Philips SRU8112/27 Manuel utilisateur

SRU 8112/27

and get support at

www.philips.com/welcome

Universal remote control

EN Remote control

Table of contents

1 Your universal remote control 3

2 Installing the remote control 3-5

3 Using the remote control 5-8

3.1 Keys and functions 5-7

3.2 Selecting devices 7-8

4 Extra possibilities 8-18

4.1 Home menu 8-9

4.2 Devices 9-10

4.3 Favorite channels 10-12

4.4 Macros 12-14

4.5 Advanced options 14-15

4.6 Learning key functions 16-18

5 Frequently asked questions 18-20

6 Need help? 20

Limited warranty 21

1 Your universal remote control

Congratulations on your purchase and welcome to Philips.

To fully benefit from the support that Philips offers,

For quick, clean and easy setup go to: www.philips.com/urc

After installing the universal remote control you can operate

a maximum of 12 different devices with it. During setup you

can define yourself exactly which devices can be operated

(see table under 2.‘Installing the remote control’).

2 Installing the remote control

Remove the protective foil from the display.

Press the tab of the battery compartment cover inwards

and lift off the cover.

3Installing the remote control

ENGLISH

Insert three 1.5 LR6 (AA) type alkaline batteries noting

the + and - configuration in the battery compartment.

Be sure to use fresh batteries.

Replace the cover and click firmly into place.

• The language selection screen appears.

Select your preferred language by pressing the

corresponding side key.

• The ‘Setup wizzard’ screen appears.

Press any key to continue.

Follow the on-screen instructions to set up the remote

control for all devices you wish to operate, using the

remote control.

• You can set up the remote control for any of the devices

listed below.

• To exit the ‘Setup wizard’ at any time, select ‘Quit’.

• After setting up the remote control to operate your devices,

the ‘Favorites’ set up screen appears.

For setting up favorite channels (‘favorites’),

refer to chapter 4.3 ‘Favorite channels’.

Notes

• To save battery life, the remote control automatically

turns off if any button (or button combination) is pressed

for 30 seconds or more.

• When the batteries are almost empty, the battery low

indication ( ) flashes on the display. Replace the

batteries and follow the local regulations for battery

disposal.

Device name Description

TV Traditional TV and flat screen TVs

DVD DVD player and recorder

Sat Satellite receiver

DVDR DVD player and recorder

Cable Cable set-top box

Amp Amplifier / tuner

VCR Video cassette player and recorder

DVBT Digital Video Broadcasting Terrestrial

device

STB Set-top box

4Installing the remote control

ENGLISH

5Using the remote control

CD CD player and recorder

LCD LCD TV

Plasma Plasma TV

Audio Amplifier / tuner

Tuner Amplifier / tuner

Tape Audio cassette tape player and recorder

MD Mini Disk player and recorder

PVR Personal Video Recorder (digital video

recorder)

DMR Digital Media Receiver

TV / VCR TV with integrated VCR

TV / DVD TV with integrated DVD

DVD / VCR DVD / VCR combination

DVDR / HDD DVD / Hard Disk Drive combination

PC Personal Computer

HTS Home Theatre System

Note

Settings made during this initial set up can be changed

afterwards. For this, refer to chapter 4 ‘Extra possibilities’.

3 Using the remote control

After installing the remote control you can operate the

devices the remote control is set up for. For operation the

appropriate keys on the remote control can be used as well

as the additional on-screen keys that are displayed when a

device is selected. For this, refer to chapter 3.2 ‘Selecting

devices’.

3.1 Keys and functions

The illustration on page 2 gives an overview of all keys and

their functions.

1yStandby switches the selected device on or off.

2 USER 1 / USER 2 display favorite channels for

‘User 1’ and ‘User 2’.

3 Side keys direct access device features.

4 Display shows the current remote control

status.

5 HOME enters / exits ‘Home’ mode and opens

the starting screen for most remote

control operations.

MODE displays list of devices that can be

selected.

FAVORITE displays list of users and items for

which favorite channels are set up

(‘User 1’, 2,‘Sports’,‘Movies’, etc. ).

6 T-CENTRAL TiVo key. Selects TiVo Central.

MENU turns the menu screen on the selected

device on and off.

7 Cursor keys cursor up, down, left, right in a menu.

The cursor left key jumps back one

level in the SRU 8112 menus.

OK confirms your selection.

8 INFO displays on-screen information.

9 - VOL + adjusts the volume of the selected

device.

mutes the sound of the selected device.

