Philips HR3868/01 Manuel utilisateur

HR3865, HR3866

HR3868

4240 002 02336

发布日期：2017-03-13

保留备用

jkl

HR3868

EN User manual 7

KO 사용 설명서 16

MS Manual pengguna 24

VI Hướng dẫn sử dụng 34

ZH-S 用户手册 42

ZH-T 使用手冊 49

ӝ૷ φ伔࡟⎜⹪໷ᯏ⨼ᵰ

ශ φ HR3865, HR3868

仓ᇐ⭫ু φ 220V Њ

仓ᇐ仇⦽ φ 50 Hz

仓ᇐ䗉ޛࣕ⦽ φ 2000 W

⭕ӝᰛᵕ φ䈭㿷ӝ૷ᓋ䜞

ӝ൦ φѣളᒵђ␧൩

伔࡟⎜δѣളεᣋ䍺ᴿ䲆ޢ

ޞള亴ᇘᵃࣗ✣㓵 : 4008 800 008

ᵢӝ૷ṯᦤളḽ GB4706.1-2005,

GB4706.30-2008 ࡬䙖

р⎭ᐸཟⴤ㾵䐥 218 1602-1605

产品中有害物质的名称及含量

部件

名称

有害物质

铅

（Pb）

汞

（Hg）

镉

（Cd）

六价铬

Cr(VI)

多溴联苯

（PBB）

多溴二苯醚

（PBDE）

主机 x O x O O O

本表格依据 SJ/T 11364 的规定编制。

○：

表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572

规定的限量要求以下。

×：

表示该有害物质至少在该部件的某一均质材料中的含量超出

GB/T 26572 规定的限量要求。

678

910

45 6

12 3

21 3

HR3868 6

(MAX)

2 L

1.8 L

1.7 L

14 x

2 L 1 min.

1 min.

30 sec

4 min.

1.7

min.

30 sec x3

600 g 30 sec

600

min.

4 min.

200 g MIN

300 g MAX

7EN

English

• Do not immerse the

appliance in water or any

other liquid.

• Check if the voltage

indicated on the

appliance corresponds to

the local mains voltage

before you connect the

appliance.

• Do not use the appliance

if the plug or the mains

cord is damaged or has

visible cracks. If the mains

cord is damaged, you

must have it replaced by

Philips, a service centre

authorized by Philips or

similarly qualied persons

in order to avoid a hazard.

• Make sure the lid and

measuring cup are

properly assembled to

the blender jar before you

use the appliance.

• This appliance shall not

be used by children. Keep

the appliance and its cord

out of reach of children.

1 Welcome

Congratulations on your purchase and

welcome to Philips! To fully benet

from the support that Philips oers,

www.philips.com/welcome.

Read this user manual carefully before

you use the appliance and save it for

future reference.

Warning

• Do not touch the

sharp blades when the

appliance is plugged in.

If the blades get stuck,

unplug the appliance

before you remove the

ingredients. Be careful

when handling the sharp

cutting blades, emptying

the bowl and during

cleaning.

• Switch o and unplug the

appliance from the power

supply before:

-Removing it from

the stand, changing

accessories or

approaching parts that

move in use.

-Assembling,

disassembling or

cleaning it.

-It is left unattended.

8EN

switching device, such as

a timer, or connected to

a circuit that is regularly

switched on and o by

the utility.

• Do not put the jar on the

main unit if the motor

coupling is still running.

• Do not take out the jar

from the main unit if

the blade is not totally

stopped.

• The blender can not be

used without load or

with a minimum quantity

of ingredient or liquid

(250 ml). Putting too less

ingredients or liquid can

cause damage to the

blender.

• The blender must be

operated with the rubber

pad. Do not remove the

rubber pad on top of the

motor unit.

Caution

• Never use any

accessories or parts from

other manufacturers or

that Philips does not

specically recommend. If

• This appliance can be

used by persons with

reduced physical, sensory

or mental capabilities or

lack of experience and

knowledge if they have

been given supervision

or instruction concerning

use of the appliance in

a safe way and if they

understand the hazards

involved.

