Numark C2 Manuel utilisateur
Confidential Numark Service Manual
Numark
C2 / CM100
Service Manual
Rev. 1
2010.02.09
The information in this document contains privileged and confidential information. It is intended
only for the use of those authorized by Numark. If you are not the authorized, intended recipient,
you are hereby notified that any review, dissemination, distribution or duplication of this document
is strictly prohibited. If you are not authorized, please contact Numark and destroy all copies of
Copyright Numark Industries
ATTENTION!
THIS DOCUMENT CONTAINS SENSITIVE
PROPRIETARY INFORMATION.
ALL RECIPIENTS MUST HAVE A CURRENT
NON-DISCLOSURE AGREEMENT ON FILE
WITH NUMARK INDUSTRIES.
DO NOT MAKE ILLEGAL
COPIES OF THIS DOCUMENT
Confidential Numark Service Manual
PREFACE
This document is intended to assist the service technician in the operation, maintenance and
repair of the Numark device. Together with the User Reference Manual, this document provides
a complete description of the functionality and serviceability of the Device. Any comments or
suggestions you may have pertaining to the document are welcome and encouraged.
READ THIS!
In addition to any purchase price that Numark may charge as consideration for Numark selling or
otherwise transferring this service manual (“Manual”) to you, if you are not a service and repair
facility (“Service Center”) authorized by Numark in writing to be an authorized Service Center,
Numark sells or transfers the Manual to you on the following terms and conditions:
Only Service Centers authorized by Numark in writing are authorized to perform service and
repairs covered by an Numark warranty (if any), and transfer of the Manual to you does not
authorize you to be an authorized Service Center. Therefore, if you perform, or if the Manual
is used to perform, any service or repairs on any Numark product or part thereof, any and
all warranties of Numark as to that product and any service contract with Numark for that
product shall be voided and shall no longer apply for such product, even if your services
or repairs were done in accordance with the Manual.
All service or repairs done by you or with reference to the Manual shall be solely your
responsibility, and Numark shall have no liability for any such repairs or service work. All such
service or repairs are performed at the sole risk of the person performing the service or
repairs. You agree that all such work will be performed in a competent, professional and safe
manner at all times and to indemnify and fully hold Numark and its successors and assigns
harmless in the event of any failure to so perform.
Your purchase of the Manual shall be for your own ultimate use and shall not be for purposes of
resale or other transfer.
As the owner of the copyright to the Manual, Numark does not give you the right to copy the
Manual, and you agree not to copy the Manual without the written authorization of Numark.
Numark has no obligation to provide to you any correction of, or supplement to, the Manual, or
any new or superseding version thereof.
Numark shall have the right to refuse to sell or otherwise transfer repair parts or materials to you
in its sole discretion. You shall not use, sell or otherwise transfer spare or replacement parts
supplied by Numark to you (i) to repair or be used in products manufactured for or by third parties
or (ii) to any third parties for any purpose.
You shall not make any warranties or guarantees with respect to the products of Numark or the
use thereof on behalf of Numark or in your own name.
The foregoing describes the entire understanding related to sale or transfer of the Manual to you,
and no other terms shall apply unless in a writing signed by an authorized representative of
Numark.
All Trademarks are property of their respective companies.
Confidential Numark Service Manual
WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK OR FIRE, DO NOT EXPOSE
THIS PRODUCT TO WATER OR MOISTURE.
The arrowhead symbol on a lightning flash inside a triangle is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the enclosed product which may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point inside a triangle is intended to alert the user
to the presence of important operating, maintenance and servicing
instructions in the literature which accompanies the product.
REPAIR BY ANY PERSON OR ENTITY OTHER THAN AN AUTHORIZED
NUMARK SERVICE CENTER WILL VOID THE NUMARK WARRANTY.
PROVISION OF THIS MANUAL DOES NOT AUTHORIZE THE RECIPIENT TO
COMPETE WITH ANY NUMARK DISTRIBUTOR OR AUTHORIZED REPAIR
SERVICE CENTER IN THE PROVISION OF REPAIR SERVICES OR TO BE
OR MAKE REPAIRS AS AN AUTHORIZED SERVICE CENTER.
ALL REPAIRS DONE BY ANY ENTITY OTHER THAN AN AUTHORIZED
NUMARK SERVICE CENTER SHALL BE SOLELY THE RESPONSIBILITY OF
THAT ENTITY, AND NUMARK SHALL HAVE NO LIABILITY TO THAT ENTITY
OR TO ANY OTHER PARTY FOR ANY REPAIRS BY THAT ENTITY.
