Spray Height Controlle

Hagie (STS 120’)

Installation Manual

HG06

Printed in Canada

Reorder P/N: UC5-BC-HG06-INST Rev C (Hagie STS 120’)

NOTICE: NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and

without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information

contained in this manual. The technical information in this manual was reviewed at the time of approval for publication.

Contents

1Introduction ............................................................................................................... 1

2General UC5 System Layout ................................................................................... 2

3Kit Parts...................................................................................................................... 3

4Ultrasonic Sensor Installation.................................................................................. 6

5Roll Sensor Installation ............................................................................................. 9

6Module Installation.................................................................................................. 13

7Connecting the Sensors to the CANbus .............................................................. 17

8Hydraulic Installation.............................................................................................. 18

9Cable Drawings........................................................................................................ 19

1Introduction

Congratulations on your purchase of the NORAC UC5 Spray Height Controller. This system

is manufactured with top quality components and is engineered using the latest technology to

provide operating reliability unmatched for years to come.

When properly used the system can provide protection from sprayer boom damage, improve

sprayer efficiency, and ensure chemicals are applied correctly.

Please take the time to read this manual completely before attempting to install the system. A

thorough understanding of this manual will ensure that you receive the maximum benefit from

the system.

Your input can help make us better! If you find issues or have suggestions regarding the parts

list or the installation procedure, please don’t hesitate to contact us.

Every effort has been made to ensure the accuracy of the information contained in

this manual. All parts supplied are selected to specially fit the sprayer to facilitate

a complete installation. However, NORAC cannot guarantee all parts fit as

intended due to the variations of the sprayer by the manufacturer.

Please read this manual in its entirety before attempting installation.

2General UC5 System Layout

Figure 1 illustrates the general layout of the UC5 system components:

Figure 1: General UC5 System Layout

3Kit Parts

3.1 Kit Overview

Figure 2: HG06 System Parts

3.2 Hydraulic Plumbing

Figure 3: HG06 Hydraulic Plumbing Parts

The use of dielectric grease is not recommended on any NORAC electrical

connections.

To ensure all stainless steel hardware does not gall or seize apply a light coating of

the supplied Permatex Anti-seize grease to all threaded parts upon installation.

Permatex Anti-seize lubricant is preferred, but other similar anti-seize products

may be used.

3.3 UC5-HYD-HG06 – HG06 Hydraulics Kit Parts List

Item Part Number Name Quantity

E02 43720 UC5 VALVE MODULE 1

P01 106034 UC5 NETWORK 2 PIN PLUG 2

V01 44960D VALVE BLOCK ASSEMBLY 3 STATION CC/LS PROP DT 4 BOLT 1

3.4 UC5-CAB-HG03/HG06 – HG03/HG06 Cab Kit Parts List

Item Part Number Name Quantity

C01 43260-13 CABLE UC5 NETWORK HAGIE STS CAB TO BULKHEAD 1

C02 43260-14 CABLE UC5 NETWORK HAGIE STS BULKHEAD TO VIM 1

C03 43260-11 CABLE UC5 NETWORK HAGIE STS CHASSIS TO BOOM DISCONNECT 1

C20 43260-10 CABLE UC5 INTERFACE CAN BUS (3 PIN DT) 36IN 1

C21 43764-01 UC5 NETWORK ADAPTER CAN LINES ONLY 1

C30 43250-16 CABLE UC5 BATTERY 6-PIN DT (ECU AND SIGNAL POWER) 1

E01 43710 UC5 CONTROLLER MODULE 2

P02A 106339 CONN DEUTSCH DT04 B KEY 12 PIN FLANGED RECEPTACLE 1

P02B 106035 UC5 NETWORK 12 PIN PLUG (A-KEY) 1

3.5 UC5-BOOM-HG06 – HG06 Boom Kit Parts List

Item Part Number Name Quantity

C04 43260-12 CABLE UC5 NETWORK HAGIE STS BOOM DISCONNECT TO 8-WAY 1

C05 43210-0.5 CABLE UC5 NETWORK 18 AWG 0.5M 1

C06 43210-03 CABLE UC5 NETWORK 18 AWG 3M 3

C07 43210-10 CABLE UC5 NETWORK 18 AWG 10M 4

C08 43210-01 CABLE UC5 NETWORK 18 AWG 1M 1

E04 43741* UC5 ROLL SENSOR VER. 2 3

E05 43750 UC5 ULTRASONIC SENSOR 5

E10 43760 UC5 NETWORK COUPLER 3-WAY 2

E11 43765 UC5 NETWORK COUPLER 8-WAY 1

E12 43764 UC5 NETWORK COUPLER 2-WAY 4

E20 43764T UC5 NETWORK COUPLER 2-WAY WITH TERMINATOR 2

M02 UC5-BC-HG06-INST MANUAL INSTALLATION UC5 HAGIE STS10/12 120' 1

P03 106162 UC5 NETWORK 6 PIN PLUG MOLDED 2

* For systems purchased BEFORE October 1, 2011, the roll sensor part number is 43740.

4Ultrasonic Sensor Installation

4.1 Ultrasonic Sensor Serial Number Arrangement

When installing the UC5 sensors, start with the smallest serial number on the left-hand side,

and proceed to the largest serial number on the right hand side. Each UC5 sensor has a serial

number stamped on the sensor housing.

Apply a light coating of the supplied Permatex Anti-seize grease to all threaded

parts upon installation.

Figure 4: Sensor Serial Number Arrangement

4.2 Wing Sensor Installation

1. Mount the NORAC UC5 ultrasonic sensor into the sensor bracket and run the sensor

cable behind the bracket so that it will not interfere with the sensor readings.

Figure 5: Inner Sensor

Figure 6: Outer Sensor
