User Guide
Nokia Wireless Loopset LPS-6
Issue 1 EN
Contents
Safety 3
Get started 4
Keys and parts 4
Charge the battery 4
Take the loopset into use 5
Pair and connect your loopset with your
phone 6
Pair and connect your loopset using NFC 6
Basic use 8
Make and receive calls 8
Handle two calls 8
Listen wirelessly with Bluetooth 8
Use USB audio connection 9
Change the volume 9
Clear settings or reset your loopset 10
Troubleshooting 11
Product and safety information 12
Copyrights and other notices 16
Copyrights and other notices 19
User Guide
Nokia Wireless Loopset LPS-6
© 2013 Nokia. All rights reserved.
2
Safety
Read these simple guidelines. Not following them may be dangerous or illegal.
We invite you to read the instructions on this guide before using the device.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may cause interference
or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for use with this device.
Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods. Exercise
caution when holding your device near your ear while the loudspeaker is in use.
© 2013 Nokia. All rights reserved.
3
Get started
Keys and parts
1 Neck loop
2 Vibrating alert motor
3Multifunctionkey
4Microphone
5NFCarea
6 USB connector
7 Charging status indicator
8Volumekeys
9Powerkey
10 Bluetooth connection indicator
Charge the battery
1. Connect the charger to a wall outlet.
2. Connect the charger cable to the charger connector.
The charging status indicator shows the progress of the charging, turning from red to yellow and
finally to green when the battery is fully charged. Charging the battery fully may take up to 2 hours.
3. When the battery is fully charged, disconnect the charger from the loopset first, then from the wall
outlet.
The fully charged battery has power for up to 12 hours of talk time or up to 300 hours of standby
time.
Tip: To check the charging status when you're connected to a phone, press the power key. The
charging status indicator shows the battery level (red=low, yellow=good, green=full).
When the battery is close to discharged, the loopset vibrates and beeps about every 5 minutes, and
the charging status indicator quickly flashes red.
© 2013 Nokia. All rights reserved.
4
Take the loopset into use
1. If necessary, pull out the neck loop plug.
2. Place the neck loop around your neck, and push the plug in the connector.
3. To switch on, press the power key.
If you haven't paired the loopset with any device before, the loopset vibrates once, and the Blueooth
connection indicator blinks quickly.
4. To enter pairing mode, press the multifunction key for about 2 seconds.
The Bluetooth connection indicator flashes steadily. You can now pair the loopset with a phone.
If you have paired the loopset before, the loopset tries to connect to the device that you last paired
with. The loopset remembers the last 8 devices that it was paired with. If it doesn't detect the latest
one, it tries to connect to the next, and so on.
Switch the loopset off
To switch off, press and hold the power key.
© 2013 Nokia. All rights reserved.
5
The loopset vibrates twice and the Bluetooth connection indicator stops blinking or flashing.
Pair and connect your loopset with your phone
Make sure your loopset is switched on, and in pairing mode.
1. Activate Bluetooth on your phone, and search for Bluetooth devices.
2. Select the loopset from the list to pair your phone with it.
3. If necessary, enter the passcode 0000.
Your loopset is now paired and connected with your phone. The Bluetooth connection indicator slowly
flashes.
When you switch on the loopset the next time, it automatically tries to recreate the latest connection.
Tip: When your loopset is connected to a device, but you need to pair with other devices, you
can go back to pairing mode by pressing the multifunction key for about 5 seconds.
If the loopset is not connected to a paired device within about 30 minutes, it switches off
automatically.
If the connection is lost, the loopset vibrates and the Bluetooth connection indicator quickly blinks.
Pair and connect your loopset using NFC
If your phone supports Near Field Communication (NFC), you can quickly pair and connect your
loopset, or switch the connection between paired devices.
© 2013 Nokia. All rights reserved.
6
1. On your phone, make sure that NFC is on and the phone keys and screen are unlocked.
2. Make sure the loopset is on and in pairing mode.
3. Tap the NFC area of the loopset with the NFC area of the phone.
4. If asked, accept the connection on your phone.
Disconnect or reconnect a paired device
To disconnect a paired and connected device from your loopset, tap the NFC areas together. To
reconnect, tap the NFC areas together again.
© 2013 Nokia. All rights reserved.
7
Basic use
Make and receive calls
Make sure that you're wearing the loopset properly, the loopset is connected to your phone, and your
hearing aid is in T-mode or MT-mode.
1. To make a call, use the phone keys to dial the number.
2. To answer or end a call, press the multifunction key, or use the phone keys.
3. To reject an incoming call, press the multifunction key twice.
4. To re-dial the number you last called, press the multifunction key twice.
Tip:If your loopset is switched off when there's an incoming call on the phoneyou last connected
the loopset with, just switch on the loopset, and it answers the call.
Handle two calls
Make sure that your phone supports Bluetooth hands-free profile 1.6, and that call waiting is available
on your phone. Call waiting is a network service.
1. To answer a waiting call and end the active call, press the multifunction key.
2. To answer a waiting call and put the active call on hold, press and hold the multifunction key for
about 2 seconds.
3. To end the active call and make the call on hold active, press the multifunction key.
4. To switch between the active call and the call on hold, press and hold the multifunction key for
about 2 seconds.
Listen wirelessly with Bluetooth
You can, for example, listen to music on your computer using a Bluetooth connection.
1. Connect the loopset to your phone or Bluetooth audio source, for example, your computer.
© 2013 Nokia. All rights reserved.
8
2. To play music, use the playback controls on the connected device.
Use USB audio connection
You can connect your loopset to a compatible device with a USB cable. This way you can make internet
calls or listen to music, for example, on your computer.
1. Connect a compatible USB cable to another device.
2. Use the controls on the device to handle the sound.
Tip: When you're connected, for example, to a computer with a USB cable, the battery is being
charged.
Change the volume
Press the volume keys up or down during a call or when listening to an audio source.
During a call, you don't need to adjust the volume on both your loopset and your phone, as the volume
controls are synchronised. Use the volume keys on one or the other. When you listen to a source
other than your phone using Bluetooth (A2DP mode), both controls affect the volume.
© 2013 Nokia. All rights reserved.
9
Change the sidetone volume
Sidetone is the sound that the loopset microphone routes to your hearing aid during a call to help
you hear your own voice.
During a call, press the multifunction key twice, and press a volume key within 15 seconds.
Clear settings or reset your loopset
1. To clear pairing and volume settings, press and hold the multifunction key for more than 8 seconds.
2. To reset, connect the loopset to a charger, and press and hold the multifunction key.
Resetting doesn't clear the settings.
© 2013 Nokia. All rights reserved.
10
