Nokia HDW-1 Manuel utilisateur

User’s Guide for the Wireless

Headset (HDW-1)

9353783

Issue 2

hdw-1_2-00.fm Page 1 Wednesday, April 24, 2002 9:24 AM

DECLARATION OF CONFORMITY

We, NOKIA CORPORATION declare under our sole responsibility that the product

HDW-1 is in conformity with the provisions of the following Council Directive:

1999/5/EC.

A copy of the Declaration of Conformity can be found from

http://www.nokia.com/phones/declaration_of_conformity/.

Reproduction, transfer, distribution or storage of part or all of the contents in this document in

any form without the prior written permission of Nokia is prohibited.

Nokia is a registered trademark of Nokia Corporation. Other product and company names

mentioned herein may be trademarks or tradenames of their respective owners.

Nokia operates a policy of continuous development. Nokia reserves the right to make changes

and improvements to any of the products described in this document without prior notice.

Under no circumstances shall Nokia be responsible for any loss of data or income or any

special, incidental, consequential or indirect damages howsoever caused.

The contents of this document are provided "as is". Except as required by applicable law, no

warranties of any kind, either express or implied, including, but not limited to, the implied

warranties of merchantability and fitness for a particular purpose, are made in relation to the

accuracy, reliability or contents of this document. Nokia reserves the right to revise this

document or withdraw it at any time without prior notice.

The availability of particular products may vary by region. Please check with the Nokia dealer

nearest to you.

9353783 / Issue 2

hdw-1_2-00.fm Page 2 Wednesday, April 24, 2002 9:24 AM

Contents

Introduction ............................. 4

Bluetooth wireless technology .......... 4

Chargers and batteries ......................... 5

The sticker in the sales package........ 5

1. Getting started..................... 6

Overview................................................... 6

Charging the battery ............................ 7

When the battery charge

falls low................................................. 8

Adjusting the headset to your ear .... 8

Switching the headset on or off ....... 9

Taking the headset into use

for the first time .................................... 9

Troubleshooting ................................ 10

Placing the headset on the ear........ 11

2. Using the headset .............. 12

Connecting the paired

headset to your phone ....................... 12

Making a call ........................................ 13

Voice dialling ........................................ 13

Ending a call......................................... 13

Answering a call.................................. 13

Rejecting a call.................................... 13

Automatic answer............................... 14

Redialling the last dialled number. 14

Adjusting the earphone volume ..... 14

Switching the call between

phone and headset ............................. 14

Disconnecting the headset

from the phone.................................... 15

Reconnecting the paired

headset to your phone................... 15

Using the headset with

several phones ..................................... 15

Using the headset with

several paired phones..................... 15

Resetting the headset........................ 16

3. Battery information ........... 17

Care and maintenance........... 19

hdw-1_2-00.fm Page 3 Wednesday, April 24, 2002 9:24 AM

Introduction

The Wireless Headset HDW-1 can be connected without wires to a

compatible phone that supports Bluetooth wireless technology. This gives

you complete freedom for making and receiving calls while on the move

or at the office.

Read this user’s guide carefully before using the headset. More detailed

information is given in your phone’s user's guide. Do not use this Wireless

Headset (HDW-1) user’s guide in place of your phone’s user's guide, which

provides important safety and maintenance information.

■Bluetooth wireless technology

Since Bluetooth devices communicate using radio waves, your Bluetooth

phone and headset do not need to be in a line of sight. The two devices

only need to be within a maximum of 10 meters of each other, although

the connection can be subject to interference from obstructions, such as

walls, or from other electronic devices.

The headset is specially designed for Nokia phones that support Bluetooth

wireless technology. The headset can, however, be used with any

compatible Bluetooth devices that support the Handsfree profile. (Here,

"Profile" means a set of Bluetooth commands that your phone uses for

controlling the headset.)

