GETTING STARTED GUIDE
NI sbRIO-9607
Single-Board RIO OEM Devices
This document describes how to begin using the NI sbRIO-9607.
Safety Guidelines
Operate the sbRIO-9607 only as described in the user documentation.
Caution The sbRIO-9607 must be installed in a suitable enclosure prior to use.
Caution NI makes no product safety, electromagnetic compatibility (EMC), or CE
marking compliance claims for the sbRIO-9607. The end-product supplier is
responsible for conformity to any and all compliance requirements.
Caution Exercise caution when designing an enclosure for the sbRIO-9607.
Auxiliary cooling may be necessary to keep the sbRIO-9607 within the specified
operating temperature range. Refer to the NI sbRIO-9607 Specifications on ni.com/
manuals for more information about the maximum operating temperature rating. For
information and examples regarding factors that can affect thermal performance,
visit ni.com/info and enter the Info Code sbriocooling.
Caution Do not operate the sbRIO-9607 in a manner not specified in this
document. Product misuse can result in a hazard. You can compromise the safety
protection built into the product if the product is damaged in any way. If the product
is damaged, return it to NI for repair.
Safety Voltages
Connect only voltages that are below these limits.
V terminal to C terminal 30 VDC maximum, Measurement Category I
Measurement Category I is for measurements performed on circuits not directly connected to
the electrical distribution system referred to as MAINS voltage. MAINS is a hazardous live
electrical supply system that powers equipment. This category is for measurements of voltages
from specially protected secondary circuits. Such voltage measurements include signal levels,
special equipment, limited-energy parts of equipment, circuits powered by regulated low-
voltage sources, and electronics.
Caution Do not connect the sbRIO-9607 to signals or use for measurements within
Measurement Categories II, III, or IV.
Preparing the Environment
Ensure that the environment in which you are using the sbRIO-9607 meets the following
specifications.
Local ambient operating temperature near
device (IEC 60068-2-1, IEC 60068-2-2)
-40 °C to 85 °C
Maximum reported onboard sensor temperature
CPU/FPGA temperature 98 °C
Primary System temperature 85 °C
Secondary System temperature 85 °C
Note Ensure that the local ambient, reported CPU/FPGA, and reported Primary
System temperatures do not exceed any of the maximum temperatures listed in this
document. For more information about how to access the onboard sensors, visit
ni.com/info and enter the Info Code sbriosensors.
Operating humidity (IEC 60068-2-78) 10% RH to 90% RH, noncondensing
Pollution Degree (IEC 60664) 2
Maximum altitude 5,000 m
Indoor use only.
Note Refer to the device specifications on ni.com/manuals for complete
specifications.
2| ni.com | NI sbRIO-9607 Getting Started Guide
Unpacking the Kit
Caution To prevent electrostatic discharge (ESD) from damaging the device,
ground yourself using a grounding strap or by holding a grounded object, such as
your computer chassis.
1. Touch the antistatic package to a metal part of the computer chassis.
2. Remove the device from the package and inspect the device for loose components or any
other sign of damage.
Caution Never touch the exposed pins of connectors.
Note Do not install a device if it appears damaged in any way.
3. Unpack any other items and documentation from the kit.
Store the device in the antistatic package when the device is not in use.
Verifying the Kit Contents
Verify that the following items are included in the sbRIO-9607 kit.
Figure 1. sbRIO-9607 Kit Contents
12 3 4
5 6 7 8
1. sbRIO Device
2. NI CompactRIO Device Drivers Media
3. Getting Started Guide
4. Power Supply
5. 10-pin IDC to 9-pin DSUB Cable
6. Power Cable Assembly
7. Standoffs and Screws
8. NI 9694 Digital I/O Breakout RMC Board
Note The provided power supply is only intended for the getting started
experience. NI recommends the use of a power supply that meets the specifications
listed in the NI sbRIO-9607 Specifications for system deployment.
NI sbRIO-9607 Getting Started Guide | © National Instruments | 3
Installing Software on the Host Computer
Before using the sbRIO-9607, you must install the following application software and device
drivers on the host computer.
1. LabVIEW 2015 or later
2. LabVIEW Real-Time Module 2015 or later
3. LabVIEW FPGA Module 2015 or later
4. NI CompactRIO Device Drivers August 2015 or later
For minimum software support information, visit ni.com/info and enter the Info Code
softwareversion.
Connecting the sbRIO-9607
The sbRIO-9607 has the following components.
Figure 2. sbRIO-9607 Components
1 2 3 4 5 6 7 8
12
11
15
13
10
10
11
14
16
99
1. J9, Power Connector
2. Chassis Ground Bracket
3. J10, USB Host Port
4. W1, CAN (CAN0)
5. J7, RJ-45 Ethernet Port
6. W2, RS-232 (COM1)
7. Reset Switch
8. LEDs
9. Mounting Holes Connected to Chassis Ground
10. Ethernet RGMII Transceiver
11. ULPI USB Transceiver
12. FPGA Processor
13. DDR Memory
14. NAND Flash
15. CPLD
16. J1, RIO Mezzanine Card Connector
4| ni.com | NI sbRIO-9607 Getting Started Guide
Connecting the sbRIO-9607 to Power
The NI sbRIO device requires a 9 VDC to 30 VDC external power supply. The NI sbRIO
device filters and regulates the supplied power and provides power for RMCs.
