NEC MultiSync FE750+ Manuel utilisateur

MultiSync FE750+

User’s Manual

English-1

English

Declaration

Declaration of the Manufacturer

We hereby certify that the color monitor

MultiSync FE750+ (JC-17W41) is in compliance with

Council Directive 73/23/EEC:

- EN 60950

Council Directive 89/336/EEC:

- EN 55022

- EN 61000-3-2

- EN 61000-3-3

- EN 55024

(IEC-61000-4-2)

(IEC-61000-4-3)

(IEC-61000-4-4)

(IEC-61000-4-5)

(IEC-61000-4-6)

(IEC-61000-4-8)

(IEC-61000-4-11)

and marked with

NEC-Mitsubishi Electric Visual Systems Corporation

686-1, NISHIOI OI-MACHI

ASHIGARAKAMI-GUN

KANAGAWA 258-8533, JAPAN

English-2

ENERGY STA R ®is a U.S. registered trademark. All other brands and product names are trademarks or

registered trademarks of their respective owners.

As an ENERGY STAR Partner, NEC-Mitsubishi has determined that this product meets the ENERGY STAR

guidelines for energy efficiency.

The ENERGY STA R emblem does not represent EPA endorsement of any product or service.

All other trademarks mentioned in this manual are the property of their respective owners.

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS UNIT

TO RAIN OR MOISTURE. ALSO, DO NOT USE THIS UNIT’S POLARIZED

PLUG WITH AN EXTENSION CORD RECEPTACLE OR OTHER OUTLETS

UNLESS THE PRONGS CAN BE FULLY INSERTED.

REFRAIN FROM OPENING THE CABINET AS THERE ARE HIGH VOLTAGE

COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

CAUTION

TO REDUCE THE RISK OF ELECTRIC SHOCK, MAKE SURE

POWER CORD IS UNPLUGGED FROM WALL SOCKET. TO FULLY

DISENGAGE THE POWER TO THE UNIT, PLEASE DISCONNECT

THE POWER CORD FROM THE AC OUTLET. DO NOT REMOVE

COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol warns user that uninsulated voltage within the unit may

have sufficient magnitude to cause electric shock. Therefore, it is

dangerous to make any kind of contact with any part inside this unit.

This symbol alerts the user that important literature concerning the

operation and maintenance of this unit has been included. Therefore, it

should be read carefully in order to avoid any problems.

CAUTION

WARNING

RISK OF ELECTRIC SHOCK •DO NOT OPEN

Safety Instruction

English-3

English

TCO’99

Congratulations! You have just purchased a

TCO’99 approved and labeled product! Your choice

has provided you with a product developed for

professional use. Your purchase has also contributed

to reducing the burden on the environment and also

to the further development of environmentally

adapted electronics products.

Why do we have environmentally labelled computers?

In many countries, environmental labelling has become an established

method for encouraging the adaptation of goods and services to the

environment. The main problem, as far as computers and other

electron-ics equipment are concerned, is that environmentally harmful

substances are used both in the products and during their manufacture.

Since it is not so far possible to satisfactorily recycle the majority of

electronics equipment, most of these potentially damaging substances

sooner or later enter nature.

There are also other characteristics of a computer, such as energy

consumption levels, that are important from the viewpoints of both the

work (internal) and natural (external) environments. Since all methods

of electricity generation have a negative effect on the environment (e.g.

acidic and climate-influencing emissions, radioactive waste), it is vital to

save energy. Electronics equipment in offices is often left running

continuously and thereby consumes a lot of energy.

What does labelling involve?

This product meets the requirements for the TCO’99 scheme which

provides for international and environmental labelling of personal

computers. The labelling scheme was developed as a joint effort by the

TCO (The Swedish Confederation of Professional Employees), Svenska

Naturskyddsforeningen (The Swedish Society for Nature Conservation)

and Statens Energimyndighet (The Swedish National Energy Adminis-

tration).

Approval requirements cover a wide range of issues: environment,

ergonomics, usability, emission of electric and magnetic fields, energy

consumption and electrical and fire safety.

English-4

The environmental demands impose restrictions on the presence and

use of heavy metals, brominated and chlorinated flame retardants,

CFCs (freons) and chlorinated solvents, among other things. The

product must be prepared for recycling and the manufacturer is obliged

to have an environmental policy which must be adhered to in each

country where the company implements its operational policy.

