Multitech MultiVOIP 100 (MVP110 Manuel utilisateur

100

Voice / Fax over IP Networks

Standalone Voice/IP Gateway

Model MVP110

H.323 Mode

Quick Start Guide

82050950 Revision A

MultiVOIP 110 (Model MVP110)

This publication may not be reproduced, in whole or in part, without prior

expressed written permission from Multi-Tech Systems, Inc. All rights

Multi-Tech Systems, Inc. makes no representations or warranties with

respect to the contents hereof and specifically disclaims any implied

warranties of merchantability or fitness for any particular purpose.

Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this

publication and to make changes from time to time in the content hereof

without obligation of Multi-Tech Systems, Inc. to notify any person or

organization of such revisions or changes.

Record of Revisions

Revision Description

AInitial Release.

(06/06/01)

Patents

This Product is covered by one or more of the following U.S. Patent

Numbers: 5.682.386; 5.757.801; 6.151.333. Other Patents Pending.

TRADEMARK

Trademark of Multi-Tech Systems, Inc. is the Multi-Tech logo.

Windows and Netmeeting are registered trademarks of Microsoft.

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112

(763) 785-3500 or (800) 328-9717

U.S. Fax 763-785-9874

Technical Support (800) 972-2439

http://www.multitech.com

iii

Contents

Introduction ................................................................................... 4

RelatedDocumentation................................................................. 5

Installing Your MultiVOIP 200........................................................ 6

Installing and Configuring Your MultiVOIP 200 ....................... 6

Deploying the VOIP Network .................................................. 7

Unpacking Your MultiVOIP 200 ..................................................... 8

Safety Warnings ............................................................................ 8

Cabling Your MultiVOIP 200.......................................................... 9

Cabling Procedure .................................................................. 9

E&M Jumper Block Positioning Procedure ..................................11

Installing Your MultiVOIP 200 Software....................................... 12

Configuring Your MultiVOIP 200.................................................. 17

Registering with a Gatekeeper Phone Directory................... 28

Building a Proprietary Phonebook Directory ......................... 35

Configuring Your Client MultiVOIP 200s ............................... 47

Deploying the VOIP Network....................................................... 60

Remote SiteAdministrator .................................................... 61

Limited Warranty ......................................................................... 64

Technical Support........................................................................ 65

FCC Declaration.......................................................................... 65

MultiVOIP Quick Start Guide

Introduction

Welcome to Multi-Tech's stand-alone Voice/IP Gateway, the

MultiVOIP, model MVP110. The MultiVOIP 110 allows analog

voice and fax communication over an IP network. Multi-Tech’s

voice/fax gateway technology allows voice/fax communication

to be transmitted, with no additional expense, over your

existing IP network, which has traditionally been data-only. To

access this free voice and fax communication, all you have to

do is connect the MultiVOIP 110 to your telephone equipment,

and then to your existing Internet connection. Once

configured, the MultiVOIP 110 then allows voice and fax to

travel down the same path as your traditional data

communications.

The MultiVOIP 110 supports the H.323 standards-based

protocol enabling your MultiVOIP 110 to communicate with

other third-party VOIP Gateways or other endpoints that

support the H.323 protocol, such as Microsoft NetMeeting®.

The H.323 standard defines how endpoints make and receive

calls, how endpoints negotiate a common set of audio and

data capabilities, and how information is formatted and sent

over the network. This version of the software also supports

communication with a Multi-Tech MVPGK1 Gatekeeper or an

optional 3rd party H.323 Gatekeeper which, when enabled,

maintains its own phonebook database, pre-registers all users,

controls the bandwidth, and handles all conferencing issues

such as transferring of calls.

Figure 1. MultiVOIP 110

Introduction

The MVP110 has one FXS voice/fax channel, a 10 Mbps

Ethernet LAN interface, and a Command port for configuration.

System management is provided through the Command port

using bundled Windows®software which provides easy-to-use

configuration menus and comprehensive online Help.

Related Documentation

The MultiVOIP 110 Quick Start Guide is intended to be used

by qualified systems administrators and network managers.

This Quick Start Guide provides the necessary information for

a qualified person to unpack, cable, load software, and

configure the unit for proper operation.

Adetailed MultiVOIP 110 User Guide is included on your

system CD and provides in-depth information on the features

and functionality of Multi-Tech’s MultiVOIP 110.

