Nvidia TESLA M2050 Manuel utilisateur

BD-05238-001_v03 | August 2010

Board Specification

TESLA M2050 AND

TESLA M2070/M2070Q

DUAL-SLOT COMPUTING

PROCESSOR MODULES

Tesla M2050 and

Tesla M2070/M2070Q

Dual-Slot Computing Processor Modules BD-05238-001_v03 | ii

DOCUMENT CHANGE HISTORY

BD-05238-001_v03

Version Date Authors Description of Change

01 April 22. 2010 GB, SM Initial Release (Preliminary information)

02 April 28, 2010 GB, DV •Removed “Preliminary Information” text

•Added Figure 3

•Memory clock changed from 1.6 GHz to 1.546

GHz

03 August 6, 2010 GG, SM •

Updated the memory clock for Tesla M2070

to 1.566 GHz

•Added Tesla M2070Q

Tesla M2050 and

Tesla M2070/M2070Q

Dual-Slot Computing Processor Modules BD-05238-001_v03 | iii

TABLE OF CONTENTS

Overview ........................................................................................... 1

Key Features..................................................................................... 2

Computing Processor Description............................................................. 3

Configuration .................................................................................... 4

Mechanical Specifications ....................................................................... 5

PCI Express System ............................................................................. 5

Standard I/O Connector Placement .......................................................... 6

Internal Connectors and headers ............................................................. 7

External PCI Express Power Connectors .................................................. 7

Power Specifications ............................................................................11

Support Information.............................................................................12

Certificates and Agencies..................................................................... 12

Agencies ...................................................................................... 12

Languages ....................................................................................... 13

Tesla M2050 and

Tesla M2070/M2070Q

Dual-Slot Computing Processor Modules BD-05238-001_v03 | iv

LIST OF FIGURES

Figure 1. Tesla T20 GPU Block Diagram ...................................................... 3

Figure 2. Tesla M2050 and Tesla M2070/M2070Q Computing Processor Module ........ 5

Figure 3. Tesla M2050 and Tesla M2070/M2070Q Bracket.................................. 6

Figure 4. 6-Pin PCI Express Power Connector................................................ 8

Figure 5. 8-Pin PCI Express Power Connector................................................ 9

LIST OF TABLES

Table 1. Board Configurations................................................................. 4

Table 2. 6-Pin PCI Express Power Connector Pinout ...................................... 10

Table 3. 8-Pin PCI Express Power Connector Pinout ...................................... 10

Table 4. Configuration with External PCI Express Connectors........................... 11

Table 5. Languages Supported ............................................................... 13

Tesla M2050 and

Tesla M2070/M2070Q

Dual-Slot Computing Processor Modules BD-05238-001_v03| 1

OVERVIEW

The NVIDIA® Tesla™M20-Series graphics processing unit (GPU) Computing Module is a

PCI Express, double-wide, full-height (4.376 inches by 9.75 inches by 1.52 inches) form

factor computing module based on the NVIDIA Fermi GPU. This module comprises a

computing subsystem wit h a GPU and high speed memory.

This module is offered with two memory sizes:

The Tesla M2050 module offers 3 GB of GDDR5 memory on board.

The Tesla M2070 and Tesla M2070Q module offers 6 GB of GDDR5 memory on

board.

Both of these products can be configured by the OEM or by the end user to enable or

disable ECC or error correcting codes that can fix single-bit errors and report double-bit

errors. Enabling ECC will cause some of the memory to be used for the ECC bits, so the

user available memory will decrease to approximately 2.62 GB for a Tesla M2050 and

approximately 5.25 GB for a Tesla M2070 and Tesla M2070Q.

The Tesla M2070Q GPU computing module uses the NVIDIA Fermi GPU that combines

Tesla’s high performance computing and the NVIDIA Quadro®professional-class

advanced visualization in the same GPU. Tesla M2070Q is the ideal solution for

customers, who want to deploy high performance computing, advanced and remote

visualization in a datacenter.

