Multitech Modem Module MT3334SMI Mode d’emploi

ModemModule

Model MT3334SMI Evaluation Kit

Data/Fax Socketed Modem

Developer’s Guide

88312201 Revision B

ModemModule (Model MT3334SMI)

This publication may not be reproduced, in whole or in part, without prior expressed written permission from

Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents hereof and

specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.

Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to make changes from

time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or

organization of such revisions or changes.

Record of Revisions

Revision Description

AManual released. All pages at revision A.

(10/22/99)

BAdded the &V command to the AT command set and added Appendix B which provides

(12/10/99) instructions for developing a customized flash prgramming utility. All pages at revision B.

Patents

This Product is covered by one or more of the following U.S. Patent Numbers: 5.301.274; 5.309.562;

5.355.365; 5.355.653; 5.452.289; 5.453.986. Other Patents Pending.

Trademarks

Trademarks of Multi-Tech Systems, Inc. are ModemModule and the Multi-Tech logo.

IBM is a registered trademark of International Business Machines Corporation.

Intel is a registered trademark of Intel Corporation.

MNP and Microcom Network Protocol are registered trademarks of Microcom, Inc.

Microsoft, Windows, Windows 95, and Windows NT are either registered trademarks or trademarks of Microsoft

Corporation in the United States and/or other countries.

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112

(612) 785-3500 or (800) 328-9717

Fax 612-785-9874

Tech Support (800) 972-2439

InternetAddress:http://www.multitech.com

iii

Contents

Chapter 1 - Introduction and Description

Introduction .......................................................................................................................................................6

Product Description...........................................................................................................................................6

Features ............................................................................................................................................................6

Technical Specifications ....................................................................................................................................7

Physical Dimensions .........................................................................................................................................9

Test/Demo Board Specifications .....................................................................................................................10

Test/Demo Board Block Diagram.............................................................................................................. 11

MT3334SMI Pin-out ........................................................................................................................................12

TypicalApplication ....................................................................................................................................13

MT3334SMI Design Considerations................................................................................................................14

Hardware Considerations .........................................................................................................................14

PC Board Layout Considerations..............................................................................................................15

MT3334SMI Placement ............................................................................................................................16

Telecom Labeling Requirements...............................................................................................................17

Chapter 2 - AT Commands, S-Registers, and Result Codes

Introduction .....................................................................................................................................................20

S-Registers .....................................................................................................................................................28

Result Codes...................................................................................................................................................30

Chapter 3 - Class 1 Fax Commands

Introduction .....................................................................................................................................................32

Class 1 Fax Command Summary .............................................................................................................32

Chapter 4 - Class 2 Fax Commands

Introduction .....................................................................................................................................................42

Class 2 Fax Command Implementation....................................................................................................42

Class 2 Fax Commands (EIASP-2388August 1990)...............................................................................42

Chapter 5 - Remote Configuration

Introduction .....................................................................................................................................................52

Basic Procedure..............................................................................................................................................52

Setup ........................................................................................................................................................52

Chapter 6 - Troubleshooting

Introduction .....................................................................................................................................................56

LocalAnalog Loopback Test (V.54 Loop 3)...............................................................................................56

Remote Digital Loopback Test (V.54 Loop 2)............................................................................................57

Local Digital Loopback Test (V.54 Loop 2)................................................................................................58

Chapter 7 - Upgrade Procedure

Introduction .....................................................................................................................................................60

Upgrade Overview ..........................................................................................................................................60

Step 1: Identify the Modem Firmware .......................................................................................................60

Step 2: Identify the Current Firmware Version ..........................................................................................60

Step 3: Download the Upgrade File ..........................................................................................................61

Step 4: Extract the Upgrade Files.............................................................................................................62

Step 5: Clear Your Stored Paramenters ...................................................................................................62

Step 6: Use FlashPro to Upgrade Modem Firmware ................................................................................62

Step 7: Restore Your Parameters .............................................................................................................62

Appendixes

AppendixA- RegulatoryAgency Compliance ................................................................................................64

International Modem Restrictions .............................................................................................................65

EMC, Safety and Terminal Directive Compliance .....................................................................................66

European Directives User Guide Statement .............................................................................................66

New Zealand Telecom Warning Notice .....................................................................................................66

Appendix B - Multi-Tech Flash Programming Protocol...................................................................................67

Introduction ...............................................................................................................................................67

Intel Hex Format .......................................................................................................................................69

Index

Chapter 1 - Introduction and Description

ModemModule Developer’s Guide

MT3334SMI6

Introduction

The MT3334SMI socket modem provides a fully-integrated data and fax communications design for

communications over wide area networks using dial-up phone lines and the Internet.

