USER

MANUAL

MODEL 1069

OnSite™ VDSL2 CPE

REGULATORY MODEL NUMBER:

3342D4-001

SALES OFFICE

(301) 975-1000

TECHNICAL SUPPORT

(301) 975-1007

Part# 07M1069-UM

Rev. C

Revised 7/3/12

An ISO-9001Certified

Company

This is a Class A device and is not intended for

use in a residential environment.

CONTENTS

1.0 Warranty Information ................................................................. 3

1.1 Regulatory Information ................................................................. 3

EMC Directive:.............................................................................. 3

Low-Voltage Direcive (Safety): ..................................................... 3

PSTN: ........................................................................................... 3

1.2 Radio and TV Interference (FCC Part 15) .................................... 3

1.3 CE Declaration of Conformity ....................................................... 4

1.4 Authorized European Representative........................................... 4

1.5 Service.......................................................................................... 4

1.6 Safety When Working With Electricity .......................................... 5

2.0 General Information.................................................................... 7

2.1 Features........................................................................................ 7

2.2 Description.................................................................................... 7

2.3 Application .................................................................................... 8

3.0 Installation................................................................................... 9

3.1 Connecting the Line Interface..................................................... 10

3.2 Connecting the 10/100Base-T Ethernet Interface ...................... 11

3.3 Connecting the POTS/ISDN Line ............................................... 11

3.4 Connecting Power ...................................................................... 12

4.0 Configuration ............................................................................ 12

5.0 Operation................................................................................... 13

5.1 Front Panel LED Status Monitors ............................................... 13

Specifications ........................................................................... 14

A.1 VDSL2 ......................................................................................... 14

A.2 LAN Connection ......................................................................... 14

A.3 Transmission Line ....................................................................... 14

A.4 LED Status Indicators ................................................................. 14

A.5 Power Supply .............................................................................. 14

A.6 Temperature Range .................................................................... 14

A.7 Humidity ...................................................................................... 14

A.8 Dimensions ................................................................................. 14

Model 1069 Series Factory

Replacement Parts and Accessories...................................... 15

Model 1069 Series Interface Pin Assignment ........................ 16

C.1 10/100Base-T Interface .............................................................. 16

RJ-45 .......................................................................................... 16

C.2 VDSL2 Interface .......................................................................... 16

RJ-45 .......................................................................................... 16

C.3 POTS/ISDN Interface .................................................................. 16

RJ-45 .......................................................................................... 16

1.0 WARRANTY INFORMATION

Patton Electronics warrants all Model 1069 components to be free from

defects, and will—at our option—repair or replace the product should it

fail within one year from the first date of the shipment.

This warranty is limited to defects in workmanship or materials, and does

not cover customer damage, abuse or unauthorized modification. If this

product fails or does not performs as warranted, your sole recourse shall

be repair or replacement as described above. Under no condition shall

Patton Electronics be liable for any damages incurred by the use of this

product. These damages include, but are not limited to, the following: lost

profits, lost savings and incidental or consequential damages arising

from the use of or inability to use this product. Patton Electronics spe-

cifically disclaims all other warranties, expressed or implied, and the

installation or use of this product shall be deemed an acceptance of

these terms by the user.

Note Conformity documents of all Patton products can be viewed

online at www.patton.com under the appropriate product page.

1.1 REGULATORY INFORMATION

EMC Directive:

• FCC Part 15, Class A

• EN55022, Class A

• EN55024

• A-tick

Low-Voltage Direcive (Safety):

• IEC/EN60950-1, 2nd Edition

• AS/NZS 60950-1, A-tick

PSTN:

• This device is not intended nor approved for connection to the PSTN

1.2 RADIO AND TV INTERFERENCE (FCC PART 15)

This device generates and uses radio frequency energy, and if not

installed and used properly-that is, in strict accordance with the manufac-

turer’s instructions-may cause interference to radio and television recep-

tion. The device has been tested and found to comply with the limits for a

Class A computing device in accordance with specifications in Subpart B

of Part 15 of FCC rules, which are designed to provide reasonable pro-

tection from such interference in a commercial installation. However,

there is no guarantee that interference will not occur in a particular instal-

lation. If the device does cause interference to radio or television recep-

tion, which can be determined by disconnecting the unit, the user is

encouraged to try to correct the interference by one or more of the follow-

ing measures: moving the computing equipment away from the receiver,

re-orienting the receiving antenna and/or plugging the receiving equip-

ment into a different AC outlet (such that the computing equipment and

receiver are on different branches).

1.3 CE DECLARATION OF CONFORMITY

Patton Electronics, Inc declares that this device is in compliance with the

essential requirements and other relevant provisions of Directive

2004/108/EC relating to electromagnetic compatibility and Directive

2006/95/EC relating to electrical equipment designed for use within cer-

tain voltage limits. The Declaration of Conformity may be obtained from

Patton Electronics, Inc at www.patton.com/certifications.

