NEC MultiSync E1100 Manuel utilisateur

MultiSync E1100

User’s Manual

Declaration of the Importer

We hereby certify that the color monitor

MultiSync E1100 JC-2144UMB

are in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 60555-2

- EN 60555-3

- EN 50082-1

(IEC 801-2)

(IEC 801-3)

(IEC 801-4)

and marked with

NEC Europe Ltd. Ismaning Office

Steinheilstraße 4-6

D-85737 Ismaning, Germany

Safety Instruction

Caution:

When operating the JC-2144UMB with a 220-240V AC power source

in Europe except UK, use the power cord provided with the monitor.

In UK, a BS approved power cord with moulded plug has a Black (five

Amps) fuse installed for use with this equipment. If a power cord is not

supplied with this equipment please contact your supplier.

When operating the JC-2144UMR with a 220-240V AC Power source

in Australia, use the power cord provided with the monitor.

For all other cases, use a power cord that matches the AC voltage of the

power outlet and has been approved by and complies with the safety

standard of your particular country.

IBM PC/XT/AT, PS/2, MCGA, VGA, 8514/A and XGA are registered trademarks of

International Business Machines Corporation.

Apple and Macintosh are registered trademarks of Apple Computer Inc.

Microsoft and Windows are registered trademarks of the Microsoft Corporation.

NEC is a registered trademark of NEC Corporation. ErgoDesign, IPM, OSM, ColorControl,

OptiClear and Advanced Digital Control System are trademarks of NEC Home Electronics,

Ltd.

MultiSync is a registered trademark of NEC Technologies, Inc in U.S., and of NEC Home

Electronics, Ltd in Canada, U.K., Germany, France, Spain, Italy, Austria, Benelux,

Switzerland, Denmark, Finland, Norway and Saudi Arabia.

All other trademarks or registered trademarks are property of their respective owners.

English

Deutsch

Français

Italiano

Español

Appendix

English

Introduction

Congratulations on your purchase of the MultiSync E1100 colour

Monitor!

The MultiSync E1100 monitor includes Microsoft’s Plug and Play,

NEC’s ErgoDesign properties, the On Screen Manager (OSM), as well

as all the unique features you expect from MultiSync Monitors.

The MultiSync technology provides you with automatic compatibility

with multiple operating platforms and a vast array of graphics standards

allowing resolution upgrades without upgrading the monitor.

The MultiSync E1100 monitor strictly follows ErgoDesign guidelines

featuring enhanced human ergonomics (human and earth condition).

The goal of ErgoDesign is to maximise the comfort and productivity of

the end user. ErgoDesign parallels the strict European standards of

power management and reduced emissions. In addition our monitor is

designed to be recyclable.

Screen Technology

The OptiClear Surface of the E1100 CRT dramatically reduces the

reflection of ambient illumination and glare resulting in greatly

improved user comfort and productivity. This multilayered screen

coating increases the contrast without sacrificing the focus level, clarity

or brightness.

A 0.28 mm dot pitch in conjunction with the Invar Shadow Mask

increases the clarity and displays greater detail. Good clarity allows

your eyes to flow over the screen image and more easily view the

on-screen information.

The flat square CRT technology reduces image distortion and glare.

Plug and Play

Plug and Play is the new Microsoft®solution with Windows®95 to

provide automatic peripheral connections without confusing and

time-consuming setup. When used with a Plug and Play compatible system

and video card, the MultiSync E1100 monitor automatically tells the

Introduction E - 1

system its identification and capabilities. The system will then select its

highest resolution and refresh rate to take advantage of your MultiSync

monitor.

GlobalSync

The GlobalSync control of the MultiSync E1100 also minimises any

effects of the earths magnetic field on screen performance.

ErgoDesign

The MultiSync ErgoDesign features enhance human ergonomics

(human and earth conditions). MultiSync monitor’s ErgoDesign will

improve the working environment, protect the health of the user and

save money. ErgoDesign parallels the strict European standards of

power management and reduced emissions:

–automatic display power-down (also known as NUTEK

specification 803299)

–emission characteristics (stricter than those referred to as

reduced electromagnetic fields as recommended by MPR II

and, for JC-2144UMB, also by TCO)

–safety (EN 60950)

MultiSync monitors comply with these standards by offering IPM

System power management and Reduced Magnetic Field technology.