This guide provides the Service Class 1 standard defining the commands that the developer can use

to configure and control a fax/data modem and the responses (result codes) that the fax/data modem

issues in response to the commands. This guide also provides the developer with specific Class 2 fax

command protocol used to control the sending and receiving of faxes.

Product Description

The MT3334SMI is a standard 64-pin Socket Modem (Figure 1-1 illustrates the MT3334SMI in

relationship to Multi-Tech’s Demo board) used for integrating data and fax communications. It

provides:

• Low power consumption

• A serial TTL level interface

• Full-featured fax and datacomm operation

• A very small footprint for embedded applications

LED 4

LED 3

LED 2

LED 1

DS1

Figure 1-1. MT3334SMI and Demo Board

Features

• Complete fax / modem solution: includes the controller, data pump, and DAA

• Modem downloads at 33.6 Kbps via enhanced V.34 server and uploads at 33.6 Kbps

(enhanced V.34)

• Supports V.42 error correction with V.42bis or MNP Class 5 data compression

• Supports industry-standardAT-style commands

• Standard TTLserial interface supporting DTE transfer speeds to 230.4 Kbps

• Remote configuration, diagnostic tests, Distinctive Ring, 3-number storage for automatic

dialing, and Flash memory for firmware updates.

• Includes NOVRAM for stored parameters

Chapter 1 - Introduction and Description

MT3334SMI 7

Technical Specifications

The ModemModulemeets the following specifications:

Data Rates

Client-to-Server DataComm: supports enhanced V.34 (33.6K), V.32bis (14.4K), V.32 (9600), V.22bis

(2400), or slower speed connection for download speeds, and upload speeds to

33.6 Kbps via enhanced V.34.

Client-to-Client 33,600, 31,200, 28,800, 26,400, 24,000, 21,600, 19,200, 16,800, 14,400,

12,000, 9600, 7200, 4800, 2400, 1200, 0-300 bps

Fax Data Rates 14,400, 9600, 7200, 4800, 2400, 300 bps

Data Format Serial, binary, asynchronous

Modem Compatibility ITU-T V.34 enhanced, V.34, V.32bis, V.32, V.22bis, V.22; Bell 212A and 103/113;

ITU-T V.29, V.42, V.42bis; ITU-T V.21 & V.23 in international versions

Fax Compatibility ITU-T Group 3, Class 1 and 2, T.4, T.30, V.21, V.27ter, V.29, V.17, and TIA/

EIA TR29.2

Error Correction ITU-T V.42 (LAP-M or MNP 3–4)

Data Compression ITU-T V.42bis (4:1 throughput), MNP 5 (2:1 throughput)

Speed Conversion Serial port data rates adjustable to 300, 1200, 2400, 4800, 9600, 19,200,

38,400, 57,600, 115,200, and 230,400 bps

Modes of Operation Fax online modes; full duplex over dial-up lines; data mode, command mode,

and online command mode; V.54 Test mode.

Flow Control XON/XOFF (software), RTS/CTS (hardware)

Intelligent Features Fully AT command compatible; autodial, redial, repeat dial; pulse or tone dial;

dial pauses; auto answer; adaptive line probing; automatic symbol and

carrier frequency during start-up, retrain, and rate renrgotiation; DTMF detection;

call status display, auto-parity and data rate selections; keyboard-controlled modem

options; non-volatile memory; on-screen displays for modem option parameters;

command lines of up to 40 characters each; help menus; remote configuration;

DTR dialing.

