CHAPTER 1 INTRODUCTION

This user’s manual explains connection, conﬁguration, and operation

information speciﬁc to the M68EM05BS8 Emulator Module (hereafter

referred to as BS8EM). The BS8EM makes possible emulation and

debugging of MC68HC05BS8 microcontroller unit (MCU) based target

systems.

The BS8EM can be part of two development systems. This chapter

describes those systems and explains the layout of the BS8EM.

1.1 DEVELOPMENT SYSTEMS

Your BS8EM can be part of two Motorola development tools: the HC05

Motorola Modular Development System (MMDS05) or the

M68HC05EVS Evaluation System (HC05EVS).

1.1.1 Motorola Modular Development System (MMDS05)

The MMDS05 is an emulator system that provides a bus state analyzer

and real-time memory windows. The unit’s integrated design environ-

ment includes an editor, an assembler, user interface, and source-level

debug. A complete MMDS05 consists of:

•a station module -- the metal MMDS05 enclosure, containing the

control board and the internal power supply. Most system cables

connect to the MMDS05 station module. (The cable to an optional

target system, however, runs through an aperture in the station mod-

ule enclosure to connect directly to the emulator module.)

•an emulator module (EM) -- such as the BS8EM: a printed circuit

board that enables system functionality for a speciﬁc MCU. The EM

ﬁts into the station module through a sliding panel in the enclosure

top. The EM has connectors for the target cable.

•two logic clip assemblies -- twisted-pair cables that connect the sta-

tion module to your target system, a test ﬁxture, a clock, or any other

circuitry useful for evaluation or analysis. One end of each cable

assembly has a molded connector, which ﬁts into station module pod

A and pod B. Leads at the other end of each cable terminate in

female probe tips. Ball clips come with the cable assemblies.

•a 9-lead RS-232 serial cable -- the cable that connects the station

module to the host computer RS-232 port.

•a 9 to 25-pin adapter -- a moulded assembly that lets you connect

the 9-lead cable to a 25-pin serial port.

•system software -- software, on 3-1/2 inch diskettes.

HC05BS8EM USER’S MANUAL

MOTOROLA

1-2

1•MMDS05 documentation -- an MMDS05 operations manual

(MMDS05OM/D) and the appropriate EM user’s manual.

As mentioned, your BS8EM gives the MMDS05 the ability to emulate

the MC68HC05BS8 MCU. By substituting a different EM, you can

enable your MMDS05 to emulate an MCU of a different series. (Your

Motorola representative can explain all the EMs available.)

Chapter 2 explains how to conﬁgure and use your BS8EM as part of an

MMDS05 system. For information about MMDS05 software or the sta-

tion module, see the MMDS05 operations manual. For layout and con-

ﬁguration information pertaining to a different EM, see the

corresponding EM user’s manual.

1.1.2 M68HC05EVS Evaluation System (HC05EVS)

An HC05EVS is an economical, two-board tool for designing, debug-

ging, and evaluating target systems based on an MC68HC05 MCU. A

complete HC05EVS consists of:

•a platform board (PFB) -- the bottom board, which supports the

emulator module. The platform board has connectors for power and

for the terminal or host computer.

•an emulator module (EM) -- such as the BS8EM: a printed circuit

board that enables system functionality for a speciﬁc MCU. The EM

ﬁts onto the PFB. The EM has connectors for a target cable and a

cable to a logic analyzer.

•an RS-232 serial cable -- the cable that connects the PFB to the host

computer RS-232 port.

•system software -- software, on 3-1/2 inch diskettes.

•HC05EVS documentation -- an HC05EVS operations manual and

the appropriate EM user’s manual.

As mentioned, your BS8EM emulates the MC68HC05BS8 MCU. By

substituting a different EM, you can enable your HC05EVS to emulate

an MCU of a different series. (Your Motorola representative can explain

all the EMs available.)

Chapter 3 explains how to conﬁgure and use your BS8EM as part of an

HC05EVS system. For information about HC05EVS software or the

platform board, see the HC05EVS operations manual. For layout and

conﬁguration information pertaining to a different EM, see the corre-

sponding EM user’s manual.

HC05BS8EM USER’S MANUAL MOTOROLA

1-3

1.2 EM LAYOUT

Figure 1-1 shows the layout of the BS8EM. Jumper header P4 controls

the path of a target reset. Jump header P6 lets you select the clock-signal

source. Jumper header P9 allows you to use the on-board emulation

RAM instead of the internal EEPROM of the device during product

development.

Connectors P7 and P8, for a 44-pin QFP or a 52-pin PLCC cable assem-

bly, (purchased separately from the BS8EM.) provide an interface to

your target system. If you install the BS8EM in the MMDS05 station

module, the target cable passes through the slit in the station module

enclosure. Connector P1 connects to a logic analyzer. (Connector P1 has

more signiﬁcance for an EVS system, as an MMDS05 system includes

a bus analyzer.) Expansion header connectors P2 and P3 connect

together the EM and the control board (for an MMDS05) or the EM and

the platform board (for an EVS).