Regarding the Power Supply Fuse
CAUTION: The product under service may employ the use of a
replaceable fuse. Danger of fire or electrocution if fuse is incorrectly
replaced. Replace with only the same type or equivalent type
recommended by the equipment manufacturer.
Regarding the Internal Battery
CAUTION: The product under service may employ the use of a
internal battery. Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries
according to the manufacturer's instruction.
Confidential Numark Service Manual
Safety Instructions
Carefully read the applicable items of the operating instructions and these safety suggestions
before using this product. Use extra care to follow the warnings written on the product itself and in
the operating instructions. Keep the operating instructions and safety suggestions for reference in
the future.
1. Power Source. The product should only be connected to a power supply which is described
either in the operating instructions or in markings on the product.
2. Power Cord Protection. AC power supply cords should be placed such that no one is likely to
step on the cords and such that nothing will be placed on or against them.
3. Periods of Non-use. If the product is not used for any significant period of time, the product's
AC power supply cord should be unplugged from the AC outlet.
4. Foreign Objects and Liquids. Take care not to allow liquids to spill or objects to fall into any
openings of the product.
5. Water or Moisture. The product should not be used near any water or in moisture.
6. Heat. Do not place the product near heat sources such as stoves, heat registers, radiators or
other heat producing equipment.
7. Ventilation. When installing the product, make sure that the product has adequate
ventilation. Improperly ventilating the product may cause overheating, which may damage the
product.
8. Mounting. The product should only be used with a rack which the manufacturer
recommends. The combination of the product and rack should be moved carefully. Quick
movements, excessive force or uneven surfaces may overturn the combination which may
damage the product and rack combination.
9. Cleaning. The product should only be cleaned as the manufacturer recommends.
10. Service. The user should only attempt the limited service or upkeep specifically described in
the operating instructions for the user. For any other service required, the product should be
taken to an authorized service center as described in the operating instructions.
11. Damage to the Product. Qualified service personnel should service the unit in certain
situations including without limitation when:
a. Liquid has spilled or objects have fallen into the product,
b. The product is exposed to water or excessive moisture,
c. The AC power supply plug or cord is damaged,
d. The product shows an inappropriate change in performance or does not operate
normally, or
