Motorola ML1500 Manuel utilisateur

4G LTE Ethernet

Cellular Modem

Model ML1500

Quick

Start

Guide

Packaged with your ML1500 modem

USB Power Cube

USB Power Cable

Ethernet Cable 2 LTE Antennas

Para una Guía de Inicio Rápido en español, por favor

vaya a

www.motorolanetwork.com/ML1500IR

Let’s get started

First attach the 2 LTE Antennas to the ML1500 by screwing

them finger-tight into the 2 gold connectors located on the

back of the unit. The best orientation for these antenna varies

by location but is normally half way between horizontal and

vertical.

Next connect the included yellow Ethernet cable between the

ML1500’s Ethernet port and the Ethernet port of your

computer, router, or other Ethernet-capable device.

If you are using your ML1500 with a wireless router, we will

explain how to configure the ML1500 for a router later in this

Quick Start.

Insert the micro SIM card

To use your ML1500 modem you need an activated micro SIM

(3FF format), which you normally get from your mobile

broadband service provider. If instead you use a nano SIM

card (used by most phones today), you must use a SIM Card

Adapter. SIM card adapters are available from online retailers.

Insert the SIM card into the SIM slot as shown above.

Cell Service Providers

The ML1500 works with AT&T®, Verizon®, T-Mobile®,

Rogers®, Telus®, Bell Canada® and many international

cell service providers worldwide. It does not work with

Sprint®.

Power up your ML1500

You can power the ML1500 from either the included AC-

powered power cube or from the USB port of a computer or

USB power bank. Using the AC-powered power cube is

preferred when an AC outlet is available.

To use the included AC power cube, plug it into an AC power

outlet. Then connect the included USB power cable between

the ML1500’s PWR jack and the AC power cube.

Whatever you use as a power source, make sure the ON/OFF

button is pressed in to turn on your ML1500.

Most modern desktop and laptop computers will supply

enough current (up to 1.2 amperes required) through their

USB port to power the ML1500. This can be very convenient if

you’re in a location where AC power isn’t available. To use the

USB port, first plug one end of the included USB power cable

into the PWR jack of the ML1500. Plug the other end of the US

power cable into the USB port you want to use to power the

ML1500.

If you use a different power cube than the one included, it

must have a nominal voltage of 5 volts DC and at least 1.2

amperes.

Establish your Mobile Broadband

Connection

When the modem powers up with an activated SIM card

installed, it will automatically search for and connect to your

mobile broadband provider. It may take several minutes to

establish a connection. The Cellular LED will turn either green

or amber to indicate a connection.

If your cell status LED and the signal strength indicator LEDs

are on, open your web browser and try browsing the web. If

browsing works, Congratulations!Your ML1500 is working.

If your ML1500 is NOT working, see Troubleshooting Tips and

We like to help at the end of this Quick Start.

If you want to connect to the Internet through the ML1500

using WiFi, you need a WiFi router that plugs into the

ML1500’s Ethernet port. For instructions about how to do

this, please see the next section: If you want to connect the

ML1500 to a WiFi Router.

If you want to connect the ML1500 to a

WiFi Router

To configure the ML1500 for use with a WiFi router, you will

need to access the ML1500’s Configuration Manager. Make

sure that the ML1500 is powered on and plugged into a

powered-on computer’s Ethernet port.

Now access the Configuration Manager, doing the following:

1. Open your computer’s browser and type 192.168.5.1 into

your browser’s address bar and then press Enter.

The login dialog box for your modem should appear. Enter

a Username and Password.

The default username is admin and the default password

is Motorola, You should use these initially, but you’ll be

able to change them as described below.

Click Login. (If you can’t access the Configuration

Manager, see the Troubleshooting Tips at the end of this

Quick Start.)

2. For security reasons, the first time you log in to the

ML1500 you will be asked to change the default password

after you log in. Enter your new password, then click Save.

Your new password can be 6 to 32 alphanumeric

characters. We recommend writing your new password

on a piece of paper and attaching it to the bottom of your

unit.

3. On the Basic Setup/APN page of the ML1500’s

Configuration Manager, go to the left hand menu, click on

Setup then Mode. On the Select your Operating Mode

page, select the Bridge Mode radio button and click Save.

Bridge mode will automatically pass the IP address from

your Service Provider to your wireless router.

Turn off your WiFi router. Now unplug the Ethernet cable from

your computer and plug it into the WAN port of your wireless

router. Your router should be setup for DHCP mode

(sometimes called Dynamic mode, or Automatic). Wait for the

ML1500 to power up and the Cell Status light to turn either

green or amber before turning your WiFi router back on.

You should now be able to access the Internet wirelessly

through your router. If you are unable to do so, see the

Troubleshooting Tips at the end of this Quick Start.

Front Panel LEDs

LIGHT COLOR DESCRIPTION

Power

Green

ML1500 Powered on

Off

ML1500 Powered off

Cell

Status

Green

Amber

Green

LTE connection established

Flashing

LTE connection passing data

Amber

3G connection established

Flashing

3G connection passing data

Signal

Strength

Green

Solid green bar(s)

The 4 green bars indicate the signal strength

of the mobile broadband service that the

ML1500 modem is connected to. Four bars

indicate the strongest signal. One green bar

is the weakest signal.

Back Panel

ANT-MAIN

This is an SMA connector for the main cellular antenna of the

ML1500. Screw one of the included LTE antennas into this

jack, or use a more powerful antenna if necessary.

RST

Press and hold the reset button in for 8 seconds in the unlikely

event that you want to reset the ML1500.

ETHERNET

Connect the included Ethernet cable from the Ethernet jack of

the ML1500 to either the Ethernet jack of your computer or

the WAN jack of your wireless router.

SIM

Insert an activated micro SIM card (3FF) into the SIM slot.

POWER

Connect the supplied power cable between the power jack

and either the included power cube or a USB port that can

supply 1 Amp. Most modern computers and USB power banks

can supply this power.

ON/OFF

Turn power on or off.

ANT-DIV

This is an SMA connector for the diversity cellular antenna of

the ML1500. Screw one of the included LTE antennas into this

jack, or use a more powerful antenna if necessary.

Troubleshooting Tips

Why can’t I connect to the Internet after installing my

modem?

•Check that the modem is powered on. The power LED on the

front panel should be on. If it is not on, then:

1. Check that the power button on the back of the unit is

pushed in.

2. Check that the USB power cable is correctly plugged into

the modem and that the other end of the cable is plugged

into the modem’s plugged-in AC Power Cube or a USB

power jack that can supply at least 1.2 amperes.

3. If you are using a USB port to power the modem and the

modem isn’t working, it’s possible that your USB port can

not supply enough power to the modem. Try plugging the

modem into AC power by using the modem’s USB Power

Cube. I

•Confirm that the modem can talk to the SIM. Log into the

Configuration Manager by typing 192.168.5.1 in the address bar

of your browser, go to that address, enter the Username and

Password. The default username is admin and the default

password is motorola. If this is your first time logging into the

ML1500, you will be asked to change the default password

after you log in. If you have already changed the password,

enter your new password. Once you have the password you

want, click the Login button. On the left hand menu, click on

Status. There should be a 19 or 20 digit number next to ICCID.

If this number is missing, try reinserting your SIM. You may

need to get a new SIM from your service provider if the

modem can not read it.

•Look at the Signal Indicator leds on the front of your unit. If

none of the leds is on, or only one is on, you should move the

modem closer to a window to try and improve signal strength.

If even that doesn’t work, you may need to buy a better

antenna.

•Verify with your service provider that your account is active.