10 SAP selects Secondary Audio Program (if

available).

SUBTITLE selects DVD subtitles.

CC TV Closed Caption (if your TV has this

feature)

11 SCAN - / 5• rewind.

• goes through a program in reverse

direction.

PLAY / 2play.

SCAN + / 6• wind.

• fast forward through a program.

12 REC / 0record (press twice).

STOP / 9stop.

PAUSE / ;pause.

13 REPEAT Replays the last 8 seconds of a

program.

Thumbs down 4sets you TiVo Thumbs rating.

LIVE TV switches to Live TV broadcast.

INPUT • dispays the DVD player’s Setup menu.

• Selects between TV and VCR.

Thumbs up 3sets you TiVo Thumbs rating.

ADVANCE catches you up to the live broadcast.

14 Numeric keys direct choice of channels, text input

and other functions. Functions in red

are available in audio mode.

15 + 100 selects channel numbers, greater than

100.

(-) selects digital channels (e.g. 2-3).

16 IR transmitter sends IR commands to the selected

device.

17 ENTER used after direct channel selection

(with the numeric keys), to

immediately switch to the selected

channel.

Using the remote control

ENGLISH

Using the remote control

18 ZOOM enlarges a specific area of the screen.

ARC Aspect Ratio Control. Selects viewing

format for the displayed picture. E.g.

Wide, Zoom, etc.

REPEAT A-B Repeat (RPT A.B).

Repeats playback of current Chapter

or Track in DVD mode.

LAST • returns to the previously selected

channel.

• repeats DVD.

19 - CHAPTER + selects previous / next track in CD

and DVD mode.

- CH + selects previous / next channel.

20 RETURN returns to previous on-screen

selection.

QUIT exits on-screen menu mode.

21 GUIDE displays Electronic Program Guide.

22 IR receiver receives IR signals in ‘Learning’ mode.

For this, refer to chapter 4.6 ‘Learning

key functions’.

3.2 Selecting devices

Press the MODE key.

• The ‘Mode’ screen appears.The devices that can be selected

are highlighted. Only devices for which the remote control is

set up can be selected. For this, refer to chapter 2.‘Installing

the remote control’.

Press the corresponding side key to select the desired

device.

• The selected device will be displayed at the bottom left of

the display. More functions for operating the device are

shown in the upper part of the display.

Cable

DVR

Audio

HTS More

Sat

VCR

DVD

Pick Device

You can now operate the selected device, using the

appropriate keys on the remote control. for this,

refer to chapter 3.1 ‘Keys and functions’.

• To use the additional functions, shown on the display,

press the corresponding side keys. Press ‘Next’ to scroll

through the list of functions.

• Each time a remote control command is sent,

this will be indicated at the bottom left of the display.

• To set up the remote control for other (more) devices

(adding devices), refer to chapter 4.2 ‘Devices’.

4 Extra possibilities

4.1 Home menu

Via the ‘Home’ menu you have access to the various extra

and advanced features of the SRU 8112.

Press the HOME key to enter the ‘Home’ menu.

• The ‘Home’ screen appears.The options below are available

in the ‘Home’ menu.

• Use the side keys to make selections in the ‘Home’ menu

and submenus.

• Use the cursor left key to go back a the previous level in

the menu.

QuickPower

Sleep

Macros

Setup

Help

Cable

8Extra possibilities

ENGLISH

Extra possibilities

Quickpower

Switches the device you wish to operate on / off.

Only devices for which the remote control is set up can be

selected.

• Select ‘QuickPower’, then select the device to switch

on / off.

Sleep

Sets devices to switch off at a preset time.The switch-off time

can be set in intervals of 15 minutes. Maximum switch-off

time is 90 minutes.

Only devices for which the remote control is set up can be

selected.

• Select ‘Sleep’, then select the device(s) to set a switch-off

time for.

• Press the corresponding side key(s) to set the desired

switch-off time(s).

• Make sure the remote control points at the device(s) you

have set a switch-off time for.

Macros

Shows available macros, if macros have already been set up.

If no macros are available, you can set up macros here.

For this, refer to chapter 4.4 ‘Macros’.

Setup

Devices: allows you to add and delete devices. For this,

refer to chapter 4.2 ‘Devices’.

Favorites: allows you to add, edit, reorder, delete and / or

rename favorite channels. For this, refer to

chapter 4.3 ‘Favorite channels.

Macros: allows you to add, edit, delete, rename and / or

extend macros. For this, refer to chapter 4.4

‘Macros’.

Advanced: See 4.5 ‘Advanced options’.

