W315A/325A User’s Manual

Second Edition, March 2011

www.moxa.com/product

W315A/325A User’s Manual

The software described in this manual is furnished under a license agreement and may be used only in accordance with

the terms of that agreement.

Trademarks

The MOXA logo is a registered trademark of Moxa Inc.

All other trademarks or registered marks in this manual belong to their respective manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not represent a commitment on the part of

Moxa.

Moxa provides this document as is, without warranty of any kind, either expressed or implied, including, but not limited

to, its particular purpose. Moxa reserves the right to make improvements and/or changes to this manual, or to the

products and/or the programs described in this manual, at any time.

Information provided in this manual is intended to be accurate and reliable. However, Moxa assumes no responsibility for

its use, or for any infringements on the rights of third parties that may result from its use.

This product might include unintentional technical or typographical errors. Changes are periodically made to the

information herein to correct such errors, and these changes are incorporated into new editions of the publication.

Technical Support Contact Information

www.moxa.com/support

Moxa Americas

Toll-free: 1-888-669-2872

Tel: +1-714-528-6777

Fax: +1-714-528-6778

Moxa China (Shanghai office)

Toll-free: 800-820-5036

Tel: +86-21-5258-9955

Fax: +86-10-6872-3958

Moxa Europe

Tel: +49-89-3 70 03 99-0

Fax: +49-89-3 70 03 99-99

Moxa Asia-Pacific

Tel: +886-2-8919-1230

Fax: +886-2-8919-1231

Table of Contents

1. Introduction ...................................................................................................................................... 1-1

Overview ...........................................................................................................................................1-2

Package Checklist ...............................................................................................................................1-2

Product Features ................................................................................................................................1-3

Hardware Specifications ......................................................................................................................1-3

Hardware Block Diagrams ....................................................................................................................1-5

W315A.......................................................................................................................................1-5

W325A.......................................................................................................................................1-5

2. Hardware Introduction ..................................................................................................................... 2-1

Appearance........................................................................................................................................2-2

W315A.......................................................................................................................................2-2

W325A.......................................................................................................................................2-2

Dimensions ........................................................................................................................................2-3

LED Indicators....................................................................................................................................2-3

Reset Button ......................................................................................................................................2-4

Real Time Clock..................................................................................................................................2-4

3. Hardware Connection Description ..................................................................................................... 3-1

Installing the W315A/325A ..................................................................................................................3-2

Wiring Requirements...........................................................................................................................3-2

Connecting the Power ..................................................................................................................3-3

Grounding the Unit ......................................................................................................................3-3

Connecting Data Transmission Cables ...................................................................................................3-3

Connecting to the Network ...........................................................................................................3-3

Connecting to a Serial Device .......................................................................................................3-4

Connecting to the Serial Console Port ............................................................................................3-4

Connecting an Antenna ................................................................................................................3-4

Installing a SIM Card...........................................................................................................................3-5

Installing an SD Card for Storage Expansion ..........................................................................................3-5

A. Regulatory Approval Statement ........................................................................................................ A-1

1. Introduction

The W315A/325A wireless RISC-based embedded computers feature a GSM/GPRS module, RS-232/422/485

serial ports, and an Ethernet port in a small, rugged chassis. In addition, the W315A and W325A come with an

SD socket, making them the ideal solution when the applications require external storage expansion.

The W315A/325A embedded computers are ideal for diverse, machine-to-machine embedded applications. The

computers enable the wireless operation of traditionally wired network and serial devices, and can handle

transparent data transfer, numerical computing, protocol conversion, data processing, and even data

encryption. You will find it easier to build embedded systems for distributed peer-to-peer communication, turn

wired devices into wireless devices, and introduce higher mobility and more intelligence to your system. In this

chapter, we cover the various capabilities of the W315A/325A series embedded computers.

The following topics are covered in this chapter:



Overview



Package Checklist



Product Features



Hardware Block Diagrams

W315A

W325A

W315A/325A Introduction

1-2

Overview

The W315A/325A wireless embedded computers are designed around the MOXA ART ARM9 32-bit RISC

processor. Unlike the X86 CPU, which uses a CISC design, the MOXA ART ARM9 uses RISC architecture and

modern semiconductor technology to provide a powerful computing engine without generating a significant

amount of heat. The processor also integrates UART and LAN functions to provide exceptional communication

performance, but without the bus bandwidth limitations associated with general ARM-based communication

products.