Note Refer to the Power Requirements section of the NI sbRIO-9607
Specifications for the complete power requirement specifications.
Note Refer to the Power Requirements section of the NI sbRIO-9607 User Manual
for formulas and examples for calculating power requirements for different
configurations and application types.
Note Refer to the Power Requirements section of the NI sbRIO-9607 User Manual
for proper wiring of the power cable assembly.
Complete the following steps to connect a power supply to the device.
Caution Do not mate or unmate the power supply connectors while power is
applied.
1. Ensure that your power supply is powered off.
2. Insert the power connector plug into the power connector receptacle of the NI sbRIO
device until the connector latches into place.
3. Turn on the power supply.
Powering On the NI sbRIO Device
The NI sbRIO device runs a power-on self test (POST) when you apply power to the device.
During the POST, the Power and Status LEDs turn on. When the Status LED turns off, the
POST is complete. If the LEDs do not behave in this way when the system powers on, refer to
the STATUS LED Indicators section.
Connecting the sbRIO-9607 to the Host Computer
Complete the following steps to connect the sbRIO-9607 to the host computer using the RJ-45
Ethernet port.
1. Power on the host computer.
2. Connect the sbRIO-9607 to the host computer using a standard Category 5 (CAT-5) or
better shielded, twisted-pair Ethernet cable.
Caution To prevent data loss and to maintain the integrity of your Ethernet
installation, do not use a cable longer than 100 m.
The first time you power up the device, it attempts to initiate a DHCP network
connection. If the device is unable to initiate a DHCP connection, it connects to the
network with a link-local IP address with the form 169.254.x.x. After the device has
NI sbRIO-9607 Getting Started Guide | © National Instruments | 5
powered up, you must install software on the device and configure the network settings in
MAX.
Note Installing software may change the network behavior of the device. For
information about network behavior by installed software version, visit ni.com/
info and enter the Info Code ipconfigcrio.
Configuring the System in Measurement &
Automation Explorer (MAX)
Complete the following steps to find the system in MAX.
1. Launch MAX on the host computer.
2. Expand Remote Systems in the configuration tree and locate your system.
3. Select your target.
Tip MAX lists the system under the model number followed by the serial
number, such as NI-sbRIO-9607-########.
Setting a System Password
Complete the following steps to set a system password.
Note The default username for the sbRIO-9607 is admin. There is no default
password for the sbRIO-9607, so you must leave the password field blank when
logging in until you set a system password.
1. Right-click your system and select Web Configuration.
The NI Web-Based Configuration and Monitoring utility opens in your default browser
and is where you set the password. If you have not installed Microsoft Silverlight,
NI Web-based Configuration & Monitoring prompts you to do so.
2. Enter a unique name for your system in the Hostname field.
3. Click the Security Configuration icon.
4. Click Login.
5. In the Login dialog box, enter the username admin and leave the password field blank.
6. Click OK.
7. Click Change Password.
8. Enter and re-enter a new password.
9. Click OK.
10. Click Save.
11. Click OK to confirm you are changing the password.
Caution NI cannot recover lost system passwords. If you forget the password,
you must contact NI and reformat the controller.
6| ni.com | NI sbRIO-9607 Getting Started Guide
Installing Software on the sbRIO-9607
Complete the following steps to install software on the sbRIO-9607.
1. In MAX, expand your system under Remote Systems.
2. Right-click Software.
3. Select Add/Remove Software to launch the LabVIEW Real-Time Software Wizard.
Tip You must log in if you set a system password.
4. Select the recommended software set for your LabVIEW and NI CompactRIO Device
Drivers versions.
5. Click Next.
6. Select NI Scan Engine from the software add-ons.
Select any additional software to install. If you plan on using the sbRIO-9607 with the
LabVIEW FPGA Module, you can click Next.
Tip You can use this wizard at anytime to install additional software.
7. Click Next.
8. Verify that the summary of software to install is correct.
9. Click Next to start the installation.
10. Click Finish when the installation is complete.
Troubleshooting the sbRIO-9607
The sbRIO-9607 is Not Communicating with the
Network
• Ensure that the Ethernet connections between the sbRIO-9607 and the host computer and
the Ethernet connections between the host computer and the router are secure.
• Ensure that you have the correct version of NI CompactRIO Device Drivers installed on
the host computer. Visit ni.com/info and enter the Info Code softwareversion for the
minimum supported versions of LabVIEW and NI CompactRIO Device Drivers.
Tip If you have recently upgraded LabVIEW, you must reinstall NI
CompactRIO Device Drivers.