• Children should be

supervised to ensure that

they do not play with the

appliance.

• Never assemble or

disassemble the blender

jar to the motor base

while the power is on.

• This appliance is

intended for household

use only.

• Read the cleaning

procedure from “User

Manual” before use.

• In order to avoid a hazard

due to inadvertent

resetting of the thermal

cut-out, this appliance

must not be supplied

through an external

9EN

English

• If the blade unit gets

stuck, unplug the

appliance before you

remove the ingredients

that block the blades.

Caution

• To prevent spillage, do

not put more than 2 litres

of liquid in the blender

jar, especially when you

process at a high speed.

Do not put more than

2 litres in the blender jar

when you process liquids

or ingredients that tend to

foam.

• Do not operate the

appliance for multiple

batches of recipes. Let

the appliance to cool

down for 30 minutes

before you continue

operating again.

• Always make sure the

lid is properly closed/

assembled on the jar

and the measuring cup is

inserted properly in the

lid before you switch on

the appliance.

• Noise level: Lc = 89 dB [A]

you use such accessories

or parts, your guarantee

becomes invalid.

• Do not exceed the

maximum indication on

the blender jar.

• Do not exceed the

maximum quantities

and processing times

indicated in the relevant

table (Fig. 7).

• If food sticks to the wall of

the blender jar, switch o

the appliance and unplug

it. Then use a spatula to

remove the food from the

wall.

• Never ll the blender jar

with ingredients hotter

than 40 °C.

• The appliance can only

be switched on if the

blender jar is assembled

on the motor unit

correctly.

Blender

Warning

• Never reach into the

blender jar with your

ngers or an object while

the appliance is running.

10 EN

Control panel

hSpeed selector (Rotary knob)

0: switch o the blender

1-10: switch on the blender and

select a blending speed

setting

P: pulse setting

iProgram LED and button

Fruit & vegetable smoothie

Five grains & soy milk

Soup

Nuts

Ice crushing

jOverheat warning LED

kTimer (M:SS)

lSleep LED

mDome (HR3868 only)

3 Before first use

Before you use the blender for the rst

time, thoroughly clean the parts that

come into contact with food.

If the timer shows “---”, turn the rotary

knob to speed 0 and place the jar on

the motor unit.

Electromagnetic elds

(EMF)

This Philips appliance complies with all

standards regarding electromagnetic

elds (EMF). If handled properly and

according to the instructions in this user

manual, the appliance is safe to use

based on scientic evidence available

today.

Recycling

Do not throw away the product with the

normal household waste at the end of its

life, but hand it in at an ocial collection

point for recycling. By doing this, you

help to preserve the environment.

2 Overview (Fig. 1)

Main unit

aTamper

bMeasuring cup

cBlender lid

dBlender jar

eRubber pad

fMotor unit

gPower switch

11EN

English

Note: if the temperature of the

appliance is too high or the appliance

is overused, the message “Hot” displays

directly and the blender will also stop

working.

To reset your blender in case of

overload and auto stop protection,

follow the steps below:

1 Switch o the blender and then

unplug it.

2 Remove some of the ingredients to

reduce the load.

3 Allow the appliance to cool down

for 30 minutes.

4 Connect the power plug to the wall

outlet and switch on the blender.

Blender jar

The jar is designed for processing

various recipes like smoothie, juice,

sauce, grain milk, soup, puree, frozen

dessert, ice crushing, nut butter,

chopping or grinding dry ingredients.

If the jar is used for grinding dry

ingredients, the jar wall will be

scratched and become cloudy. There

is no negative impact on the blending

performance and no food safety

concern. It is still safe to use.

Built-in safety lock

This feature ensures that you can only

switch on the appliance if you have put

the blender jar correctly on the motor

unit. If the blender jar is put correctly,

the built-in safety lock is unlocked.

When the blender jar is not placing well

on the motor unit during blending, the

message “Err” displays.

To reset your blender in this case, follow

the steps below:

1 Switch o the blender. Make sure

the rotary knob is at “0”.