An onboard NOR Flash ROM and SDRAM provide ample storage capacity, and the SD slot gives applications

extra room to expand. The built-in GSM/GPRS function supports the 850/900/1800/1900 MHz frequency bands,

providing a coding scheme from CS-1 to CS-4. The backup LAN port not only provides an alternative solution

for networking, but also supports Ethernet clients, allowing any network device to plug in and connect to the

GPRS network. The built-in RS-232/422/485 serial ports support a wide range of serial devices, making this

platform suitable for data acquisition and protocol conversion applications.

The Linux-based operating system comes pre-installed and ready to run, providing an open platform for

software development. Software written for desktop PCs can be ported easily to W315A/325A series embedded

computers by using a common compiler, so you do not need to spend a lot of time modifying existing software

code. In addition, the operating system, device drivers, and user-developed software can all be stored in the

built-in flash memory.

Package Checklist

The W315A/325A Series includes the following models:

W315A-LX

Mini RISC-based, ready-to-run, wireless embedded computer with GSM/GPRS, one serial port, LAN, SD, and

Linux OS

W325A-LX

Mini RISC-based, ready-to-run, wireless embedded computer with GSM/GPRS, two serial ports, LAN, SD, and

Linux OS

Each model is shipped with the following items:

•W315A or W325A embedded computer

•Wall mounting kit

•Ethernet cable: RJ45 to RJ45 cross-over cable, 100 cm

•CBL-4PINDB9F-100: 4-pin pin header to DB9 female console port cable, 100 cm

•GSM/GPRS antenna

•Documentation and software CD

•Quick installation guide (printed)

•Warranty card

Optional Accessories

•35 mm DIN-rail mounting kit (DK-35A)

NOTE: Please notify your sales representative if any of the above items are missing or damaged.

W315A/325A Introduction

1-3

Product Features

W315A/325A series embedded computers have the following features:

•MOXA ART 32-bit ARM9 RISC industrial communication processor

•16 MB built-in flash memory

•RS-232/422/485 serial ports with software selectable interface

•Baudrate between 50 and 921.6Kbps; supports non-standard baudrates

•10/100M Ethernet for backup networking

•Built-in quad band 850/900/1800/1900 MHz GSM/GPRS module

•GPRS class 10

•Coding scheme from CS1 to CS4

•SD card slot for storage expansion

•Designed to withstand continuous 5G vibration and a 50G shock

•LED indicators for status, serial transmission, and wireless signal strength

•Ready-to-run Linux platform

•Can be installed on a DIN-Rail or wall mounted

•Fanless design for increased ruggedness

Hardware Specifications

Computer

CPU: MOXA ART ARM9 32-bit RISC CPU, 192 MHz

OS (pre-installed): Embedded Linux with MMU support

DRAM: 32 MB

Flash: 16 MB

Storage

Storage Expansion: SD slot

Ethernet Interface

LAN: 1 auto-sensing 10/100 Mbps port (RJ45)

Magnetic Isolation Protection: 1.5 KV built-in

Cellular Interface

Cellular Modes: GSM, GPRS

Radio Frequency Bands: 850/900/1800/1900 MHz

GPRS Class: 10

Coding Schemes: CS1 to CS4

Serial Interface

Serial Standards: 1 or 2 RS-232/422/485 ports, software-selectable (DB9 male)

ESD Protection: 15 KV ESD protection for all signals

Console Port: RS-232 interface (TxD, RxD, GND), with 4-pin pin header output

Serial Communication Parameters

Data Bits: 5, 6, 7, 8

Stop Bits: 1, 1.5, 2

Parity: None, Even, Odd, Space, Mark

Flow Control: RTS/CTS, XON/XOFF, ADDC™ (automatic data direction control) for RS-485

Baudrate: 50 bps to 921.6 Kbps (non-standard baudrates supported; see user's manual for details)

Serial Signals

RS-232: TxD, RxD, DTR, DSR, RTS, CTS, DCD, GND

RS-422: TxD+, TxD-, RxD+, RxD-, GND

RS-485-4w: TxD+, TxD-, RxD+, RxD-, GND

RS-485-2w: Data+, Data-, GND

W315A/325A Introduction

1-4

LEDs

System:Ready, SD

LAN: 10M/Link, 100M/Link (on connector)

