USER GUIDE

NI USB-6008/6009 OEM

This document provides information about the dimensions, connectors, and

other components of the National Instruments USB-6008/6009 OEM

device. For more information about the device, refer to the USB-6008/6009

User Guide and Specifications document available at ni.com/manuals.

Caution There are no product safety, electrogmagnetic compatibility (EMC), or

CE marking compliance claims made for the NI USB-6008/6009 OEM devices.

The NI USB-6008/6009 OEM device is intended to be used as a component of a larger

system. National Instruments can help developers meet their compliance requirements.

The end product supplier, however, is responsible for conforming to any and all compliance

requirements.

Figure 1. USB-6008/6009 OEM Device

NI USB-6008/6009 OEM User Guide 2 ni.com

Dimensions

Figure 2 shows the USB-6008/6009 OEM device dimensions.

Figure 2. USB-6008/6009 OEM Device Dimensions in Inches (Millimeters)

0.000 (0.00)

1.300 (33.02)

1.775 (45.09)

–0.150 (–3.81)

–

0.106 (–2.69) –0.150 (–3.81)

–0.575 (–14.61)

–0.725 (–18.42)

0.119 (3.02)

0.000 (0.00)

0.344 (8.74)

0.516 (13.11)

0.433 (11.00)

0.063 (1.60)

0.000 (0.00)

2.305 (58.55)

2.725 (69.22)

0.650 (16.51)

–0.160 (–4.06)

0.413 (10.49)

0.887 (22.53)

1.025 (26.04)

0.275 (6.99)

0.459 (11.66)

1.645 (41.78)

–0.345 (–8.76)

–0.475 (–12.07)

3.300 (83.82)

2.250 (57.15)

1.990 (50.55)

PIN 33

PIN 34

PIN 1

PIN 2

3x φ0.125 (3.18)

©National Instruments Corporation 3 NI USB-6008/6009 OEM User Guide

I/O Connector

Figure 3 shows the USB-6008/6009 OEM device I/O connector pinout.

AI signal names are shown in single-ended mode. Differential mode signal

names are in parentheses.

Figure 3. USB-6008/6009 OEM Terminal Assignments

AO 1

AI GND

AI 7 (AI 3–)

AI 6 (AI 2–)

AI 5 (AI 1–)

AI 4 (AI 0–)

AI GND

VBUS

LED

P0.0

P0.2

P0.4

P0.6

P1.0

P1.2

+5 V

D GND

AO 0

AI GND

AI 3(AI 3+)

AI 2 (AI 2+)

AI 1 (AI 1+)

AI 0 (AI 0+)

AI GND

D–

D+

D GND

P0.1

P0.3

P0.5

P0.7

P1.1

P1.3

PFI 0

3433

3231

3029

2827

26 25

24 23

22 21

20 19

1817

16 15

14 13

12 11

10 9

–

NI USB-6008/6009 OEM User Guide 4 ni.com

Signal Descriptions

Most of the signals available on the I/O connector are described in the

USB-6008/6009 User Guide and Specifications document available for

download at ni.com/manuals. Table 1 describes additional signals on

the I/O connector of the OEM devices.

Note The +2.5 V signal is not available on the USB-6008/6009 OEM device.

For more information about USB signals, refer to the Universal Serial Bus

Specification accessible at www.usb.org.

Table 1. Signal Descriptions

Signal Name Reference Direction Description

VBUS GND Input USB Power

D+, D– GND Input/Output USB Data Lines

LED GND Output Status LED

Driver

©National Instruments Corporation 5 NI USB-6008/6009 OEM User Guide

Using the 34-Pin Connector with a Board Mount Socket

The USB-6008/6009 OEM device can be mounted to a motherboard using

the 34-pin connector, as shown in Figure 4 and Figure 5.

Figure 4. Mounting Using a 34-Pin Connector

Note Refer to the Device Components section for more information about mounting

components.

Figure 5. USB Device Installed on Motherboard

1 Board Mount Socket

234-Pin Connector

3Mounting Screws

4 USB-6008/6009 OEM Device

5 Mounting Standoff

NI USB-6008/6009 OEM User Guide 6 ni.com

Connecting to USB

You can use the USB connector on the USB-6008/6009 OEM device to

connect to the USB host. In this case, leave the D+ and D– signals (on the

34-pin connector) and VBUS unconnected. If +5 V is needed, supply it

from the 34-pin connector.

You can also use a USB connector on your motherboard to connect the

USB-6008/6009 OEM device to the USB host through the 34-pin

connector. In this case, do not connect to the USB connector on the

USB-6008/6009 OEM device.

