Smartio C168H/HS User’s Manual

Universal 8 Port Serial Board

May 1999 (6th Edition)

The content of this manual is also available in CD-ROM and at Moxa Web Site.

Moxa Technologies Co., Ltd.

Tel: +866-2-8665-6373

Fax: +886-2-8665-6372

www.moxa.com

[email protected]

Smartio C168H/HS User’s Manual

The software described in this manual is furnished under a license agreement and may be used only in

accordance with the terms of the agreements.

Reproduction in any form without permission is prohibited.

Trademarks

MOXA is a registered trademark of Moxa Technologies Co., Ltd.

All other trademarks or registered marks in this manual belong to their respective manufacturers.

Disclaimer

Information in this document is subject to change without notice and does not represent a commitment on

the part of Moxa.

Moxa provides this document “as is”, without warranty of any kind, either expressed or implied,

including, but not limited to, the particular purpose. Moxa may make improvements and/or changes in

this manual or in the product(s) and/or the program(s) described in this manual at any time.

Information provided in this manual is intended to be accurate and reliable. However, Moxa

Technologies assumes no responsibility for its use, or for any infringements of rights of the fourth parties

which may result from its use.

This product could include technical or typographical errors. Changes are periodically made to the

information herein; these changes may be incorporated in new editions of the publication.

MOXAInternetServices

Customer’s satisfaction is always our number one concern. To ensure that customers get the full benefit

of our services, Moxa Internet Services have been built for technical support, product inquiry, new driver

update, user’s manual update, etc.

The followings are the services we provide.

E-mail for technical support

address:[email protected]

FTP site for free driver update

address: ftp.moxa.com

ftp.moxa.com.tw

user ID: ftp

password: your_email_address

World Wide Web (WWW) Site for product info

address: www.moxa.com

www.moxa.com.tw

AboutThisManual

This manual is composed of six Chapters and one Appendix. This manual is written for installer, system

administrator and software programmer.

If you are a first-time installer and system administrator, we recommend you to go through the whole

manual except Chapter 4.

If you are a software programmer, you may refer to Chapter 4 “Serial Programming Tools”.

If you need cable wiring information, please see Chapter “Connection Option (Opt8x) and Cable

Wiring”.

If you encounter any problem during installation, please refer to Chapter “Troubleshooting”.

+In this manual, C168 Series refers to C168H and C168HS.

Chapter 1 Introduction

Overview and features of the Smartio C168 Series boards, list of items and overall installation guide.

Chapter 2 Hardware Installation

Hardware installation for the Smartio C168 Series boards and connection option (Opt8x) is detailed.

Chapter 3 Software Installation

This Chapter details the software installation, configuration, driver loading/unloading, driver

upgrade and removal for various operating systems: Windows NT, Windows 95/98 , UNIX, DOS.

Chapter 4 Serial Programming Tools

This Chapter roughly describes the programming tools for various O.S. platforms, including PComm

under Windows NT, Windows 95/98, API-232 under DOS and standard UNIX system calls. Also

RS-485 programming issue is covered (for Opt8J).

Chapter 5 Connection Option (Opt8x) and Cable Wiring

This Chapter describes the RS-232/422/485 cable wiring for each connection option (Opt8x).

Chapter 6 Troubleshooting

This Chapter describes the problems and possible answers for Smartio C168 Series boards.

Appendix Technical Reference

Specification details, UART, I/O port address map, and DB62 pinouts are described.

TableofContents

Introduction..................................................................... 1-1

Overview................................................................................................................1-1

Features.................................................................................................................1-4

Check List..............................................................................................................1-5

Installation Guide...................................................................................................1-8

Hardware Installation ...................................................... 2-1

Default Settings .....................................................................................................2-1

Quick Hardware Installation...................................................................................2-2

How to Do Quick Hardware Installation..........................................................................2-2

Hardware Installation with IO-IRQ Utility................................................................ 2-3

IO-IRQ Utility and Hardware Configuration....................................................................2-4

Software Installation ....................................................... 3-1

Windows NT ..........................................................................................................3-1

Installing Driver.............................................................................................................3-2

Configuring Board and Port........................................................................................... 3-7

Updating Driver.............................................................................................................3-9

Removing Driver ...........................................................................................................3-9

Windows 95/98......................................................................................................3-9

Installing Driver...........................................................................................................3-10

Configuring Board and Port......................................................................................... 3-14

Updating Driver........................................................................................................... 3-15

Removing Driver .........................................................................................................3-16

DOS.....................................................................................................................3-17

Installing Driver...........................................................................................................3-17

Driver Setup................................................................................................................ 3-18