Learn: See 4.6 ‘Learning key functions’.

Help

Gives you extra information on how to set up and use your

remote control.

10 Extra possibilities

ENGLISH

4.2 Devices

During installation you set up the remote control to operate

a number of devices.The ‘Setup’ submenu enables you to add

and delete devices at any time.

Adding devices

You can add a device more than once and save it under a

different name each time.

Press the HOME key and select ‘Setup’ in the ‘Home’

menu.

Select ‘Devices’.

• The available devices (already added) are highlighted on the

display.

Select the device you wish to set up the remote control

for (add) and follow the on-screen instructions.

Select ‘Save’, then ‘Save code’ when finished.

Repeat above steps for other devices you wish to set up

the remote control for (add).

• Select ‘Quit’ to exit the ‘Setup’ submenu at any time.

Deleting devices

Press the HOME key and select ‘Setup’ in the ‘Home’

menu.

Select ‘Advanced’.

Select ‘Clear Settings’.

Select ‘Devices’.

Select the device you wish to delete.

Select ‘Clear’.

Repeat step 4-6 for all devices you wish to delete.

• For selecting devices, refer to chapter 3.2 ‘Selecting

devices’.

4.3 Favorite channels

You can set favorite channels for various users (‘User 1’,‘User

2’,‘Kids’, etc.) and / or various items (‘Sports’,‘News’,‘Movies’,

etc.).

Adding / editing favorite channels

Press the HOME key and select ‘Setup’ in the ‘Home’

menu.

Select ‘Favorites’.

Select ‘Add/Edit’.

Select the user (‘User 1’,‘User 2’, etc.) or the item

(‘General’,‘Movies’, etc.) you wish to add favorite channels

to.

Press the OK key.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Philips Télécommande

Philips

Philips SBCRU621/00 Manuel utilisateur

Philips

Philips SBC RU 520 Manuel utilisateur

Philips

Philips SBCRU460/00 Manuel utilisateur

Philips

Philips SBCRU641 Manuel utilisateur

Philips

Philips TSU9600/05 Guide de sécurité

Philips

Philips SRP 1001/10 Manuel utilisateur

Philips

Philips DTR230 - Manuel utilisateur

Philips

Philips MELICONI Manuel utilisateur

Philips

Philips SRU5130/53 Manuel utilisateur

Philips

Philips SpeechMike Premium Touch SMP3700 Manuel utilisateur

Philips

Philips SRU3007/27 Manuel utilisateur

Philips

Philips SBCRU610/00 Manuel utilisateur

Philips

Philips SRU 5086 Manuel utilisateur

Philips

Philips SBC RU 220/00 Manuel utilisateur

Philips

Philips SRU3005 Manuel utilisateur

Philips

Philips SBCRU610/00U Manuel utilisateur

Philips

Philips SRP2024A/27 Manuel utilisateur

Philips

Philips SBCRU510/87B Manuel utilisateur

Philips

Philips US2-PHBIG4 Manuel utilisateur

Philips

Philips PM525S - Phlips 5 Device Universal Remote... Manuel utilisateur

Philips

Philips SBCRU111/00 Manuel utilisateur

Philips

Philips Perfect replacement SRP5107/27 Manuel utilisateur

Philips

Philips SRP2104/27 Manuel utilisateur

Philips

Philips SBCRU410/00 Manuel utilisateur

Manuels Télécommande populaires d'autres marques

Panasonic

Panasonic EUR7622KB0 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen Beo4 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuel utilisateur

Multiplex

Multiplex PROFI TX 9 Manuel utilisateur

One Remote

One Remote RMB4 Manuel utilisateur

FUTABA

FUTABA 9ZAP - PART2 Manuel utilisateur

HR Matic

HR Matic HR MULTI 3 Manuel utilisateur

Yamaha

Yamaha ACC-GNRST-30-20 Manuel utilisateur

EisSound

EisSound KBSOUND Manuel utilisateur

Marantz

Marantz RC101 Manuel utilisateur

Conrad

Conrad FS20 TC6 Manuel utilisateur

Anritsu

Anritsu MP1777A Manuel utilisateur

Niles

Niles WVC100 Guide de dépannage

RCA

RCA RCU1300 Manuel utilisateur

Bang & Olufsen

Bang & Olufsen BEO6 Manuel utilisateur

GE 94901 Manuel utilisateur

Onbon

Onbon YQ1-75 Manuel utilisateur

FUTABA

FUTABA R7108SB Instructions d'installation