The CD media is produced usingAdobeAcrobatTM for viewing

and printing the user guide. To view or print your copy of a

user guide, loadAcrobat ReaderTM onto your system from the

CD, or obtain it as a free download fromAdobe’s Web site:

http://www.adobe.com

The MultiVOIP 110 User Guide is also available from Multi-

Tech’s Web site:

http://www.multitech.com

Viewing and printing a user guide from the Web also requires

that you have theAcrobat Reader loaded on your system. To

select the MultiVOIP 110 User Guide from the Multi-Tech

Systems home page, click Documents, then click MultiVOIP in

the product list, then click MultiVOIP Manuals.All MultiVOIP 110

documents will be displayed at the bottom of the page and you

can choose User Guide (MVP110) to view or download the .pdf

file.

MultiVOIP Quick Start Guide

Installing Your MultiVOIP 110

The basic steps of installing your MultiVOIP 110 network

involve unpacking the units, connecting the cables, and

configuring the units using management software (MultiVOIP

110 Configuration). This process results in a fully functional

Voice Over IP network. Abrief description is provided below

with detailed instructions provided later.

Installing and Configuring Your MultiVOIP 110

The VOIP administrator must first install the MultiVOIP 110

software and then configure each MultiVOIP 110 for its specific

function. During the configuration process, it’s important to

note that the Phone Directory Database is configured

differently depending on whether or not you have Gatekeeper

support on your VOIP network.

If your VOIP network supports an H.323 Gatekeeper, you

must register all H.323 endpoints with the Gatekeeper. The

procedure for doing this is explained in the section

“Registering with a Gatekeeper Phone Directory.”

If your VOIP network does not have Gatekeeper software or

the Gatekeeper software is not enabled, then you must build a

proprietary phonebook with a “Host” MultiVOIP 110 and

“Client” MultiVOIP 110s. The “Host” unit includes the

assignment of a unique LAN IP address, subnet mask, and

Gateway IP address; as well as the selection of appropriate

channel interface type for each of the Voice/Fax channels.

Once all connections have been made, the VOIP administrator

configures the unit and builds the Phone Directory Database

that will reside in the Host unit.

After the “Host” MultiVOIP 110 is configured, the administrator

moves on to configure the MultiVOIP 110s designated as

“Client” units. Again, unique LAN IP addresses, subnet

masks, and Gateway IP addresses are assigned, and each

Voice/Fax channel is configured for the appropriate channel

interface type. When this is done, the Phone Directory

Introduction

Database option is set to Client, and the IP address of the

Host MultiVOIP 110 is entered. Once all Client units are

configured, the process moves on to the “Deploying the VOIP

Network” section.

Deploying the VOIP Network

The final phase of the installation is deployment of the

network. When the remote MultiVOIP 110s are sent to their

remote sites, the remote site administrators need only connect

the units to their LAN and telephone equipment.Afull Phone

Directory Database (supplied by the Host MultiVOIP 110

Proprietary Phonebook will be loaded into their units within

minutes of being connected and powered up.

For remote VOIPs that were configured with the Gatekeeper

option enabled, each MultiVOIP 110 will be registered with the

Gatekeeper (the Gatekeeper phonebook directory is NOT

downloaded to the remote units).

MultiVOIP Quick Start Guide

Unpacking Your MultiVOIP 110

Remove all items from the box. (See Figure 2.)

MADE IN U.S.A

www.multitech.com

Voice/Fax over IP Networks

Figure 2. Unpacking

Safety Warnings

Caution: Danger of explosion if battery is incorrectly replaced.

A lithium battery on the circuit board provides backup power

for the time keeping capability. The battery has an estimated

life expectancy of ten years.

When the battery starts to weaken, the date and time may be

incorrect. If the battery fails, the board must be sent back to

Multi-Tech Systems for battery replacement.

The E&M, FXS, and Ethernet ports are not designed to be

connected to a Public Telecommunication Network.

Cabling

Cabling Your MultiVOIP 110

Cabling your MultiVOIP 110 involves making the proper

Power, Command Port, and Internet connections. Figure 6

shows the back panel connectors and the associated cable

connections. The Cabling Procedure section provides step-by-

step instructions for cabling your MultiVOIP 110.

Cabling Procedure

1. Using the supplied cable, connect the power supply to a

liveAC outlet, then plug the power supply into the

MultiVOIP 110 as shown in Figure 3.