The headset provides the best performance when it is used with a

compatible Nokia phone. If you use the headset with a phone produced by

hdw-1_2-00.fm Page 4 Wednesday, April 24, 2002 9:24 AM

Introduction

another manufacturer, all the functions described in this user’s guide may

not be available.

In some countries, there may be restrictions on using Bluetooth devices.

Check with your local authorities.

■Chargers and batteries

Check the model number of any charger before use with this device. The

Wireless Headset HDW-1 is intended for use with the following chargers:

ACP-7, ACP-8, ACP-9, ACP-12, LCH-8 and LCH-9.

Warning! Use only batteries and chargers approved by the phone

manufacturer for use with this particular accessory. The use of

any other types will invalidate any approval or warranty applying

to the accessory, and may be dangerous.

For availability of approved batteries and chargers, please check with your

dealer.

When you disconnect the power cord of any accessory, grasp and pull the

plug, not the cord.

■The sticker in the sales package

The sticker contains the Bluetooth passkey you need for pairing your

phone with the headset. Keep this sticker in a safe and secure place.

For using the passkey, see Taking the headset into use for the first time on

page 9.

hdw-1_2-00.fm Page 5 Wednesday, April 24, 2002 9:24 AM

Getting started

1. Getting started

■Overview

The headset has the

following parts.

1 - Handset ():

Answers or ends the call.

This key can also be used

for voice dialling and

switching an active call

between the headset and

the phone.

2 - Indicator light:

Shows the current status

of the headset.

3 - Volume up: Increases the earphone volume during a call.

4 - Volume down: Decreases the earphone volume during a call. To

switch the headset on or off, press and hold this key.

5 - Earphone: Relays the caller’s voice.

6 - Charger connector

7 - Microphone: Picks up your voice.

hdw-1_2-00.fm Page 6 Wednesday, April 24, 2002 9:24 AM

Getting started

■Charging the battery

The headset has a built-in rechargeable NiMH battery. If you need to

replace the battery, take the headset to your nearest qualified service

facility.

To charge the battery:

1. Connect the charger cable to the headset. For a list of compatible

chargers, see Chargers and batteries on page 5.

2. Connect the charger to an AC wall outlet. The red indicator light is

shown during charging. Charging the battery fully takes about 1 to 2

hours, depending on the charger.

3. When the battery is fully charged, the green indicator light is shown.

Disconnect the charger from the AC wall outlet and the headset.

hdw-1_2-00.fm Page 7 Wednesday, April 24, 2002 9:24 AM

Getting started

When the battery charge falls low

The fully charged battery has power for up to 4 hours of talk time and up

to 100 hours of standby time. (In standby mode, the headset is switched

on but no call is in progress.)

When the battery is running out of power, the headset beeps. Charge the

battery as described above.

■Adjusting the headset to your ear

You can wear the headset on either ear.

To change the orientation of the earpiece, turn the earpiece boom to back

and rotate it to the opposite side of the headset.

hdw-1_2-00.fm Page 8 Wednesday, April 24, 2002 9:24 AM

Getting started

■Switching the headset on or off

To switch on: Press and hold the volume down key for 2 seconds. The

headset beeps and the green indicator light starts blinking. The blinking

continues until the headset is connected to your phone, within 5 minutes.

If the headset cannot be connected to your phone during this time, the

headset is switched off.

To switch off: Press and hold the volume down key for 2 seconds. The

headset beeps and the red indicator light is shown briefly. Note that the

headset cannot be switched off during a call.

■Taking the headset into use for the first time

1. Make sure that your phone is switched on.

2. Switch on the headset.

3. Enter your phone’s Bluetooth menu and make sure that the Bluetooth

feature is activated.

4. Enter the submenu where you can set the phone to search for

Bluetooth devices, and start the search.

The phone searches for all Bluetooth devices within about 10 meters

and shows them as a list.

5. Select the headset from the list.

6. Enter the passkey to associate ("pair") and connect the headset to your

phone. The passkey is marked on the sticker that is provided in the

sales package of the headset.

hdw-1_2-00.fm Page 9 Wednesday, April 24, 2002 9:24 AM

Getting started

Once you have entered the passkey, your phone becomes the default

phone that uses the headset, if the headset has not been previously

paired with another phone. See also Using the headset with several

phones on page 15.

