TAPR802

Wireless Speaker

S6305

User manual

www.philips.com/support

EN 1

Contents

1 Important 2

Safety 2

2 Your wireless speaker 3

Introduction 3

What's in the box 3

Overview of the speaker 3

3 Get started 4

Charge the built-in battery 4

Turn on/o 4

4 Play from Bluetooth devices 5

Play from Bluetooth devices 5

Control playback 5

Control phone call 5

Pairing for stereo mode 5

5 Other features 6

Play from an external audio device 6

Charge an external audio device 6

Multi-color LED light 7

6 Product information 7

7 Troubleshooting 8

General 8

Bluetooth 8

8 Notice 9

Compliance 9

Care of the environment 9

FCC Statement 9

Trademark notice 10

EN2

1 Important

Safety

Important safety instructions

•Make sure that the power supply voltage

corresponds to the voltage on the back or

the underside of the unit.

•The speaker shall not be exposed to

dripping or splashing.

•Do not place any source of danger on the

speaker (e.g. liquid ﬁlled objects, lit candles).

•Make sure that there is enough free space

around the speaker for ventilation.

•Please use the speaker safely in an

environment with temperature between

0°and 45°.

•Only use attachments and accessories

speciﬁed by the manufacturer.

Battery safety precautions

•Danger of explosion if a battery is

incorrectly replaced. Replace only with the

same or equivalent type.

•A battery (battery pack or battery installed)

shall not be exposed to excessive heat such

as sunshine, ﬁre or the like.

•A battery in extreme high or low

temperatures during use, storage or

transportation, and low air pressure at high

altitude can pose safety hazards.

•Do not replace a battery with an incorrect

type that can defeat a safeguard (for

example, some lithium battery types).

•Disposing a battery into ﬁre or a hot oven,

mechanically crushing or cutting a battery

can result in an explosion.

•Leaving a battery in an extremely high

temperature surrounding, or an extremely

low air pressure environment may result in

an explosion or leakage of ﬂammable liquid

or gas.

Warning

•Never remove the casing of this speaker.

•Never lubricate any part of this speaker.

•Place this speaker on a ﬂat, hard and stable

surface.

•Never place this speaker on other electrical

equipment.

•Only use this speaker indoors. Keep this speaker

away from water, moisture and liquid-ﬁlled

objects.

•Keep this speaker away from direct sunlight,

naked ﬂames or heat.

•Risk of explosion if a battery is replaced by an

incorrect type.

EN 3

2 Your wireless

speaker

Congratulations on your purchase, and welcome

to Philips! To fully beneﬁt from the support that

Philips oers, register your product at www.

philips.com/welcome.

Introduction

With this speaker, you can enjoy audio from

Bluetooth-enabled devices or other audio

devices through a 3.5mm audio-in cable.

What's in the box

Check and identify the contents of your package:

•Speaker

•USB cable

•Audio cable

•Quick start guide

•Safety sheet

•Worldwide warranty

Overview of the speaker

•Enter Bluetooth pairing mode.

•Clear Bluetooth pairing information.

•Respond to an incoming call through

Bluetooth connection.

LED indicator

•In Bluetooth mode, press to pause or

resume play.

•In Bluetooth mode, press twice to play

the next track.

•Press to turn the Multi-color LED light

on or o.

•Press and hold to enter Stereo pairing

mode.

Microphone

•Adjust volume.

•Turn the speaker on or o.

•Check the battery level.

•Show the Bluetooth status.

Battery level indicators

•Show the charging progress.

•Show the battery level.

Multi-color LED light

•Charge an external audio device.

•Charge the built-in battery.

•Connect an external audio device.

EN4

3 Get started

Always follow the instructions in this chapter in

sequence.

Charge the built-in battery

The speaker is powered by a built-in

rechargeable battery.

Note

•Fully charge the built-in battery before using.

•When the speaker is turned on and the battery

is low, the battery level LED indicator blinks

green.

Connect the USB-C socket on the speaker to

an outlet (5V 3A) by using the provided USB

cable.

5V 3 A

When the speaker is being charged,

the battery level LED indicator lights up

gradually.

When the speaker is fully charged, the

battery level LED indicator lights on.

Caution

•Risk of speaker damage! Make sure the power

supply voltage corresponds to the voltage

printed on the back or the underside of the

speaker.

•Risk of electric shock! When unplug the USB

cable, always pull the plug from the socket.

Never pull the cable.

•Use only a USB cable speciﬁed by the

manufacturer or sold with this speaker.

