NXP Semiconductors I.MX 8M Manuel utilisateur

AN13027

EdgeLockTM SE05x Quick start guide with i.MX 8M

Rev. 1.1 — 7 December 2020 Application note

Document information

Information Content

Keywords EdgeLock SE05x, Plug & Trust middleware, i.MX 8M

Abstract This document explains how to get started with the EdgeLock SE05x Plug &

Trust middleware using the EdgeLock SE05x development boards and i.MX

8M board. It provides detailed instructions for connecting the boards, installing

the software, running the EdgeLock SE05x Plug & Trust project examples and

executing the ssscli tool

NXP Semiconductors AN13027

EdgeLockTM SE05x Quick start guide with i.MX 8M

Revision history

Revision number Date Description

1.0 2020-10-21 First document release.

1.1 2020-12-07 Updated to latest template and fixed broken links

Revision history

Application note Rev. 1.1 — 7 December 2020

2 / 26

NXP Semiconductors AN13027

EdgeLockTM SE05x Quick start guide with i.MX 8M

1 How to use this document

The Plug & Trust middleware includes a set of project examples that demonstrate the use

of EdgeLock SE05x product family in the latest IoT security use cases. This document

provides detailed instructions to run project examples for EdgeLock SE05x in i.MX 8M

board. The main body of this document should be used in this sequence:

1. Order board samples. Section 2 contains the ordering details of the demo boards

required in this document;

2. Prepare the hardware. Section 3 describes how to setup the OM-SE05xARD and i.MX

8M boards.

3. Flash the microSD card image. Section 4 describes how to create a micro-SD card

with the Linux image with the pre-installed Plug & Trust middleware.

4. Run project examples. Section 5 describes how to run EdgeLock SE05x included in

Plug & Trust middleware.

Supplementary material is provided in the appendices.

Application note Rev. 1.1 — 7 December 2020

3 / 26

NXP Semiconductors AN13027

EdgeLockTM SE05x Quick start guide with i.MX 8M

2 Hardware required

The EdgeLock SE05x works as an auxiliary security device attached to a host controller,

communicating with through an I²C interface. To follow the instructions provided in this

document, you need an EdgeLock SE05x development board and a i.MX 8M MCU

board, acting as a host controller.

EdgeLock SE05x development boards ordering details

The EdgeLock SE05x support package provides development boards for evaluating

EdgeLock SE050 and EdgeLock SE051 features. Select the development board of the

product you want to evaluate. Table 1 details the ordering details of the EdgeLock SE05x

development boards.

Part number 12NC Description Picture

OM-SE050ARD 935383282598 SE050 Arduino®

compatible

development kit

OM-SE051ARD 935399187598 SE051 Arduino®

compatible

development kit

Table 1. EdgeLock SE05x development boards.

Note: The pictures in this guide will show OM-SE050ARD, but OM-SE051ARD can be

used as well with the same configuration.

i.MX 8M MCU board ordering details

Table 2 details the ordering details for the i.MX 8M board.

Part number 12NC Content Picture

MCIMX8M-EVK 935378743598 i.MX 8M evaluation kit

Table 2. i.MX 8M development kit details

Application note Rev. 1.1 — 7 December 2020

4 / 26

NXP Semiconductors AN13027

EdgeLockTM SE05x Quick start guide with i.MX 8M

3 Boards setup

This section explains how to prepare the OM-SE05xARD boards and i.MX 8M board to

run the EdgeLock SE05x Plug & Trust middleware project examples. Follow these steps:

1. Connect the OM-SE05xARD to the i.MX 8M board. The i.MX 8M board does not

come with an Arduino connector, so you have to connect the Arduino shield of the

OM-SE05xARD board to the J801_I2C connector of the i.MX 8M board using wires.

Table 3 details the jumper connection

OM-SE05xARD (# jumper - #

pin)

I.MX 8M (# jumper - # pin) Description

J2 - Pin 10 J801 - Pin 1 SCL

J2 - Pin 7 J801 - Pin 2 Ground

J2 - Pin 9 J801 - Pin 3 SDA

J8 - Pin 3 J801 - Pin 5 3.3 Volt supply

Table 3. Wire connection OM-SE05xARD - i.MX 8M

and Figure 1 illustrate the wiring between boards.