The safety advice in the documentation accompanying this device shall

be obeyed. The conformity to the above directive is indicated by CE

mark on the device.

1.4 AUTHORIZED EUROPEAN REPRESENTATIVE

D R M Green

European Compliance Services Limited.

Avalon House, Marcham Road

Abingdon, Oxon OX14 1UD, UK

1.5 SERVICE

All warranty and non-warranty repairs must be returned freight prepaid

and insured to Patton Electronics. All returns must have a Return Materi-

als Authorization number on the outside of the shipping container. This

number may be obtained from Patton Electronics Technical Services at:

• Tel: +1 (301) 975-1007

• Email: support@patton.com

• URL: http://www.patton.com

Note Packages received without an RMA number will not be

accepted.

1.6 SAFETY WHEN WORKING WITH ELECTRICITY

• This device contains no user serviceable parts. This

device can only be repaired by qualified service per-

sonnel.

• Do not open the device when the power cord is con-

nected. For systems without a power switch and without

an external power adapter, line voltages are present

within the device when the power cord is connected.

• For devices with an external power adapter, the power

adapter shall be a listed Limited Power Source. The

mains outlet that is utilized to power the device shall be

within 10 feet (3 meters) of the device, shall be easily

accessible, and protected by a circuit breaker in com-

pliance with local regulatory requirements.

• For AC powered devices, ensure that the power cable

used meets all applicable standards for the country in

which it is to be installed.

• For AC powered devices which have 3 conductor

power plugs (L1, L2 & GND or Hot, Neutral &

Safety/Protective Ground), the wall outlet (or socket)

must have an earth ground.

• For DC powered devices, ensure that the interconnect-

ing cables are rated for proper voltage, current, antici-

pated temperature, flammability, and mechanical

serviceability.

• WAN, LAN & PSTN ports (connections) may have haz-

ardous voltages present regardless of whether the

device is powered ON or OFF. PSTN relates to inter-

faces such as telephone lines, FXS, FXO, DSL, xDSL,

T1, E1, ISDN, Voice, etc. These are known as “hazard-

ous network voltages” and to avoid electric shock use

caution when working near these ports. When discon-

necting cables for these ports, detach the far end con-

nection first.

• Do not work on the device or connect or disconnect

cables during periods of lightning activity.

WARNING

In accordance with the requirements of council direc-

tive 2002/96/EC on Waste of Electrical and Electronic

Equipment (WEEE), ensure that at end-of-life you sepa-

rate this product from other waste and scrap and deliver

to the WEEE collection system in your country for recy-

cling.

This device contains no user serviceable parts. This

device can only be repaired by qualified service per-

sonnel.

This device is NOT intended nor approved for connec-

tion to the PSTN. It is intended only for connection to

customer premise equipment.

Electrostatic Discharge (ESD) can damage equipment

and impair electrical circuitry. It occurs when electronic

printed circuit cards are improperly handled and can

result in complete or intermittent failures. Do the fol-

lowing to prevent ESD:

• Always follow ESD prevention procedures when

removing and replacing cards.

• Wear an ESD-preventive wrist strap, ensuring that it

makes good skin contact. Connect the clip to an

unpainted surface of the chassis frame to safely chan-

nel unwanted ESD voltages to ground.

• To properly guard against ESD damage and shocks,

the wrist strap and cord must operate effectively. If no

wrist strap is available, ground yourself by touching the

metal part of the chassis.

WARNING

2.0 GENERAL INFORMATION

Thank you for your purchase of this Patton Electronics product. This

product has been thoroughly inspected and tested and is warranted for

one year for parts and labor. If any questions or problems arise during

installation or use of this product, contact Patton Electronics Technical

Support at +1 (301) 975-1007.

2.1 FEATURES

• VDSL2 - Easy to configure

• Auto-MDIX Ethernet

• Auto-Negotiating Ethernet 10/100BaseTX, Full/Half Duplex

• Extends up to 4x 10/100Base-TX Ethernet beyond 328-foot (100-

meter) limitation over a single twisted-pair or Cat5+

• POTS/ISDN splitter on board

• Transparent operation

• LED indicators for Power, DSL, CPE, and Ethernet Link/Activity

2.2 DESCRIPTION

The Patton Electronics Model 1069 OnSite CPE provides high-speed

VDSL2 connections to any standards-based VDSL2 DSLAM.

The Model 1069 can automatically forward LAN broadcasts, multicasts,

and frames across a 2-wire voice-grade twisted-pair link. The data is

passed transparently (unmodified) from the VDSL2 DSLAM through the

1069. The 1069 automatically adds and deletes MAC addresses, only

passing packets across the VDSL2 link.