Loading Driver................................ ............................................................................. 3-22

Unloading Driver..........................................................................................................3-23

UNIX....................................................................................................................3-23

Installing Driver...........................................................................................................3-24

MOXA TTY Device Naming Convention......................................................................3-27

Baud Rate Settings......................................................................................................3-28

Administration Utility – moxaadm ................................................................................ 3-28

Setting MOXA Ports to Terminal.................................................................................. 3-35

Serial Programming Tools................................................ 4-1

Windows NT and Windows 95/98..........................................................................4-1

Installation..................................................................................................................... 4-1

PComm Programming Library .......................................................................................... 4-2

Utilities.......................................................................................................................... 4-2

UNIX......................................................................................................................4-6

Programming the MOXA Ports ...................................................................................... 4-6

Extended UNIX Ioctl() Commands................................................................................. 4-6

Utilities........................................................................................................................ 4-13

DOS.....................................................................................................................4-15

Installation................................................................................................................... 4-15

DOS API-232 Library...................................................................................................4-15

Utilities........................................................................................................................ 4-16

RS-485 Programming for Opt8J ..........................................................................4-17

Connection Option (Opt8x) and Cable Wiring ........................ 5-1

RS-232 Cable Wiring for Opt8A/B/C/D/S............................................................... 5-1

RS-422 Cable Wiring for Opt8J/F/Z.......................................................................5-7

RS-485 Cable Wiring for Opt8J...........................................................................5-10

RS-422/485 Impedance Matching........................................................................5-11

Troubleshooting............................................................... 6-1

General Troubleshooting.......................................................................................6-1

Windows NT ..........................................................................................................6-4

Windows 95/98......................................................................................................6-5

DOS.......................................................................................................................6-6

UNIX......................................................................................................................6-6

Technical Reference........................................................A-1

Specifications.........................................................................................................A-1

UART 16C550C.....................................................................................................A-2

PC I/O Port Address Map.......................................................................................A-3

DB62 Connector Pinouts .......................................................................................A-4

Smartio C168H/HS User’s Manual 1-1

1 Introduction

Overview

Smartio - The Smart Multiport Async Solutions

The term Smartio stands for smart multiport serial I/O solution. The Smartio C168

Series multiport boards offer 8 serial ports for connecting terminals, modems,

printers, data acquisition equipment and any other serial devices to the PC/AT and

its compatible systems. With the well-designed and fine-tuned device driver, the

Smartio boards make full use of the 32 byte Tx/Rx FIFO and on-chip H/W flow

control, so that they can transfer data without data loss even at high speed such as

921.6 Kbps, which offers a reliable and high performance solution for serial

multiport communications.

The Smartio C168 Series is equipped with custom-designed ASIC chip which

replaces lots of conventional ICs and reduces the board to half-size. The whole

family supports 16 bit architecture. Full range of I/O addresses and IRQs are

available. In addition, with on-board EEPROM for storing the configuration data,

the family is designed without jumper or switch. These features make each port on

the board truly independent to any other port and thus compatible with most existing

multiport boards.

The Smartio C168 Series is also available in PCI bus. Please contact MOXA

dealer/distributor or MOXA Web site for more details.

1-2 Smartio C168H/HS User’s Manual

Hardware Configuration Method

SmartioFamily

JP1

Traditional

Multipoort Board

Jumper

1 2 3 4

Switch

.........

New : set I/O address Traditional : set switch and

and IRQ via software and jumper manually for

Utility. I/O address and IRQ.

Instead of using traditional jumper or switch for IRQ and I/O address settings,

hardware configuration of each port is easily set by DOS utility, Io-irq.exe, which

read and write the on-board EEPROM for configuration information through the

CAP (Configuration Access Port) address. The CAP address is the only channel

via which the configuration utility Io-irq.exe can access the board, which is identical

to the first port's base I/O address.

The only jumper, JP1, is designed in case that users forget the CAP address.

Normally JP1 is left open. When JP1 is short, the CAP address is forced to a fixed

I/O address, 0xA700. However, to adopt quick installation (described later), it is a

must to keep JP1 always short.

Quick Installation

To ease the hardware configuration, users who install only one Smartio C168

Series board under Windows NT/95/98 are recommended to adopt quick

installation described in Chapter 2.

Because the family is so flexible in hardware configuration that they are compatible

virtually with all kinds of other manufacturer's multiport boards using 16450 or

16550 UART.

Introduction

Smartio C168H/HS User’s Manual 1-3

Surge Protection

To prevent the boards from damage caused by lighting or high potential voltage,

surge protection technology is introduced in some model to protect the board.