The energy requirements include a demand that the computer and/or

display, after a certain period of inactivity, shall reduce its power con-

sumption to a lower level in one or more stages. The length of time to

reactivate the computer shall be reasonable for the user.

Labelled products must meet strict environmental demands, for

example, in respect of the reduction of electric and magnetic fields,

physical and visual ergonomics and good usability.

Below you will find a brief summary of the environmental requirements

met by this product. The complete environmental criteria document may

be ordered from:

TCO Development

SE-114 94 Stockholm, Sweden

Fax: +46 8 782 92 07

Email (Internet): development@tco.se

Current information regarding TCO’99 approved and labelled products

may also be obtained via the Internet, using the address:

http://www.tco-info.com/

Environmental requirements

Flame retardants

Flame retardants are present in printed circuit boards, cables, wires,

casings and housings. Their purpose is to prevent, or at least to delay

the spread of fire. Up to 30% of the plastic in a computer casing can

consist of flame retardant substances. Most flame retardants contain

bromine or chloride, and those flame retardants are chemically related

to another group of environmental toxins, PCBs. Both the flame

retardants containing bromine or chloride and the PCBs are suspected

of giving rise to severe health effects, including reproductive damage in

fish-eating birds and mammals, due to the bio-accumulative* processes.

Flame retardants have been found in human blood and researchers fear

that disturbances in foetus development may occur.

English-5

English

The relevant TCO’99 demand requires that plastic components weighing

more than 25 grams must not contain flame retardants with organically

bound bromine or chlorine. Flame retardants are allowed in the printed

circuit boards since no substitutes are available.

Cadmium**

Cadmium is present in rechargeable batteries and in the colour-

generating layers of certain computer displays. Cadmium damages the

nervous system and is toxic in high doses. The relevant TCO‘99

requirement states that batteries, the colour-generating layers of display

screens and the electrical or electronics components must not contain

any cadmium.

Mercury**

Mercury is sometimes found in batteries, relays and switches. It

damages the nervous system and is toxic in high doses. The relevant

TCO‘99 requirement states that batteries may not contain any Mercury.

It also demands that no mercury is present in any of the electrical or

electronics components associated with the labelled unit.

CFCs (freons)

The relevant TCO‘99 requirement states that neither CFCs nor HCFCs

may be used during the manufacturing and assembly of the product.

CFCs (freons) are sometimes used for washing printed circuit boards.

CFCs break down ozone and thereby damage the ozone layer in the

stratosphere, causing increased reception on Earth of ultraviolet light

with e. g. increased risks of skin cancer (malignant melanoma) as a

consequence.

Lead**

Lead can be found in picture tubes, display screens, solders and

capacitors. Lead damages the nervous system and in higher doses,

causes lead poisoning. The relevant TCO‘99 requirement permits the

inclusion of lead since no replacement has yet been developed.

*Bio-accumulative is defined as substances which accumulate within living

organisms.

**Lead, Cadmium and Mercury are heavy metals which are Bio-accumulative.

English-6

Contents

Your new MultiSync FE750+ monitor box* should contain the following:

•MultiSync FE750+ Monitor with tilt/swivel base

•Power cord

•Captive Signal Cable

•User’s Manual

•CD-ROM:

Includes complete User’s Manual in PDF format and Windows related

files (Inf file and color profile). To see the complete User’s Manual,

Acrobat Reader 4.0 must be installed at your PC.

* Remember to save your original box and packing material to

transport or ship the monitor.

Power Cord

Captive Signal Cable

User’s Manual

CD-ROM

English-7

English

Quick Start

To attach the MultiSync FE750+ monitor to your system, follow these

instructions:

1. Turn off the power to your computer.

2. If necessary, install the display card into your system. For more

information, refer to the display card manual.

3. For the PC: Connect the 15-pin mini D-SUB of the captive signal

cable to the connector of the display card in your system

(Figure A.1). Tighten all screws.

For the Mac: Connect the Macintosh cable adapter (not included) to

the monitor connector on the Macintosh (Figure B.1). Attach the

15-pin mini D-SUB end of the captive signal cable to the Macintosh

cable adapter on the computer (Figure B.1). Tighten all screws.