Figure 1 on page 8 describes the rear panel ports on the Model 1069

VDSL CPE.

Figure 1. Model 1069 rear panel

2.3 APPLICATION

In an example application, the VDSL2 CPE modem is placed in either

MxU environments or individual residents for delivering triple play ser-

vices including “fiber like” high-speed broadband service. Built-in

POTS/ISDN splitters allow for both data and voice to be broken out at the

CPE.

Figure 2. Model 1069 and VDSL DSLAM application

!"#$

!"#%!"#&!"#'

&'()*+&,

-./0120)3

Power

ack

Reset switch

Ethernet ports

(0-3)

VDSL twisted-pair

RJ-45 interface

POTS/ISDN twisted-pair

RJ-45 interface

3.0 INSTALLATION

To connect the Model 1069, do the following:

1. Connect the Line port of the Model 1069 with a telephone cable

(refer to section 3.1, “Connecting the Line Interface” on page 10).

2. Connect an Ethernet port to the network card of a PC via an Ether-

net cable (refer to section 3.2, “Connecting the 10/100Base-T Ether-

net Interface” on page 11).

3. Connect the Power plug to the wall outlet (refer to section 3.4, “Con-

necting Power” on page 12).

Figure 3 displays the connections of the unit to a PC, telephones, DSL

outlet, and power outlet.

Figure 3. Model 1069 connection diagram

The Interconnecting cables shall be acceptable for

external use and shall be rated for the proper applica-

tion with respect to voltage, current, anticipated tem-

perature, flammability, and mechanical serviceability.

CAUTION

Wall Outlet with

VDSL2 Service

POTS/ISDNLineEth0 Eth1 Eth2 Eth3Power

3.1 CONNECTING THE LINE INTERFACE

The Model 1069 supports communication over a distance of up to 10,000

ft (3 km) over 24 AWG (0.5 mm) twisted-pair wire or Cat5+.

Note Actual distance and link performance may vary.

Follow the steps below to connect the Model 1069 interfaces.

1. To function properly, the Model 1069 must be connected with the

VDSL2 DSLAM using twisted-pair, unconditioned, dry, metal wire,

between 19 (0.9mm) and 26 AWG (0.4mm). Leased circuits that run

through signal equalization equipment are not acceptable.

2. The Model 1069 is equipped with an RJ-45 interface jack that can be

used on the VDSL2 link interface. The VDSL2 link interface is a two-

wire interface. Observe the signal/pin relationships on the Model

1069's VDSL2 interface jack.

The RJ-45 connector on the Model 1069's twisted pair interface is polar-

ity insensitive and is wired for a two-wire interface. The signal/pin rela-

tionship is shown in Figure 4.

Figure 4. Model 1069 (RJ-45) twisted pair line interface.

The Interconnecting cables shall be acceptable for

external use and shall be rated for the proper applica-

tion with respect to voltage, current, anticipated tem-

perature, flammability, and mechanical serviceability.

CAUTION

1 (no connection)

2 (no connection)

3 (no connection)

4 (RING)

5 (TIP)

6 (no connection)

7 (no connection)

8 (no connection)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Patton electronics Modem

Patton electronics

Patton electronics RocketLink 3202 Manuel utilisateur

Patton electronics

Patton electronics 1068 Manuel utilisateur

Patton electronics

Patton electronics OnSite 1052 Series Manuel utilisateur

Patton electronics

Patton electronics 1088/I Manuel utilisateur

Patton electronics

Patton electronics 1000P Manuel utilisateur

Patton electronics

Patton electronics 1092A Manuel utilisateur

Patton electronics

Patton electronics NetLink 1082/I Manuel utilisateur

Patton electronics

Patton electronics 1002S Manuel utilisateur

Patton electronics

Patton electronics 1010B Manuel utilisateur

Patton electronics

Patton electronics 1094 Manuel utilisateur

Patton electronics

Patton electronics 1040 Manuel utilisateur

Patton electronics

Patton electronics 3010 Manuel utilisateur

Patton electronics

Patton electronics 1093 Manuel utilisateur

Patton electronics

Patton electronics 1017 Manuel utilisateur

Patton electronics

Patton electronics 1008 Manuel utilisateur

Patton electronics

Patton electronics 2703RC Manuel utilisateur

Patton electronics

Patton electronics Kilolight 1184 Manuel utilisateur

Patton electronics

Patton electronics 1045 Manuel utilisateur

Patton electronics

Patton electronics ParaLink 1225 Manuel utilisateur

Patton electronics

Patton electronics RS-232 Manuel utilisateur

Patton electronics

Patton electronics 1194 Manuel utilisateur

Patton electronics

Patton electronics 1080A Manuel utilisateur

Patton electronics

Patton electronics 1004A Manuel utilisateur

Patton electronics

Patton electronics 1088/C Manuel utilisateur

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