2 Switch on the blender.

Auto stop

Your blender will be automatically

turned o after 4 minutes of continuous

operation. This can avoid potential

problems due to prolonged usage.

Overload protection

The overheat warning LED

(thermometer icon) ashes when the

blender is overloaded. If the blender

continues working with heavy load,

the message “Hot” displays when it

is fully overloaded. The blender will

automatically stop working.

12 EN

5 Manual blending

mode (Fig. 3)

1 Assemble your blender jar as

indicated.

2 Put the ingredients in the jar.

3 Insert the measuring cup and close

the lid.

4 Put the plug in the wall outlet and

switch on the blender.

5 Turn the knob to a speed setting as

needed.

» The blender starts blending.

» The timer starts counting up.

• To switch to pulse blending

mode during the blending

process, turn the knob to P

several times.

6 Turn the knob to speed 0 to stop

blending.

» Let the blender cool down for

5 minutes after blending.

7 Switch o the blender and unplug

it. Then remove the blender jar from

the motor unit.

8 Open the lid and pour out the

ingredients from the blender jar.

6 Sleep mode

Your blender will go into sleep mode

after 3 minutes when there is no

operation and sleep LED (power LED) is

on. You can wake up the appliance and

start manual blending by turning rotary

knob to a speed setting needed.

4 Preset blending

mode (Fig. 2)

1 Assemble your blender jar as

indicated.

2 Put the ingredients in the jar.

3 Insert the measuring cup and close

the lid.

4 Put the plug in the wall outlet and

switch on the blender.

» The timer shows 0:00 and

program LEDs turn on. The

appliance is ready to use.

5 Select a program by pressing a

program button on the panel.

» The blender starts blending as

programmed.

» The timer starts counting down.

• See table 1 for purposes and

blending time of dierent

programs.

• To stop the current blending

program, press the selected

program button again.

• To switch to manual blending

mode during the blending

process, turn the knob to a

speed setting as needed.

• To switch to pulse mode during

the blending process, turn the

knob to P several times.

6 Switch o the blender and unplug it

after blending.

» The blender stops blending

when the timer reaches 0:00.

7 Remove the blender jar from the

motor unit.

8 Open the lid and pour out the

ingredients from the blender jar.

13EN

English

9 Cleaning (Fig. 6)

Warning

• Before you clean the appliance, unplug it.

• Refer to Fig. 6 for information on cleaning the

parts with water, dishwashing machine and/or

moist cloth.

• Do not remove the rubber pad on top of the

motor unit.

Caution

• Make sure that the cutting edges of the blades

do not come into contact with hard objects.

This may cause the blade to get blunt.

• The cutting edges are sharp. Be careful when

you clean the blade units.

1 Clean the motor unit with a moist

cloth.

2 Clean the other parts in hot water

(< 60°C) with some washing-up

liquid or in a dishwasher.

3 Store the appliance and accessories

in a dry place after cleaning.

Quick cleaning

Follow the steps below to clean the

blender jar easier.

1 Pour lukewarm water (not more

than 1 liters) and a few drops of

washing-up liquid into the blender

jar.

2 Insert the measuring cup and close

the lid.

3 Turn the knob to speed 10. Let the

blender run for 30 seconds or until

the blender jar is clean.

4 After use, switch o the blender and

then unplug the appliance.

5 Remove the blender jar and rinse it

with clean water.

7 Use the tamper

(Fig. 4)

You can use the tamper to process

very thick mixtures or recipes with less

liquid which cannot be processed well

in a normal blender, e.g. nut butters,

frozen dessert or puree vegetables. The

tamper helps circulation by preventing

air formed.

The tamper is used to stir and push

ingredients into the blades when the

blender is on.

Note: Use the tamper only when the lid

is assembled correctly to the jar to avoid

tamper hitting the blades.

Tips: You can move the tamper up and

down, turn around or push it toward

the side or corner of the jar to help

ingredients circulate.