4. The Windows®95/98/2000 INF file for your MultiSync monitor can be

found on the CD-ROM, delivered with the monitor.

5. Connect one end of the power cord to the MultiSync FE750+ monitor

and the other end to the power outlet (Figure C.1).

6. Turn on the monitor (Figure D.1) and the computer.

NOTE: If you have any problems, please refer to the

Troubleshooting section of this User’s Manual.

Captive Signal Cable

15-pin mini D-SUB

Figure A.1

English-8

Figure B.1

Figure C.1

15-pin mini D-SUB

Captive Signal Cable

Computer Mac Adapter

(not included)

Power Outlet

Power Cord

EXIT PROCEED RESET

+–

Power Button

Figure D.1

English-9

English

Controls

OSM (On-Screen Manager) control buttons on the front of the monitor

function as follows:

NOTE: When RESET is pressed in the main and sub-menu, a

warning window will appear allowing you to cancel the reset

function.

When OSM controls are activated, icons are displayed at the top of the

menu. If an arrow (→) is displayed in a sub-menu, it indicates further

choices are available. To enter a sub-menu, press PROCEED.

Brightness/Contrast Controls

Brightness: Adjusts the overall image and background screen

brightness.

Contrast: Adjusts the image brightness in relation to the background.

Degauss: Eliminates the build-up of stray magnetic fields which alter the

correct scan of the electron beams and affect the purity of the screen

colours, focus, and convergence. When activated, your screen image will

jump and waver a bit as the screen is demagnetised.

Sub-Menu

Exits to the OSM main menu.

Moves the highlighted area

up/down to select one of the

controls.

Moves the bar in the - or +

direction to decrease or

increase the adjustment.

Only executes control or

enters sub-menu.

Resets the highlighted control

to the factory setting.

EXIT

CONTROL ▲/▼

CONTROL -/+

PROCEED

RESET

Main Menu

Exits the OSM menu.

Moves the highlighted

area up/down to select

one of the controls.

Moves highlighted area

left/right to select one of

the controls.

Has no function.

Resets all the controls

within the highlighted

menu to the factory

setting.

Autres manuels pour MultiSync FE750+

Table des matières

Autres manuels NEC Moniteur

NEC

NEC LCD1560NX - MultiSync - 15" LCD Monitor Guide de l'utilisateur

NEC

NEC LCD1920NX BK - MultiSync - 19" LCD Monitor Manuel utilisateur

NEC

NEC MultiSync EA221WM Manuel de la liste des pièces

NEC

NEC AccuSync AS242W Manuel utilisateur

NEC

NEC M40 - MULTEOS - 40" LCD TV Manuel utilisateur

NEC

NEC MULTISYNC LCD1510+ Manuel

NEC

NEC MultiSync 20WGX2 Series Manuel utilisateur

NEC

NEC JC1402HME Manuel utilisateur

NEC

NEC MultiSync MD21GS-3MP Instructions d'utilisation et de sécurité

NEC

NEC 42/50PD1 Manuel utilisateur

NEC

NEC LCD1990SXP - MultiSync - 19" LCD Monitor Manuel utilisateur

NEC

NEC PlasmaSync 61XM1A Manuel utilisateur

NEC

NEC LCD1760VM - MultiSync - 17" LCD Monitor Manuel utilisateur

NEC

NEC MultiSync XM37 Xtra Manuel utilisateur

NEC

NEC LCD1700V - MultiSync - 17" LCD Monitor Manuel utilisateur

NEC

NEC LCD2190UXI - MultiSync - 21.3" LCD Monitor Manuel utilisateur

NEC

NEC MultiSync X462UN Manuel utilisateur

NEC

NEC MultiSync EX231W Guide de l'utilisateur

NEC

NEC EA273WM-BK Manuel utilisateur

NEC

NEC MultiSync EA192M Manuel utilisateur

NEC

NEC LCD1920NX BK - MultiSync - 19" LCD Monitor Manuel utilisateur

NEC

NEC P461 - MultiSync - 46" LCD Flat Panel... Manuel utilisateur

NEC

NEC AccuSync AS203WMi-BK Manuel utilisateur

NEC

NEC PlasmaSync PX-50XM4G Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation

LG M1950D-PZ Manuel utilisateur
