User manual

Always there to help you

Question?

Contact

Philips

CSS5235Y

CSS5235Y_93_UM_V1.0.indb 2 4/24/2015 3:50:42 PM

English

Contents

1 Important 2

Safety 2

Care for your product 3

Care of the environment 3

Help and support 3

2 Your product 4

Main unit 4

Remote control 5

Connectors 6

Wireless speakers 6

Wireless subwoofer 7

3 Connect and set up 8

Connect the main unit 8

Charge speakers 8

Pair up with speakers/subwoofer 8

Place speakers 9

Connect to TV 10

Connect audio from TV and

other devices 11

4 Use your product 12

Adjust the volume 12

Choose your sound 12

Play music via Bluetooth 13

Play music via NFC 13

MP3 player 14

USB storage devices 14

Auto standby 15

Apply factory settings 15

5 Update software 15

Check software version 15

Update software via USB 15

6 Productspecications 17

7 Troubleshooting 18

CSS5235Y_93_UM_V1.0.indb 1 4/24/2015 3:50:51 PM

2EN

1 Important

Read and understand all instructions

before you use your product. If damage is

caused by failure to follow instructions, the

warranty does not apply.

Safety

Riskofelectricshockorre!

• Before you make or change any

connections, make sure that all devices

are disconnected from the power

outlet.

• Never expose the product and

accessories to rain or water. Never

place liquid containers, such as vases,

near the product. If liquids are spilt on

or into the product, disconnect it from

the power outlet immediately. Contact

Consumer Care to have the product

checked before use.

• Never place the product and

accessories near naked ames or

other heat sources, including direct

sunlight.

• Never insert objects into the

ventilation slots or other openings on

the product.

• Where the mains plug or an appliance

coupler is used as the disconnect

device, the disconnect device shall

remain readily operable.

• Batteries (battery pack or batteries

installed) shall not be exposed to

excessive heat such as sunshine, re or

the like.

• Disconnect the product from the

power outlet before lightning storms.

• When you disconnect the power cord,

always pull the plug, never the cable.

Riskofshortcircuitorre!

• For identication and supply ratings,

see the type plate at the back or

bottom of the product.

• Before you connect the product to the

power outlet, ensure that the power

voltage matches the value printed on

the back or bottom of the product.

Never connect the product to the

power outlet if the voltage is different.

Riskofinjuryordamagetothisproduct!

• Never place the product or any

objects on power cords or on other

electrical equipment.

• If the product is transported in

temperatures below 5°C, unpack the

product and wait until its temperature

matches room temperature before

connecting it to the power outlet.

• Parts of this product can be made of

glass. Handle with care to avoid injury

and damage.

Riskofoverheating!

• Never install this product in a conned

space. Always leave a space of at least

four inches around the product for

ventilation. Ensure curtains or other

objects never cover the ventilation

slots on the product.

Riskofcontamination!

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Danger of explosion if batteries are

incorrectly replaced. Replace only with

the same or equivalent type.

• Remove batteries if they are

exhausted or if the remote control is

not to be used for a long time.

CSS5235Y_93_UM_V1.0.indb 2 4/24/2015 3:50:51 PM

English

• Batteries contain chemical substances,

they should be disposed of properly.

Riskofswallowingbatteries!

• The product/remote control may

contain a coin/button type battery,

which can be swallowed. Keep the

battery out of reach of children at all

times! If swallowed, the battery can

cause serious injury or death. Severe

internal burns can occur within two

hours of ingestion.

• If you suspect that a battery has been

swallowed or placed inside any part

of the body, seek immediate medical

attention.

• When you change the batteries, always

keep all new and used batteries out

of reach of children. Ensure that the

battery compartment is completely

secure after you replace the battery.

• If the battery compartment cannot be

completely secured, discontinue use

of the product. Keep out of reach of

children and contact the manufacturer.

This is CLASS II apparatus with double

insulation, and no protective earth

provided.

Care for your product

Use only microber cloth to clean the

product.

Care of the environment

Disposal of your old product

Your product is designed and

manufactured with high quality materials

and components, which can be recycled

and reused.

Do not throw away the product with the

normal household waste at the end of its

life, but hand it in at an ofcial collection

point or recycling. By doing this, you help

to preserve the environment.