8 Use the dome

(HR3868 only)

(Fig. 5)

You can use the dome to reduce the

noise during blending.

Follow the steps to assemble and use

the dome as indicated in g. 5.

14 EN

10 Guarantee and service

If you have a problem, need service, or need information, see www.philips.com/

support or contact the Philips Consumer Care Center in your country. The phone

number is in the worldwide guarantee leaet. If there is no Consumer Care Center in

your country, go to your local Philips dealer.

Table 1

Program

Fruit &

vegetable

Smoothie

Five grains

& soy milk

Soup Nuts Ice

crushing

Purpose Blend whole

fruits and

vegetables to

get both the

juice and ber

Blend any

types of

grains,

beans, nuts

and water

into smooth

milk

Blend

vegetables

into silky

soup

Grind

whole

nuts into

nely

chopped

result

Crush ice

cubes

within few

pulse

Blending

time

1 min 2 min 4 min 30 sec 30 sec

Suggested

recipe

Carrot, apple

and celery

juice

Soy milk Creamy

tomato

soup

Grinding

almond or

spices

Mango and

yoghurt

with

crushed ice

Recipe:

Ingredients:

950 g minced pork

20 g scallion

Procedure:

1. Put the minced pork and scallion into jar.

2. Blend the recipe for 10 seconds at speed 10.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Philips Mixer

Philips

Philips AVENT SCF885 Manuel utilisateur

Philips

Philips HR1316/00 Manuel utilisateur

Philips

Philips HR7782 Manuel utilisateur

Philips

Philips HR2034 Manuel utilisateur

Philips

Philips Easy Pappa SCF885 Manuel utilisateur

Philips

Philips HR2200 Manuel utilisateur

Philips

Philips Robust Collection HR2181/00 Manuel utilisateur

Philips

Philips CUCINA HR7745 Manuel utilisateur

Philips

Philips HR1700/00 Manuel utilisateur

Philips

Philips H R1393 Manuel utilisateur

Philips

Philips HR1602 Manuel utilisateur

Philips

Philips AVENT SCF870 Manuel utilisateur

Philips

Philips HR1610/00-01 Manuel utilisateur

Philips

Philips HR1369 Manuel utilisateur

Philips

Philips Avance HR2202/80 Manuel utilisateur

Philips

Philips HR2162 Manuel utilisateur

Philips

Philips HR1614 Manuel utilisateur

Philips

Philips RI2035 Manuel utilisateur

Philips

Philips HR1727 Manuel utilisateur

Philips

Philips HR3770 Manuel utilisateur

Philips

Philips HR2636 Manuel utilisateur

Philips

Philips HR1741/80 Manuel utilisateur

Philips

Philips Cucina HR1799 Manuel utilisateur

Philips

Philips HR3652 Manuel utilisateur

Manuels Mixer populaires d'autres marques

ROTOR

ROTOR 1125.201 Manuel utilisateur

Braun

Braun Multiquick 5 Vario series Manuel utilisateur

ARENDO

ARENDO MIRA 305424 Manuel utilisateur

CHEF-BUILT

CHEF-BUILT CCB-3500 Manuel utilisateur

Viconte

Viconte VC-4406 Manuel utilisateur

Oster

Oster BLSTAB-CB0 Manuel utilisateur

HOFFEN

HOFFEN MC-3005 Manuel utilisateur

Black & Decker

Black & Decker BLC18750DM Manuel utilisateur

Sunbeam

Sunbeam 4182 Manuel utilisateur

Bialetti

Bialetti FMX35 Manuel utilisateur

Black & Decker

Black & Decker BL8000 Manuel utilisateur

Duronic

Duronic BL530 Manuel utilisateur

Exquisit

Exquisit MS 3002 wes Manuel utilisateur

Lumme

Lumme LU-KP1891A Manuel utilisateur

Binatone

Binatone HB-735 Manuel utilisateur

Moulinex

Moulinex LM936E10 Manuel utilisateur

Oster

Oster VERSA Manuel d'installation et d'exploitation

Ninja

Ninja NN210Q Manuel utilisateur