Command Buffer 40 characters

Data Modulation FSK at 300 bps, PSK at 1200 bps, QAM at 2400, 4800, and 9600 bps (non-

trellis), QAM with trellis-coded modulation (TCM) at 9600, 12,000, 14,400,

16,800, 19,200, 21,600, 24,000, 26,400, 28,800, 31,200, and 33,600, bps

Fax Modulation V.21 CH2 FSK at 300 bps (half duplex)

V.27ter DPSK at 4800 and 2400 bps

V.29 QAM at 9600 and 7200 bps

V.17TCM at 14400, 12000, 9600, and 7200 bps

Carrier Frequencies 1600, 1646, 1680, 1800, 1829, 1867, 1920,

ITU-T V.34 1959, 2000 Hz

Carrier Frequencies 1800 Hz

ITU-T V.32bis/V.32

Carrier Frequencies Transmit originate: 1200 Hz

V.22bis/V.22 or Transmit answer: 2400 Hz

Bell 212A Standard Receive originate: 2400 Hz

(2400 & 1200 bps) Receive answer: 1200 Hz

ModemModule Developer’s Guide

MT3334SMI8

Carrier Frequencies Transmit originate: 390 Hz mark

ITU-T V.23 450 Hz space

(1200 bps) Receive originate: 1300 Hz mark

2100 Hz space

Transmit answer: 1300 Hz mark

2100 Hz space

Receive answer: 390 Hz mark

450 Hz space

Carrier Frequencies Transmit originate: 980 Hz mark

ITU-T V.21 1180 Hz space

(0–300 bps) Receive originate: 1650 Hz mark

1850 Hz space

Transmit answer: 1650 Hz mark

1850 Hz space

Receive answer: 980 Hz mark

1180 Hz space

Carrier Frequencies Transmit originate: 1270 Hz mark

Bell 103/113 1070 Hz space

(0–300 bps) Receive originate: 2225 Hz mark

2025 Hz space

Transmit answer: 2225 Hz mark

2025 Hz space

Receive answer: 1270 Hz mark

1070 Hz space

Fax Carrier V.21 Ch2 (half duplex):

Frequencies 1650 Hz mark, 1850 HZ space for transmit originate

1650 HZ mark, 1850 Hz space for transmit answer

V.27ter: 1800 Hz originate/answer

V.29 QAM: 1800 Hz originate/answer

V.17 TCM: 1800 Hz originate/answer

Transmit Level -11 dBm (dial-up)

Frequency Stability ±0.01%

Receiver Sensitivity -43 dBm under worst-case conditions

AGC Dynamic Range 43 dB

Interface Serial interface for EIA RS-232C/ITU-T V.24/V.28

Diagnostics Local analog loop, local digital loop, remote digital loop.

Weight 0.02 Kg. (0.04 lb.)

Dimensions: 1.045" × 2.541" × 0.680"

(2.7 x 6.5 x 1.8 cm)

Power consumption: Typical: 215 mA (1.3 W @ 5v DC)

Maximum: 420 mA (2.1 W @ 5.25v DC)

Environmental: 0-50° C; humidity range 20–90% (non-condensing)

Approvals*: UL 1950 approved

FCC Part 68 approved

Industry canada CS0s

EN60950

* Approvals are provided in controlled configurations and must be re-evaluated in end-user configurations.

Chapter 1 - Introduction and Description

MT3334SMI 9

Physical Dimensions

Figure 1-2 illustrates the the physical dimensions of the MT3334SMI.

.020 ± .0002 SQUARE

[0,51]

.228

[5,8]

.063

[1,6]

.310

[7,87]

.118

[3]

MAXIMUM COMPONENT

HEIGHT SOL ER SI E

.945 REF.

[24]

.062

[1,57]

.354

[8,99]

.050

[1,27]

.050

[1,27]

1.045

[26,54]

.079

[2,01]

.286

[7,26]

1.861

[47,27]

.079 TYP.

[2,01]

.995

[25,27]

1.861

[47,27]

2.019

[51,28]

2.256

[57,3]

2.550

[64,77]

Figure 1-2. MT3334SMI Physical Dimensions

CAUTION: If any component(s) is placed under the socket modem or if any component(s) should

extend to the point where part of it is under the socket modem, the component(s) must NOT exceed

.060 inches in height.