Operating System Support

The family is operational under most popular operating systems such as Windows

NT, Windows 95/98, SCO UNIX/XENIX/OpenServer, DOS, Linux, QNX,

FreeBSD, UNIX SVR4.2, However, MOXA device drivers for Windows NT,

Windows 95/98, Linux, SCO UNIX/OpenServer, UNIX SVR4.2 and DOS are

provided for easier installation, configuration and better performance. In this

manual, chapters for MOXA Windows NT,Windows 95/98,UNIX and DOS

device drivers are included. For other compatible systems not mentioned, please

refer to the respective operating system’s manual for how to install and configure

the standard driver.

MOXA Serial Comm Tools

For easy application development, MOXA provides an easy-use serial

communication library under Windows NT/95/98 (PComm) and DOS (API-232).

Users can use this library to develop your own applications using Microsoft C,

Turbo C, Assembly, QuickBASIC, Turbo Pascal, Clipper, Visual Basic, Visual C++,

Borland Delphi, etc. Utilities, such as diagnostic and monitor, are included for

diagnosing the board/port or monitoring the communication status.

Wide Applications

The Smartio C168 Series are suitable for many applications. Here are a few:

lInternet/Intranet Connection

lRemote Access Application

lMulti-user Application

lIndustrial Automation

lOffice Automation

lTelecommunication

lPC-based (vending) Machine or Kiosk System

lPoint-of-Sale (POS) System

1-4 Smartio C168H/HS User’s Manual

Features

The Smartio C168 Series consist of members as follows,

C168H 8 port RS-232 or RS-422, high speed 16550C or compatible UART

C168HS 8 port RS-232 or RS-422, surge protection, 16550C or compatible

UART

vCustom-designed ASIC, compact board size (half-size)

vNo switch no jumper, easily configured by software

vIndependent I/O address, IRQ setting for each of 8 serial ports

v16 bit AT bus architecture, more IRQs supported

vSurge protection for RS-232 (C168HS)

vIsolation protection for RS-422 (optional connection box Opt8F)

vHigh speed 16550C Communication Controller with on-chip hardware flow

control, no data loss

vPComm serial communication tool

vSupport popular OS¡ÐWindows NT, Windows 95/98, SCO UNIX/OpenServer,

UNIX SVR4.2, DOS, Linux

vCompatible with many other OS¡ÐQNX, SCO XENIX, Free BSD

C168H/HS

Windows NT 3

Windows 95/98 3

DOS 3

SCO UNIX/OpenServer 3

UNIX SVR4.2 3

Linux R

QNX C

SCO XENIX C

FreeBSD C

3: Driver supported by Moxa and shipped with product

R : Driver supported by Moxa but sent by request

C : Driver supported by OS

Note: MOXA FTP site is available for driver download

Autres manuels pour Moxa Smartio C168H

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Moxa Technologies Matériel informatique

Moxa Technologies

Moxa Technologies Industio CP-114 Series CP-114 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies CP-602U-I Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-8410 Instructions d'utilisation

Moxa Technologies

Moxa Technologies VPort 66-2MP Series Manuel utilisateur

Moxa Technologies

Moxa Technologies ABC-02-USB Manuel utilisateur

Moxa Technologies

Moxa Technologies THINKCORE W311 Manuel utilisateur

Moxa Technologies

Moxa Technologies TC-6110 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies CP-602U-I-T Manuel utilisateur

Moxa Technologies

Moxa Technologies CP-118U Series Manuel utilisateur

Moxa Technologies

Moxa Technologies RKP-A110 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies CP-118EL Manuel utilisateur

Moxa Technologies

Moxa Technologies Industio CI-132 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies Smartio C104H Manuel utilisateur

Moxa Technologies

Moxa Technologies UPort 200A Series Manuel utilisateur

Moxa Technologies

Moxa Technologies CP-102N-T Manuel utilisateur

Moxa Technologies

Moxa Technologies Smartio CP-168U Manuel utilisateur

Moxa Technologies

Moxa Technologies UC-7420-CE Manuel utilisateur

Moxa Technologies

Moxa Technologies CP-118U Series Manuel utilisateur

Moxa Technologies

Moxa Technologies CI-104J Manuel utilisateur

Moxa Technologies

Moxa Technologies CA-132/132I Manuel utilisateur

Moxa Technologies

Moxa Technologies EM-1220 LX Manuel utilisateur

Moxa Technologies

Moxa Technologies CSM-G200 Series Manuel utilisateur

Moxa Technologies

Moxa Technologies ABC-02-USB-T Manuel utilisateur

Moxa Technologies

Moxa Technologies MAR-2000 Instructions d'utilisation

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