e. The enclosure of the product has been damaged.
PARTS NO. DESCRIPTION C2
C-CM-033-00T C-C 33P TAPING 4
C-CM-047-00T C-C 47P TAPING 9
C-CM-068-00T C-C 68P TAPING 8
C-CM-110-00T C-C 100P TAPING 12
C-CM-122-00T C-C 220P TAPING 12
C-CM-133-00T C-C 330P TAPING 2
C-CM-147-00T C-C 470P TAPING 2
C-CM-168-00T C-C 680P TAPING 6
C-CM-210-00T C-C 102P TAPING 2
C-CM-247-02 C-C 472/400V 1
C-CM-322-00T C-C 223Z TAPING 2
C-CM-410-00T C-C 104Z TAPING 3
C-EC-010-30T C-E 10U25V TAPING 11
C-EC-010-31T C-E 10U25V MINI TAPING 24
C-EC-022-30T C-E 22U25V TAPING 6
C-EC-022-31T C-E 22U25V MINI TAPING 4
C-EC-047-20T C-E 47U16V TAPING 17
C-EC-047-21T C-E 47U16V MINI TAPING 15
C-EC-110-21T C-E 100U16V MINI TAPING 14
C-EC-122-30 C-E 220U25V 2
C-EC-210-30 C-E 1000U25V 2
C-EC-Z10-51T C-E 1U50V MINI TAPING 4
C-EC-Z47-50T C-E 4.7U50V TAPING 8
C-EC-Z47-51T C-E 4.7U50V MINI TAPING 8
C-PL-210-00T C-P 102J TAPING 2
C-PL-227-00T C-P 272J TAPING 2
C-PL-239-00T C-P 392J TAPING 1
C-PL-247-00T C-P 472J TAPING 2
C-PL-282-00T C-P 822J TAPING 6
C-PL-310-00T C-P 103J TAPING 2
C-PL-315-00T C-P 153J TAPING 1
C-PL-327-00T C-P 273J TAPING 6
C-PL-333-00T C-P 333J TAPING 2
C-PL-339-00T C-P 393J TAPING 2
C-PL-347-00T C-P 473J TAPING 6
C-XT-368-02 CASE MINI 683J 2
C-XT-415-00 CASE MINI 154J 2
C-XT-482-00T C-MONOL 824M 4
E-DO-003-00T DIODE IN4004 5
E-DO-004-02 DIODE IN4531 17
E-FU-001-01 FUSE 0.5A250V UL CSA 1
E-IC-002-01 IC NJM7805 1
E-IC-006-01 IC NJM7815 1
E-IC-009-01 IC NJM7915 1
E-IC-013-01 IC AN6554 4
E-IC-059-01 IC NJM4558L 16
E-IC-064-01 IC NJM4556L 1
E-IC-087-00 IC 78L05 1
E-IC-102-00 IC LB1482M 1
E-IC-106-00 IC 74HCT14 2
E-JK-021-00 RCA JACK 4P CPS-044 6
E-JK-023-00 H/P JACK CPJ-065 1
E-JK-027-02 AC INPUT SOCKET SC-8F 1
E-JK-038-00 CANNON JACK 087-35-180 2
E-JK-046-00 P/H JACK 0611 1
E-JK-051-00 NEUTRIK NCJ5FI-V-0 1
E-JK-053-00 H/P JACK CPJ-3055G 2
E-LD-041-00 LED 3* BL-B5141J 7
E-LD-043-00 LED 3* BL-B3141J 27
E-LD-050-00 LED SL1-0748CP 2
E-LD-051-00 LED SLP-0749CO 2
E-PC-164-00 FADER VR PCB 1
E-PC-170-01 CM100 MAIN PCB 1
E-PC-171-00 CM100 SUB PCB 1
E-PT-038-00 P.T XDM-242 1
E-SW-010-01 SW SDDLE1007 1
E-SW-056-00 SW ROTARY L430Y022H01 2
E-SW-059-00 LEVER SW LBC23M-095 1
E-SW-064-00 SW HF-308 3PIN 1
E-SW-066-00 LEVER SW LBC22M-085 5
E-SW-077-00 SLIDE SW SS-22F39-G5 3
E-SW-101-00 SW SS90040-0402-9T-NN 1
E-SW-104-00 SW SPEA12MC01 6
E-SW-108-00 SW SPEA12MA01 2
E-SW-109-00 SW SPEA12MC03 2
E-TR-008-00 TR 2SA1015 1
E-TR-034-00 TR 2SC2878 4
E-TR-038-00 TR DTC114 2
E-VR-062-10 VR RA3030-20-20A1-B15 1
E-VR-116-00 VR RK16K1140133 50KB C.C. 2
E-VR-117-00 VR RK16K12D0019 50KAX2 2
E-VR-118-00 VR RK16K1240042 10KBX2 5
E-VR-120-00 VR RK16K124A038 50KMN 1
E-VR-124-00 VR RK16K12D0038 50KBX2 1
E-VR-125-00 VR RK16K1140038 50KA 1
E-VR-128-10 VR RA3022-20-20DA-B24-C 20KBX2 5
E-VR-164-00 VR RS45Y12A2019 50KAX2 5
E-VR-168-00 VR RF45T12G3101 100KBX2 1
E-WI-019-00 CORD AL201*AL501 0.5
E-WI-021-00 CORD AL300*AL501 0.5