ModemModule Developer’s Guide

MT3334SMI10

Test/Demo Board Specifications

The ModemModule Test/Demo Board kit includes a modem module, a power transformer for the test

board, and a diskette (this Developer’s Guide manual, etc.). Figure 1-3 illustrates the demo/test

board and Figure 1-4 illustrates the Test/Demo board block diagram.

LED 4

LED 3

LED 2

LED 1

DS1

Figure 1-4. MT3334SMI Test/Demo Board

Designation Function

DS1 Speaker

J1 25-Pos. DSUB

J2 6-Pin Mod. Jack (Line Jack)

J3, J6 4-Pos. Connector

J4, J5 10-Pos. Connector

J7 2-Pos. Header

LED1-LED4 Red LED

S1 SPST Switch

Table des matières

Autres manuels Multitech Modem

Multitech

Multitech MultiConnect Adapter Manuel utilisateur

Multitech

Multitech Multimodem MTCBA-G-F1 Manuel utilisateur

Multitech

Multitech MT1932ZDXI Manuel d'utilisation

Multitech

Multitech MT5600BA Manuel utilisateur

Multitech

Multitech MultiModem ZBA USB MT5634ZBA-USB Manuel utilisateur

Multitech

Multitech QuickCarrier USB-D MTD-MVW1 Manuel utilisateur

Multitech

Multitech MTCBA-C-U-N1 Manuel utilisateur

Multitech

Multitech MMCModem MTMMC-G-F4 Manuel utilisateur

Multitech

Multitech Dragonfly MTQ-LNA7 Manuel utilisateur

Multitech

Multitech IWAY MT128ISA-UV Manuel utilisateur

Multitech

Multitech MMCModem MTMMC-G-F4 Mode d’emploi

Multitech

Multitech SocketModem Series Guide d'application

Multitech

Multitech SocketModem Cell MTSMC-LVW3 Guide d'application

Multitech

Multitech MultiModemISDN MTA128ST-USB Manuel utilisateur

Multitech

Multitech MultiModem MT9234ZPX-UPCI Manuel utilisateur

Multitech

Multitech MultiConnect Cell MTC-LVW2 Manuel utilisateur

Multitech

Multitech MultiConnect Series 100 Manuel utilisateur

Multitech

Multitech SocketModem MTSMC-G-F1 Mode d’emploi

Multitech

Multitech MultiModem MT5600ZDX Manuel utilisateur

Multitech

Multitech CommPlete MT3334HD8 Manuel utilisateur

Multitech

Multitech MultiConnect MicroCell MTCM-LAT3 Manuel utilisateur

Multitech

Multitech MTC-EV3 Manuel utilisateur

Multitech

Multitech MultiModem IND MT5634IND Manuel utilisateur

Multitech

Multitech Dragonfly Nano MTQN-MNG3-B02 Guide d'application

Manuels Modem populaires d'autres marques

Davicom

Davicom DM562AP Manuel utilisateur

EpiValley

EpiValley TATA indicom SXC-1080 Manuel utilisateur

Zte

Zte WiMAX Manuel utilisateur

Intelimax

Intelimax MA-2060 Manuel utilisateur

SMC Networks

SMC Networks D3CM1604V Manuel d'utilisation et d'entretien

Telstra

Telstra Wi-Fi 4G Advanced Pro X Manuel utilisateur

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Manuel utilisateur

Samsung

Samsung AceLink SAM-335A Manuel utilisateur

Enfora

Enfora Enabler-G Guide de configuration rapide

iRZ

iRZ ATM2-232 Manuel utilisateur

Zhone

Zhone 6310 Manuel utilisateur

Paradyne

Paradyne Hotwire 7976 Manuel utilisateur

US Robotics

US Robotics 3453C Manuel utilisateur

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Manuel utilisateur

Zte

Zte MF823 Manuel utilisateur

Four-Faith

Four-Faith F1403 Manuel utilisateur

Sierra Wireless

Sierra Wireless AIRLINK MP595W Manuel utilisateur

Gemtek

Gemtek WiMAX WIXFBR-103 Manuel utilisateur
