RAU OEM
End-User Installation Manual
Spray Height Controller
Improving the competitiveness of Industry and
Agriculture through Precision Measurement
Printed in Canada
Copyright ©2005-08 by NORAC Systems International Inc.
Reorder P/N: UC4+BC+RA1+INSTE Rev A (RAU OEM)
NOTICE
NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update
products sold previously. Every effort has been made to ensure the accuracy of the information contained in this manual. The technical information in
this manual was reviewed at the time of approval for publication.
1
1 INTRODUCTION
Congratulations on your purchase of the NORAC UC4+ Spray Height Controller. This system is
manufactured with top quality components and is engineered using the latest technology to provide
operating features and reliability unmatched for years to come.
When properly used the system can provide protection from sprayer boom damage, improve sprayer
efficiency, and ensure chemicals are applied correctly.
Please take the time to read this manual completely before attempting to install the system. A thorough
understanding of this manual will ensure that you receive the maximum benefit from the system.
YOUR INPUT CAN HELP MAKE US BETTER! If you find issues or have suggestions regarding
the parts list or the installation procedure, please don’t hesitate to contact us via the information
given below:
Phone: 1-800-667-3921 Canada (Toll Free)
1-866-306-6722 United States (Toll Free)
0-800-404-8389 United Kingdom (Toll Free)
1-306-664-6711 all other regions
2 PARTS LISTS
The parts that come with your UC4+ Sprayer Boom System are listed below. The item number on the left
side of this table references each part.
Item Part Number Name Quantity
C10* 44650-35 CABLE POWER GENERIC PULL-TYPE 1
E01* 4461BC+ UC4 PLUS BOOM CONTROL PANEL 1
M01A* 446BC+MAN6-1 MANUAL UC4+ BOOM CONTROL 2008 OPERATORS SMALL BOOKLET 1
M01B* 446BC+MAN6-2 MANUAL UC4+ BOOM CONTROL 2008 QUICK REFERENCE SMALL BOOKLET 1
M13* UC4+BC+RA1-INSTE MANUAL INSTALLATION END-USER RAU 1
2
3 CONTROL PANEL MOUNTING
Install the UC4+ control panel (E01) in the cab of the sprayer with the supplied mounting bracket. The
location must facilitate connecting the power cable (C10) to the bottom of the UC4+ Control Panel.
Using the adjustable RAM mount on the control panel (E01), mount panel as shown in Figure 1.
Figure 1 – Mounted UC4 panel
3
4 CABLE INSTALLATION
Figure 2 – Cable Routing Overview
1. Connect C10 to the UC4 control panel in the sprayer cab. Ensure that both plugs (P16A and P4)
are connected to the panel.
2. Route the receptacle end (R16) of C10 to the exterior of the cab and connect to C11 at the hitch.
Ensure cable is routed in a safe manner to avoid damage.
3. Connect Power to Harness C10 via the 3-pin AMP plug. If this plug does not fit a power source in
the tractor, cut off the connector and hard-wire to a power source. Ensure the power source is
fused (10A).
4. All other cables and connections have already been factory installed.
POWER
CONNECTION
HITCH
CONNECTION
4
5 COMPLETING THE INSTALLATION
1. Turn on the power for the UC4+ Control Panel using the switch on the side of its chassis. Ensure that
the display lights up to confirm that the panel has proper +12 volt power.
2. After a moment the panel will display the main operational screen:
↓M 45 M↓
3. For optimal performance, the UC4+ system must calibrate itself to the tractor unit powering the
sprayer hydraulics, which is an automated process.
Performing a RETUNE requires that the sprayer is unfolded and the booms have full range
of moment. This should also be performed on a flat area of ground, over gravel or dirt. Do
not attempt to perform a retune over grass.
4. To initiate the RETUNE process, navigate from the Main Operational Screen to the “RETUNE”
menu, following the instructions below:
•Using the left-hand toggle switch on the UC4+ panel, toggle the switch down towards “Setup”
until ↓RETUNE?↓appears on the display.
•At this point, answer YES to the panel by toggling the right-hand toggle switch up towards “Yes”.
•The panel will start the RETUNE process. Follow the on-screen prompts.
Additional information concerning the RETUNE procedure may be found in the UC4+
Operator’s Manual and the UC4+ Quick Reference Manual
5. The installation of the UC4+ system is now complete. Refer to the Quick Guide (M01B) for
operation instructions.
5
Notes:
6
Canada
NORAC Systems International Inc.
CALL TOLL FREE: 1-800-667-3921
(306)664-6711
SHIPPING ADDRESS:
3702 Kinnear Place
Saskatoon, SK
S7P 0A6
United States
Norac, Inc.
CALL TOLL FREE: 1-866-306-6722
(763)786-3080
SHIPPING ADDRESS:
1290 Osborne Rd NE, Suite F
Fridley, MN
55432-2892