Power Manager

IPM (Intelligent Power Manager) System is an innovative power-saving

utility that complies with both the EPA’s Energy Star requirements and

Europe’s TCO NUTEK’s power management requirements. Energy Star

products use less than 30 watts when in the main power saving mode. The

NUTEK specification 803299 requires automatic power down to less than

30 watts in the suspend mode and less than 8 watts in the off mode.

When in the maximum power-down mode, the MultiSync E1100

monitor will consume less than 10% of the total power drawn under

normal operation. This innovation adds up to more than 90% energy

savings, longer monitor life, environmental protection, reduced

E - 2 Introduction

emissions and reduced air conditioning costs of the work environment.

The IPM System increases the monitor’s life and saves energy and costs

by powering down when not in use.

MultiSync monitors follow the Video Electronics Standard Association

(VESA) approved DPMS power-down signalling method. VESA’s

Display Power Management Signalling (DPMS) method, which is

endorsed by the EPA, is the power-down process a system should use to

communicate to the monitor to save power. Power-down functions can

be utilised only with an Energy Star system or video card which adheres

to the VESA DPMS standard. By using the monitor’s horizontal and

vertical SYNC signals, the monitor can be prompted into the different

IPM modes. The following is the description of the LED indicator for

the IPM power-saving modes:

Mode LED Indicator Power Saving

On Green None

Stand By Green Minimum (Quickest Recovery)

Suspend Yellow Moderate (< 15 Watts, Moderate

Recovery)

Off (IPM Mode) Orange Maximum (< 5 Watts, Slow Recovery)

Off (Power

Switch, Off) No Light No Power Used (Fully Off)

Reduced Emissions

The E1100 monitor incorporates Reduced Magnetic Field technology

designed to reduce magnetic and alternating electric field emissions and static

electricity. NEC’s monitors follow the strictest magnetic field, alternating

electric field, and electrostatic recommendations of the Swedish Board for

Technical Accreditation, or SWEDAC (previously known as MPR, National

Board for Measurement and Testing). The JC-2144UMB follows the

recommendations of the TCO which specify maximum recommended values

of electric and magnetic fields.

Introduction E - 3

Multiple Frequency Technology

Multiple Frequency Technology automatically adjusts the monitor to

the video card’s scanning frequency, displaying the resolution you

desire. The MultiSync E1100 color monitor also supports multiple

operating platforms such as PC compatible, Macintosh family and

workstation systems.

Increased refresh rates at all resolutions provide a flicker-free image.

The clearer image is easier on your eyes and extends your viewing time.

A wide range of graphics standards of PC and Macintosh computers,

including VESA standards, is supported by the MultiSync E1100 color

monitor including:

–640 x 480: 60 - 120 Hz vertical refresh

–800 x 600: 55 - 120 Hz vertical refresh

–832 x 624: 55 - 120 Hz vertical refresh

–1024 x 768: 55 - 100 Hz vertical refresh (non-interlaced, 85 Hz

recommended)*

–1152 x 870: 55 - 90 Hz vertical refresh

–1280 x 1024: 55 - 75 Hz vertical refresh (non-interlaced)**

* NEC cites recommended resolutions for optimal display performance.

** Maximum resolution based on horizontal and vertical frequencies only.

NOTE: Some system may not support all modes listed.

Horizontal and vertical FullScan capability can increase the display size

of a variety of video modes to the edges of the monitor bezel. The

FullScan capability allows you to use the entire screen area in most

resolutions, significantly expanding image size.

E - 4 Introduction

Contents of the Package

Included with your MultiSync E1100 color monitor are the following

items:

–MultiSync E1100 (JC-2144UMB/R)

–Power cord

–User’s manual

Recommended use

For optimum performance when setting up and using the MultiSync

E1100 colour monitor, please note the following:

–The optimum monitor position is away from direct sunlight.

–Place the monitor just below eye level for the ideal viewing

angle.

–Allow adequate ventilation around the monitor so that heat can

properly dissipate.

–Do not place any heavy objects on the power cord. Damage of

the cable may cause shock or fire.

Contents of the Package E - 5