Overview

Tesla M2050 and

Tesla M2070/M2070Q

Dual-Slot Computing Processor Modules BD-05238-001_v03 | 2

KEY FEATURES

GPU

Number of processor cores: 448

Processor core clock: 1.15 GHz

Package size: 42.5 mm × 42.5 mm 1981-pin ball grid array (BGA)

Board

PCI Express Gen2 ×16 system interface

Physical dimensions: 4.376 inches × 9.75 inches, dual slot

Board power dissipation: < = 225 W

External Connectors

None

Internal Connectors and Headers

One 6-pin PCI Express power connector

One 8-pin PCI Express power connector

Memory

Memory clock

●1.546 GHz for Tesla M2050

●1.566 GHz for Tesla M2070 and Tesla M2070Q

Interface: 384-bit

●Tesla M2050

―3 GB

―24 pieces 64M × 16 GDDR5 136-pin BGA, SDRAM

●Tesla M2070 and Tesla M2070Q

―6 GB

―24 pieces 128M × 16 GDDR5 136-pin BGA, SDRAM

BIOS

2Mbit Serial ROM

Overview

Tesla M2050 and

Tesla M2070/M2070Q

Dual-Slot Computing Processor Modules BD-05238-001_v03 | 3

COMPUTING PROCESSOR DESCRIPTION

Figure 1 is a block diagram of the Tesla T20 GPU used on the Tesla M20-series products.

Figure 1. Tesla T20 GPU Block Diagram

Overview

Tesla M2050 and

Tesla M2070/M2070Q

Dual-Slot Computing Processor Modules BD-05238-001_v03 | 4

CONFIGURATION

There is one configuration available (Table 1) for the Tesla M2050 and Tesla M2070.

Table 1. Board Configurations

Specification Tesla M2050 Tesla M2070 and Tesla M2070Q

Generic SKU reference 900-21030-0050-000 •

Tesla M2070: 900-21030-0070-000

•Tesla M2070Q: 900-21030-0080-000

Chip Tesla T20 GPU Tesla T20 GPU

Package size GPU 42.5 mm x 42.5 mm 42.5 mm x 42.5 mm

Processor clock 1.15 GHz 1.15 GHz

Memory clock 1.546 GHz 1.566 GHz

Memory size •3 GB total

•2.62 GB available with ECC

enabled

•6 GB total

•5.25 GB available with ECC

enabled

Memory I/O 384-bit GDDR5 384-bit GDDR5

Memory configuration 24 pcs 64M × 16 GDDR5 SDRAM 24 pcs 128M × 16 GDDR5 SDRAM

External connectors None None

Internal connectors

and headers

•8-pin PCI Express power

connector

•6-pin PCI Express power

connector

•8-pin PCI Express power connector

•6-pin PCI Express power connector

Board power < = 225 W < = 225 W

Thermal cooling

solution

Passive heat sink Passive heat sink

Tesla M2050 and

Tesla M2070/M2070Q

Dual-Slot Computing Processor Modules BD-05238-001_v03| 5

MECHANICAL SPECIFICATIONS

PCI EXPRESS SYSTEM

The Tesla M2050 and Tesla M2070/M2070Q computing processor boards (Figure 2)

conform to the PCI Express full height (4.376 inches by 9.75 inches) form factor. Figure 2

is shown without the bracket.

Figure 2. Tesla M2050 and Tesla M2070/M2070Q Computing Processor

Module

9.75 inches

4.376 inches

Mechanical Specifications

Tesla M2050 and

Tesla M2070/M2070Q

Dual-Slot Computing Processor Modules BD-05238-001_v03 | 6

STANDARD I/O CONNECTOR PLACEMENT

As shown in Figure 3, the Tesla M2050 and Tesla M2070/M2070Q include a vented

bracket. If you are an OEM who qualifies for bracket modifications, you have the option

of receiving your modules with no bracket installed.

Figure 3. Tesla M2050 and Tesla M2070/M2070Q Bracket