The headset beeps and appears in the phone menu where you can view

the Bluetooth devices that are currently paired with your phone.

7. Start using the headset (see page 12).

Troubleshooting

If you cannot connect the headset to your phone, proceed as follows:

•Make sure that the headset is switched on and paired with your phone.

•Make sure that the Bluetooth feature is activated on your phone.

•Check that the headset is within a maximum of 10 meters of your

phone and that there are no obstructions, such as walls, or other

electronic devices between the headset and the phone.

•The pairing information list of the headset may be full. The headset

can store the information of up to 8 phones at a time. If the list

becomes full, reset the headset to the original settings, see page 16.

•If the headset does not respond to your actions, press and hold the

volume down key for 10 seconds.

hdw-1_2-00.fm Page 10 Wednesday, April 24, 2002 9:24 AM

Table des matières

Autres manuels Nokia casque

Nokia

Nokia BH-803 - Headset - Over-the-ear Manuel utilisateur

Nokia

Nokia BH-601 Manuel utilisateur

Nokia

Nokia BH-503 Manuel utilisateur

Nokia

Nokia BH-940 Manuel utilisateur

Nokia

Nokia BH-500 Manuel utilisateur

Nokia

Nokia BH-500 Manuel utilisateur

Nokia

Nokia hs-13w - Wireless Image Headset Manuel utilisateur

Nokia

Nokia HS-16 Manuel utilisateur

Nokia

Nokia HS-21W Manuel utilisateur

Nokia

Nokia HS 26W - Headset - Over-the-ear Manuel utilisateur

Nokia

Nokia BH 604 - Headset - Binaural Manuel utilisateur

Nokia

Nokia 9232254 Manuel utilisateur

Nokia

Nokia BH-902 Manuel utilisateur

Nokia

Nokia HS-27R Manuel utilisateur

Nokia

Nokia BH-806 Manuel utilisateur

Nokia

Nokia WH-500 Manuel utilisateur

Nokia

Nokia BH 104 - Headset - Over-the-ear Guide d'installation

Nokia

Nokia BH 300 - Headset - Over-the-ear Manuel utilisateur

Nokia

Nokia BH 604 - Headset - Binaural Manuel utilisateur

Nokia

Nokia HS 11W Manuel utilisateur

Nokia

Nokia BH-607 Manuel utilisateur

Nokia

Nokia BH-303 - Headset - Over-the-ear Manuel utilisateur

Nokia

Nokia BH-222 Manuel utilisateur

Nokia

Nokia HS-54W - Headset - Over-the-ear Guide de démarrage rapide

Manuels casque populaires d'autres marques

Sena

Sena SMH10 Manuel utilisateur

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuel utilisateur

Sennheiser

Sennheiser EPOS ADAPT 230 Manuel utilisateur

Doro

Doro Flexus HS2005 Manuel utilisateur

GE 98971 Manuel utilisateur

Hama

Hama 00184070 Manuel utilisateur

Plantronics

Plantronics Blackwire 3200 Series Manuel utilisateur

Blue Tiger

Blue Tiger Advantage PLUS Manuel utilisateur

Jawbone

Jawbone Icon Manuel utilisateur

Jabra

Jabra FR 20 Manuel utilisateur

Roxcore

Roxcore Flow A+ Manuel utilisateur

Turtle Beach

Turtle Beach XP 510 Manuel utilisateur

Philips

Philips SHB6101 Manuel utilisateur

Jabra

Jabra PRO 9460 Duo Manuel utilisateur

HyperX

HyperX HyperX Cloud Flight Manuel utilisateur

Bose

Bose MIE2 Mobile Manuel utilisateur

Jabra

Jabra Steel Manuel utilisateur

HyperX

HyperX cloud ii Manuel utilisateur