Network Connection

Power Connection

Command Port Connection

FXS

Hub

Figure 3. Cable Connections

2. Connect the MultiVOIP 110 to a PC using the RJ-45 to

DB9 (female) cable provided with your unit. Plug the RJ-45

end of the cable into the Command port of the MultiVOIP

110 and connect the other end to the PC’s serial port

(Figure 3).

3. Connect a network cable to the Ethernet 10Base-T

connector on the back of the MultiVOIP 110. Connect the

other end of the cable to your network.

4. If you are connecting a station device such as an analog

MultiVOIP Quick Start Guide

telephone, fax machine, or Key Telephone System (KTS)

to your MultiVOIP 110, connect the smaller end of a

special adapter cable (supplied) to the Voice/Fax Channel

1 FXS connector on the back of the MultiVOIP 110 and the

other end to the station device.

5. Turn on power to the MultiVOIP 110 by setting the power

switch on the right side to the On position. Wait for the

Boot LED on the MultiVOIP 110 to go off before

proceeding. This may take a couple of minutes.

Autres manuels pour MultiVOIP 100 (MVP110

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Multitech Porte

Multitech

Multitech MultiVOIP MVP130-AV-FXS Manuel utilisateur

Multitech

Multitech Conduit AP Manuel utilisateur

Multitech

Multitech MultiVOIP MVP200 Manuel utilisateur

Multitech

Multitech VoIP Manuel utilisateur

Multitech

Multitech Conduit MTCDT-246L-US-EU-GB Instructions d'installation

Multitech

Multitech Conduit AP MTCAP-L4E1 Manuel utilisateur

Multitech

Multitech MultiVOIP MVP400 Manuel utilisateur

Multitech

Multitech MultiConnect Conduit MTCDT Instructions d'installation

Multitech

Multitech MultiVOIP MVPFX2-8 Manuel utilisateur

Multitech

Multitech MultiVOIP MVP100GK Gatekeeper Manuel utilisateur

Multitech

Multitech MultiConnect Conduit Manuel utilisateur

Multitech

Multitech OneBox Smart Building Manuel utilisateur

Multitech

Multitech RouteFinder RF550VPN Manuel utilisateur

Multitech

Multitech MultiVOIP MVPFX2-2 Manuel utilisateur

Multitech

Multitech 410 Manuel utilisateur

Multitech

Multitech E1 Manuel utilisateur

Multitech

Multitech MVP-2410, MVP-3010 Manuel utilisateur

Multitech

Multitech MultiVOIP 800 MVP800 Manuel utilisateur

Multitech

Multitech MultiConnect Conduit IP67 Base Station Manuel utilisateur

Multitech

Multitech MultiVOIP GSM SIP-to-Cellular Gateways... Manuel utilisateur

Multitech

Multitech MULTIVOIP MVP-130 Manuel utilisateur

Multitech

Multitech RouteFinder RF550VPN Manuel utilisateur

Multitech

Multitech MultiVOIP MVPFXS-8 Manuel utilisateur

Multitech

Multitech MULTIVOIP MVP-210 Manuel utilisateur

Manuels Porte populaires d'autres marques

LST

LST M500RFE-AS Manuel utilisateur

Kinnex

Kinnex Media Gateway Manuel utilisateur

2N Telekomunikace

2N Telekomunikace 2N StarGate Manuel utilisateur

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manuel utilisateur

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manuel utilisateur

Telsey

Telsey CPVA 500 - SIP Manuel utilisateur

RTA

RTA 460A-NNA4 Fiche technique

Shaw

Shaw Gateway HDPVR Manuel utilisateur

ABB

ABB VSN900 Guide de démarrage rapide

Commander

Commander Pulse Manuel utilisateur

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manuel utilisateur

NETGEAR

NETGEAR C6300BD Manuel utilisateur

Amit

Amit CDW531AM Manuel utilisateur

HMS

HMS Netbiter EasyConnect EC150 Manuel utilisateur

Huawei

Huawei EchoLife HG620 Manuel utilisateur

AT&T

AT&T U-verse 3801 Manuel d'utilisation et d'entretien

Logic IO

Logic IO RTCU MX2 turbo Manuel utilisateur

Suttle

Suttle MediaMAX MXM-521 Manuel utilisateur
