Phonak Standard and micro hearing systems Manuel utilisateur

Standard and micro hearing systems

User Guide

Manufacturer:

Phonak AG

Laubisrütistrasse 28

CH-8712 Stäfa

Switzerland

EU Representative:

Phonak GmbH

D-70736 Fellbach-Oefﬁngen

Germany

www.phonak.com 0459

029-1006-03/2010-08/A+W/FO Printed in Switzerland

2 3

1. Welcome 4

2. Important information:

Please read before operating your hearing

system for the ﬁrst time 6

Hazard warnings 6

Information on product safety 8

3. Hearing system description 10

4. Step-by-step instructions for using

the hearing system 15

Step 1. Getting to know your hearing system 15

Step 2. Battery preparation 18

Step 3. Inserting the battery 18

Step 4. Turning on the hearing system 19

Step 5. Inserting the hearing system 20

Step 6. Adjusting the volume control

behind the ear 26

Step 7. Selecting the hearing program

behind the ear 28

Contents

Step 8. Removing the hearing system 29

Step 9. Turning off the hearing system 31

Step 10. Changing the battery 32

Step 11. Changing the battery in hearing

systems with a secured battery compartment 32

5. Care and maintenance 34

6. Troubleshooting 36

7. Wireless accessories and FM systems 37

8. Service and warranty 39

9. Compliance information 40

10. Information and explanation of symbols 43

11. For US market only 46

4 5

1. Welcome

Your new hearing system is a premium Swiss quality

product. It was developed by Phonak, one of the

world‘s leading companies in hearing technology. Your

hearing system offers the most modern digital hearing

technology currently available on the market.

Please read these user instructions thoroughly in order

to beneﬁt from all the possibilities your new hearing

system has to offer. With proper use and care, you will

be able to enjoy your hearing system for many years

to come.

If you have any questions, please consult your hearing

care professional.

Phonak - life is on www.phonak.com

0459

6 7

Please read the information on the following pages

before using your hearing system.

A hearing system will not restore normal hearing

and will not prevent or improve a hearing impairment

resulting from organic conditions. Infrequent use

of a hearing system does not permit a user to attain

full beneﬁt from it. The use of a hearing system is

only part of hearing habilitation and may need to be

supplemented by auditory training and instruction

in lipreading.

2.1Hazard warnings

Use only hearing systems that have been specially

programmed for you by your hearing care professional.

Other systems may be ineffective and may, in

certain cases, damage your hearing.

Changes or modifications to the hearing system

that were not explicitly approved by Phonak are

not permitted. Such changes may damage your ear

or the hearing system.

2. Important safety information

Hearing system batteries are toxic if they are

swallowed! Keep out of reach of children and pets.

If batteries are swallowed, consult your physician

immediately!

If you feel pain in or behind your ear, if it is inﬂamed

or if skin irritation and accelerated accumulations

of ear wax occur, please check with your hearing care

professional or physician.

In very rare cases, the dome can remain in your ear

canal when removing the hearing tube from the

ear. In the unlikely case that the dome does get stuck

in your ear canal, it is strongly recommended to

see a physician for safe removal.

Hearing programs in the directional microphone

mode reduce background noises. Please be aware

that warning signals or noises coming from behind,

e. g. cars, are partially or entirely suppressed.

The hearing system contains small parts which can

be swallowed by children.

8 9

External devices may only be connected if they

have been tested in accordance with corresponding

IECXXXXX standards. Only use accessories approved

by Phonak AG.

2.2 Information on product safety

Never immerse your hearing system in water!

Protect it from excessive moisture. Always remove

your hearing system before showering, bathing,

or swimming.

Protect your hearing system from heat (never leave

it near a window or in the car.) Never use a micro-

wave or other heating devices to dry your hearing

system. Ask your hearing care professional about

suitable drying methods.