F-AL-059-13 FADER PANEL 2008 1
F-AL-113-04 FRONT PANEL C2 1
F-BK-032-00 EARTH BRACKET DM1190 1
F-CH-112-00 TOP COVER DM1090 1
F-CH-178-02 RAER PANEL C2 1
F-CH-179-00 MAIN CHASSIS CM100 1
K-CT-143-03 INNER CARTON C2 1
K-CT-144-03 OUTER CARTON C2 0.25
K-MU-105-02 INSTR MANUAL C2 1
K-MU-128-00 SAFETY MANUAL, NUMARK 1
K-PL-025-00 POLY LON DM1090 2
P-CN-002-01 CONNECTOR M2411-2 180-RED 1
P-CN-004-01 CONNECTOR 3P XH 3
P-CN-005-00 CONNECTOR M2411-4P 1
P-CN-007-01 CONNECTOR 5P XH 1
P-CN-025-01 CONNECTOR M2411 2P-90 1
P-CN-026-01 CONNECTOR M2411-5P 90 1
P-CN-027-01 CONNECTOR M2411-6P 90 1
P-CN-030-01 CONNECTOR M2411-3P RED 2
P-CN-031-01 CONNECTOR M2411-2P 3
P-CN-032-01 CONNECTOR M2411-3P 3
P-CN-035-01 CONNECTOR M2411-3P BULE 1
P-CN-039-01 CONNECTOR M2411-3P 1
P-CN-042-01 CONNECTOR M2411-4P 3
P-CN-043-01 CONNECTOR M2411-6P 1
P-CN-058-00 BNC CONNECTOR 94V-204C1 1
P-FR-024-00 SLIDE VR HOLDER 1080 5
P-FR-035-00 EQ HOLDER 5P XDM-242 1
P-FR-040-00 LED HOLDER 12孔 DM1000X 2
P-FR-045-00 FADER HOLDER CM100 1
P-KB-004-00 SLIDE VR KNOB SV-N001 6
P-KB-004-05 FADER KNOB SV-N001 NUMARK 1
P-KB-064-00 KNOB 7*7 PS-W006 1
P-KB-065-01 EQ KNOB DM1175 5
P-KB-066-03 LV KNOB LV-S002 6
P-KB-067-00 KNOB 15* K003 DM1080 2
P-KB-067-03 KNOB 15* K003 12
P-KB-079-00 KNOB 7* ROUND 10
P-RB-005-00 FOOT GL-4 2
P-RB-011-00 FOOT 12*H36 2
P-XT-001-00 CABLE TIES LCT-98 7
P-XT-024-00 EVA 30*10*4 2
P-XT-056-00 DUST CLOTH 20*9*0.5 1
P-XT-060-00 LED HOLDER LE48216 10
P-XT-064-01 DUST CLOTH 76*20*0.25T 1
P-XT-067-00 ORNAMENT P.V.C 1.0T 1
P-XT-071-00 SPACER L550D098H01 1
P-XT-072-00 DUST CLOTH 30*5*1085 6
P-XT-086-00 DUST CLOTH 35*35 1
P-XT-095-00 FIBER 42*42 1
P-XT-096-00 DUST CLOTH EQ 5P 69*50 1
P-XT-120-01 TUBE 30*35MM 1
P-XT-121-01 TUBE 6* 15MM 6
R-CB-010-10T R-C 1/16W 10J 2
R-CB-033-10T R-C 1/16W 33J 8
R-CB-039-10T R-C 1/16W 39J 6
R-CB-110-10T R-C 1/16W 100J 26
R-CB-110-30 R-C 1/2W 100J 1
R-CB-118-10T R-C 1/16W 180J 6
R-CB-122-10T R-C 1/16W 220J 23
R-CB-139-10T R-C 1/16W 390J 4
R-CB-147-10T R-C 1/16W 470J 8
R-CB-182-10T R-C 1/16W 820J 4
R-CB-191-10T R-C 1/16W 910J 4
R-CB-210-10T R-C 1/16W 1K 8
R-CB-212-10T R-C 1/16W 1.2K 8
R-CB-218-10T R-C 1/16W 1.8K 5
R-CB-222-10T R-C 1/16W 2.2K 26
R-CB-227-10T R-C 1/16W 2.7K 4
R-CB-233-10T R-C 1/16W 3.3K 16
R-CB-239-10T R-C 1/16W 3.9K 5
R-CB-247-10T R-C 1/16W 4.7K 10
R-CB-256-10T R-C 1/16W 5.6K 4
R-CB-282-10T R-C 1/16W 8.2K 6
R-CB-310-10T R-C 1/16W 10K 16
R-CB-315-10T R-C 1/16W 15K 24
R-CB-318-10T R-C 1/16W 18K 8
R-CB-322-10T R-C 1/16W 22K 14
R-CB-327-10T R-C 1/16W 27K 2
R-CB-333-10T R-C 1/16W 33K 2
R-CB-339-10T R-C 1/16W 39K 2
R-CB-347-10T R-C 1/16W 47K 17
R-CB-356-10T R-C 1/16W 56K 4
R-CB-368-10T R-C 1/16W 68K 1
R-CB-375-10T R-C 1/16W 75K 9
R-CB-410-10T R-C 1/16W 100K 35
R-CB-412-10T R-C 1/16W 120K 5
R-CB-447-10T R-C 1/16W 470K 1
R-CB-456-10T R-C 1/16W 560K 1
R-CB-510-10T R-C 1/16W 1M 4
R-MR-033-40 R-C 1W 33J 1
W-BC-122-00 LEAD 60MM 3P 2877AWG26 1
