GETTING STARTED GUIDE
NI REM-11175
Digital Output Module for Remote I/O
This document explains how to connect to the REM-11175.
Note The guidelines in this document are specific to the REM-11175. The other
components in the system might not meet the same safety ratings. Refer to the
documentation for each component in the system to determine the safety and EMC
ratings for the entire system.
Caution Do not operate the REM-11175 in a manner not specified in this
document. Product misuse can result in a hazard. You can compromise the safety
protection built into the product if the product is damaged in any way. If the product
is damaged, return it to NI for repair.
Isolation Withstand Voltages
Test section Test voltage
5 V communications power (logic), 24 V supply (I/O) 500 VAC, 50 Hz, 1 min.
5 V supply (logic)/functional earth ground 500 VAC, 50 Hz, 1 min.
24 V supply (I/O)/functional earth ground 500 VAC, 50 Hz, 1 min.
Electromagnetic Compatibility Guidelines
This product was tested and complies with the regulatory requirements and limits for
electromagnetic compatibility (EMC) stated in the product specifications. These requirements
and limits provide reasonable protection against harmful interference when the product is
operated in the intended operational electromagnetic environment.
This product is intended for use in industrial locations. However, harmful interference may
occur in some installations, when the product is connected to a peripheral device or test object,
or if the product is used in residential or commercial areas. To minimize interference with
radio and television reception and prevent unacceptable performance degradation, install and
use this product in strict accordance with the instructions in the product documentation.
Furthermore, any changes or modifications to the product not expressly approved by National
Instruments could void your authority to operate it under your local regulatory rules.
Preparing the Environment
Ensure that the environment in which you are using the REM-11175 meets the following
specifications.
Operating temperature -25 °C to 60 °C
Operating humidity 5% RH to 95% RH, noncondensing
Pollution Degree 2
Maximum altitude 3,000 m
Indoor use only.
Note Refer to the device datasheet on ni.com/manuals for complete specifications.
2| ni.com | REM-11175 Getting Started Guide
Verifying the Kit Contents
Verify that the following items are included in the REM-11175 kit.
Figure 1. REM-11175 Kit Contents
12 3 4
1. NI REM-11175
2. Bus connector
3. Supply voltage connector
4. Spring-terminal block (x8)
Unpacking the Kit
Caution To prevent electrostatic discharge (ESD) from damaging the device,
ground yourself using a grounding strap or by holding a grounded object, such as
your computer chassis.
1. Touch the antistatic package to a metal part of the computer chassis.
2. Remove the device from the package and inspect the device for loose components or any
other sign of damage.
Caution Never touch the exposed pins of connectors.
Note Do not install a device if it appears damaged in any way.
3. Unpack any other items and documentation from the kit.
Store the device in the antistatic package when the device is not in use.
REM-11175 Getting Started Guide | © National Instruments | 3
Installing the REM-11175
Figure 2. Structure of the REM-11175
1
5
3
4
6
5
2
1. Bus connector
2. REM-11175
3. Module function label
4. Supply voltage connector
5. Spring-terminal block
6. LED indicators
Table 1. Module Function Labels
Label Color Module Function
Blue Digital input
Red Digital output
Green Analog input, thermocouple
Yellow Analog output
White Bus coupler, power module
Installing Bus Connectors
What to Use
• Bus connector
• DIN rail
What to Do
Complete the following steps to install bus connectors on the DIN rail.
4| ni.com | REM-11175 Getting Started Guide
1
2
1. Insert the bus connector for the REM-11175 into the DIN rail.
Caution Verify that you are using the correct bus connector for the module
width.
2. Slide the bus connector along the DIN rail until it connects to the preceding bus
connector.
Note A bus connector will not attach to a preceding bus connector with a
mounted module. Remove the preceding module before installing additional
bus connectors.
3. Repeat Steps 2 and 3 for additional bus connectors.
Installing the Module
What to Use
• REM-11175
• Mounted bus connector
What to Do
Complete the following steps to install the REM-11175 on the DIN rail.
REM-11175 Getting Started Guide | © National Instruments | 5
1. Align the REM-11175 over the appropriate bus connector.
Note Verify that the bus connector socket aligns with the socket on the
underside of the module.
2. Press the REM-11175 directly onto the bus connector and DIN rail until it clicks into
place.
Caution Tilting the module when mounting it on the DIN rail will damage the
contacts.
Installing Spring-Terminal Blocks
What to Use
• REM-11175
• Spring-terminal block
What to Do
Align the spring-terminal block over the REM-11175 and press until it clicks into place.
6| ni.com | REM-11175 Getting Started Guide
REM-11175 Pinout
DO0 to DO7
GND
GND
FE
DO8 to DO15
GND
GND
FE
24 VDC
24 VDC
GND
GND
a1
a2
b2
b1
71
61
51
41
70
60
50
40
73
63
53
43
72
62
52
42
75
65
55
45
74
64
54
44
77
67
57
47
76
66
56
46
00
10
20
30
01
11
21
31
04
14
24
34
05
15
25
35
06
16
26
36
07
17
27
37
02
12
22
32
03
13
23
33
Table 2. REM-11175 Signal Descriptions
Signal Color Description
a1, a2 Red 24 VDC (UO) Supply to digital output modules (internally
jumpered)
b1, b2 Blue GND Reference potential of the supply voltage
(internally jumpered)
00 to 07 Orange DO0...DO7 Digital outputs 0 to 7
40 to 47 Orange DO8...DO15 Digital outputs 8 to 15
REM-11175 Getting Started Guide | © National Instruments | 7
Table 2. REM-11175 Signal Descriptions (Continued)
Signal Color Description
10 to 17, 50 to 57 Blue GND Reference potential for all channels
20 to 27, 60 to 67 Blue GND Reference potential for all channels
30 to 37, 70 to 77 Green FE Functional earth ground (FE)
Figure 3. REM-11175 LEDs
D
UI
E1
E2
00 02 04 06
10 12 14 1611 13 15 17
20 22 24 2621 23 25 27
30
41 43 45 47
51 53 55 57
61 63 65 67
71 73 75 77
40 42 44 46
50 52 54 56
60 62 64 66
70 72 74 76
32 34 3631 33 35 37
01 03 05 07
Table 3. LED Indicators
LED LED Color LED Pattern Indication
D
Green
Solid The REM-11175 is ready for operation.
Flashing Data is invalid or unavailable.
Green/Yellow Flashing The REM-11175 cannot communicate with
the connected devices.
D
Yellow
Solid The REM-11175 did not detect a valid cycle
after power-on.
Flashing The REM-11175 is not part of the
configuration.
Red
Solid The REM-11175 has lost connection to the
Bus Coupler.
Flashing The REM-11175 has lost connection to the
preceding adjacent module.
— Off The REM-11175 is in reset mode.
8| ni.com | REM-11175 Getting Started Guide
Table 3. LED Indicators (Continued)
LED LED Color LED Pattern Indication
UO
Green Solid Supply to digital output module present.
— Off No supply to digital output modules.
E1
Red Solid Breakdown or overload/short-circuit of an
output.
— Off No I/O error.
00 to 07, 40 to
47
Yellow Solid Output is set.
— Off Output is not set.
10 to 17, 50 to
57
Red Solid Short-circuit/overload of the output.
— Off No short-circuit/overload of the output.
Connecting the REM-11175
24 VDC
D0 (0:7)
GND
GND
FE
REM-11175
FE
GND
GND
DO (8:15)
+
–
a1
a2
b1
b2
x8
Device
Device
• DO terminals supply the digital output voltages.
• GND provides a path for return current to flow.
• The output switches the load directly.
