NI-9260 Getting

Started

2022-07-12

Contents

Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Safety Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Safety Voltages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Safety Guidelines for Hazardous Voltages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Safety Guidelines for Hazardous Locations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Electromagnetic Compatibility Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Preparing the Environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

NI 9260 Pinout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

NI-9260 with mini XLR Analog Output Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

NI 9260 with BNC Analog Output Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

NI-9260 Connection Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Overvoltage Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Where to Go Next. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

NI Services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

ni.com

NI-9260 Getting Started

Overview

This document explains how to connect to the NI-9260. In this document, the

NI-9260 with BNC and the NI-9260 with mini XLR are referred to inclusively as the

NI-9260.

Note Before you begin, read the NI-9260 Safety, Environmental, and

Regulatory Information document on ni.com/manuals and complete the

soware and hardware installation procedures in your chassis

documentation.

Note The guidelines in this document are specific to the NI-9260. The

other components in the system might not meet the same safety ratings.

Refer to the documentation for each component in the system to

determine the safety and EMC ratings for the entire system.

Safety Guidelines

Caution Observe all instructions and cautions in the user documentation.

Using the product in a manner not specified can damage the product and

compromise the built-in safety protection.

Attention Suivez toutes les instructions et respectez toutes les mises

en garde de la documentation d'utilisation. L'utilisation du produit de

toute autre façon que celle spécifiée risque de l'endommager et de

compromettre la protection de sécurité intégrée.

Safety Voltages

AO-to-COM voltage 3.16 V RMS (±4.68 V peak) maximum

NI-9260 Getting Started

Overvoltage protection ±30 V

Channel-to-earth ground ±30 V maximum

Isolation Voltages

Channel-to-channel None

Channel-to-earth ground None

Safety Guidelines for Hazardous Voltages

Caution Ensure that hazardous voltage wiring is performed only by

qualified personnel adhering to local electrical standards.

Caution Do not mix hazardous voltage circuits and human-accessible

circuits on the same module.

Caution Ensure that devices and circuits connected to the module are

properly insulated from human contact.

Caution When module terminals are hazardous voltage LIVE (>42.4 Vpk/60

V DC), you must ensure that devices and circuits connected to the module

are properly insulated from human contact.

Safety Guidelines for Hazardous Locations

The NI-9260 is suitable for use in hazardous locations; , and hazardous locations;

and nonhazardous locations only. Follow these guidelines if you are installing the

NI-9260 in a potentially explosive environment. Not following these guidelines may

result in serious injury or death.

Caution Do not disconnect I/O-side wires or connectors unless power has

been switched o or the area is known to be nonhazardous.

ni.com

NI-9260 Getting Started

Caution Do not remove modules unless power has been switched o or

the area is known to be nonhazardous.

Caution Substitution of components may impair suitability for Class I,

Division 2, or Zone 2.

Caution The system must be installed in an enclosure certified for the

intended hazardous (classified) location, having a tool secured cover/door,

where a minimum protection of at least IP54 is provided.

Special Conditions for Hazardous Locations Use in Europe and

Internationally

The NI-9260 has been evaluated as equipment under DEMKO ATEX and is IECEx

certified. Each NI-9260 is marked and is suitable for use in Zone 2 hazardous

locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C. If you are using the NI-9260

in Gas Group IIC hazardous locations, you must use the device in an NI chassis that

has been evaluated as Ex nC IIC T4, Ex IIC T4, Ex nA IIC T4, or Ex nL IIC T4 equipment.

Caution Transient protection shall be provided that is set at a level not

exceeding 140% of the peak rated voltage value of 85 V at the supply

terminals to the equipment.

Caution The system shall only be used in an area of not more than

Pollution Degree 2, as defined in IEC/EN 60664-1.

Caution The system shall be mounted in an ATEX/IECEx-certified

enclosure with a minimum ingress protection rating of at least IP54 as

defined in IEC/EN 60079-15.

Caution The enclosure must have a door or cover accessible only by the

use of a tool.