P7 P8

P2 P3

Figure 1-1. HC05BS8 Emulator Module

HC05BS8EM USER’S MANUAL

MOTOROLA

1-4

11.3 TARGET CONNECTORS AND CABLE INFORMATION

Figure 1-2 shows the pin assignments for connectors P7 and P8. For sig-

nal descriptions, consult the technical data book for the M68HC05BS8

MCU.

As connector P1 has more importance to an HC05EVS than to an

MMDS05, pin assignments for connector P1 are in Chapter 3.

To conﬁgure your BS8EM for use as part of an MMDS05, follow the

instructions of Chapter 2. To conﬁgure your BS8EM as part of an

HC05EVS, follow the instructions of Chapter 3.

RCLK

GND

/RESET

PA2

GND

PA7

GND

PB5

PB7

PC3

PC4

PC6

TCAP

GND

VTTL

SAM

CSYNC

HSYNC

VDD

/IRQ

PA3

GND

PB6

GND

PB4

PB6

PC2

GND

TCMP

RSB

GND 1

RSA

SCL

GND

PA0

PA4

GND

PB1

PB3

GND

PC1

GND

PC5

PC7

GND

SDA

HTTL

GND

VSYNC

GND

PA1

PA5

GND

PB0

PB2

GND

PC0

GND

GPWM

Figure 1-1 Connectors P7 P8 Pin Assignments

GND

HC05BS8EM USER’S MANUAL MOTOROLA

1-5

To connect your BS8EM to your target system via a separately pur-

chased, target cable and head assembly, follow the instructions below.

Figure 1-3 is a generic representation of a Motorola supplied target

cable assembly, which consists of a ﬂexible cable and a QFP/PLCC tar-

get head. To emulate a QFP device, the surface-mount adapter that

comes with the target head is required to be soldered directly to the tar-

get PCB. Emulation of a PLCC device is achieved by ﬁtting the PLCC

target head into the MCU socket of the target system. Table 1-1 shows

the target cable and head part numbers required to form a 44-pin QFP

and a 52-pin PLCC target cable assembly for the BS8EM.

To use a QFP target cable, connect the small square cable terminator (the

one with two 50-mil connectors) of M68CBL05C to

M68TC05BS8FB44. They should be connected in such a way that the

arrow marked on the target head is pointing to the target cable. Next,

connect the large rectangular cable terminator to the BS8EM target con-

nectors P7 and P8. The connector at the far end of the cable should be

connected to P7 and the other to P8. Remove the surface-mount adapter

from the target head and solder it to the target system board, then re-con-

nect the target head back onto the surface-mount adapter.

To use a PLCC target cable, connect the large cable terminator of

M68CLB05B to M68TB05BS8FN52. They should be connected in

such a way that the arrow marked on the target head is pointing to the

target cable. Next, connect the small cable terminator to the BS8EM tar-

get connectors P7 and P8. The connector at the far end of the cable

should be connected to P7 and the other to P8. Plug the target head into

the MCU socket of your target system.

If you install the BS8EM in the MMDS05 station module, run the target

cable through the slit in the station module enclosure.

Table 1-1. Parts required to form a target cable assembly for BS8EM

Cable No. Target Head No. Notes

M68CBL05B M68TB05BS8FN52 52-pin PLCC cable assembly

M68CBL05C M68TC05BS8FB44 44-pin QFP cable assembly

HC05BS8EM USER’S MANUAL

MOTOROLA

1-6

Target

Cable

Head

Terminator

(connects to

target head)

Emulator

Terminator

(Connects to EM

target connectors)

Target Head

(Plugs to target system MCU

socket or surface mount adapter)

Table des matières

Autres manuels Motorola Unité de contrôle

Motorola

Motorola WA9901 Instructions de montage

Motorola

Motorola G24 Guide Mode d’emploi

Motorola

Motorola M68EM05D32 Manuel utilisateur

Motorola

Motorola DSP56852 Manuel utilisateur

Motorola

Motorola MVME2300 Series Guide de démarrage rapide

Motorola

Motorola HC05L1 Series Manuel utilisateur

Motorola

Motorola M68EML08GZ16 Manuel utilisateur

Motorola

Motorola MVME2400 Series Guide de démarrage rapide

Motorola

Motorola 56F8323 Manuel utilisateur

Motorola

Motorola MVME123 Manuel utilisateur

Motorola

Motorola MVME410 Manuel utilisateur

Motorola

Motorola MVME761EXT Guide de démarrage rapide

Motorola

Motorola C24 CDMA 1X Manuel utilisateur

Motorola

Motorola MVME224A Series Manuel utilisateur

Motorola

Motorola DSP56F826EVM Instructions d'utilisation

Motorola

Motorola M68705EVM Manuel utilisateur

Motorola

Motorola 82543 Manuel utilisateur

Motorola

Motorola SE955 Guide de configuration rapide

Motorola

Motorola MVME147 Guide de démarrage rapide

Motorola

Motorola MVME712M Guide de démarrage rapide

Motorola

Motorola Canopy Manuel utilisateur

Motorola

Motorola ACE3600 RTU Manuel utilisateur

Motorola

Motorola Canopy Backhaul Module Manuel utilisateur

Motorola

Motorola Canopy Subscriber Module Manuel utilisateur

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