Turn on/o

Press to turn the speaker on.

You will hear the prompt sound.

If no external audio device is connected

to the AUX socket, it will enter

Bluetooth pairing mode automatically

and the LED indicator will blink blue.

To turn the speaker o, press again.

Note

•The speaker will turn o automatically after

15minutes without audio signal from Bluetooth

or via AUX IN.

EN 5

4 Play from

Bluetooth

devices

Play from Bluetooth devices

With this speaker, you can enjoy audio from

your Bluetooth device.

Note

•Make sure that the Bluetooth function is enabled

on your device.

•

•Keep away from any other electronic device that

may cause interference.

1Press to turn the speaker on, it will

enter Bluetooth pairing mode automatically.

You can also press and hold for 2

seconds to enter Bluetooth pairing mode.

2Enable Bluetooth and select "Philips S6305"

in the Bluetooth list on your device for

pairing.

If a message prompts for permission

for Bluetooth connection, conﬁrm it.

If a password is required, enter 0000

and then conﬁrm.

3Play audio on your Bluetooth deviceto start

streaming music.

LED indicator Description

Blinking blue quickly Ready for pairing

Blinking blue slowly Reconnecting the last

connected device

Solid blue Connected

Note

•To disconnect a device, press and hold for

2 seconds until the LED indicator blinks blue

quickly.

•When you turn on the speaker, it always

automatically tries to reconnect the last

successfully connected device.

•To clear the pairing information, press and hold

for 8 seconds until the LED indicator slowly

blinking cyan for 3 times.

Control playback

During playing the music,

Press to pause or resume play

Press twice to play the next track

Adjust the volume

Control phone call

Press to answer or end a call

Press and hold to reject a call

Adjust the volume

Pairing for stereo mode

Two identical wireless speakers (Philips S6305)

can pair with each other for stereo sound.

Note

•Any speaker can be used as the primary speaker.

•The speaker connected to a Bluetooth device

can only be used as the primary speaker.

•Before stereo pairing, make sure that the

secondary speaker is under Bluetooth pairing

mode.

•The maximum distance for pairing the speaker

and your Bluetooth device is 20 meters (66 feet).

The maximum distance for pairing the speaker

and your Bluetooth device is 20 meters (66 feet).

•In stereo mode, the button operation on the

secondary speaker is as same as that of the

primary speaker.

EN6

1Press to power on both speakers,

they will enter Bluetooth pairing mode

automatically. The speaker connected to

your Bluetooth device will be used as the

primary speaker.

2On the primary speaker, press and hold

to enter stereo pairing mode until

the LED indicator blinks blue and green

alternately.

You will hear a prompt sound when

successfully connected.

The LED indicator lights up blue and

green alternately on the primary

speaker.

The LED indicator lights up in blue on

the secondary speaker.

3Press on either speaker. The music will

be played through both speakers.

To exit the stereo mode, press and hold the

on either speaker.

5 Other features

Play from an external audio

device

With this speaker, you can enjoy music from an

external audio device such as an MP3 player.

1Connect an audio cable to the socket

on the speaker and the headphone socket

on an external audio device.

The speaker will switch to AUX IN

mode automatically.

The LED indicator lights up in green.

2Control playback and volume through the

connected external audio device.

Charge an external audio

device

Charge an external audio device (for example,

a smartphone or an MP3 player) via the port

on the back of the speaker.

Note

•The USB charging out current is 5V 2A.

•Use the original data cable of the corresponding

device.

•Not all USB devices are guaranteed for charging.

EN 7

Multi-color LED light

The speaker is equipped with multi-color LED

light on both sides. When playing the music, the

color and brightness of the multi-color LED light

vary by the audio signal.

Press to turn the multi-color LED light on

6 Product

information

Note

•Product information is subject to change without

prior notice.

General information

Power supply: 5V 3A

Built-in Lithium battery7.4V, 4400mAh

USB port5V 2A

Dimensions (W x H x D)230 x 100 x 100 mm

Weight (main unit)1 kg

Ampliﬁer

Output power10W x 2

30W

Frequencyresponse

Rated power

100 Hz - 20 kHz

Signal to noise ratio> 70 dB

Speakers

Impedance 4

Maximum input power10 W

Size2.25"

Bluetooth

Bluetooth version 5.0

Frequencyrange2402- 2480 MHz

Maximum transmition

power5 dBm

Compatible Bluetooth

proﬁlesA2DP, AVRCP

Bluetooth rangeapprox. 20m

EN8

7 Troubleshooting

Warning

•Never remove the casing of the speaker.