W-DB-222-00 LEAD 80MM 2P 5051 2877AWG26 1
W-EA-132-00 LEAD 90MM UL1007AWG24 1
W-ED-222-00 LEAD 90MM 4P 5051 2877AWG26 3
W-FB-122-00 LEAD 100MM 2P 2877AWG26 1
W-FC-122-00 LEAD 100MM 3P UL2877AWG26 1
W-FE-222-00 LEAD 100MM 5P 5051 2877AWG26 1
W-GB-122-00 LEAD 110MM 2P 2877AWG26 1
W-HC-522-00 LEAD 120MM 3P 2877AWG26 1
W-IB-122-00 LEAD 130MM 2P UL2877AWG26 1
W-IC-222-00 LEAD 130MM 5051 UL2877AWG26 2
W-IC-561-00 LEAD 130MM 3P P241852 1
W-IC-581-00 LEAD 130MM 3P P241852 1
W-IC-922-00 LEAD 130MM 3P 5051 紅色 1
W-JP-006-00 JP 6MM 50
W-JP-010-00 JP 10MM 45
W-JP-015-00 JP 15MM 15
W-JP-020-00 JP 20MM 2
W-LF-122-00 LEAD 160MM 6P 2877AWG26 3
W-MB-222-00 LEAD 180MM 2P 5051 UL2877AWG26 1
W-MB-922-00 LEAD 180MM 2P 5051 RED 1
W-MC-122-00 LEAD 180MM 3P 2877AWG26 1
W-MF-222-00 LEAD 180MM 6P 5051 2877AWG26 1
W-NC-222-00 LEAD 200MM 3P 5051 2877AWG26 2
W-NE-122-00 LEAD 200MM 5P UL2877AWG26 1
W-OA-132-00 LEAD 220MM 1007AWG24 1
W-OB-222-00 LEAD 220MM 2P 5051 2877AWG26 1
W-OD-222-00 LEAD 220MM 4P 5051 UL2877AWG26 1
W-PF-222-00 LEAD 240MM 6P 5051 UL2877AWG26 1
W-RC-822-00 LEAD 280MM 3P 5051 BLUE 1
W-SB-222-00 LEAD 300MM 2P 5051 2877AWG26 1
W-ZZ-003-00 LEAD 130MM 1617AWG22 BLUE 1
W-ZZ-004-00 LEAD 130MM 1617AWG22 BRN 1
W-ZZ-110-00 LEAD 200MM 3P 2877AWG26 1
Autres manuels pour C2
1
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Numark Matériel de DJ
Numark
Numark DXM 06 Document technique
Numark
Numark NS7 Manuel utilisateur
Numark
Numark IDJ PRO Manuel utilisateur
Numark
Numark iCDMIX 3 Manuel utilisateur
Numark
Numark DJ2Go2 Manuel utilisateur
Numark
Numark iDJ Document technique
Numark
Numark MIXTRACK PLATINUM FX Manuel utilisateur
Numark
Numark iCDMIX 2 Manuel utilisateur
Numark
Numark NDX500 Manuel utilisateur
Numark
Numark NS6 Manuel utilisateur
Numark
Numark NS6 Manuel utilisateur
Numark
Numark NS4 FX Manuel utilisateur
Numark
Numark NS7 III Manuel utilisateur
Numark
Numark PHAT TRAK Manuel utilisateur
Numark
Numark 4TRAK Manuel utilisateur
Numark
Numark STEALTH CONTROL Manuel d'instructions
Numark
Numark PARTY MIX Manuel utilisateur
Numark
Numark OMNI CONTROL Manuel d'instructions
Numark
Numark MIXSTREAM PRO Manuel utilisateur
Numark
Numark NS6 Manuel utilisateur
Manuels Matériel de DJ populaires d'autres marques
thomann
thomann Stairville DJ Lase 40-G MK-III Manuel utilisateur
Eagletone
Eagletone 6 Eyes Flower Manuel utilisateur
EuroLite
EuroLite FLD-1508 Manuel utilisateur
Technical Pro
Technical Pro LG8xSEA Manuel utilisateur
JB Systems
JB Systems Lounge Laser DMX Manuel utilisateur
Lightmaxx
Lightmaxx Vega Halo 90 Manuel utilisateur
Elation
Elation FUZE WASH Z350 Manuel utilisateur
Maverick
Maverick MK3 WASH Manuel utilisateur
Infinity
Infinity TF-260C7 Fresnel Manuel utilisateur
Chauvet
Chauvet EVE E-50Z Manuel utilisateur
Eliminator Lighting
Eliminator Lighting E 138 Manuel utilisateur
EuroLite
EuroLite Mini Multicolor LED Flashing Light SC Manuel utilisateur