Help and support

For extensive online support, visit www.

philips.com/support to:

• download the user manual and the

quick start guide

• watch video tutorials (available only for

selected models)

• nd answers to frequently answered

questions (FAQs)

• email us a question

• chat with our support representative.

Follow the instructions on the website to

select your language, and then enter your

product model number.

Alternatively, you can contact Consumer

Care in your country. Before you contact,

note down the model number and serial

number of your product. You can nd this

information on the back or bottom of your

product.

CSS5235Y_93_UM_V1.0.indb 3 4/24/2015 3:50:52 PM

4EN

2 Your product

Congratulations on your purchase, and

welcome to Philips! To fully benet from

the support that Philips offers, register your

product at www.philips.com/welcome.

Main unit

The main unit of this product is comprised

of left and right base speakers.

a LED indication

Red LED

• Lights up when the main unit is

switched to standby.

White LED

• Lights up when the main unit is

switched on.

• Blinks once each time you press a

button on the remote control.

• Blinks twice when Dolby Digital

audio is input.

• Blinks three times when DTS audio

is input.

• Blinks continuously when no

audio from the selected HDMI

ARC source is detected, or when

an unsupported audio format is

detected.

Blue LED

• Lights up when you switch to

Bluetooth mode and Bluetooth

devices are paired.

• Blinks when you switch to

Bluetooth mode and Bluetooth

devices are not paired.

b NFC tag

Tap the NFC-enabled device on the

tag for Bluetooth connection.

c (Standby-On)

Switch the main unit on or to standby.

Switch to Bluetooth mode.

Toggle through all sources.

f Volume +/-

Increase or decrease volume.

CSS5235Y_93_UM_V1.0.indb 4 4/24/2015 3:50:53 PM

English

Remote control

This section includes an overview of the

remote control.

a (Standby-On)

• Switch the main unit on or to

standby.

b Source buttons

COAX: Switch your audio source to

the coaxial connection.

OPTICAL: Switch your audio source

to the optical connection.

AUX: Switch your audio source to the

connection of an external device with

3.5mm jack or with red/white audio

jacks.

USB: Switch to USB mode.

Bluetooth: Switch to Bluetooth

mode; Press and hold three seconds

to break the current Bluetooth

connection.

HDMI ARC: Switch your source to

HDMI ARC connection.

c /

Skip to the previous or next track

in USB mode and Bluetooth mode

(only for AVRCP-supported Bluetooth

devices).

Start, pause or resume play in USB

mode and Bluetooth mode ( only for

AVRCP-supported Bluetooth devices).

e BASS +/-

Increase or decrease bass.

f Volume control

• +/-: Increase or decrease volume.

• : Mute or restore volume.

g Sound mode control

VOICE: Select voice clarity sound

mode.

MUSIC: Select stereo sound mode.

MOVIE: Select surround sound mode.

h AUDIO SYNC +/-

Increase or decrease audio delay.

i NIGHT ON/OFF

Turn night mode on or off.

j TREBLE +/-

Increase or decrease treble.

CSS5235Y_93_UM_V1.0.indb 5 4/24/2015 3:50:54 PM

6EN

Connectors

This section includes an overview of the

connectors available on this product.

a TO R SPEAKER

Connect to the right base speaker.

b DC IN

Connect to the power supply.

c TO L SPEAKER

Connect to the left base speaker.

d COAXIAL

Connect to a coaxial audio output on

the TV or a digital device.

• Connect to a USB storage device

for audio media play.

• Upgrade software of this product.

• Charge a USB device.

f OPTICAL

Connect to an optical audio output on

the TV or a digital device.

g AUDIO IN

Audio input from, for example, an MP3

player (3.5mm jack).

a cb d ef g

h TO TV - HDMI OUT (ARC)

Connect to the HDMI (ARC) input on

the TV.

Wireless speakers

This product comes with a pair of wireless

surround speakers.

* The illustration above is for either of

wireless surround speakers.

a LED indicaton

Red LED

• Lights up when the battery

capacity is less than 30% remaining

(undocked from the main unit).

• Blinks when the battery capacity is

less than 10% remaining (undocked

from the main unit).

• If the speaker is not wirelessly

connected to the main unit,

the LED blinks red and orange

alternatively.