To keep the warranty valid, never try to repair

the speaker yourself.

If you encounter problems when using this

speaker, check the following points before

requesting service. If the problem remains

unsolved, go to the Philips website (www.philips.

com/welcome). When you contact Philips,

ensure that the speaker is nearby and the model

number and serial number are available.

General

No power

•Make sure the speaker is fully charged.

•Make sure the USB socket of the speaker is

properly connected.

•As a power-saving feature, the speaker

turns o automatically 15 minutes after no

audio signal is received or no audio device

is connected.

No sound

•Adjust the volume on this speaker.

•Adjust the volume on the connected

device.

•In AUDIO IN mode, make sure that music

playback through Bluetooth is stopped.

•Make sure that your Bluetooth device is

within the operational range.

No response from the speaker

•Restart the speaker.

Bluetooth

The audio quality is poor after

connection with a Bluetooth-enabled

device

•The Bluetooth reception is poor. Move the

device closer to this speaker or remove any

obstacle between them.

Fail to ﬁnd [Philips S6305] on your

Bluetooth device for pairing

•Press and hold for 2 seconds to enter

Bluetooth pairing mode, and then try again.

Cannot connect with your Bluetooth

device

•The Bluetooth function of your device is

not enabled. Refer to the user manual of

your device to ﬁnd out how to enable the

function.

•This speaker is not in pairing mode.

•This speaker is already connected to

another Bluetooth-enabled device.

Disconnect and try again.

EN 9

8 Notice

Any changes or modiﬁcations made to this

device that are not expressly approved by

TP Vision Europe B.V. may void the user’s

authority to operate the product.

Compliance

Hereby, TP Vision Europe B.V. declares that

this product is in compliance with the essential

requirements and other relevant provisions

of Directive 2014/53/EU. You can ﬁnd the

Declaration of Conformity on www.philips.com/

support.

Care of the environment

Disposal of your old product and battery

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

This symbol on a product means that the

product is covered by European Directive

2012/19/EU.

This symbol means that the product contains

batteries covered by European Directive

2013/56/EU which cannot be disposed of with

normal household waste.

Inform yourself about the local separate

collection system for electrical and electronic

products and batteries. Follow local rules and

never dispose of the product and batteries with

normal household waste. Correct disposal of old

products and batteries helps prevent negative

consequences for the environment and human

health.

Removing the disposal batteries

To remove the disposable batteries, see battery

install section.

For INSPIRATION only

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard (box),

polystyrene foam (buer) and polyethylene

(bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by

a specialized company. Please observe the

local regulations regarding the disposal of

packaging materials, exhausted batteries and old

equipment.

FCC Statement

This device complies with Part 15 of the FCC

Rules. Operation is subject to the following

two conditions: (1) This device may not cause

harmful interference, and (2) This device must

accept any interference received, including

interference that may cause undesired

operation.

Warning: Changes or modiﬁcations not

expressly approved by the party responsible for

compliance could void the user’s authority to

operate the equipment.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Intervenants

Philips

Philips 7000 series Manuel utilisateur

Philips

Philips CSP652/51 Manuel utilisateur

Philips

Philips TAB7305 Manuel utilisateur

Philips

Philips SPA7355 Manuel utilisateur

Philips

Philips BT50 Manuel utilisateur

Philips

Philips SPA7380 Manuel utilisateur

Philips

Philips STS9500/00 Manuel utilisateur

Philips

Philips AW5000 Manuel utilisateur

Philips

Philips SBT50/00 Manuel utilisateur

Philips

Philips Fidelio HTL7180 Manuel utilisateur

Philips

Philips SPA3210 Manuel utilisateur

Philips

Philips SPA 3210 Manuel utilisateur

Philips

Philips SHOQBOX SB7200 Manuel utilisateur

Philips

Philips HTL3120 Manuel utilisateur

Philips

Philips TANX50 Manuel utilisateur

Philips

Philips CSP6910/00 Manuel utilisateur

Philips

Philips SPA2210V Fiche d'information produit

Philips

Philips HTB3520X Manuel utilisateur

Philips

Philips HTS3111/05 Manuel utilisateur

Philips

Philips Fidelio AS851 Manuel utilisateur

Philips

Philips TAS2505 Manuel utilisateur

Philips

Philips BT2500 Fiche d'information produit

Philips

Philips Fidelio SoundRing DS3801W/37 Manuel utilisateur

Philips

Philips Fidelio DS3800W/10 Manuel utilisateur

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