When you are not using your hearing system,

leave the battery compartment open so that any

moisture can evaporate. Make sure that you

always completely dry your hearing system after

use. Store the hearing system in a safe, dry and

clean place.

Do not drop your hearing system! Dropping onto a

hard surface can damage your hearing system.

Always use new batteries for your hearing system.

You can return used batteries to your hearing care

professional.

Remove the battery if you are not using your hearing

system for a long period of time.

X-ray radiation (e. g. CT scans, MRI scans) may

adversely affect the correct functioning of your

hearing systems. We recommend that you

remove them before undergoing X-ray procedures

and keep them outside the room.

Do not use your hearing system in areas where

electronic equipment is prohibited.

2. Important safety information

10 11

Standard model

Option A: with classic earmold

aRight or left indicator (right=red, left=blue),

placed in the battery compartment

bBattery compartment with ON/OFF switch

cVolume control

dProgram button

eMicrophone input with Wind and Weather Protector

fHook/sound output

gHearing tube

hClassic earmold

The following user instructions describe two hearing

system models: The standard and the micro hearing

system.

The standard and the micro hearing system can be

adapted with a variety of earmolds.

On the following pages use the labeled drawings to

identify the hearing system and the earmold that

you use.

Your hearing care professional will tell you what size

of battery you need for your hearing system.

3. Hearing system description

e f

12 13

Standard model

Option B: with dome Option C: with SlimTip

g Hearing tube

iEarmold: Dome

jRetention

kEarmold: SlimTip

lRemoval handle

micro model

Option A: with classic earnold

aRight or left indicator (right=red, left=blue),

placed in the battery compartment

bBattery compartment with ON/OFF switch

cProgram button

d Microphone input with Wind and Weather

Protector

e Hook/sound output

f Hearing tube

g Classic earmold

3. Hearing system description

14 15

micro model

Option B: with dome Option C: with SlimTip

f Hearing tube

hEarmold: Dome

iRetention

jEarmold: SlimTip

kRemoval handle

3. Hearing system description

The following chapter provides step-by-step instructions

on how to use your hearing system. Please follow

these steps carefully. In the drawings, the parts that

are particularly important for each step are shown

in green.

Step 1. Getting to know your hearing system

Take the hearing instrument in your hand and try out

the hearing system controls. This will make it easier

for you to feel and operate the controls later on when

wearing the hearing system.

4. Step-by-step instructions for using

the hearing system

16 17

Standard model

To increase the volume, press the volume control

upwards. To decrease the volume, press the volume

control downwards (Fig. 1a) (for standard models

only, the micro model does not have a volume control).

In order to change a hearing program, press the program

button displayed (Fig. 1b).

micro model

Your hearing care professional can configure your

hearing system (push) button as either a volume

control or a program selector.

To increase the volume, press the button on your

right hearing system. To decrease the volume, press

the button on your left hearing system (Fig. 1c).

In order to change a

hearing program, press

the button displayed

(Fig. 1d).

Fig. 1a

Fig. 1d

Fig. 1c

Fig. 1b

4. Using the hearing system

Decrease volume

Increase volume

Increase

volume

Decrease

volume

Left hearing system Right hearing system

18 19

Step 2. Battery preparation

Remove the protective foil from the new battery (Fig. 2).

Wait for two minutes before inserting to activate the

battery.

Step 3. Inserting the battery

Take the hearing system in your hand (Fig. 3a) and

open the battery door. Insert the battery so that you

see the + symbol on the battery (Fig. 3b).

Fig. 2

Fig. 3a Fig. 3b

Step 4. Turning on the hearing system

Switch on the hearing system by closing the battery

compartment (Fig. 4).

Open and close the battery compartment gently

and carefully.

Check if you feel resistance when closing the

battery compartment. Check to make sure the

battery is correctly inserted and in the correct

direction. If the battery is inserted the wrong

way, the hearing system will not work and the

battery compartment can be damaged.

Fig. 4

4. Using the hearing system