Cellular: GPRS Enabled, GSM Signal Strength

Serial: TxD, RxD

Switches and Buttons

Reset Button: Supports "Reset to Factory Default"

Physical Characteristics

Housing: Aluminum (1 mm)

Weight: 195 g

Dimensions: (without ears or antenna)

77 x 111 x 26 mm (3.03 x 4.37 x 1.02 in)

Mounting: DIN-rail (requires optional DK-35A DIN-rail kit), wall

Antenna Length: 84 mm

Environmental Limits

Operating Temperature: -10 to 60°C (14 to 140°F)

Operating Humidity: 5 to 95% RH

Storage Temperature: -20 to 80°C (-4 to 176°F)

Anti-vibration: 5 g @ IEC-68-2-6, sine wave, 5-500 Hz, 1 Oct./min, 1 hr/axis

Anti-shock: 50 g @ IEC-68-2-6, half-sine wave, 30 ms

Power Requirements

Input Voltage: 12 to 48 VDC

Power Consumption:

Without GPRS loading: 4.8 W

• 100 mA @ 48 VDC

• 200 mA @ 24 VDC

• 400 mA @ 12 VDC

With GPRS loading: 12 W

• 330 mA @ 48 VDC

• 540 mA @ 24 VDC

• 1000 mA @ 12 VDC

• 200 mA @ 24 VDC

• 400 mA @ 12 VDC

Regulatory Approvals

EMC: CE (EN55022 Class A, EN61000-3-2, EN61000-3-

3, EN55024), FCC (Part 15 Subpart B, CISPR 22 Class

A, ANSI C63.4)

Safety: UL/cUL (UL60950-1), LVD (EN 60950-1)

R&TTE: EN301 489-1, EN301 489-7, EN301 511

Safety: LVD: EN60950-1

UL/cUL: UL60950-1, CSA C22.2 No. 60950-1-03

Green Product: RoHS, CRoHS, WEEE

Reliability

Alert Tools: Built-in buzzer and RTC (real-time clock) with battery backup

Automatic Reboot Trigger: Built-in WDT (watchdog timer)

Warranty

Warranty Period: 5 years

Details: See www.moxa.com/warranty

W315A/325A Introduction

1-5

Hardware Block Diagrams

W315A

W325A

2. Hardware Introduction

The W315A/325A series embedded computers are compact, well-designed, and built rugged enough for

industrial applications. LED indicators help you monitor performance and identify trouble spots, multiple serial

ports allow you to connect different devices for wireless operation, and the reliable and stable hardware

platform lets you devote your attention to developing your applications.

The following topics are covered in this chapter:



Appearance

W315A

W325A



Dimensions



LED Indicators



Reset Button



Real Time Clock

W315A/325A Hardware Introduction

2-2

Appearance

W315A

W325A

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Moxa Technologies Matériel informatique

Moxa Technologies

Moxa Technologies CSM-G200 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies ioLogik E2000 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies TC-6110 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies C104P Manuel utilisateur

Moxa Technologies

Moxa Technologies CP-114UL Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MAR-2000 Instructions d'utilisation

Moxa Technologies

Moxa Technologies THINKCORE W311 Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-7420-CE Manuel utilisateur

Moxa Technologies

Moxa Technologies CP-102E Manuel utilisateur

Moxa Technologies

Moxa Technologies CP-118EL Manuel utilisateur

Moxa Technologies

Moxa Technologies C104P Manuel utilisateur

Moxa Technologies

Moxa Technologies V2201 Instructions d'utilisation

Moxa Technologies

Moxa Technologies RKP-A110 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies DA-661 Instructions d'utilisation

Moxa Technologies

Moxa Technologies WAPN008 Manuel utilisateur

Moxa Technologies

Moxa Technologies WAPN008-1 Manuel utilisateur

Moxa Technologies

Moxa Technologies Industio C114HI Manuel utilisateur

Moxa Technologies

Moxa Technologies ABC-02-USB Manuel utilisateur

Moxa Technologies

Moxa Technologies UPort 200A Series Manuel utilisateur

Moxa Technologies

Moxa Technologies Industio CI-132 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies MPC-2101 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies Smartio CP-168U Manuel utilisateur

Moxa Technologies

Moxa Technologies Smartio C104H Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-8410 Instructions d'utilisation

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
