TESLA™K20

AcTivE AccELErATor

for WorKSTATion

inSTALLATion guidE

NVIDIA Tesla K20

Active Accelerator

for Workstation

TESLA K20 inSTALLATion guidE

TABLE OF CONTENTS

Introduction 1

About This Guide 1

Minimum System Requirements 2

Unpacking 3

Equipment 3

Hardware Installation 5

Safety Instructions 5

Before You Begin 6

Installing the Tesla K20 Graphics Card 6

Driver Installation 11

Downloading and Installing Windows Driver 11

Verifying the Windows Driver Installation 13

Linux Installation 14

Compliances 17

TABLE OF CONTENTS



INTRODUCTION

With many mainstream applications now taking

advantage of the GPU computing found in the

NVIDIA®Tesla™K20, leading-edge customers

are producing breakthroughs in their industries

by achieving better results in a shorter period

of time. Adding the NVIDIA Tesla K20 to an

industry-standard workstation and conﬁguring

it with an NVIDIA Quadro Professional Graphics

Solution enables performance scaling across a

wide range of professional applications.

About This Guide

This installation guide discusses the installation and conﬁguration of

the Tesla K20 Active Accelerator for Workstations.



INTRODUCTION

 Minimum System Requirements

Prior to unpacking your new Tesla K20, conﬁrm that your system meets

all the requirements for a smooth installation.

>Operating System

zMicrosoft Windows Vista, Windows 7 (32-bit versions of

Windows are not supported, 64-bit only)

zLinux 32-bit and 64-bit on:

zFedora 16

zRHEL 5.x

zRHEL 6.x

>Processor

zIntel Pentium 4 or Xeon processor or higher

zAMD Athlon processor or higher

>RAM

z5 GB recommended per Tesla K20

>PCI Express Slot

zPCI Express x16 slot, Gen2 recommended but not required

>Power Consumption

z225 W maximum power consumption

zPower supply must have two 6-pin power connectors.



UNPACKING

Prior to unpacking your new NVIDIA Tesla

K20 Active Accelerator graphics card, it is

important to make sure you meet all the system

requirements listed on page 2 for a smooth

installation.

Be sure to inspect each piece of equipment

shipped in the packing box. If anything is missing

or damaged, contact your reseller.

Equipment

The following equipment and documentation are included in the

graphics card box.

WELCOME

Registration Card

phone support.

Tesla K20 Active Accelerator

Installs into the PCI Express x16 slot in your computer.

(An image of the card showing the connectors is on the

following page.



UNPACKING



SLI and Framelock

connectors disabled

Power connectors

back-edge of card

Tesla K20 Computing Processor



HARDWARE INSTALLATION

Installing the NVIDIA Tesla K20 Active

Accelerator graphics card hardware involves

opening up your computer. Follow all of the

safety instructions provided here to ensure that

there is no damage to you, your computer, or the

graphics board.

Safety Instructions

To reduce the risk of ﬁre, electric shock, or injury, always follow basic

safety precautions.

Note: All hardware must be installed prior to installation of

the drivers.

>Remove power from your computer by disconnecting the AC main

source before installation.

>Do not operate this product near water or when your hands or

body are wet.

>Do not place this product on soft surfaces that could block the

ventilation slots and cause overheating.

>Do not place this product near a heating register or radiator.

>Place this product securely on a stable surface. Serious damage

to this product may result if it falls.

>Do not allow anything to rest on the power cord. Do not place

this product where a person can step or trip on the power cord.