Using the Status LED Driver

The LED signal indicates the device status as described in Table 2. An open

collector driver drives the LED signal. For applications that use the LED

signal, connect a 4.7 kΩresistor from the LED signal to the +5 V signal.

Two possible uses of the LED signal are as follows:

• To drive an LED to give a visual indication that the device is active.

• To drive a watchdog timer circuit that monitors the device state.

Electrical Characteristics

Table 3 lists the LED electrical characteristics.

Table 2. Device Status/LED Signal Behavior

Device Status LED Signal Behavior

USB device enumerated, configured and not

suspended

Square wave with frequency of 2 Hz

USB device is not enumerated, not configured,

or is suspended

Not driven (pulled up)

Table 3. Electrical Characteristics

Parameter Conditions Min Typ Max

LED Output Low Voltage IOL = 8.5 mA

IOL = 10 μA

IOL = 25 mA

—

1.0 V

0.6 V

0.1 V

—

©National Instruments Corporation 7 NI USB-6008/6009 OEM User Guide

Device Components

Table 4 lists the components used for interfacing and interacting with the

USB-6008/6009 OEM device.

Table 4. NI USB-6008/6009 OEM Device Components

Component

Reference

Designator(s)

on PCB Manufacturer

Manufacturer

Part Number

Part

Specifications

USB connector J002 AMP 787780-1 —

USB cable, 2 m —NI 184125-02 —

34-pin connector J004 3M N2534-6002RB —

34-pin mating

connector

— 3M 8534-4500JL

(or equivalent)

—

Mounting

Standoff *

Using

34-pin

board

mount

socket

—NI 745798-01 3/16 in. HEX

female-to-female,

14 mm long

Using

ribbon

cable

—NI 745830-01 3/16 in. HEX

female-to- female,

1/4 in. long

Screw — — — M3 ×0.5,

4–40 mm

*To order, contact NI.

NI USB-6008/6009 OEM User Guide 8 ni.com

USB-6008/6009 OEM Device Specifications

Most specifications of the USB-6008/6009 OEM device are listed

in the USB-6008/6009 User Guide and Specifications document on

ni.com/manuals. The following sections contain exceptions to the main

specifications:

External Voltage

Note 2.5 V output is not available.

Physical Characteristics

Dimensions .............................................8.76 cm ×5.72 cm ×1.55 cm

(3.45 in. ×2.25 in. × 0.610 in.)

I/O connector ..........................................3M, 4-wall header

(part number: N2534-6002RB)

Weight ....................................................1 oz

National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation.

Refer to the Terms of Use section on ni.com/legal for more information about National

Instruments trademarks. Other product and company names mentioned herein are trademarks or trade

names of their respective companies. For patents covering National Instruments products, refer to the

appropriate location: Help»Patents in your software, the patents.txt file on your CD, or

ni.com/patents.

Where to Go for Support

The National Instruments Web site is your complete resource for technical

support. At ni.com/support you have access to everything from

troubleshooting and application development self-help resources to email

and phone assistance from NI Application Engineers.

National Instruments corporate headquarters is located at

11500 North Mopac Expressway, Austin, Texas, 78759-3504.

National Instruments also has offices located around the world to help

address your support needs. For telephone support in the United States,

create your service request at ni.com/support and follow the calling

instructions or dial 512 795 8248. For telephone support outside the United

States, contact your local branch office:

Australia 1800 300 800, Austria 43 0 662 45 79 90 0,

Belgium32027570020,Brazil551132623599,

Canada 800 433 3488, China 86 21 6555 7838,

Czech Republic 420 224 235 774, Denmark 45 45 76 26 00,

Finland3850972572511,France330148142424,

Germany 49 0 89 741 31 30, India 91 80 41190000,

Israel 972 0 3 6393737, Italy 39 02 413091, Japan 81 3 5472 2970,

Korea820234513400,Lebanon96101332828,

Malaysia 1800 887710, Mexico 01 800 010 0793,

Netherlands 31 0 348 433 466, New Zealand 0800 553 322,

Norway 47 0 66 90 76 60, Poland 48 22 3390150,

Portugal 351 210 311 210, Russia 7 095 783 68 51,

Singapore 1800 226 5886, Slovenia 386 3 425 4200,

South Africa 27 0 11 805 8197, Spain 34 91 640 0085,

Sweden460858789500,Switzerland41562005151,

Taiwan 886 02 2377 2222, Thailand 662 278 6777,

United Kingdom 44 0 1635 523545