Figure 1. Connection between OM-SE05xARD and i.MX 8M boards

Application note Rev. 1.1 — 7 December 2020

5 / 26

NXP Semiconductors AN13027

EdgeLockTM SE05x Quick start guide with i.MX 8M

2. Make sure the jumper settings in your OM-SE05xARD board are configured as shown

in Figure 2:

Figure 2. Jumper configuration for i.MX 8M board

Note: For more information about the jumper settings, refer to AN12395 (OM-

SE05xARD) and AN13016 (OM-SE051ARD) respectively.

Application note Rev. 1.1 — 7 December 2020

6 / 26

NXP Semiconductors AN13027

EdgeLockTM SE05x Quick start guide with i.MX 8M

4 Software setup

The software setup consists of:

1. Preparing a micro-SD card with the pre-compiled Linux image with the preinstalled

Plug & Trust middleware for i.MX 8M board, as described in Section 4.1.

2. Installing the USB to UART Bridge VCOM driver in your laptop, as described in

Section 4.2.

3. Installing TeraTerm terminal application, as described in Section 4.3.

4. Booting the i.MX 8M board, as described in Section 4.4.

4.1 Micro-SD card preparation

To prepare the micro-sd card with the pre-compiled Linux image that includes the Plug &

Trust middleware, you need to:

1. Download from NXP website the Plug & Trust middleware SD Card Image. This

image contains the Plug & Trust middleware pre-installed with already some

examples on a bootable SD Card Image.

Note: In case the image provided by NXP does not suit your use case, you can

find the explanation of how to create an card image using Yocto in the Plug & Trust

middleware documentation (simw-top/doc/dev-platforms/platform_imx8_linux.html) .

2. Download and install Win32 Disk Imager software. Win32 Disk Imager is a Windows

open source program to format SD card images. Instead of Win 32 Disk Imager, you

could also use any other software for this operation.

3. Plug your micro-SD card in your laptop.

Application note Rev. 1.1 — 7 December 2020

7 / 26

NXP Semiconductors AN13027

EdgeLockTM SE05x Quick start guide with i.MX 8M

4. Open Win32 Disk Imager, (1) select from your file system the pre-compiled Linux

image you downloaded from the website, and (2) click on the Write button as shown

in Figure 3.

Note: the SD card image might come in a ZIP package. Make sure to unzip the

package and change the extension to .img before selecting the image file in Win32

Disk Imager.

Figure 3. Micro-SD card preparation with Win32 Disk Imager software

4.2 Drivers

To install the i.MX 8M drivers, follow these steps:

Application note Rev. 1.1 — 7 December 2020

8 / 26

NXP Semiconductors AN13027

EdgeLockTM SE05x Quick start guide with i.MX 8M

1. Plug the power supply and connect the USB cable to your laptop as shown in

Figure 4.

Figure 4. Plug the power supply and connect the USB cable to your laptop

2. Download the USB to UART Bridge VCOM driver for your processor (either 32 or 64

bits). Install the driver by following the setup wizard until it is finished.

3. Unplug and plug your board.

Application note Rev. 1.1 — 7 December 2020

9 / 26

NXP Semiconductors AN13027

EdgeLockTM SE05x Quick start guide with i.MX 8M

4. Go to your Device Manager, and check that your board is recognized and assigned

to a port number (COMxx). Write down the assigned port number (COMxx) as it is

needed in the next steps. Your Device Manager should look like Figure 5.

Note: if you see more than one COM port, use the one denoted as Enhanced COM

port.

Figure 5. Check that i.MX 8M board is recognized in Device Manager

4.3 Terminal setup

We need to install a terminal application, for instance TeraTerm, to communicate

and view the serial output of the i.MX 8M board from our laptop. To setup TeraTerm

application:

1. Download TeraTerm and run the installer.

2. Launch TeraTerm, click the Serial option and select from the dropdown list the

Enhanced COM port number assigned to your i.MX 8M board (In this case COM11)

as shown in Figure 6. Click the OK button to confirm the setup. If you cannot see the

Application note Rev. 1.1 — 7 December 2020

10 / 26
