inserted into the charger.

14 15

The hearing aid’s indicator light will show the charging

state of the battery until the hearing aid is fully charged.

When fully charged the indicator light will remain on,

i.e. solid green light.

The charging process will automatically stop when the

batteries are fully charged, so the hearing aids can be

safely left in the charger. It can take up to 3 hours to

charge the hearing aids. The charger lid can be closed

while charging.

Indicator lights while charging

Indicator light Charging state Approx. charging times

0 – 10%

11 – 80%

30 min (25%)

60 min (50%)

90 min (75%)

81 – 99%

100% 3 h

16 17

Remove the hearing aids from the charging inserts by

simply lifting them out of the charger.

Do not hold the tubes to remove the hearing aids

from the charger as this can damage the tubes.

Turn o your hearing aid before inserting it in the

disconnected charger to store it.

The hearing aid can be set to switch on automatically

when removed from the charger. The indicator light starts

blinking. The solid green light indicates the hearing aid is

ready for use. If you unplug the charger while the

hearing aid is charging inside, please make sure to turn

o the hearing aid to prevent discharge.

To switch o the charger, remove the power supply from

the power outlet.

18 19

5. Left & right hearing aid markings

There is a L / R marking on the bottom of the hearing aid

and a red or blue marking on the speaker. This will tell you

if it is a left or a right hearing aid.

L/Blue marking

for left hearing aid.

R/Red marking

for right hearing aid.

6. Putting on the hearing aid

Place the hearing aid behind

your ear.

Insert the earpiece into your

ear canal.

If there is an anchor attached

to the earpiece, tuck it into

the bowl of your ear to secure

your hearing aid.