• Temporarily disable any network firewalls or other security software.
Configure the IP and other network settings by completing the following steps.
1. Use a standard Category 5 (CAT-5) or better shielded, twisted-pair Ethernet cable to
connect the sbRIO-9607 Ethernet port to a host computer. The sbRIO-9607 attempts to
initiate a DHCP network connection at powerup.
NI sbRIO-9607 Getting Started Guide | © National Instruments | 7
2. In MAX, expand your system under Remote Systems and select Troubleshoot Remote
System Discovery.
System Reset
The following figure shows the reset behavior of the sbRIO-9607.
Figure 3. Reset Button Behavior
Press and hold RESET button for ≥5 s
Press and hold RESET button for <5 s
Run Mode
Safe Mode
Press and hold RESET button for <5 s
Press and hold RESET button for ≥5 s
Press and hold
RESET button for ≥5 s
Press and hold
RESET button for <5 s
• Console Out enabled
• Network settings reset
• RT Startup App disabled
• FPGA Startup App disabled
• Console Out enabled
• RT Startup App disabled
• FPGA Startup App disabled
Safe Mode
STATUS LED Indicators
The following table lists the STATUS LED indicators.
8| ni.com | NI sbRIO-9607 Getting Started Guide
Table 1. STATUS LED Indicators
LED Pattern Indication
Blinks twice and
pauses
The sbRIO-9607 is in safe mode. Software is not installed, which is the
factory default state, or software has been improperly installed on the
sbRIO-9607.
An error can occur when an attempt to upgrade the software is
interrupted. Reinstall software on the sbRIO-9607. Refer to the
Measurement & Automation Explorer (MAX) Help for information
about installing software on the sbRIO-9607.
Blinks three times
and pauses
The sbRIO-9607 is in user-directed safe mode, or the sbRIO-9607 is in
install mode to indicate that software is currently being installed.
This pattern may also indicate that the user has forced the sbRIO-9607
to boot into safe mode by pressing the reset button for longer than five
seconds or by enabling safe mode in MAX. Refer to the Measurement
& Automation Explorer (MAX) Help for information about safe mode.
Blinks four times
and pauses
The sbRIO-9607 is in safe mode. The software has crashed twice
without rebooting or cycling power between crashes.
This usually indicates that the sbRIO-9607 has run out of memory.
Review your LabVIEW Real-Time application to resolve any memory
leaks.
Continuously blinks The sbRIO-9607 has not booted into NI Linux Real-Time. The
sbRIO-9607 either booted into an unsupported operating system, was
interrupted during the boot process, or detected an unrecoverable
software error.
On momentarily The sbRIO-9607 is booting. No action required.
Off The sbRIO-9607 is in run mode. Software is installed and the
operating system is running.
NI sbRIO-9607 Getting Started Guide | © National Instruments | 9
Autres manuels pour sbRIO-9607
1
Table des matières
Autres manuels National Instruments Matériel informatique
National Instruments
National Instruments PXIe-8108 Manuel utilisateur
National Instruments
National Instruments Network Adapter NI PXIe-1075 Manuel utilisateur
National Instruments
National Instruments BNC-208 Series Manuel utilisateur
National Instruments
National Instruments NI-9146 Manuel du propriétaire
National Instruments
National Instruments PXI-8110 Manuel utilisateur
National Instruments
National Instruments SCB-19 Manuel utilisateur
National Instruments
National Instruments PMC-GPIB Manuel utilisateur
National Instruments
National Instruments NI PXIe-8130 Manuel utilisateur
National Instruments
National Instruments PXI/CompactPCI Embedded Computer NI PXI-8108 Manuel utilisateur
National Instruments
National Instruments NI 9213 Manuel utilisateur
National Instruments
National Instruments PXI-8186 Manuel utilisateur
National Instruments
National Instruments PXI-8106 Manuel utilisateur
National Instruments
National Instruments Two-Slot Embedded Controller NI PXI-8183 Manuel utilisateur
National Instruments
National Instruments Deterministic Ethernet Expansion Chassis NI... Manuel utilisateur
National Instruments
National Instruments USB-6211 OEM Manuel utilisateur
National Instruments
National Instruments AT-GPIB/TNT Manuel utilisateur
National Instruments
National Instruments NI PXIe-8103 Manuel utilisateur
National Instruments
National Instruments NAT7210 Manuel utilisateur
National Instruments
National Instruments VME-PCI8022 Manuel utilisateur
National Instruments
National Instruments PXI-8196 Manuel utilisateur
Manuels Matériel informatique populaires d'autres marques
EMC2
EMC2 VNX Series Manuel du propriétaire
Panasonic
Panasonic DV0PM20105 Manuel utilisateur
Mitsubishi Electric
Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur
Gigabyte
Gigabyte B660M DS3H AX DDR4 Manuel utilisateur
Raidon
Raidon iT2300 Manuel utilisateur
Hauppauge
Hauppauge WinTV-HVR-2250 Manuel utilisateur