White LED

• Lights up when the battery capacity

is full or more than 30% remaining

(undocked from the main unit).

• Lights up when the speaker is

wirelessly connected to the main

unit (undocked from the main unit).

a b

CSS5235Y_93_UM_V1.0.indb 6 4/24/2015 3:50:55 PM

English

Orange LED

• Lights up when the surround

speaker is being charged (only for

the wireless speaker docked onto

the main unit).

• If the speaker is not wirelessly

connected to the main unit,

the LED blinks red and orange

alternatively.

• Switch the surround speaker on.

• The surround speaker

automatically turns off after

4 minutes of being wirelessly

disconnected from the main unit.

Wireless subwoofer

This product comes with a wireless

subwoofer.

a CONNECT (connect)

Press to to enter the pairing mode for

the subwoofer.

b Subwoofer indicator

• When the power is turned on, the

indicator lights up.

• During wireless pairing between

the subwoofer and the main unit,

the indicator blinks white quickly.

• When the pairing succeeds, the

indicator lights up white.

• When the pairing fails, the indicator

blinks white slowly.

• When wireless connection is

disconnected for 4 minutes, the

indicator turns off.

c AC MAINS~

Connect to the power supply.

CSS5235Y_93_UM_V1.0.indb 7 4/24/2015 3:50:55 PM

8EN

3 Connect and set

This section helps you connect this

product to a TV and other devices, and

then set it up.

For information about the basic

connections of this product and

accessories, see the quick start guide.

Note

• For identication and supply ratings,

see the type plate at the back or

bottom of the product.

• Before you make or change any

connections, make sure that all devices

are disconnected from the power

outlet.

Connect the main unit

With the supplied DIN cable, connect the

left base speaker to the right base speaker

as main unit. See the quick start guide for

details.

Charge speakers

If the wireless surround speaker is

undocked from the main unit, its battery

level is indicated by the LED on the

wireless speaker.

• Light up white: full battery or more

than 30% capacity remaining

• Light up red: low battery level, less

than 30% remaining

• Blink red: near empty, less than 10%

remaining

1 Dock the left and right wireless

speakers onto the main unit (the left

and right base speakers) to charge the

speakers.

2 Turn on the main unit.

» During charging, the orange LED

on the wireless speaker lights up.

» When fully charged, the orange

LED on the wireless speaker turns

off.

Note

• It may take around 3 hours to fully

charge the speakers.

Pair up with speakers/

subwoofer

The wireless speakers and subwoofer

automatically pair up with the main unit

(left and right base speakers) for wireless

connection when you turn on the main unit,

the speakers and the subwoofer.

If no audio from the wireless speakers and

subwoofer can be heard, do the following

for pairing.

CSS5235Y_93_UM_V1.0.indb 8 4/24/2015 3:50:56 PM

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Intervenants

Philips

Philips FX20 Manuel utilisateur

Philips

Philips BLAST BT Manuel utilisateur

Philips

Philips DS9/37 Manuel utilisateur

Philips

Philips Fidelio CSS7235Y Manuel utilisateur

Philips

Philips SoundRing SB3700 Manuel utilisateur

Philips

Philips TAS1505 Manuel utilisateur

Philips

Philips MMS171/17 Manuel utilisateur

Philips

Philips AD7000W/93 Manuel utilisateur

Philips

Philips BM5 Manuel utilisateur

Philips

Philips HTB9150 Manuel utilisateur

Philips

Philips FB651 Manuel utilisateur

Philips

Philips Fidelio E5 Manuel utilisateur

Philips

Philips BM5C/98 Manuel utilisateur

Philips

Philips SBC BP015 Manuel utilisateur

Philips

Philips BT55 Manuel utilisateur

Philips

Philips BT3500 Fiche d'information produit

Philips

Philips DS3880W/93 Manuel utilisateur

Philips

Philips HTL2150 Manuel utilisateur

Philips

Philips HTL2161B Manuel utilisateur

Philips

Philips AD7000W/10 Manuel utilisateur

Philips

Philips MMS430W Manuel utilisateur

Philips

Philips DS7580/10 Fiche d'information produit

Philips

Philips CSP620 Manuel utilisateur

Philips

Philips HTL3160B Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