NI-9260 Getting Started

Electromagnetic Compatibility Guidelines

This product was tested and complies with the regulatory requirements and limits

for electromagnetic compatibility (EMC) stated in the product specifications. These

requirements and limits provide reasonable protection against harmful interference

when the product is operated in the intended operational electromagnetic

environment.

This product is intended for use in industrial locations. However, harmful

interference may occur in some installations, when the product is connected to a

peripheral device or test object, or if the product is used in residential or

commercial areas. To minimize interference with radio and television reception and

prevent unacceptable performance degradation, install and use this product in strict

accordance with the instructions in the product documentation.

Furthermore, any changes or modifications to the product not expressly approved

by National Instruments could void your authority to operate it under your local

regulatory rules.

Special Conditions for Marine Applications

Some products are approved for marine (shipboard) applications. To verify marine

approval certification for a product, visit ni.com/product-certifications, search by

model number, and click the appropriate link.

Notice In order to meet the EMC requirements for marine applications,

install the product in a shielded enclosure with shielded and/or filtered

power and input/output ports. In addition, take precautions when

designing, selecting, and installing measurement probes and cables to

ensure that the desired EMC performance is attained.

Preparing the Environment

Ensure that the environment in which you are using the NI-9260 meets the following

specifications.

Operating temperature (IEC 60068-2-1, IEC 60068-2-2) -40 °C to 70 °C

ni.com

NI-9260 Getting Started

Operating humidity (IEC 60068-2-30) 10% RH to 90% RH, noncondensing

Pollution Degree 2

Maximum altitude 5,000 m

Indoor use only.

Note Refer to the NI-9260 Specifications on ni.com/manuals for

complete specifications.

NI 9260 Pinout

CHASSIS GND

AO0–

AO0+ AO0+

AO0–

AO1+

AO1–

CHASSIS GND

A10–

A10+

Signal Description

AO+ Positive analog output signal connection

AO- Negative analog output signal connection

Chassis GND Chassis ground connection

Table 1. Signal Descriptions

NI-9260 with mini XLR Analog Output Connection

NI-9260 Getting Started

Load

NI 9260

with mini XLR

AO+

AO–

IN+

IN–

CHASSIS

GND

Note You can only use the NI-9260 with mini XLR with dierential

instruments.

Notice Do not connect AO- to chassis ground on the NI-9260 with mini

XLR. Connecting this pin to chassis ground will short circuit the output.

Notice Do not connect the NI-9260 with mini XLR to a ground referenced

single-ended instrument. Refer to the Circuitry section in the device

datasheet on ni.com/manuals for further information.

NI 9260 with BNC Analog Output Connections

NI 9260 with BNC Load

AO+

AO–

IN+

IN–/GND

50 Ω

NI-9260 Connection Guidelines

■ Make sure that devices you connect to the NI-9260 are compatible with the

module specifications.

■To minimize ground noise, make sure you connect the chassis ground to

earth ground.

Overvoltage Protection

The NI-9260 provides overvoltage protection for each channel.

ni.com

NI-9260 Getting Started

Note Refer to the NI-9260 Specifications on ni.com/manuals for more

information about overvoltage protection.

Where to Go Next

CompactRIO NI CompactDAQ

Located at ni.com/manuals

RELATED INFORMATION

C Series Documentation

& Resources

ni.com/info cseriesdoc

Services

ni.com/services

Installs with the software

NI 9260 Datasheet

NI-RIO Help

LabVIEW FPGA Help

NI 9260 Datasheet

NI-DAQmx Help

LabVIEW Help

NI Services

Visit ni.com/support to find support resources including documentation,

downloads, and troubleshooting and application development self-help such as

tutorials and examples.

Visit ni.com/services to learn about NI service oerings such as calibration options,

repair, and replacement.

Visit ni.com/register to register your NI product. Product registration facilitates

technical support and ensures that you receive important information updates from

NI.

NI corporate headquarters is located at 11500 N Mopac Expwy, Austin, TX,

78759-3504, USA.
